Quick start guide

Rapid IoT Connect developer kit with CYSBSYS-RP01

system-on-module and OPTIGA™ Trust M security controller

CYSBSYSKIT-DEV-01

www.infineon.com/CYSBSYSKIT-DEV-01

Kit contents

• CYSBSYSKIT-DEV-01 board

Header compatible with

Adafruit Feather (J5)

KitProg3 status LED (Yellow – LED3) Power LED (Blue – LED4)

Reset button (RST)

User button (USR_BTN)

User LED (Red – LED2) Charging indicator LED (Yellow – LED5)

Chip antenna (A1)

CYSBSYS-RP01 module

JTAG header*

Battery connector (J3)

3.3-V regulator (TPS7A2533DRVR - U15)

17.2032-MHz ECO (Y1)

Header compatible with

Adafruit Feather (J1)

Micro-B USB connector (J4)

CYSBSYSKIT-DEV-01 board top view

UM_2203_PL32_2204_092120

Quick start guide

IMPORTANT:

CYSBSYSKIT-DEV-01 Rapid IoT connect developer kit is sensitive to ESD. Hold the board only by

its stack-up headers. Aer removing the board from its box, place it on a grounded, static-free

surface. Use a conductive foam pad, if available. Do not slide the board over any surface.

* Footprint only; not populated on the board.

CYSBSYSKIT-DEV-01 board bottom view

Infineon 512-Mbit serial NOR flash

(S25FL512S – U3)

Super capacitor*

KitProg3 (PSoC™ 5LP)

programmer and debugger

(CY8C5868LTI-LP039 – U2)

Thermistor (RT1)

KitProg3

programming mode

selection button

(KP3_MODE)

OPTIGA™ Trust M (U7)

1.8-V regulator

(TPS7A2518DRVR – U14)

3.6-V regulator (RT6158AWSC – U11)

Li-Po battery charger IC

(BQ24074RGTT – U10)

P6_1/SDA

P6_0/SCL

P8_4/IO5

P9_7/IO6

P9_4/IO9

P9_3/IO10

P9_2/IO11

P9_1/IO12

P9_0/IO13

5.0V

VBAT

P5_3/CS

P6_5/TX

P6_4/RX

P5_1/MISO

P5_0/MOSI

P5_2/SCK

P10_5/A5

P10_4/A4

P10_3/A3

P10_2/A2

P10_1/A1

P10_0/A0

GND

3.3V

XRES

Quick start guide

Before you start

1. Ensure that you have the following:

• PC with USB port

• UART terminal soware such as Tera Term

or Minicom

• USB cable with Micro-B connector at one end

• (Optional) 3.7-V, 350-mAh Li-Po battery with

JST connector (Adafruit 2750 or similar)

2. With the USB cable, connect the board to the

PC and wait for the driver installation to

complete.

3. Verify that the following LEDs glow:

• Power LED (Blue – LED4)

• KitProg3 Status LED (Yellow – LED3)

• Charging LED (Yellow – LED5) if the Li-Po

battery is connected and charging

Connect the kit with the UART

terminal soware

1. Open the UART terminal soware and connect

the kit’s USB-UART COM port with the following

settings:

• Baud rate: 115200, Data: 8 bit, Parity: None,

Stop bit: 1 bit, Flow control: None

2. Press the reset button (RST_BTN) to reset the

device. You should see the output of the

pre-loaded application (Wi-Fi scan) on the

serial terminal.

Next Steps

Visit the kit website for information on

Quick IoT Experience and code examples

supported for this kit and kit

documentation.

Kit with pin mapping

USB-UART COM port setup

Serial terminal

Quick start guide

Document number: 002-30996 Rev. *B

Table 1

Header

J1.1

J1.2

J1.3

J1.4

J1.5

J1.6

J1.7

J1.8

J1.9

J1.10

J1.11

J1.12

J5.1

J5.2

J5.3

J5.4

J5.5

J5.6

J5.7

J5.8

J5.9

J5.10

J5.11

J5.12

J5.13

J5.14

J5.15

J5.16

VBAT

VBUS

GPIO

I2C SCL

I2C SDA

XRES

3.3 V

GND

Analog GPIO

SPI Clock

SPI MOSI

SPI MISO

UART RX

UART TX

SPI CS

–

P9_0

P9_1

P9_2

P9_3

P9_4

P9_7

P8_4

P6_0

P6_1

XRES

VDDA, VDDIO

–

P10_0

P10_1

P10_2

P10_3

P10_4

P10_5

P5_2

P5_0

P5_1

P6_4

P6_5

P5_3

–

GPIO13

GPIO12

GPIO11

GPIO10

GPIO9

GPIO6

GPIO5

SCL

SDA

XRES

VCC

–

GND

SCK

MOSI

MISO

GPIO14

Li-Po battery supply

Input to turn OFF power regulators

USB power

–

Connected to KitProg3

–

Analog voltage for PSoC™ 6 MCU (in the

Rapid IoT Connect system-on-module)

Not connected

–

SPI clock

SPI Master Out / Slave In (MOSI)

SPI Master In / Slave Out (MISO

Connected to KitProg3

SPI Chip Select

Primary onboard

function

PSoC™ 6

MCU pin

FeatherWings

compatibility

CYSBSYSKIT-DEV-01 pinout

Connection details
