B681 Quick Start

Note:

Figures in this guide are only for your reference. For details about the

particular model you have chosen, contact your service provider.

Check the information about the product and its accessories when you

purchase it. Some accessories are not provided in the product package. If

necessary, contact your local dealer to purchase them.

This guide briefly describes the device functions. For details about how to

set the management parameters, see the help information on the web

management page.

1 Getting to Know Your Device

Application Scenarios

Scenario 1:

You can connect your computer to the device to access the Internet. The specific

connection steps depend on your computer's operating system. Follow the

displayed instructions to connect the device to your computer.

Scenario 2:

You can connect a telephone to the device's telephone port to make voice calls.

Appearance

1. Power button

2. Wi-Fi/WPS button

3. Wi-Fi/WPS indicator

4. Network status indicator

5. Power indicator

6. LAN indicators

7. External antenna port

8. Telephone port

9. Power port

10. LAN ports

Indicators

Indicator Status

Wi-Fi/WPS indicator

Steady on: Wi-Fi turned on or data transfer

in progress.

Blinking: WPS connection being set up.

Off: Wi-Fi turned off.

Network status indicator

Blinking red fast: Subscriber Identity Module

(SIM) card unavailable (SIM card not

installed or malfunctioning, or PIN code not

verified).

Steady yellow: device registered with the

network.

Steady green: device connected to the

Internet.

Off: no signal received.

Power indicator

Steady on: device powered on.

Off: device powered off.

LAN indicators

Steady on: network cable connected.

Blinking: data transfer in progress.

Off: network cable not connected.

2 Installation

Installing the SIM Card

Step 1 Slide the card cover off.

Step 2 Insert the SIM card into the card slot. Ensure that the gold contact area

faces down and that the beveled edge of the SIM card aligns with that of

the card slot.

Step 3 Slide the card cover back onto the device.

Attention:

Before removing the SIM card, ensure that the device is powered off and

disconnected from the power outlet.

(Optional) Using the Table Stand

You can place the device on a flat surface such as a table or a desk, or hang it on

a wall. You can also use the table stand on the device to place it upright.

To use the table stand, insert its latches into the device's table stand slots, as

shown in the following figure.

Note:

To ensure good signal reception, place the device in a high place or near a

window.

To prevent interference caused by radio signals, place the device at least 1

meter (3.28 feet) away from other electrical devices.

(Optional) Installing an External Antenna

In areas with poor network coverage, connect an external antenna to the device's

external antenna port. Screw the external antenna in fully, as shown in the

following figure.

Note:

Skip this section if you do not need to connect an external antenna to the

device.

Before using an external antenna, log in to the web management page

(http://192.168.1.1) and set antenna mode to external. For details, see the

help information on the web management page.

Only use the external antenna indoors.

You cannot switch between the internal antenna and the external antenna

while using a voice or data service.

(Optional) Connecting to a Telephone

If you want to use the device to make voice calls, connect the device to a

telephone, as shown in the following figure.

Note:

Skip this section if you do not plan to use the device's voice services.

Radio signals can interfere with telephone call connection and quality. To

eliminate the risk of possible interference, place the telephone at least 1

meter (3.28 feet) away from the device.

Do not connect the device to the telephone wall outlet (or any Public

Switched Telephone Network), which will cause excessive heat or even

damage the device.

Connecting to a Computer

Use an Ethernet cable to connect a computer to one of the device's LAN ports, as

shown in the following figure.

When the connection between the device and the computer is set up, the device's

corresponding LAN indicator turns on.

Ensure that the Ethernet cable is no longer than 100 meters (328 feet).

Connecting to a Power Outlet

Connect a compatible power adapter to the device's power port, and then plug the

power adapter into a power outlet.

Note:

Using an incompatible power adapter may damage the device.

3 Powering the Device On or Off

After connecting to a power outlet, the device will power on automatically.

To manually power the device off, press and hold until all indicators turn

off.

To manually power the device on, press and hold until all indicators turn

on.

4 Setting Up a Wireless Connection

Turning the Device's Wi-Fi On

By default, the device's Wi-Fi automatically turns on when the device is powered

on.

To manually turn Wi-Fi off, press and hold for 2 seconds, and then

release your finger. turns off.

To manually turn Wi-Fi on, press and hold until turns steady on.

Setting Up a Wi-Fi Connection

Note:

Before setting up a Wi-Fi connection, ensure that a wireless network adapter

has been installed on your computer. If the wireless network adapter is

functioning correctly, you will be able to find a wireless network connection in

your computer's connection manager application.

Method 1: Set up a Wi-Fi connection.

Step 1 Ensure that is steady on.

Step 2 Scan for available wireless network connections using your computer's

connection manager application.

Step 3 Connect to the wireless network that has the same service set

identification (SSID) as the device.

Note:

If a security mechanism has been enabled for the wireless network

connection, enter the correct Wi-Fi key.

The SSID and the Wi-Fi key are printed on the device label.

To protect your wireless network from unauthorized access, change the

SSID and Wi-Fi key a regular intervals. For details, see the help information

on the web management page.

Method 2: Set up a WPS connection.

If the client to which your device connects supports WPS, a Wi-Fi key is generated

automatically. For details about the client's operations, see its user guide.

To set up a WPS connection:

Step 1 Ensure that is steady on.

Step 2 Press and hold until blinks to activate the WPS

connection on your device.

Step 3 Activate the WPS connection on the client.

5 Using the Web Management Page

You can configure and manage the device settings using the web management

page.

Step 1 Launch a web browser, and enter http://192.168.1.1 in the address bar.

Step 2 Enter the password, and log in to the web management page. The

default password is admin.

Note:

To protect your device, only one user can log in to the web management

page at a time.

To protect your account, change the password promptly. For details, see

the help information on the web management page.

6 Accessing the Internet

After a connection between your device and the client is set up, you can access

the Internet using the modes listed in the following table.

Select an appropriate mode according to your data service charging plan. For

example, if you are charged according to the length of time you are connected to

the Internet, it is recommended that you select manual mode. For details about

your data service charging plan, contact your service provider.

Mode Description

Auto After being powered on, the device will automatically connect to the

Internet. Once connected, the device will not automatically disconnect

from the Internet.

Manual Log in to the web management page, and then connect to or

disconnect from the Internet as prompted.

Demand

After being powered on, if there is data being transferred, the device

will automatically connect to the Internet. If no data is transferred

within a pre-defined period, the device will automatically disconnect

from the Internet.

7 Restoring Factory Defaults

If you are uncertain of which settings you have configured or changed, you can restore

the factory defaults that the device came with, and then reconfigure the device.

To restore the factory defaults, Use a sharp-pointed object to press and hold the RESET

button until all indicators ( , and ) blink.

After the factory defaults are restored, the device will restart automatically.

Attention:

Restoring factory defaults will delete all the device's user-defined settings and

restore all settings on the web management page to their defaults.

8 Further Tips

If the device does not work properly:

See the help information on the web management page.

Restart the device.

Restore the device to its factory defaults.

Contact your service provider.

9 Safety Information

This section contains important information pertaining to the operating instructions of

your device. It also contains information about how to use the device safely. Read this

information carefully before using your device.

Electronic Device

Do not use your device if using your device is prohibited. Do not use the device when

using your device causes danger or interference with electronic devices.

Medical Device

Follow rules and regulations set forth by hospitals and health care facilities. Do

not use your device when using the device is prohibited.

Some wireless devices may affect the performance of hearing aids or

pacemakers. For any such problems, consult your service provider.

If you are using an electronic medical device, consult the doctor or the device

manufacturer to confirm whether radio waves affect the operation of this device.

Potentially Explosive Atmosphere

Do not use your device in any area with a potentially explosive atmosphere, and

comply with all signs and instructions. Areas that may have potentially explosive

atmospheres include the areas where you would normally be advised to turn off

your vehicle engine. Triggering of sparks in such areas could cause an explosion

or a fire, resulting in bodily injuries or even deaths. Do not use your device at

refueling points such as service stations. Comply with restrictions on the use of

radio equipment in fuel depots, storage, and distribution areas, and chemical

plants. In addition, adhere to restrictions in areas where blasting operations are in

progress. Before using the device, watch out for areas that have potentially

explosive atmospheres that are often, but not always, clearly marked. Such

locations include areas below the deck on boats, chemical transfer or storage

facilities, and areas where the air contains chemicals or particles such as grain,

dust, or metal powders. Ask the manufacturers of vehicles using liquefied

petroleum gas (such as propane or butane) whether this device can be safely

used in their vicinity.

Traffic Security

Observe local laws and regulations while using the device. To prevent

accidents, do not use your wireless device while driving.

RF signals may affect electronic systems of motor vehicles. For more

information, consult the vehicle manufacturer.

In a motor vehicle, do not place the device over the air bag or in the air bag

deployment area. Otherwise, the device may hurt you owing to the strong force

when the air bag inflates.

Do not use your device while flying in an aircraft and before boarding an aircraft.

Using wireless devices in an aircraft may cause danger to the operation of the

aircraft and disrupt the wireless telephone network. It may also be considered

illegal.

Operating Environment

Do not use or charge the device in dusty, damp, and dirty places or places with

magnetic fields. Otherwise, it may result in a malfunction of the circuit.

While using the device, observe the local laws and regulations, and respect

others' privacy and legal rights.

Place the device or accessories in well-ventilated, cool, and out-of-direct-

sunlight place. Avoid enveloping the device, or covering towels and placing

articles on the device. Place the device out of a box or case to avoid poor heat

dissipation that results in the damage to the device.

On a stormy day with thunder, do not use your device, to prevent any danger

caused by lightning.

Keep the ambient temperature between 0°C to 45°C for using the device.

This device should be installed and operated with a minimum distance of 20 cm

between the antenna and all persons.

Safety of Children

Comply with all precautions with regard to children's safety. Letting the child play

with your device or its accessories, which may include parts that can be detached

from the device, may be dangerous, as it may present a choking hazard. Ensure

that small children are kept away from the device and accessories.

Accessories

Use the accessories delivered only by the manufacturer. Using accessories of

other manufacturers or vendors with this device model may invalidate any

approval or warranty applicable to the device, result in the non-operation of the

device, and cause danger.

Charger

Use the AC power supply defined in the specifications of the charger. An

improper power voltage may cause a fire or a malfunction of the charger.

If the power cable is damaged (for example, the cord is exposed or broken), or

the plug loosens, stop using the cable at once. Otherwise, it may lead to an

electric shock, a short circuit of the charger, or a fire.

Cleaning and Maintenance

It is normal that your wireless device gets hot when you use or charge it. Before

you clean or maintain the wireless device, stop all applications and disconnect the

wireless device from your PC.

Use your wireless device and accessories with care and in a clean environment.

Keep the wireless device away from a fire or a lit cigarette.

Protect your wireless device and accessories from water and vapor, and keep

them dry.

Autres manuels pour B681

Table des matières

Autres manuels Huawei Modem

Huawei

Huawei M3710 Manuel utilisateur

Huawei

Huawei HiLink E3131 Manuel utilisateur

Huawei

Huawei MT992 Manuel utilisateur

Huawei

Huawei Mobile Broadband Manuel utilisateur

Huawei

Huawei EchoLife BM635 WiMAX CPE Manuel utilisateur

Huawei

Huawei E270 Manuel utilisateur

Huawei

Huawei Mobile WiFi Smart E355 Manuel utilisateur

Huawei

Huawei U.S.Cellular UML397 Manuel utilisateur

Huawei

Huawei EC306 Manuel utilisateur

Huawei

Huawei B2368 Manuel utilisateur

Huawei

Huawei EC152 Manuel utilisateur

Huawei

Huawei SmartAX MT882a Manuel utilisateur

Huawei

Huawei E160G Manuel utilisateur

Huawei

Huawei E368 Manuel utilisateur

Huawei

Huawei E181 HSPA Manuel utilisateur

Huawei

Huawei E182E HSPA+ Guide de dépannage

Huawei

Huawei HiLink K3773 Manuel utilisateur

Huawei

Huawei 4G Dongle Manuel utilisateur

Huawei

Huawei U.S. Cellular FT2260 Manuel utilisateur

Huawei

Huawei Optus Manuel utilisateur

Huawei

Huawei EC150 Manuel utilisateur

Huawei

Huawei E372 Manuel utilisateur

Huawei

Huawei E180 Manuel utilisateur

Huawei

Huawei E303U-6 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
