Product Description

HUAWEI E587 Mobile WiFi

V100R001

Issue

Date

2011-11-11

HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 2 of 22

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address:

Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website:

http://www.huawei.com

Email:

[email protected]

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 3 of 22

About This Document

Summary

This document provides information about the major functions, supported services,

system architecture, and technical references.

The following table lists the contents of this document.

Chapter

Details

1 Overview

The supported network modes, basic services and functions,

and the appearance of the product.

2 Features

The supported features and technical specifications of the

product.

3 Services and Applications

The services and applications of the product.

4 System Architecture

The architecture of the product.

5 Technical Reference

The technical references of the product.

6 Packing List

The items contained in the package of the product.

A Acronyms and Abbreviations

The acronyms and abbreviations mentioned in this document.

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 4 of 22

History

Issue

Details

Date

Initial draft completed.

2011-02-15

Update

2011-09-22

Update

2011-11-11

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 5 of 22

Contents

1 Overview..........................................................................................................................6

2 Features...........................................................................................................................8

2.1 Main Features .................................................................................................................................. 8

2.2 Technical Specifications ................................................................................................................... 9

2.2.1 Hardware................................................................................................................................. 9

2.2.2 Software................................................................................................................................. 10

3 Services and Applications ...........................................................................................12

3.1 Data Service................................................................................................................................... 12

3.1.1 USB Modem .......................................................................................................................... 12

3.1.2 Wireless Modem.................................................................................................................... 12

3.2 SMS................................................................................................................................................ 13

3.3 Sharing Data Stored on the microSD card..................................................................................... 13

4 System Architecture.....................................................................................................14

4.1 System Architecture ....................................................................................................................... 14

4.2 Functional Modules........................................................................................................................ 15

5 Technical Reference .....................................................................................................16

5.1 DATACOM Products....................................................................................................................... 16

5.2 Wireless Um Interface.................................................................................................................... 16

6 Packing List...................................................................................................................20

A Acronyms and Abbreviations......................................................................................21

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 6 of 22

1 Overview

HUAWEI E587 Mobile WiFi (hereinafter referred to as the E587) is a high-speed

packet access (HSPA) universal serial bus (USB) modem. It is a multi-mode wireless

terminal for SOHO (Small Office and Home Office) and business professionals. To

meet requirements from different markets, the E587 has three branch types, E587u-2,

E587u-5, and GP02, within Huawei. The differences lie in their supported bands:

E587u-2: DC-HSPA+/HSPA+/HSPA/UMTS 2100/900MHz (except DC-HSPA+

900MHZ at the first stage), EDGE/GPRS/GSM 1900/1800/900/850 MHz;

E587u-5: DC-HSPA+/HSPA+/HSPA/UMTS 2100/1900/AWS/850 MHz,

EDGE/GPRS/GSM 1900/1800/900/850 MHz;

GP02: DC-HSPA+/HSPA+/HSPA/UMTS 2100/1700 MHz.

The E587 supports the following standards:

Dual Carrier High Speed PacketAccess plus (DC-HSPA+)

High Speed Packet Access Plus (HSPA+)

High Speed Uplink PacketAccess (HSUPA)

High Speed Downlink Packet Access (HSDPA)

Universal Mobile Telecommunications System (UMTS)

Enhanced Data rates for Global Evolution (EDGE)

General Packet Radio Service (GPRS)

Global System for Mobile communications (GSM)

The E587 provides the following services:

DC-HSPA+ packet data service of up to 43.2 Mbit/s

HSPA+ packet data service of up to 21.6 Mbit/s

HSPA (HSUPA/HSDPA)/UMTS packet data service of up to 14.4 Mbit/s

EDGE/GPRS packet data service of up to 236.8 Kbit/s

UMTS/GSM Short Message Service (SMS)

You can connect the E587 with the Wi-Fi, or connect the E587 with the USB interface

of a computer. In the service area of the

DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM network, you can surf the

Internet and send/receive messages/emails cordlessly. The E587 is fast, reliable, and

easy to operate. Thus, mobile users can experience many new features and services

with the E587. These features and services will enable a large number of users to use

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 7 of 22

the E587 and the average revenue per user (ARPU) of operators will increase

substantially.

Figure 1-1 shows the profile of the E587.

Figure 1-1 E587 profile

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 8 of 22

2 Features

2.1 Main Features

The E587 mainly supports the following features:

DC-HSPA+ data service of up to 43.2Mbit/s

HSPA+ data service of up to 21.6 Mbit/s

HSUPA (UL) data service of up to 5.76 Mbit/s

HSDPA (DL) data service of up to 14.4 Mbit/s

UMTS PS domain data service of up to 384 Kbit/s

EDGE packet data service of up to 236.8 Kbit/s

GPRS packet data service of up to 85.6 Kbit/s

PS domain data service based on UMTS and GSM

SMS based on GSM and UMTS

Wi-Fi and WPS

Built-in DHCP Server, DNS RELAY, DHCP Client and NAT

Plug and play (PnP)

Personal computer/Smart card (PC/SC) Driver

USB Extension Cable, easy to connect

Standard micro USB interface

Built-in UMTS and WLAN high gain antenna

Micro Secure Digital Memory (mircoSD) Card

Sharing the microSD card on web page

Windows XP, Windows Vista, Windows 7, Mac OS X 10.5, Mac OS X 10.6, Mac

OS X 10.7

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 9 of 22

2.2 Technical Specifications

2.2.1 Hardware

Table 2-1 lists the hardware specifications.

Table 2-1 Hardware specifications

Item

Specifications

Technical

standard

WAN：DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM

WLAN: IEEE 802.11b/g/n (1*1 antenna)

Operating

frequency

DC-HSPA+/

HSPA+/HS

PA/UMTS

E587u-2: 2100/900MHz

E587u-5: 2100/1900/AWS/850MHz

GP02: 2100/1700 MHz

EDGE/GPR

S/GSM

E587u-2: 850/900/1800/1900MHz

E587u-5: 850/900/1800/1900MHz

WLAN: 2.401GHz–2.495GHz

Internal memory

128MB Flash, 32MB SD-RAM

Maximum

transmitter

power

UMTS: ≥24 (+1/-3) dBm

WLAN (Battery mode): 4~10dBm

WLAN (Power adapter

mode)

802.11b: 11~17dbm

802.11g: 9~15dbm

802.11n: 4~10dbm

Receiver

sensitivity

UMTS: -106.7dbm/3.84MHz

WLAN 802.11b: -76dBm@11Mbps/-82dBm@1Mbps

WLAN 802.11g: -65dBm@54Mbps

WLAN 802.11n: -64dBm@65Mbps

WLAN speed

802.11b: Up to 11Mbit/s

802.11g: Up to 54Mbit/s

802.11n: Support MCS0–MCS7; Up to 72.2Mbit/s

Maximum power

consumption

4.3W

Power supply

AC: 100V–240V

DC: 5V, 1A

HUAWEI E587 Mobile WiFi V100R001

Product Description

Issue 03 (2011-11-11)

Commercial in Confidence

Page 10 of 22

Item

Specifications

Battery

Type: Li (Rechargeable)

Capacity: 3.7V, 2200mAh

Maximum working time: 4.5 hours

Maximum standby time: 210 hours while Wi-Fi is off; 50 hours

while Wi-Fi is often on.

External

interfaces

USB interface: Micro USB

Standard microSD card interface

SIM card: standard 6-pin SIM card interface

Display screen

OLED

Key-press

Power switch, WPS switch, Reset switch

Antenna

Built-in GSM/UMTS primary antenna

Built-in UMTS diversity antenna

Built-in WLAN antenna

External main diversity antenna interface (Optional)

Dimensions

(D ×W ×H)

102.0mm×56.0mm×15.5mm

Weight

about 110g (including the battery)

Temperature

Operating: -10℃to +35℃

Storage: -20℃to +70℃

Humidity

5% to 95%

2.2.2 Software

Table 2-2 lists the software specifications.

Table 2-2 Software specifications

Item

Description

SMS

Writing/Sending/Receiving

Storage: Up to 250 messages can be saved in the

internal memory of the E587.

Setting the SMS center number

New message prompt

Network connection

setup

APN management: create, delete, edit.

Set up network connection.

Autres manuels pour E587

Table des matières

Autres manuels Huawei Modem

Huawei

Huawei E3372 Manuel utilisateur

Huawei

Huawei EchoLife HG510 Manuel utilisateur

Huawei

Huawei Mobile WiFi Manuel utilisateur

Huawei

Huawei Turbo Stick E182 Manuel utilisateur

Huawei

Huawei E220 Guide de l'utilisateur

Huawei

Huawei EC199 Manuel utilisateur

Huawei

Huawei E600 Manuel utilisateur

Huawei

Huawei E2010 Instructions de montage

Huawei

Huawei MT992 Manuel utilisateur

Huawei

Huawei E156G Manuel utilisateur

Huawei

Huawei USB 3G Manuel d'installation et d'exploitation

Huawei

Huawei U.S.Cellular UML397 Manuel utilisateur

Huawei

Huawei E372 Manuel utilisateur

Huawei

Huawei USB modem Manuel utilisateur

Huawei

Huawei Vodafone USB Extreme Manuel d'installation et d'exploitation

Huawei

Huawei E160E Manuel utilisateur

Huawei

Huawei HiLink E3131 Caractéristiques techniques

Huawei

Huawei Mobile WiFi Smart E355 Manuel utilisateur

Huawei

Huawei Broadband E219 Manuel utilisateur

Huawei

Huawei E3372h Manuel utilisateur

Huawei

Huawei E220 Manuel utilisateur

Huawei

Huawei Globe BROADBAND Manuel utilisateur

Huawei

Huawei E397 Manuel utilisateur

Huawei

Huawei e3276 Guide d'installation

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
