1 About This Document

Purpose

This document describes the general-purpose compute module G530 V2 and heterogeneous

compute module GP316 of the Huawei FusionServer G5500 server in terms of appearances,

features, performance parameters, and configurations, helping users have a deep

understanding of a compute node consisting of a G530 V2 and a GP316.

NOTE

In this document, a compute node consists a G530 V2 and a GP316.

Intended Audience

This document is intended for:

lHuawei presales engineers

lChannel partner presales engineers

lEnterprise presales engineers

Change History

Changes between document issues are cumulative. The latest document issue contains all

changes made in previous issues.

Issue 03 (2018-02-12)

This is the third official release.

Mode Change Description

Modify Changed ESN to SN and modified the description of the year and

month.

Issue 02 (2018-01-05)

This is the second official release.

Huawei G5500 Server G530 V2 Compute Node

White Paper 1 About This Document

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

Mode Change Description

Modify Modified DIMM configuration rules.

New Added the B/D/F information of PCIe devices.

Delete Deleted the CPU list. To obtain CPU models, use the Huawei Server

Compatibility Checker.

Issue 01 (2017-10-20)

This issue is the first official release.

Huawei G5500 Server G530 V2 Compute Node

White Paper 1 About This Document

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

2 About the G530 V2 and GP316

2.1 Overview

2.2 Appearance

2.3 Ports

2.4 Indicators and Buttons

2.5 Physical Structure

2.6 Logical Structure

2.7 Technical Specifications

2.1 Overview

The G530 V2 is a half-width compute module that uses the new-generation Intel® Xeon®

Scalable processors with the Purley platform to support a large memory capacity and deliver

powerful computing capabilities. The GP316 supports a maximum of 16 half-height half-

length single-slot PCIe slots for installing general-purpose GPU (GPGPU) cards and is used

together with the G530 V2 to expand the computing capabilities.

The G530 V2 and GP316 are installed in a G5500 chassis (chassis for short) and centrally

managed by the management module. Each chassis can be installed with a maximum of two

compute nodes, and each compute node contains a G530 V2 and a GP316.

2.2 Appearance

Appearances of the G530 V2 and GP316

Figure 2-1 and Figure 2-2 show the appearances of the G530 V2 and GP316.

Huawei G5500 Server G530 V2 Compute Node

White Paper 2 About the G530 V2 and GP316

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

Figure 2-1 Appearance of the G530 V2

Figure 2-2 Appearance of the GP316

Installation Position

The G530 V2 compute modules are installed in the lower two slots of the chassis,

corresponding to G530 V2-1 and G530 V2-2. The GP316 heterogeneous compute modules

used together with the G530 V2 compute modules are installed in the upper two slots of the

chassis, corresponding to GP316-1 and GP316-2. See Figure 2-3.

Huawei G5500 Server G530 V2 Compute Node

White Paper 2 About the G530 V2 and GP316

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

Figure 2-3 Installation positions of the G530 V2 and GP316 modules

NOTE

lA maximum of two G530 V2 compute modules can be installed in a chassis, and each G530 V2

combines with the GP316 in its upper slot to form a G530 V2 compute node. The two combinations

are independent of each other. When configuring only one compute node, select the combination

(G530 V2-1 and GP316-1) on the left.

lIn each combination, the G530 V2 and GP316 must be installed and removed in the following

sequence: Install the GP316 and then the G530 V2. Remove the G530 V2 and then the GP316.

lMaintaining one combination does not affect the proper operation of the other combination.

Front Panel

Figure 2-4 shows the front panel of the G530 V2.

Figure 2-4 Front panel of the G530 V2

1Label plate 2 USB 3.0 ports

3 Power button/indicator 4 UID button/indicator

5 HLY indicator 6 Release button

7 M.2 module adapter 8 M.2 module

9 Ejector lever 10 2.5-inch hard disk

Huawei G5500 Server G530 V2 Compute Node

White Paper 2 About the G530 V2 and GP316

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

11 Hard disk activity indicator 12 Hard disk fault indicator

13 Product model 14 M.2 module activity indicator

15 M.2 module fault indicator 16 VGA port

Figure 2-5 shows the front panel of the GP316.

Figure 2-5 Front panel of the GP316

1 Ejector release button 2 Ejector lever

NOTE

When a compute node is installed in the chassis, the ejector release button and ejector lever on the

GP316 front panel are invisible because they are blocked by the G530 V2. After the G530 V2 is

removed, they can be seen.

A serial number (SN) is a string that uniquely identifies a server. A SN is required when you

apply for Huawei technical support.

Figure 2-6 shows the SN format.

Figure 2-6 SN example

Huawei G5500 Server G530 V2 Compute Node

White Paper 2 About the G530 V2 and GP316

Issue 03 (2018-02-12) Huawei Proprietary and Confidential

No. Description

1 Indicates the SN ID (two digits). The value is fixed to 21.

2 Indicates the item identification code (eight characters).

3 Indicates the vendor code (two characters). 10 indicates Huawei

and other values indicates manufacturing partners.

4 Indicates the year and month (two characters).

lThe first character indicates the year. The digits 1 to 9

indicate 2001 to 2009, the letters A to H indicate 2010 to

2017, the letters J to N indicate 2018 to 2022, and the letters

P to Y indicate 2023 to 2032.

NOTE

The years from 2010 are represented by upper-case letters excluding

I, O, and Z because the three letters are similar to the digits 1, 0, and

lThe second character indicates the month. The digits 1 to 9

indicate January to September, and the letters A to C indicate

October to December.

5 Indicates the sequence number (six digits).

6 Indicates RoHS compliance (one character). Y indicates

compliance.

7 Indicates the internal model of the board.

2.3 Ports

Table 2-1 Port description

Port Type Quantit

Description

USB port USB 3.0

Type A

2 The panel provides two USB 3.0 ports, which

are compatible with USB 2.0.

VGA port DB15 1 The panel provides a DB15 VGA port for local

maintenance of the compute node.

2.4 Indicators and Buttons

This section describes the indicators and buttons of the G530 V2.

Huawei G5500 Server G530 V2 Compute Node

White Paper 2 About the G530 V2 and GP316

Issue 03 (2018-02-12) Huawei Proprietary and Confidential
