Huawei SmartLogger2000 series Manuel utilisateur

SmartLogger2000

User Manual

Date 2016-06-20

HUAWEI TECHNOLOGIES CO., LTD.

(2016-06-20) Huawei Proprietary and Confidential

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

SmartLogger2000

User Manual About This Document

(2016-06-20) Huawei Proprietary and Confidential

About This Document

Overview

This document introduces the SmartLogger2000 (SmartLogger for short) in terms of

installation, cable connections, system operation and maintenance, and troubleshooting.

Readers should understand the SmartLogger features, functions, and safety precautions

provided in this document before installing and operating the SmartLogger.

The figures provided in this document are for reference only. The actual product appearance

prevails.

You can print the document based on your requirements. Store the paper copy properly for

future use. You can log in to http://support.huawei.com/carrier/, click Product Support, and

search for SmartLogger to view and obtain the latest user manual.

Intended Audience

This document is intended for photovoltaic (PV) plant operators and qualified electrical

technical personnel.

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol Description

Indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not

avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not

avoided, could result in equipment damage, data loss,

performance deterioration, or unanticipated results.

NOTICE is used to address practices not related to personal

SmartLogger2000

User Manual About This Document

(2016-06-20) Huawei Proprietary and Confidential

iii

Symbol Description

injury.

Calls attention to important information, best practices and

tips.

NOTE is used to address information not related to personal

injury, equipment damage, and environment deterioration.

Change History

Changes between document issues are cumulative. The latest document issue contains all the

changes made in earlier issues.

SmartLogger2000

User Manual Contents

(2016-06-20) Huawei Proprietary and Confidential

Contents

About This Document.................................................................................................................... ii

1 Safety Precautions.........................................................................................................................1

2 Overview.........................................................................................................................................3

2.1 Overview ...................................................................................................................................................................... 3

2.2 Appearance ................................................................................................................................................................... 6

2.3 Nameplate Description ............................................................................................................................................... 10

2.4 Typical Networking Scenarios.................................................................................................................................... 11

2.5 System Wiring Diagram.............................................................................................................................................. 14

3 Installation....................................................................................................................................22

3.1 Checking Before Installation ...................................................................................................................................... 22

3.2 Preparing Tools ........................................................................................................................................................... 23

3.3 Determining the Installation Position ......................................................................................................................... 25

3.4 Installing the SmartLogger ......................................................................................................................................... 27

3.4.1 Mounting the SmartLogger on a Wall...................................................................................................................... 27

3.4.2 Mounting the SmartLogger Along a Guide Rail...................................................................................................... 31

3.5 Installing the RS485 signal SPD................................................................................................................................. 34

4 Connecting Cables ......................................................................................................................36

4.1 Connection Description .............................................................................................................................................. 37

4.2 Connecting the PE Cable ............................................................................................................................................ 37

4.2.1 Connecting the PE Cable for the SmartLogger........................................................................................................ 37

4.2.2 Connecting the PE Cable for the RS485 Signal SPD .............................................................................................. 39

4.3 Connecting the RS485 signal SPD ............................................................................................................................. 40

4.4 Connecting Inverters................................................................................................................................................... 44

4.4.1 Connecting the SUN2000 ........................................................................................................................................ 44

4.4.2 Connecting the SUN8000 ........................................................................................................................................ 52

4.4.3 Connecting Multiple Inverters to the SmartLogger ................................................................................................. 54

4.5 Connecting an EMI..................................................................................................................................................... 56

4.6 Connecting a Power Meter ......................................................................................................................................... 58

4.7 Connecting the Box-type Transformer........................................................................................................................ 59

4.8 Connecting a PID Module .......................................................................................................................................... 61

4.9 Connecting a Ripple Control Receiver ....................................................................................................................... 62

SmartLogger2000

User Manual Contents

(2016-06-20) Huawei Proprietary and Confidential

4.10 Connecting an Ethernet Network Cable ................................................................................................................... 65

4.11 Connecting Optical Fibers ........................................................................................................................................ 66

5 System Operation........................................................................................................................69

5.1 Checking Before Power-On........................................................................................................................................ 69

5.2 Powering On the System............................................................................................................................................. 70

6 User Interface...............................................................................................................................72

6.1 USB Flash Drive Operations ...................................................................................................................................... 72

6.1.1 Exporting Data......................................................................................................................................................... 72

6.1.2 Exporting All Files................................................................................................................................................... 73

6.1.3 Importing All Files................................................................................................................................................... 74

6.1.4 Upgrading the Application....................................................................................................................................... 76

6.1.5 Upgrading the BSP .................................................................................................................................................. 77

6.2 NMS Operations......................................................................................................................................................... 78

6.3 APP Operations........................................................................................................................................................... 78

7 Maintenance.................................................................................................................................79

7.1 Daily Maintenance...................................................................................................................................................... 79

7.2 Troubleshooting .......................................................................................................................................................... 79

7.3 Alarms......................................................................................................................................................................... 81

8 Disposing of the SmartLogger..................................................................................................84

9 Certification Declaration ...........................................................................................................85

9.1 CE............................................................................................................................................................................... 85

9.2 FCC............................................................................................................................................................................. 85

10 Technical Specifications ..........................................................................................................86

A Product User Lists ......................................................................................................................88

B Acronyms and Abbreviations ..................................................................................................89

SmartLogger2000

User Manual 1 Safety Precautions

(2016-06-20) Huawei Proprietary and Confidential

1 Safety Precautions

Read the safety precautions carefully. Otherwise, human injury and equipment damage may

occur.

Personnel Requirements

Only qualified and trained electrical technicians are allowed to install and operate the

SmartLogger.

Operation personnel should understand the composition and working principles of the

PV grid-tied power generating system and local regulations.

Read this document thoroughly before operations. Huawei shall not be liable for any

consequence caused by violation of the storage, transportation, installation, and operation

regulations specified in this document.

Identification Protection

The signs on the SmartLogger shell specify important information about secure

operations. Do not damage the signs.

The nameplate attached to the bottom of the SmartLogger lists the SmartLogger

parameters. Do not damage the nameplate.

Installation

Before installation, read this document carefully. Huawei shall not be liable for any

consequence caused by violation of the regulations specified in this document.

Before installing the SmartLogger, ensure that it is not connected or energized.

Install the SmartLogger in well-ventilated environments to ensure system performance.

SmartLogger2000

User Manual 1 Safety Precautions

(2016-06-20) Huawei Proprietary and Confidential

Ensure that the heat dissipation holes of the SmartLogger are not blocked.

Do not move the components inside the shelf except for the wiring terminals at the

bottom.

Install the SmartLogger in a dedicated area.

Operation

Strictly comply with the safety precautions in this document and associated documents to

operate the SmartLogger.

When operating the SmartLogger, follow local laws and regulations.

Maintenance and Replacement

A faulty SmartLogger requires overall maintenance. Contact the dealer if any fault

occurs in the SmartLogger shelf.

Maintain the SmartLogger after you get familiar with this document and tools and testing

equipment are available.

When maintaining the SmartLogger, wear ESD gloves and comply with ESD

precautions.

The device has multiple inputs. Switch off all inputs before the maintenance.

SmartLogger2000

User Manual 2 Overview

(2016-06-20) Huawei Proprietary and Confidential

2 Overview

About This Chapter

2.1 Overview

2.2 Appearance

2.3 Nameplate Description

2.4 Typical Networking Scenarios

2.5 System Wiring Diagram

2.1 Overview

Function

The SmartLogger is a highly integrated device dedicated for monitoring and managing the PV

power system. It converges ports, converts protocols, collects and stores data, and centrally

monitors and maintains devices in the PV power system.

Features

The SmartLogger provides the following features:

Wide application

−Industrial-grade application, wide temperature range: –40°C to +60°C

−High altitude: applicable at an altitude of 4000 m

Various communications modes

−Bluetooth

Has a built-in Bluetooth module through which the SUN2000 APP (APP for short)

connects to the SmartLogger for parameter configuration and device maintenance.

The SmartLogger Bluetooth is named as LOG+the last eight figures of the ESN

of the SmartLogger.

−Optical fiber ring switch

Provides two 100M Ethernet optical ports that support RSTP and STP to implement

fiber ring networking. If RSTP is used, fiber ring protection can be completed

SmartLogger2000

User Manual 2 Overview

(2016-06-20) Huawei Proprietary and Confidential

within 10 seconds. If STP is used, fiber ring protection can be completed within 60

seconds.

−PLC

Has a built-in PLC CCO module through which southbound devices connect to the

SmartLogger over AC power cables.

−Ethernet electrical port

Provides two 10/100M Ethernet electrical ports that can be used as southbound

ports to connect to southbound devices or used as northbound ports to connect to an

NMS.

A southbound port connects to a downstream device for collecting data and setting parameters.

Southbound devices include the inverter, environmental monitoring instrument (EMI), power meter,

box-type transformer, and PID module.

A northbound port connects to an upstream NMS for uploading data.

−RS485

Supports six RS485 routes and access of devices that use Modbus-RTU, IEC103,

and DL/T645.

Graphical data

−In addition to displaying the electricity yield and real-time monitoring information

in graphic and text format, the embedded WebUI can also display performance data

of power stations and devices in tables or curves.

−The APP displays the electricity yield and real-time monitoring information in

graphic and text format.

Centralized monitoring

−Manages a maximum of 200 devices in centralized mode and supports the access of

up to 80 inverters.

−Allows you to monitor and manage the PV power system on the embedded WebUI,

for example, viewing real-time information about power stations, devices, and

faults, setting device parameters, and maintaining devices in remote mode.

−Allows you to monitor the devices in the PV power system on the APP in real time,

such as viewing information about power stations, devices, products, and faults,

setting device parameters, and maintaining devices.

Easy maintenance

−Allows users to upgrade the firmware of the SmartLogger and export data by using

a USB flash drive.

−Allows you to upgrade the firmware of the SmartLogger, inverter, AC combiner box,

PLC module, and PID module, and export logs and data over the embedded WebUI.

−Allows you to manage the devices connecting to the SmartLogger and classify

alarms over the APP.

Intelligent management

−Automatically searches for and accesses Huawei inverters, AC combiner boxes,

PLC modules, and PID modules. If you import a parameter configuration table, the

SmartLogger can access third-party devices that support Modbus-RTU and IEC103.

−Automatically assigns RS485 addresses to the connected Huawei inverters, AC

combiner boxes, and PID modules, and allows for RS485 address adjustment based

on ESNs to facilitate remote configuration and maintenance.

−Supports remote configuration of inverter parameters over the embedded WebUI

and synchronizes the parameters from one inverter to other inverters in batches.

Autres manuels pour SmartLogger2000 series

Table des matières

Autres manuels Huawei Unité de contrôle

Huawei

Huawei MU509-b Guide de l'utilisateur

Huawei

Huawei V100R001C00 Manuel utilisateur

Huawei

Huawei MU509 Series Instructions d'installation

Huawei

Huawei ME909s-120 Instructions d'installation

Huawei

Huawei MU609 Instructions d'installation

Huawei

Huawei SmartAX MA5612 Manuel d'utilisation

Huawei

Huawei MG323 Instructions d'installation

Huawei

Huawei PLC CCO01A Manuel utilisateur

Huawei

Huawei MU739 Instructions d'installation

Huawei

Huawei EM660 Manuel utilisateur

Huawei

Huawei RRU3269 Manuel utilisateur

Huawei

Huawei UPS5000-E Series Manuel utilisateur

Huawei

Huawei ME909s-120 Instructions d'installation

Huawei

Huawei ME906V Manuel utilisateur

Huawei

Huawei ATOM GPS Manuel utilisateur

Huawei

Huawei ME909u-521 Instructions d'installation

Huawei

Huawei SMU01C Manuel utilisateur

Huawei

Huawei ICD OPS D Series Manuel utilisateur

Huawei

Huawei CX320 Manuel utilisateur

Huawei

Huawei MU709 Series Instructions d'installation

Huawei

Huawei ME909u-523 Instructions d'installation

Huawei

Huawei ME909U-523D Manuel utilisateur

Huawei

Huawei ME936 Instructions d'installation

Huawei

Huawei MU736 HSPA+ M.2 Instructions d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
