H3C SecPath DC2400 Manuel utilisateur

H3C SecPath DC2400 Power Module

User Manual

New H3C Technologies Co., Ltd.

http://www.h3c.com.hk

Document version: 6PW101-20170414

and its licensors

No part of this manual may be reproduced or transmitted in any form

or by any means without prior written consent of New H3C

Technologies Co., Ltd.

Trademarks

H3C, , H3CS, H3CIE, H3CNE, Aolynk, ,

H3Care, , IRF, NetPilot, Netflow, SecEngine, SecPath,

SecCenter, SecBlade, Comware, ITCMM and HUASAN are

trademarks of New H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the

property of their respective owners

Notice

The information in this document is subject to change without notice.

Every effort has been made in the preparation of this document to

ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of

any kind, express or implied.

Environmental protection

This product has been designed to comply with the environmental

protection requirements. The storage, use, and disposal of this

product must meet the applicable national laws and regulations.

Obtaining documentation

To access the most up-to-date H3C product documentation, go to the

H3C website at http://www.h3c.com.hk

To obtain information about installation, configuration, and

maintenance, click http://www.h3c.com.hk/Technical_Documents

To obtain software version information such as release notes,

click http://www.h3c.com.hk/Software_Download

Technical support

[email protected]

http://www.h3c.com.hk

Documentation feedback

You can e-mail your comments about product documentation to

[email protected].

We appreciate your comments.

Contents

Overview ·················································· 1

Front panel ···································································· 2

LEDs············································································ 2

Technical specifications ··················································· 4

Power module configuration·············································· 5

Installing and removing the power module······· 6

Installing the power module··············································· 6

Installing the power module ·········································· 7

Connecting the power cord··········································10

Removing the power module············································11

Removing the power cord············································12

Removing the power module········································12

Overview

The DC2400 DC-input and DC-output power module provides a

maximum output of 2400 W. The available model is NSQM1DC2400.

It has the following features:

•It has protection against undervoltage input, overvoltage input,

overvoltage output, output short circuit, overcurrent output, and

overtemperature.

•It is hot swappable. You can install and remove the power

module on an operating device.

•It can operate in N+1 or N+N redundancy. For more information,

see "Power module configuration."

NOTE:

The power module shuts down automatically when its

temperature exceeds the acceptable range. When the

temperature returns to the acceptable range, the power module

restarts automatically.

Front panel

Figure 1 Front panel

(1) Captive screw (2) Handle

(3) Power receptacle (4) Power cord screw hole

(5) Power input status LED

(INP OK) (6) Power output status LED

(DC/FLT)

LEDs

The power module has two LEDs.

Table 1 LED description

LED Mark Color Description

Power

input

status

LED

INP OK

Green Normal power input.

Off

•No power input.

•Low power input voltage.

The power module has

entered self-protection

mode.

Power

output

status

LED

DC/FLT

Green Normal power output.

Red

•An output exception has

occurred, for example,

output short circuit, output

overcurrent, output

overvoltage, input

undervoltage,

overtemperature, or remote

shutdown. The power

module has entered

self-protection mode.

•No power is being input to

the power module. Other

power modules are

supplying power to the

device.

Orange

The temperature of the power

module exceeds the

acceptable range. The power

module has entered

self-protection mode.

NOTE:

fte

the circuit breaker of the power module is switched off, the

LEDs on the power module will remain on for a while. Make sure

the LEDs are off when you remove the power module.

Technical specifications

Table 2 Technical specifications

Item Specifications

Rated input voltage –48 to –60 VDC

Rated output voltage 12 VDC

Maximum input current 60 A

Maximum output current 200 A at 12 VDC

Maximum output power 2400 W

Dimensions (H × W × D) 41 × 102 × 391 mm (1.61 ×

4.00 × 15.36 in)

Ambient

temperatur

Operating

temperature –10°C to +50°C (–14°F to

+122°F)

Storage

temperature –40°C to +85°C (–40°F to

+185°F)

Relative

humidity

Operating

humidity 30% to 95%, non-condensing

Storage humidity 10% to 95%, non-condensing

Power module configuration

Follow these guidelines to configure power modules for a device:

•Determine the required number of power modules based on the

actual power consumption, the power module slot number, and

power redundancy design.

•Determine the power module redundancy design based on the

power source conditions.

{When two mains power inputs are provided, you can

configure the power modules in N+N redundancy. N+N must

be not greater than the total number of power module slots.

{When one mains power input is provided, you can configure

the power modules in N+1 or N+N redundancy. N+1 or N+N

must be not greater than the total number of power module

slots.

•For easy usage and maintenance, configure a circuit breaker for

each power input. The rated current of the circuit breaker must

be greater than 80 A.

Installing and removing the power

module

CAUTION:

Do not install the DC2400 power module and other types of

power modules on the same device.

The power module slots are either vertically or horizontally oriented,

depending on the device model. The power module installation and

removal procedure is similar for vertical and horizontal power module

slots. The figures in this section are for illustration only.

Installing the power module

To avoid bodily injury and device damage, follow the procedure

in Figure 2 to install the power module.
