Gram C3 Series Manuel utilisateur

SERIES / SERIE / SÉRIE

300 / 500 / 1T

OPERATION MANUAL

MANUAL DE UTILIZACION

MANUEL D´UTILISATION

INDEX English

Safety recommendations 5

Function keys on remote control 6

Use of crane scale 7

Turn ON 7

Turn OFF 7

Tare / Zero 7

Display brightness 7

Hold function 8

Weighing accumulation function 8

ON / OFF Save power 8

Calibration 9

Calibration using the remote controller 9

Calibration using keys of crane scale 9

Parameters setting 10

Parameters setting using the remote controller 10

Parameters setting using keys of crane scale 11

Guarantee 12

ÍNDICE Español

Requisitos para una óptima instalación 13

Función de las teclas del control remoto 14

Utilización del gancho 15

Encender el gancho 15

Apagar el gancho 15

Tara y puesta a cero 15

Brillo del display 15

Función Hold 16

Función de acumulación de pesadas 16

Ahorro de energía 16

Calibración 17

Calibración utilizando las teclas del mando a distancia 17

Calibración utilizando las teclas del gancho 17

Configuración de parámetros 18

Configuración de parámetros utilizando las teclas del mando a distancia 18

Configuración de parámetros utilizando las teclas del gancho 19

Garantía 21

SOMMAIRE Français

Conditions requises pour une installation optimale 22

Función de las teclas del control remoto 23

Utilisation du crochet 24

Allumer le crochet 24

Eteindre le crochet peseur 24

Tare et retour au zéro 24

Luminosité de l’ecran 24

Fonction Hold 25

Fonction d’accumulation de pesées 25

ON / OFF Save power 25

Etalonnage 26

Calibration avec la commande a distance 26

Calibration avec les touches du crochet 26

Configuration des parametres 27

Configuration des parametres avec la commande a distance 27

Configuration des parametrs avec les touches du crochet 28

Garantie 29

ENGLISH

SAFETY RECOMMENDATIONS

Before using the crane scale, please, read this manual carefully and

follow the instructions.

• DON´T overload the crane scale, this could seriously damage the

loadcell (repair not covered by the warranty).

• DON´T leave any weight on the hook for a long time, this reduces the

accuracy of the equipment and shorts the life of the loadcell.

• Before using the scale, check rings, hooks and other parts, cotter pin,

if the screw is loose and deformation loose every 3 months.

• Charge the battery when the display shows the low power indicator.

• DON’T use the crane scale in rain or storms.

• After used, hook should vertical suspended or the loadcell could be

damaged.

• DON´T try to repair the crane scale. Please contact with your

Distributor.

Model Capacity Division (e)

C3-300 300kg 50kg

C3-500 500kg 100g

C3-1T 1.000kg 200g

Accuracy Class III

Tare range 100% Max. capacity

Time of stability 10´s

Overload alarm Max +9e

Max. overload 125% Max. capacity

Power Fwll seal rechargeable battery 6V/4AH

Display Super light LED

Temperature 0ºC – 40C

Remote control range ≤20m

FUNCTION KEYS ON REMOTE CONTROL

Key Function

A – Confirm

B – T/0 Tare / zero

C - Accumulation

D - H Hold

USE OF CRANE SCALE

Turn ON

Press the key on the crane, the scale begin the self test, at the same

time, auto-zero initialization, then the display will show power status “Pbt85”

(85% power) and finally the crane scale enters to weighing mode.

Turn OFF

Press the key for 3 seconds or Dand Btogether on remote control, the

display will show “PA80” (80% power), 1.5 seconds later, the display will

show “off” and scale power off.

Tare / Zero

To obtain the net weight of a product. Place a container and press the

key or Bon remote control, the display shows zero value, put the product into

the container, the display will show the net weight of the product.

Display brightness

1. With the crane scale disconnected, press the key the same time

press also the key .

2. The display will show: “Dsp X”.

3. Available options:

X=0 Low brightness.

X=1 High brightness.

X=2 Automatical brightness (when weight changes, the high

brightness is activated, after 20 seconds of stability, the low

brightness is activated).

4. Press key to select the desired mode.

5. Press the key to return to normal weighing mode.

Hold function

1. Press the key Don remote control, the display´s reading will remain

locked for 30 seconds.

2. Press again the key Don remote control, the Hold function will be turn

off, the balance will return to normal weighing mode.

Weighing accumulation function

When the weight is stable, press the Ckey on the remote control to accumulate

the display values and view the accumulation times “n32”, 2 seconds later,

back to normal weighing mode.

To cancel accumulation function, press the Bkey on remote control and

returns to normal weighing mode.

ON / OFF Save power

Press the Akey on remote control for 2 seconds, the display will power off,

only shows “-“ to save power.

Press the Akey on remote control for 2 seconds, back to normal weighing

mode.

CALIBRATION

Calibration using the remote controller

1. Power on the crane scale and keep pressed the Dkey until display shows

“CAL SP”.

2. The display will show “CAL 00”, press A key once to display “CAL00”.

3. Do not hang on the hook any goods at this time.

4. Display will show “LOAD”, press the Akey until view “-------“ and then

later on display “LOAD”.

5. Press the Dkey to input the calibration weight value (long press Dkey to

increase the number of digit, click to the left shift).

6. Lifting weights, until steady 4 to 5 seconds.

7. Press the Akey to show “--------“, 2 seconds after the display of the

hanging weight values, calibration is finished, put weight down, turn it off.

Calibration using keys of crane scale

1. When power on and self detecting, keep pressed key until display

shows “CAL SP”.

2. Press the key once the display shows “CAL00”.

3. Do not hang on the hook any goods at this moment.

4. Press the key once the display shows “--------“, after few seconds,

the display will read “LOAD”.

5. Press the key to input the weighing value of the calibration weight

(keeping pressed the key means adding number, single clicking

means left shift).

6. Hang the calibration weight and wait for 4 – 5 seconds until the stable

sign light on.

7. Press the key once the display shows “-----------“, few seconds

after, the display will show the weight calibration value. Calibration is

over by now. Put down the weights and power off the scale.

PARAMETERS SETTING

Parameters setting using the remote controller

1. Post holding down the Dkey and so display “CAL SP”.

2. Press the Dkey to display “SET”.

3. Press the Akey on remote control to display “dx” (division parameter).

4. Use the Dkey to change the division value.

5. When finished, press the Akey to view the capacity of the crane scale.

6. Press the Dkey to change the capacity value.

7. Press the Akey to show “FLT 00” (filter parameter 0 – 4).

8. Press the Dkey to change the filter value.

9. Press the Akey to show “rng 1” (zero tracking parameter).

10. Press the Dkey to change the zero tracking value.
