Foxconn 661MXPlus Fiche technique

EasyInstallationGuide

P/N:3A2507U00-000-G

V1.1

661MXPlusMotherboardLayout

NOTE:

The abovemotherboardlayout isprovided for referenceonly;

please refertothephysicalmotherboard.

184-pinDIMMSlots

ATXPower

Connector

ATA66/100/133

IDEConnectors

FAN1Connector

ClearCMOS

Jumper

FrontPanel

Connector

12VATXPower

Connector

SiS661GXChipset

IrDAConnector

(optional)

SpeakerConnector

478-pinCPUSocket

PCIExpansionSlots

SiS964L

Chipset

CPUFANConnector

FDDConnector

SPDIF_OUT

Connector(optional)

USB2.0

Connectors

8XAGP

Slot

CD-IN

Connector

CPUModelSelection

Jumper

FrontAudio

Connector

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

SerialPort

(COM1)

PS/2 Mouse

Connector

ParallelPort

(PrinterPort)

Line-injack

Line-out jack

Microphone

jack

PS/2Keyboard

Connector

LANPort

(optional)

VGAPort

(optional)

5USB2.0Ports6

661MXPlus RearPanel

PS/2MouseConnector

Thisgreen 6-pinconnectorisfor aPS/2mouse.

PS/2KeyboardConnector

Thispurple6-pinconnectorisfor aPS/2keyboard.

SerialPort (COM1)

This9-pinCOM1portisforpointingdevices orotherserialdevices.

ParallelPort (PrinterPort)

This25-pinportconnectsaparallelprinter, ascanner, or other devices.

VGAPort(optional)

The VGAportisforoutput toaVGA-compatibledevice.

USB2.0Ports

These fourUniversalSerialBus(USB) portsareavailableforconnectingUSB 2.0

devices.

LAN Port (optional)

ThisportallowsconnectiontoaLocalAreaNetwork(LAN)throughanetworkhub.

Line-injack,Line-out jack,Microphonejack

Usethethreeaudioportstoconnectaudiodevices.TheLine-injackisforatape

player orotheraudiosources. The Line-outjackisforaheadphoneor aspeaker.

TheMicrophonejackisfor amicrophone. In6-Channelmode, thefunctionofthe

three jacksbecomesRearSpeaker Out, FrontSpeakerOutand Center/Subwoofer

Speakerrespectively.

PDF 件使用 "pdfFactory" 试用版本创建 ÿwww.fineprint.com.cn

Thanksforyourpurchasing Foxconn s661MXPlusseries motherboard.Please

carefullycheck the package;if thereareanymissing ordamaged items,contact

yourdistributorassoonaspossible.

v661MXPlus motherboard(x1)

vFoxconnUtilityCD (x1)

vEasyInstallation Guide(x1)

vIDE Ribboncable(x1)

vFDD Ribboncable(x1)

vI/OShield(x1)

AccessoryChecklist

CPU/ MemorySupportFeatures

CPU:

vSupportsIntel®Pentium ®4socket478(Willamette/Northwood/Prescott) pro-

cessors

vSupportsIntel®Celeron ®Dsocket478 processors

vSupportsIntel®Celeron ®socket478 (Willamette/Northwood)processors

vSupportsFSBat400MHz/533MHz

vOverclock to800MHz

Memory:

vTwo184-pinDIMMslots

vSupports266/333/400MHzSingleChannelDDRDRAMinterface

vSupports128/256/512/1024Mbmemorytechnologyup to2.0GB

vSupportsunbuffered non-ECC RAM

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Youcan clearCMOStorestoredefaultsystemsetting.TocleartheCMOS,follow

theprocedures described below.

1.Turnoff the systemandunplugthe ACpower.

2.RemoveATXpowercablefromPWR1connector.

3. Short pins 1and2onthisjumper.

4. Returnthe jumpertothenormalsetting bylockingpins 2and3togetherwith

thejumpercap.

5. Turnthesystemon. TheBIOSisreturnedtothedefaultsettings.

2. CPUModel SelectionJumper:J2

J2 isOPEN atdefault, whichsupportsthePrescottandNorthwoodCPU. IfJ2is

setasSHORT,it supportsthe WillametteCPU.

1. ClearCMOSJumper:CLS_CMOS

CLS_CMOS

ClearCMOS

Normal

(default)

SHORT

OPEN

(Default)

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Plug theCPU cooling fancableintothe3-pinCPUFANpowersupplyon the

motherboard.Connectthe casecoolingfan connectortoFAN1.

4.FrontAudioConnector

The audiointerface provides twokindsof audiooutputchoices:the FrontAudio,

the RearAudio.Theirpriorityissequencedfromhightolow(FrontAudiotoRear

Audio). Ifheadphones arepluggedintothefront panelof thechassis(usingthe

FrontAudio), then theLine-out (RearAudio)onthe rearpanelwill notwork. If you

do notwanttouse theFrontAudio, pin5and6,pin9and10mustbe SHORT,and

thenthesignalwill besenttotherearaudioport.

3. CPUFAN &FAN1

FAN1

SENSE

+12V

GND

CPUFAN

GND

+12V

SENSE

F_AUDIO

MIC_IN MIC_GND

MIC_PWR +5VA

AUD_OUT_R AUD_RET_R

AUD_OUT_L AUD_RET_L

910

EmptyNC

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

CD_INisSonystandardCDaudioconnector, itcanbeconnected toaCD-ROM

drive through aCD audiocable.

5. CD_INConnector

Attach the power LED,IDE LED,resetswitchandpowerswitchconnectorstothe

corresponding pins.

6. FrontPanel Connector

FP1

PWR-LED

HDD_LED

PWRSW

- +

RESET NC

- +

CD_IN

CD_R

GND

CD_L

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Thespeaker connectorisusedtoconnectthespeakerof thechassis.

7. SpeakerConnector

TheSPDIFoutputconnectoriscapableofprovidingdigitalaudiotoexternal

speakers, orcompressed AC3datatoanexternalDolbydigitaldecoder.

8.SPDIFOutConnector(optional)

SPDIF_OUT

GND

+5V

EMPTY

SPDIF_OUT

SPEAKER

+5V1

SPKJ

EMPTY

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

The F-USB1/2connectorsareavailableforadditional USBportsif theUSBports

ontherearpanelareinadequate. Compared totraditionalUSB1.1withthespeed

of 12Mb/s, USB2.0has afancyspeedup to480Mb/s, whichallowsfasterInternet

connection,interactivegaming,andsimultaneous runningofhigh-speed

peripherals.

9. USB2.0Connectors

F_USB1/2

D0+

D0-

Empty

GND

VCC VCC

GND

D1-

D1+

Warning:

Beforeinstalling the USB cables, please pay attention tothemarker of

eachindividualUSB cable; make suretomatch themwitheachUSB pin

headerscorrectly,otherwise theUSB portswill notwork.Incorrect

connectioncouldalsodamagethemotherboard.

PDF 件使用 "pdfFactory" 试用版本创建 ³ ³www.fineprint.com.cn

11. 6-channelAudioEffects

ThemotherboardisequippedwiththeCODEC ALC655 chip,which provides supp-

ortfor6-channelaudiooutput,including2front,2rear, 1centerand1subwoofer

channel. ALC655allowsthe boardtoattach4or6speakersforabetter surround

sound effect. Toapplythisfunction,you havetoinstallthe audiodriverinutilityCDas

wellas an audioapplication supporting 6-channel.Theillustration belowrepre-

sentsthestandardlocation ofallspeakersin6-channelsoundtrack. Connectthefront

speakertothegreen audiooutput; connectthesurround sound speakertotheblue

audiooutput and connectthecenter speaker/subwoofertotheredmicrophoneoutput.

Thisheadersupportswireless transmitting and receiving devices.Beforeusing

thisfunction,Configurethe settings ofIRmodefromthe “Integrated Peripherals”

sectionof theCMOSSetupUtility.

+5V

GND

IRRX

IRTX

Empty

10.IrDAConnector(optional)

Blue

FrontLeft Front Right

RearLeft RearRight

Subwoofer

Center

Green

Red

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Thismotherboardcomeswithone UtilityCD. Tobeginusingthe CD, simplyinsert

the CDdiscintotheCD-ROM drive.The CDwill automaticallybringupthemain

menuscreen. Click “Install Driver”, thenclickthe relevantbuttonstoinstall the IDE

Driver,AGPDriver,VGADriver,DirectX9.0b, USB2.0Driver,AudioDriverandLAN

Driver fromthisCD.

Follow thescreen

ordertoinstallthe

motherboarddrivers

13.Foxconn UtilityCD

Afteryoufinishthesetting of jumpersandconnectcorrect cables,poweron the

systemand press <Del>duringPOST(PowerOnSelf Test) toenterthe BIOSSetup

Utility.Choose “Load Optimized Defaults”forrecommendedoptimalperformance.

12.PoweronandLoadOptimizedDefaults

Select this option

andpress<Enter>.

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn
