D270S/D250S/D255/D255-S

Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.1 for D270S/D250S/D255/D255-S motherboard.

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

CAUTION

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard D270S/D250S/D255/D255-S

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio

disturbance characteristics of information technology

equipment

■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current

<= 16A

■ EN 55024/A2:2003 Information technology equipment-Immunity

characteristics limits and methods of measurement

Signature : Place / Date : TAIPEI/2011

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name: D270S/D250S/D255/D255-S

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2011

Installation Precautions

Please carefully read the following procedures to install your computer :

■ It is suggested to select high-quality, certied fans in order to avoid damage

to the motherboard and CPU due to high temperature. Never turn on the

computer if the CPU fan is not properly installed.

■ We cannot guarantee that your system can operate normally when your

CPU/Memory is overclocked. Normal operation depends on the overclocking

capacity of your device.

■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure

their pinouts are matching with the connectors on the motherboard. Incorrect

connections might damage the motherboard.

■ When handling the motherboard, avoid touching any metal leads or connec-

tors.

■ If there is a PCI Express x16 graphics card installed in your system, we

recommend using a 24-pin ATX power supply to get the best performance.

■ Before turning on the power, please make sure the power supply AC input

voltage setting has been congured to the local standard.

■ To prevent damage to the motherboard, do not allow screws to come in contact

with the motherboard circuit or its components. Also, make sure there are no

leftover screws or metal components placed on the motherboard or within the

computer casing.

■ If you are uncertain about any installation steps or have a problem related to

the use of the product, please consult a certied computer technician.

CAUTION

■ Electrostatic discharge (ESD) is the sudden and momentary electric current

that ows between two objects at different electrical potentials. Normally it

comes out as a spark which will quickly damage your electronic equipment.

Please wear an electrostatic discharge (ESD) wrist strap when handling

components such as a motherboard, CPU or memory.

■ Ensure that the DC power supply is turned off before installing or removing

CPU, memory, expansion cards or other peripherals. It is recommended to

unplug the AC power cord from the power supply outlet. Failure to unplug

the power supply cord may result in serious damage to your system.

TABLE OF CONTENTS

Chapter 1 Product Introduction

Product Specications.................................................................. 2

Layout...........................................................................................4

Back Panel Connectors................................................................ 5

Chapter 2 Installation

Install the Memory ........................................................................ 8

Install other Internal Connectors .................................................. 9

Jumpers......................................................................................13

Install Driver and Utility...............................................................14

Chapter 3 BIOS Setup

Enter BIOS Setup....................................................................... 15

Main ...........................................................................................16

F-Center....................................................................................... 17

Advanced ...................................................................................21

Boot ............................................................................................27

Power ........................................................................................28

Health ........................................................................................29

Security ......................................................................................31

Save & Exit ...............................................................................32

Chapter 4 CD Instruction

Utility CD content........................................................................35

Install driver and utility................................................................ 36

FOX ONE

Main Page............................................................................. 37

CPU Control.......................................................................... 42

Frequency Control ................................................................45

Limit Setting ..........................................................................46

Voltage Control .....................................................................47

Fan Control............................................................................48

FOX LiveUpdate

Local Update......................................................................... 51

Online Update .......................................................................53

Congure ............................................................................. 55

About & Help......................................................................... 57

FOX LOGO.................................................................................58

FOX DMI/Smart Charger............................................................ 59

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnsupport.com/inquiry.aspx

CPU Support List :

http://www.foxconnsupport.com/cpusupportlist.aspx

Memory, VGA Compatibility List :

http://www.foxconnsupport.com/complist.aspx

Support

Thank you for buying Foxconn D270S/D250S/D255/D255-S

motherboard. Foxconn products are engineered to maximize

computing power, providing only what you need for break-through

performance.

D270S/D250S/D255/D255-S enables you to unleash more power

from your computer.

This chapter includes the following information:

■ Product Specications

■ Layout

■ Back Panel Connectors

1-1 Product Specications

CPU

Support

Cedarview-D,Dual core CPU processor D2700&D2500&D2550,

Max processor power up to 10W

For the latest CPU information,

please visit:

http://www.foxconnsupport.com/cpusupportlist.aspx

Chipset Tigerpoint - NM10

Memory

2 x SO-DIMM DDR3 SDRAM

Support up to 4GB of system memory

DDR3 1066 MHz architecture

Expansion Slots 1 x PCI slot

Storage 2 x SATAII

LAN

Realtek 8111E Gbe LAN chip

Audio Realtek ALC662 Audio chip

- High Denition Audio

-2/4/5.1-channel

- Support Jack-Sensing function

USB Support up to 8 x USB ports (2 USB 2.0+ 2 USB 3.0 rear panel ports,

2 onboard USB headers providing 4 extra ports) (D270S/D255-S)

Support up to 8 x USB 2.0 ports (4 rear panel ports,

2 onboard USB headers providing 4 extra ports) (D250S/D255)

Support USB 2.0 protocol up to 480Mb/s

Support USB 3.0 protocol up to 5Gb/s.

Internal Connectors

1 x 24-pin ATX main power connector

1 x 4-pin ATX 12V power connector

2 x SATAII

connectors

2 x USB 2.0 header (supporting 4 x USB devices)

1 x CPU fan header (4-pin)

1 x System fan header (4-pin)

1 x Front panel header

1 x Front audio header

1 x Speaker header

1 x Clear CMOS

header

1 x TPM/TCM header

1 x IR/CIR header

1 x Intrusion Alarm header

(Continued on the next page)

Back Panel

Connectors

1 x PS/2 Keyboard port

1 x PS/2 mouse port

1 x RJ-45 LAN port

1 x COM1 port

1 x VGA port

1 x HDMI port

2 x USB 2.0 + 2 x USB 3.0 port

(D270S/D255-S)

4 x USB 2.0 port

(D250S/D255)

3 ports audio jacks

Hardware Monitor

System voltage detection

CPU/System temperature detection

CPU/System fan speed detection

CPU overheating warning

CPU/System fan speed control

Green Function

Support ACPI (Advanced Conguration and Power Interface)

Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),

S4 (suspend to disk), S5 (soft - off)

Support EuP function

Bundled Software

FOX ONE, FOX LiveUpdate, FOX LOGO, FOX DMI,Smart Charger

Operating System

Support for Microsoft® Windows® 7/Vista

Form Factor

Mini-ITX Form Factor, 6.7 inches x 6.7 inches (17 cm x 17 cm)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Foxconn Carte mère

Foxconn

Foxconn M61PMP-K Manuel utilisateur

Foxconn

Foxconn Renaissance Manuel utilisateur

Foxconn

Foxconn A76ML-K 3.0 Manuel utilisateur

Foxconn

Foxconn H55MX-S Series Manuel utilisateur

Foxconn

Foxconn A88GMX Series Manuel utilisateur

Foxconn

Foxconn Renaissance II Manuel utilisateur

Foxconn

Foxconn 760GXK8MB series Manuel utilisateur

Foxconn

Foxconn 661FX7MJ Series Manuel utilisateur

Foxconn

Foxconn Z75A-S Manuel utilisateur

Foxconn

Foxconn P4M8907MA Manuel utilisateur

Foxconn

Foxconn 720AX Manuel utilisateur

Foxconn

Foxconn 915PL7AE series Manuel utilisateur

Foxconn

Foxconn P31A-S Manuel utilisateur

Foxconn

Foxconn 661GX7MJ Series Manuel utilisateur

Foxconn

Foxconn A85GM Series Manuel utilisateur

Foxconn

Foxconn Z68A-S Series Manuel utilisateur

Foxconn

Foxconn P4M8907SA Manuel utilisateur

Foxconn

Foxconn A7GMX-K Manuel utilisateur

Foxconn

Foxconn K8S755A series Manuel utilisateur

Foxconn

Foxconn 945G7ME Instructions d'utilisation

Foxconn

Foxconn G31AX-K Manuel utilisateur

Foxconn

Foxconn T20-H3 Manuel utilisateur

Foxconn

Foxconn G31 MX series Instructions d'utilisation d'origine

Foxconn

Foxconn 600A01 series Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
