ROMED8-2T

User Manual

Version 1.0

Published February 2020

Version 1.0 (MB R1.0X)

Published August 2020

No part of this documentation may be reproduced, transcribed, transmitted, or translated

in any language, in any form or by any means, except duplication of documentation by the

purchaser for backup purpose, without written consent of ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not be

registered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock Rack. ASRock Rack assumes no responsibility

for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to the implied

warranties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for loss of

prots, loss of business, loss of data, interruption of business and the like), even if ASRock

Rack has been advised of the possibility of such damages arising from any defect or error

in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re

welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact

your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 7

1.5 Onboard LED Indicators 10

1.6 I/O Panel 12

1.7 Block Diagram 14

Chapter 2 Installation 15

2.1 Screw Holes 15

2.2 Pre-installation Precautions 16

2.3 Installing the CPU 17

2.4 Installation of Memory Modules (DIMM) 21

2.5 Expansion Slots (PCI Express Slots) 23

2.6 Jumper Setup 24

2.7 Onboard Headers and Connectors 26

2.8 Dr. Debug 32

2.9 Unit Identication purpose LED/Switch 38

2.10 Driver Installation Guide 38

2.11 M.2_SSD (NGFF) Module Installation Guide 39

Chapter 3 UEFI Setup Utility 41

3.1 Introduction 41

3.1.1 UEFI Menu Bar 41

3.1.2 Navigation Keys 42

3.2 Main Screen 43

3.3 Advanced Screen 44

3.3.1 CPU Conguration 45

3.3.2 Chipset Conguration 46

3.3.3 Storage Conguration 49

3.3.4 ACPI Conguration 50

3.3.5 USB Conguration 51

3.3.6 Super IO Conguration 52

3.3.7 Serial Port Console Redirection 53

3.3.8 H/W Monitor 56

3.3.9 AMD CBS 58

3.3.10 AMD PBS 59

3.3.11 PSP Firmware Versions 60

3.3.12 Instant Flash 61

3.4 Server Mgmt 62

3.4.1 System Event Log 63

3.4.2 BMC Network Conguration 64

3.4.2 BMC Tools 66

3.5 Security 67

3.5.1 Key Management 68

3.6 Boot Screen 71

3.6.1 CSM Parameters 73

3.7 Event Logs 75

3.8 Exit Screen 77

Chapter 4 Software Support 78

4.1 Install Operating System 78

4.2 Support CD Information 78

4.2.1 Running The Support CD 78

4.2.2 Drivers Menu 78

4.2.3 Utilities Menu 78

4.2.4 Contact Information 78

Chapter 5 Troubleshooting 79

5.1 Troubleshooting Procedures 79

5.2 Technical Support Procedures 81

5.3 Returning Merchandise for Service 81

ROMED8-2T

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack ROMED8-2T motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

• ASRock Rack ROMED8-2T Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

• Quick Installation Guide

• 1 x I/O Shield

• 2 x Mini SAS HD to 4*SATA Cables (60cm)

• 2 x Screws for M.2 Sockets

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

2 3

English

1.2 Specications

ROMED8-2T

MB Physical Status

Form Factor ATX

Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)

Processor System

CPU AMD EPYC™ 7002/7001 Series Processor Family

Socket Single Socket SP3 (LGA4094)

Chipset N/A

System Memory

Type - Eight Channel DDR4 memory technology

- Supports DDR4 RDIMM, LRDIMM, and NVDIMM (Jump

Option)

DIMM Size Per

DIMM

- RDIMM: 64GB*, 32GB, 16GB, 8GB

- LRDIMM: 128GB**, 64GB*, 32GB

- NV DIMM: 32GB***

*64GB: wait for the device to be validated

**128GB: wait for the device to be validated

***Wait for the device to be validated

DIMM Frequency - RDIMM: 3200MHz

- LRDIMM: 3200MHz

- NVDIMM: 2666MHz*

*Wait for the device to be validated

Voltage 1.2V

Expansion Slot

PCIe 4.0 x 16 PCIE1: Gen4 x16 link

PCIE2: Gen4 x16 link (shared with M2_1/OCU1/OCU2/

SATA_4_7 by PE8_SEL/PE16_SEL jumpers)

PCIE3: Gen4 x16 link

PCIE4: Gen4 x16 link

PCIE5: Gen4 x16 link

PCIE6: Gen4 x16 link

PCIE7: Gen4 x16 link

Storage

SATA Controller 9 x SATA3 6.0 Gb/s (from 2x mini SAS HD and 1x SATA DOM

port)

M.2 Slot 2(2230/2242/2260/2280/22110, SATA/PCIE(X4))

Ethernet

Interface 10000/1000 /100 /10 Mbps by Intel X550

ROMED8-2T

2 3

English

LAN Controller - 2 x RJ45 10G base-T by Intel® X550

- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

- LAN1 supports NCSI

Management

BMC Controller ASPEED AST2500

IPMI Dedicated

GLAN

1 x Realtek RTL8211E for dedicated management GLAN

Features Watch Dog

NMI

Graphics

Controller ASPEED AST2500

Rear Panel I/O

VGA Port 1 x D-Sub

Serial port 1 x COM port

USB 3.1 Gen1 Port 2

USB 3.1 Gen2 Port 1 (typeC)

LAN Port - 2+1 RJ45 Gigabit Ethernet LAN port

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

UID 1

Internal Connector

Auxiliary Panel

Header

1 (includes chassis intrusion, location button & LED, and front

LAN LED)

TPM Header 1

TPM-SPI Header 1

IPMB Header 1

Fan Header 7 Fans x 6-pin

ATX Power 1 x (24-pin) + 1 x (8-pin) + 1 x (4-pin) + 1 x (6-pin)(6 pin for

GPU for PCIE Slot)

USB 3.1 Gen1

Header

1 (supports 2 USB 3.1 Gen1 ports)

USB 3.1 Gen2 Type

C Header

1 (supports 2 USB 3.1 Gen2 ports)

M.2 2(M2_1: 2230/2242/2260/2280, SATA/PCIE(X4);

M2_2:2230/2242/2260/2280/22110, SATA/PCIE(X4))

SATA DOM 1

OCulink 2

BMC SMB 1

PSU SMB 1
