Foxconn D250S Manuel utilisateur
D270S/D250S
Motherboard
User’s Manual
Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for D270S/D250S motherboard.D270S/D250S motherboard.motherboard.
Symbol description:
Caution : refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning : indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard D270S/D250S
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current
<= 16A
■ EN 55024/A2:2003 Information technology equipment-Immunity
characteristics limits and methods of measurement
Signature : Place / Date : TAIPEI/2011
Printed Name : James Liang
Declaration of conformity
Trade Name: FOXCONN
Model Name: D270S/D250S
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2011
Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU/Memory is overclocked. Normal operation depends on the overclocking
capacity of your device.
■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or
S/PDIF cables to the internal connectors on the motherboard, make sure
their pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!
TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications.................................................................. 2
Layout...........................................................................................4
Back Panel Connectors................................................................ 5
Chapter 2 Installation
Install the Memory ........................................................................ 8
Install other Internal Connectors .................................................. 9
Jumpers......................................................................................13
Install Driver and Utility...............................................................14
Chapter 3 BIOS Setup
Enter BIOS Setup....................................................................... 15
Main ...........................................................................................16
F-Center....................................................................................... 17
Advanced ...................................................................................21
Boot ............................................................................................27
Power ........................................................................................28
Health ........................................................................................29
Security ......................................................................................31
Save & ExitSave & Exit ...............................................................................32
Chapter 4 CD Instruction
Utility CD content........................................................................35
Install driver and utility................................................................ 36
FOX ONE
Main Page............................................................................. 37
CPU Control.......................................................................... 42
Frequency Control ................................................................45
Limit Setting ..........................................................................46
Voltage Control .....................................................................47
Fan Control............................................................................48
FOX LiveUpdate
Local Update......................................................................... 51
Online Update .......................................................................53
Congure ............................................................................. 55
About & Help......................................................................... 57
FOX LOGO.................................................................................58
FOX DMI/Smart Charger............................................................ 59
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnsupport.com/inquiry.aspx
CPU Support List :
http://www.foxconnsupport.com/cpusupportlist.aspx
Memory, VGA Compatibility List :
http://www.foxconnsupport.com/complist.aspx
Support
Thank you for buying Foxconn D270S/D250S motherboard. FoxconnD270S/D250S motherboard. Foxconnmotherboard. Foxconn
products are engineered to maximize computing power, providing only
what you need for break-through performance.
D270S/D250S enables you to unleash more power from yourenables you to unleash more power from your
computer.
This chapter includes the following information:
■ Product Specications
■ Layout
■ Back Panel Connectors
2
1
1-1 Product Specications
CPU
Support
Cedarview-D,Dual core CPU processor D2700&D2500,
Max processor power up to 10W
For the latest CPU information,
please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Tigerpoint - NM10
Memory
2 x SO-DIMM DDR3 SDRAM
Support up to 4GB of system memory
DDR3 1066 MHz architecture
Expansion Slots 1 x PCI slot
Storage 2 x SATAII
LAN
Realtek 8111E Gbe LAN chip8111E Gbe LAN chip
Audio Realtek ALC662 Audio chip
:
- High Denition Audio
-2/4/5.1-channel
- Support Jack-Sensing function
USB Support up to 8 x USB ports (2 USB 2.0+ 2 USB 3.0 rear panel ports,
2 onboard USB headers providing 4 extra ports) (D270S)
Support up to 8 x USB 2.0 ports (4 rear panel ports,
2 onboard USB headers providing 4 extra ports) (D250S)
Support USB 2.0 protocol up to 480Mb/s
Support USB 3.0 protocol up to 5Gbps.
Internal Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATAII
connectors
2 x USB 2.0 header (supporting 4 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel header
1 x Front audio header
1 x Speaker header
1 x Clear CMOS
header
1 x TPM/TCM header
1 x IR/CIR header
1 x Intrusion Alarm header
(Continued on the next page)
3
1
Back Panel
Connectors
1 x PS/2 Keyboard port
1 x PS/2 mouse port
1 x RJ-45 LAN port
1 x COM1 port
1 x VGA port
1 x HDMI port
2 x USB 2.0 + 2 x USB 3.0 port
(D270S)
4 x USB 2.0 port
(D250S)
3 ports audio jacks
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
Green Function
Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4 (suspend to disk), S5 (soft - off)
Support EuP function
Bundled Software
FOX ONE, FOX LiveUpdate, FOX LOGO, FOX DMI,Smart Charger
Operating System
Support for Microsoft® Windows® 7/Vista
Form Factor
Mini-ITX Form Factor, 6.7 inches x 6.7 inches (17 cm x 17 cm)
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Foxconn Carte mère
Foxconn
Foxconn H61A Series Manuel utilisateur
Foxconn
Foxconn A88GMX Series Manuel utilisateur
Foxconn
Foxconn Z75M-S Series Manuel utilisateur
Foxconn
Foxconn A74ML Series Manuel utilisateur
Foxconn
Foxconn G41MD Manuel utilisateur
Foxconn
Foxconn Q45M Series Manuel utilisateur
Foxconn
Foxconn 45CMX Manuel utilisateur
Foxconn
Foxconn 45CTD Instructions d'utilisation d'origine
Foxconn
Foxconn H61MX Series Manuel utilisateur
Foxconn
Foxconn M61PMV Series Manuel utilisateur
Foxconn
Foxconn Bloodrage Manuel utilisateur
Foxconn
Foxconn P31A-G Manuel utilisateur
Foxconn
Foxconn G31MX 2.0 Series Manuel utilisateur
Foxconn
Foxconn Inferno Katana Manuel utilisateur
Foxconn
Foxconn 845GV4MR-ES Fiche technique
Foxconn
Foxconn Q57M Series Manuel utilisateur
Foxconn
Foxconn K8M890M2MA Manuel utilisateur
Foxconn
Foxconn A76ML-K 3.0 Manuel utilisateur
Foxconn
Foxconn H61MD Series Manuel utilisateur
Foxconn
Foxconn 760GXK8MC Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
