MARS Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.2 for MARS Series motherboard.

P/N: 3A2216E00-000-G

Symbol description:

Caution: refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning: indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste.Byensuringthisproductisdisposedof correctly, you will helppreventpotential

negativeconsequencesfortheenvironmentandhumanhealth,whichcouldotherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

CAUTION

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard MARS

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio

disturbance characteristics of information technology

equipment

■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current <=

16A

■ EN 55024/A2:2003 Information technology equipment-Immunity characteristics

limits and methods of measurement

Signature : Place / Date : TAIPEI/2008

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name: MARS

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2008

Installation Precautions

Please carefully read the following procedures to install your computer :

■ It is suggested to select high-quality, certied fans in order to avoid damage

to the motherboard and CPU due to high temperature. Never turn on the

computer if the CPU fan is not properly installed.

■ We cannot guarantee that your system can operate normally when your

CPU is overclocked. Normal operation depends on the overclocking capac-

ity of your device.

■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure

their pinouts are matching with the connectors on the motherboard. Incorrect

connections might damage the motherboard.

■ When handling the motherboard, avoid touching any metal leads or connec-

tors.

■ If there is a PCI Express x16 graphics card installed in your system, we

recommend using a 24-pin ATX power supply to get the best performance.

■ Before turning on the power, please make sure the power supply AC input

voltage setting has been congured to the local standard.

■ Toprevent damage to themotherboard,do notallowscrews to comein contact

with the motherboard circuit or its components. Also, make sure there are no

leftover screws or metal components placed on the motherboard or within the

computer casing.

■ If you are uncertain about any installation steps or have a problem related to

the use of the product, please consult a certied computer technician.

CAUTION

■ Electrostatic discharge (ESD) is the sudden and momentary electric current

that ows between two objects at different electrical potentials. Normally it

comes out as a spark which will quickly damage your electronic equipment.

Please wear an electrostatic discharge (ESD) wrist strap when handling

components such as a motherboard, CPU or memory.

■ Ensure that the DC power supply is turned off before installing or removing

CPU, memory, expansion cards or other peripherals. It is recommended to

unplug the AC power cord from the power supply outlet. Failure to unplug

the power supply cord may result in serious damage to your system.

TABLE OF CONTENTS

Chapter 1 Product Introduction

Package List......................................................................................2

Product Specications.......................................................................3

Layout ...............................................................................................5

Back Panel Connectors.....................................................................6

Chapter 2 Hardware Install

Install the CPU and CPU Cooler.......................................................9

Install the Memory...........................................................................12

Install an Expansion Card...............................................................14

Install other Internal Connectors.....................................................15

Jumpers ..........................................................................................19

Onboard Button...............................................................................20

Onboard LED..................................................................................20

Chapter 3 BIOS Setup

Enter BIOS Setup............................................................................22

Main Menu ......................................................................................22

Standard CMOS Features...............................................................24

Advanced BIOS Features ...............................................................26

Advanced Chipset Features............................................................28

Integrated Peripherals.....................................................................29

Power Management Setup..............................................................33

PnP/PCI Congurations ..................................................................36

PC Health Status.............................................................................37

Gladiator BIOS ...............................................................................38

Load Fail-Safe Defaults...................................................................44

Load Optimized Defaults................................................................44

Set Supervisor Password................................................................44

Set User Password .........................................................................44

Save & Exit Setup...........................................................................44

Exit Without Saving.........................................................................44

Chapter 4 CD Instruction

Utility CD Introduction .....................................................................46

AEGIS PANEL

Main Panel .................................................................................49

Overclocking...............................................................................50

HWM INFO.................................................................................51

ALARM.......................................................................................52

CONFIG .....................................................................................53

FOX LiveUpdate

Local Update ..............................................................................54

Online Update ............................................................................56

Congure ...................................................................................59

About & Help ..............................................................................61

Chapter 5 RAID Conguration

RAID Conguration Introduction .....................................................64

Intel®Matrix Storage Manager........................................................66

Create a RAID Driver Diskette........................................................67

BIOS Conguration .........................................................................69

Create RAID in BIOS ......................................................................69

Create RAID Volume..................................................................70

Delete RAID Volume ..................................................................86

Reset Disks to Non-RAID...........................................................88

Exit RAID BIOS ..........................................................................92

Install a New Windows XP..............................................................93

Existing Windows XP with RAID built as data storage....................97

Appendix - CrossFileTM Technology................................................101

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnchannel.com/support/online.aspx

CPU, Memory, VGA Compatibility Supporting Website :

http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx

Support

ThankyouforbuyingFoxconnQuantumForceseriesmotherboard-

MARS. Foxconn Quantum Force products are engineered to

maximize computing power, providing only what you need for

break-through performance.

With advanced overclocking capability and a range of connectivity

features for today multi-media computing requirements, MARS

enables you to unleash more power from your computer.

This chapter includes the following information:

■ Package List

■ Product Specications

■ Layout

■ Back Panel Connectors

Package List

Check your product package for the following items:

Before your purchase, if any of the above items is damaged or missing, please contact

your retailer. Accessories are not in the warranty, only motherboard is.

CAUTION

Motherboard Foxconn MARS motherboard

I/O modules 1 x USB 2.0 x 2 ports and 1 x 1394a module

Cables 4 x SATA Power and Signal cables

2 x SATA Power and Signal cables right angle

1 x Ultra DMA 133/100/66 cable

1 x Floppy Disk Drive cable

Accessory I/O Shield

1 x Foxconn Optional Fan

Application CD Foxconn motherboard support CD

Documentation User’s Manual

Easy Guide

Registration Card

Quantum Force stickers

Quantum Force tattoos

Quantum Force Dogtags

1-1 Product Specications

CPU Support LGA775 socket Intel®CPU:

CoreTM 2 Extreme / CoreTM 2 Quad / CoreTM 2 Duo

Pentium® 4 Extreme Edition / Pentium®D / Pentium® 4 processors

Future-proof supporting for 45nm processors

Support Intel®Hyper-Threading Technology

Front Side Bus 1333/1066/800 MHz FSB

Chipset North Bridge: Intel® P35 chipset

South Bridge: Intel®ICH9R

Memory 4 x 240-pin DDR2 DIMM sockets

Support up to 8GB of system memory

Dual channel DDR2 1066(oc*)/800/667MHz architecture

(oc*: Overclocking)

Audio Realtek ALC888 chip

High Denition Audio

2/4/5.1/7.1-channel

Support for S/PDIF out

Support Jack-Sensin function

LAN On board Realtek 8111B chip

Support 10/100/1000 Mb/s Ethernet

Expansion Slots 2 x PCI Express x16 slots(1 x PCI-E x16 mode, 1 x PCI-E x4 mode)

2 x PCI Express x1 slots

3 x PCI slots

Onboard Serial ATA 6 x SATA connectors

1 x External SATA connector

300MB/s data transfer rate

Support hot plug and NCQ (Native Command Queuing )

Support RAID 0, RAID 1, RAID 5, RAID 10

Support Intel®Matrix Storage Technology

USB Support hot plug

Support up to 12 USB 2.0 ports (6 rear panel ports, 3 onboard USB

connectors providing 6 extra ports)

Supports USB 2.0 protocol up to 480Mb/s

Internal Connectors 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x AUX Power connector

1 x Floppy disk drive connector

1 x IDE connector

6 x SATA connectors

3 x USB 2.0 connectors (supporting 6 x USB devices)

1 x CPU fan header (4-pin)

1 x System fan header (3-pin)

1 x NB fan header (3-pin)

2 x Power fan headers (3-pin)(FAN1, FAN2)

1 x Front panel connector

Table des matières

Autres manuels Foxconn Carte mère

Foxconn

Foxconn A88GMX Series Manuel utilisateur

Foxconn

Foxconn H67S Series Manuel utilisateur

Foxconn

Foxconn P43A Series Manuel utilisateur

Foxconn

Foxconn 760GXK8MC Manuel utilisateur

Foxconn

Foxconn A6GMV Series Manuel utilisateur

Foxconn

Foxconn P9657AA Manuel utilisateur

Foxconn

Foxconn A76ML-K 3.0 Manuel utilisateur

Foxconn

Foxconn G31AX-K Manuel utilisateur

Foxconn

Foxconn H61MXL Series Manuel utilisateur

Foxconn

Foxconn 755FXK8AA series Manuel utilisateur

Foxconn

Foxconn M61PMP-K Manuel utilisateur

Foxconn

Foxconn D250S Manuel utilisateur

Foxconn

Foxconn 720MX-K Manuel utilisateur

Foxconn

Foxconn K8T890M2AB Instructions d'utilisation

Foxconn

Foxconn Rattler Manuel utilisateur

Foxconn

Foxconn 45CMV series Manuel utilisateur

Foxconn

Foxconn BLACKOPS Manuel utilisateur

Foxconn

Foxconn Q77M Series Manuel utilisateur

Foxconn

Foxconn WinFast 748K7AA Manuel utilisateur

Foxconn

Foxconn WinFast 6150K8M Series Manuel utilisateur

Foxconn

Foxconn P55A Manuel utilisateur

Foxconn

Foxconn G31S Guide de l'utilisateur

Foxconn

Foxconn 848P7MB Manuel utilisateur

Foxconn

Foxconn G41MD Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
