Foxconn 955X7AA series Manuel utilisateur
This manual is the intellectual property of FOXCONN, Inc. Although the
information in this manual may be changed or modified at any time,
Foxconn does not obligate itself to inform the user of these changes.
Statement:
All trademarks are the property of their respective owners.
User’s Manual V1.1 in English for 955X7AA series motherboard.
P/N: 91-181-955-A1-1E
Symbol description:
Note: refers to important information that can help you to use motherboard
better.
Attention: indicates that it may damage hardware or cause data loss,
and tells you how to avoid such problems.
Warning: means that a potential risk of property damage or physical
injury exists.
More information:
If you want more information about our products, please visit FOXCONN
website: www.foxconnchannel.com
Version:
Trademark:
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard
955X7AA series
is in conformity with
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
EN 55022: 1998/A2: 2003 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
EN 61000-3-2: 2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage fluctuations and flicker in low-voltage
supply systems for equipment with rated current <= 16A
EN 55024: 1998/A2: 2003 Information technology equipment-Immunity characteristics limits
and methods of measurement
Signature : Place / Date : TAIPEI/2005
Printed Name : James Liang Position/ Title : Assistant President
Declaration of conformity
Trade Name: FOXCONN
Model Name: 955X7AA
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classification: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer:HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions : (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Tested to comply with FCC standards.
Signature : Date : 2005
Product Introduction
Installation Instructions
Supply ............................................................................................
BIOS Description
Standard CMOS Features .......................................................................... 34
BIOS Features ...........................................................................................
Advanced BIOS Features ..........................................................................
Advanced Chipset Features ......................................................................
Integrated Peripherals ................................................................................
Power Management Setup .........................................................................
PnP/PCIConfigurations ...............................................................................
PC Health Status ........................................................................................
Load Fail-Safe Defaults .............................................................................
Load Optimized Defaults ............................................................................
Set Supervisor/User Password ................................................................. 60
Save & Exit Setup ......................................................................................
Exit Without Saving ....................................................................................
Table of Contents
Chapter
Chapter
Chapter
Driver CD Introduction
Utility CD content ........................................................................................ 63
Start to install drivers ................................................................................. 64
Install Chipset Software ............................................................................. 64
Install DirectX 9.0 ....................................................................................... 65
Install IAA RAID .......................................................................................... 65
Install ITE RAID ....................................................................................66
Install Silicon Image RAID ..................................................................66
Install Audio Driver (optional) ............................................................... 67
Install LAN Driver (optional).................................................................. 67
Install 1394b Driver .............................................................................68
Install SuperUtility ....................................................................................... 68
Install Adobe Reader .................................................................................. 69
Install Norton Internet Security ................................................................... 69
Install Word Perfect Office 12 .................................................................... 70
Directions for Bundled Software
SuperStep ................................................................................................. 72
SuperLogo ................................................................................................. 75
SuperUpdate .............................................................................................. 77
Special BIOS Functions
SuperBoot ................................................................................................. 83
SuperBIOS-Protect .................................................................................... 84
SuperRecovery ......................................................................................... 85
SuperSpeed ............................................................................................... 94
Appendix
Using 8-channel Audio (optional) ............................................................... 95
Table of Contents
Chapter
Chapter
Chapter
1. Attach the CPU and heatsink using silica gel to ensure full contact.
2. It is suggested to select high-quality, certified fans in order to avoid
damage to the motherboard and CPU due high temperatures.
3. Never turn on the machine if the CPU fan is not properly installed.
4. Ensure that the DC power supply is turned off before inserting or
removing expansion cards or other peripherals, especially when
you insert or remove a memory module. Failure to switch off the DC
power supply may result in serious damage to your system or
memory module.
Warning:
We cannot guarantee that your system will operate normally while
over-clocked. Normal operation depends on the over-clock capacity
of your device.
Warning:
Attention:
Since BIOS programs are upgraded from time to time, the BIOS
description in this manual is just for reference. We do not guarantee
that the content of this manual will remain consistent with the actual
BIOS version at any given time in the future.
Attention:
The pictures of objects used in this manual are just for your reference.
Please refer to the physical motherboard.
This manual is suitable for motherboard of 955X7AA series.
Each motherboard is carefully designed for the PC user who
wants diverse features.
-L with onboard 10/100M LAN
-K with onboard Giga LAN
-6 with 6 channel audio
-8 with 8 channel audio
-E with 1394
-S with SATA
-R with RAID
You can find PPID label on the motherboard. It indicates the
functions that the motherboard has.
For example:
On the blue mark of the PPID label, it means the
motherboard supports 6-Channel Audio(-6), 1394 port(-E),
onboard 10/100M LAN (-L), SATA function(-S).
Chapter
Thank you for buying FOXCONN 955X7AA series motherboard.
This series of motherboard is one of our new products, and
offers superior performance, reliability and quality, at a reason-
able price. This motherboard adopts the advanced Intel® 955X+
ICH7R chipset, providing users a computer platform with a high
integration-compatibility-performance price ratio.
This chapter includes the following information:
Main Features
Motherboard Layout
1
1
Chapter 1 Product Introduction
2955X7AA Series User Manual
Main Features
Size
ATX form factor of 12 inch x 9.6 inch
Microprocessor
Supports Intel® Prescott, Smithfield, Cedar Mill processor in an LGA775
package
Supports FSB at 1066MHz/800MHz
Supports Hyper-Threading technology
Supports FSB Dynamic Bus Inversion (DBI)
Chipset
Intel®955X (North Bridge) + ICH7R (South Bridge)
System Memory
Four 240-pin DIMM slots
Supports single channel or dual channel mode
Supports DDR2 type DIMMs
Supports 256-Mb, 512-Mb, and 1-Gb DRAM densities
supports opportunistic refresh scheme
Supports Performance Acceleration Technology (PAT)
Maxinum DRAM address decode space is 8GB
Registered DIMMs not supported
USB 2.0 Ports
Supports hot plug
Eight USB 2.0 ports (four rear panel ports, two onboard USB connectors
providing four extra ports)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 Protocol up to 480 Mbps transmission rate
Onboard Serial ATA
Serial ATA I Data transfer rates up to 150MB/s
Serial ATA II Data transfer rates up to 300MB/s
Intel ICH7R South Bridge supports 4 x Serial ATA II with RAID 0, RAID 1, RAID
10 (0+1), RAID 5, Matrix RAID
3
955X7AA Series User Manual
Chapter 1 Product Introduction
Silicon Image 3114 RAID controller supports 4 x Serial ATA I with RAID 0,
RAID 1, RAID 5, RAID 10(0+1), JBOD
Onboard IDE
Intel®ICH7R South Bridge supports 1 x Ultra DMA 100/66/33
ITE®8212F IDE RAID controller supports 2 x Ultra DMA 133/100/66 with RAID
0, RAID 1, RAID10 (0+1), JBOD
Onboard LAN (-L/-K) (optional)
One Giga LAN port with PCI Express x1 bus supported by BCM5789
controller
One 10/100M/Giga LAN port with PCI bus supported by BCM4401/BCM5788
controller
Supports 10/100/1000 (-L/-K) Mbit/sec Ethernet
LAN interface built-in on board
Onboard 1394 (-E ) (optional)
Support hot plug
1 x IEEE 1394b connector with rate of transmission at 800 Mbps
2 x IEEE 1394a connectors with rate of transmission at 400 Mbps
Self-configured addressing
Onboard Audio (-8)(optional)
Supports 8-channel audio
Supports SPDIF output
Supports Intel®High Definition Audio
Supports high quality differential CD input
PCI Express x16 Support
Supports 4 GB/sec (8 GB/sec concurrent) bandwidth
Low power consumption and power management features
PCI Express x1 Support
Supports 250 MB/sec (500 MB/sec concurrent) bandwidth
Low power consumption and power management features
Table des matières
Autres manuels Foxconn Carte mère
Foxconn
Foxconn A88GMV Series Manuel utilisateur
Foxconn
Foxconn A690GM2MA Instructions d'utilisation
Foxconn
Foxconn A76ML Series Manuel utilisateur
Foxconn
Foxconn 915G7MC Manuel utilisateur
Foxconn
Foxconn P4M800P7MB Manuel utilisateur
Foxconn
Foxconn M61PMP-K Manuel utilisateur
Foxconn
Foxconn D42S Manuel utilisateur
Foxconn
Foxconn G31MXP-K Manuel utilisateur
Foxconn
Foxconn 6100M2MA series Manuel utilisateur
Foxconn
Foxconn H77MXV Series Manuel utilisateur
Foxconn
Foxconn 45CMX Manuel utilisateur
Foxconn
Foxconn G41MD Manuel utilisateur
Foxconn
Foxconn K7S741GXMG-6L Manuel utilisateur
Foxconn
Foxconn A7GMP-S Manuel utilisateur
Foxconn
Foxconn 661FX4MR-ES Layout Fiche technique
Foxconn
Foxconn 6497MC series Manuel utilisateur
Foxconn
Foxconn ELA Manuel utilisateur
Foxconn
Foxconn H55MXV LE Manuel utilisateur
Foxconn
Foxconn K8S755A series Manuel utilisateur
Foxconn
Foxconn 720MX-K Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
