Foxconn M61PMV Series Manuel utilisateur

M61PMV Series Motherboard

User’s RAID Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s RAID Manual for M61PMV Series motherboard.

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury

may exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could other-

wise be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

CAUTION

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard M61PMV/M61PMV-E

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio

disturbance characteristics of information technology

equipment

■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current

<= 16A

■ EN 55024/A2:2003 Information technology equipment-Immunity

characteristics limits and methods of measurement

Signature : Place / Date : TAIPEI/2008

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name: M61PMV/M61PMV-E

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2008

TABLE OF CONTENTS

Chapter 1 RAID Conguration

RAID Conguration Introduction................................................... 3

NVIDIA® MediaShield Driver .......................................................5

Create two RAID Driver Diskettes ................................................ 7

RAID Enable in BIOS ...................................................................9

Select a RAID Array for Use.........................................................9

Install a New Windows XP..........................................................25

Setting Up a Non-Bootable RAID Array...................................... 32

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide Online Contact Support :

http://www.foxconnchannel.com/support/online.aspx

CPU, Memory, VGA Compatibility Supporting Website :

http://www.foxconnchannel.com/support/online.aspx

Support

This chapter will cover two topics :

■ Creating a Bootable Array - Installing a new Windows XP

(Vista) in a brand new RAID system.

■ Creating a Non-Bootable Array - Existing Windows XP

(Vista) system with new RAID built as data storage.

It includes the following information :

■ RAID Conguration Introduction

■ NVIDIA®MediaShield Driver

■ Create two RAID Driver Diskettes

■ RAID Enable in BIOS

■ Select a RAID Array for Use

■ Install a New Windows XP

■ Setting Up a Non-Bootable RAID Array

The RAID BIOS Setup pictures shown in this chapter are for

reference only, please refer to the practical screen.

Creating a Bootable Array - Installing a new Windows XP (or Vista) in

a brand new RAID system.

1. Follow 5-1 to create two RAID driver diskettes.

2. Follow 5-2 to set RAID enabled in BIOS.

3. Follow 5-3 to select a RAID array for use.

4. Follow 5-4 to Install a new Windows Operating System.

What kinds of hardware and software you need here :

1. A oppy drive.

2. A DVD-ROM drive.

3. Several SATA hard disks.

4. Two RAID driver diskettes. (Can be created by using motherboard driver CD)

5. A motherboard driver CD.

6. Windows XP or Vista Install CD.

Creating a Non-Bootable Array - Existing Windows XP (or Vista)

system with new RAID built as data storage.

Follow 5-5 to go through the processes to build a new RAID array in your existing

Windows XP system, it includes :

1. Set RAID enabled in BIOS.

2. Follow 5-3 to select a RAID array for use.

3. Run setup program to install NVIDIA RAID driver into your current Windows XP

system.

4. Use Administrative Tools in Control Panel to format new RAID array.

What kinds of hardware and software you need here :

1. A DVD-ROM drive.

2. Several SATA hard disks.

3. A motherboard driver CD.

RAID Conguration Introduction

RAID (Redundant Array of Independent Disks) is a method for computer data storage

schemes that divide and/or replicate data among multiple hard drives. RAID can be

designed to provide increased data reliability (fault tolerance) or increased I/O (input/

output) performance, or both. The following RAID congurations are provided for

users.

There are three major key concepts in RAID:

1. Mirroring : The copying of data to more than one disk;

2. Striping : The splitting of data across more than one disk;

3. Error correction : Where redundant data is stored to allow problems to be detected

and possibly xed (known as fault tolerance).

Different RAID levels use one or more of these techniques, depending on the system

requirements. The main aims of using RAID are to improve reliability, important for

protecting information that is critical to a business, for example a database of customer

orders; or where speed is important, for example a system that delivers video on

demand TV programs to many viewers.

The conguration affects reliability and performance in different ways. The problem

with using more disks is that it is more likely that one will go wrong, but by using

error checking the total system can be made more reliable by being able to survive

and repair the failure. Basic mirroring can speed up reading data as a system can

read different data from both the disks, but it may be slow for writing if it insists that

both disks must conrm that the data is correctly written. Striping is often used for

performance, where it allows sequences of data to be read off multiple disks at the

same time. Error checking typically will slow the system down as data needs to be

read from several places and compared. The design of RAID systems is therefore a

compromise and understanding the requirements of a system is important. Modern

disk arrays typically provide the facility to select the appropriate RAID conguration.

RAID is often used in high availability systems, where it is important that the system

keeps running as much of the time as possible.

RAID 0 (Striping)

RAID 0 reads and writes sectors of data interleaved among multiple drives. If any disk

member fails, it affects the entire array. The disk array data capacity is equal to the

number of drive members times the capacity of the smallest member. RAID 0 does

not support fault tolerance.

RAID 1 (Mirroring)

RAID 1 writes duplicate data onto a pair of drives and reads both sets of data in

parallel. If one of the mirrored drives suffers a mechanical failure or does not respond,

the remaining drive will continue to function. Due to redundancy, the drive capacity of

the array is the capacity of the smallest drive.

RAID 5 (Parity)

RAID 5 provides data striping at the byte level and also stripes error correction

information. This results in excellent performance and good fault tolerance. Level 5 is

one of the most popular implementations of RAID.

RAID 0+1 (Stripe Mirroring)

RAID 10 is a combination of striping and mirroring. This conguration provides optimal

speed and reliability, but you need four SATA hard disks.

Spanning (JBOD)

JBOD stands for “Just a Bunch of Disks”. Each drive is accessed as if it was on a

standard SCSI host bus adapter. This is useful when a single drive conguration is

needed, but it offers no speed improvement or fault tolerance. A spanned volume is a

formatted partition which data is stored on more than one hard disk, yet appears as

one volume. Unlike RAID, spanned volumes have no fault-tolerance, so if any disk

fails, the data on the whole volume could be lost. Additionally, the system or boot

partitions cannot be included in a spanned volume. FAT16/32 and NTFS le systems

may be used, and the volume can span up to 32 hard disks.

Comparison Table :

Solution Hard Disks No. Capacity Performance Reliability Application

RAID0 >=2 All Highest Dangerous Look for speed

RAID1 2 50% Read faster Excellent 100% Data backup

RAID5 >=3 N-1 Read faster

Write slower Good Limited budget

RAID0+1 >=4

(Even number) Smallest

*2 High Excellent Unlimited budget

Span >=1 All none Dangerous Big disk space

NVIDIA®MediaShield Driver

The NVIDIA®MediaShield driver supports RAID 0, RAID 1, RAID 5, and RAID 0+1

functions. It allows you to get high performance with fault tolerance, big capacity, or

data safety provided by different RAID functions.

Here, we will use four SATA hard disks as an example to guide you how to select your

RAID system. Assume four hard disks are connected to the motherboard :

SATA port 1 - WDC WD1200JD-98HBBO, 111.79GB

SATA port 2 - Hitachi HDT725025VLA, 232.88GB

SATA port 3 - HDS728080PLA380, 76.69GB

SATA port 4 - ST3320620AS, 298.09GB

The relationships between RAID settings and SATA ports on the motherboard are :

SATA Pri-Master RAID is the SATA port 1 of the motherboard.

SATA Pri-Slave RAID is the SATA port 2.

SATA Sec-Master RAID is the SATA port 3.

SATA Sec-Slave RAID is the SATA port 4.

In section 5-3 later, you will know the relationships between port numbers in the

MediaShield BIOS and SATA ports on the motherboard. We put their descriptions here

for better arrangement. They are :

Port 1.1 is the SATA port 2 of the motherboard.

Port 1.0 is the SATA port 1.

Port 2.1 is the SATA port 4.

Port 2.0 is the SATA port 3.

Phoenix - AwardBIOS CMOS Setup Utility

RAID Cong

RAID Enable [IDE]Item Help

SATA Pri-Master RAID [Enabled]

SATA Pri-Slave RAID [Enabled] Menu Level ►

SATA Sec-Master RAID [Enabled]

SATA Sec-Slave RAID [Enabled]

↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F7: Optimized Defaults

Enabled

Autres manuels pour M61PMV Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Foxconn Carte mère

Foxconn

Foxconn 945GZ Manuel utilisateur

Foxconn

Foxconn G41MX 2.0 Manuel utilisateur

Foxconn

Foxconn 760GXK8MB series Manuel utilisateur

Foxconn

Foxconn P43A Series Manuel utilisateur

Foxconn

Foxconn 845GVME-S Fiche technique

Foxconn

Foxconn 865M01 series Manuel utilisateur

Foxconn

Foxconn NF4K8MC Manuel utilisateur

Foxconn

Foxconn A690GM2MA Instructions d'utilisation

Foxconn

Foxconn Rattler Manuel utilisateur

Foxconn

Foxconn 760GXK8MC Manuel utilisateur

Foxconn

Foxconn IGPSK7MA series Manuel utilisateur

Foxconn

Foxconn D255 Manuel utilisateur

Foxconn

Foxconn Bloodrage Manuel utilisateur

Foxconn

Foxconn H67M Series Manuel utilisateur

Foxconn

Foxconn G41M Series Manuel utilisateur

Foxconn

Foxconn P31A-S Manuel utilisateur

Foxconn

Foxconn K8M890M2MA Manuel utilisateur

Foxconn

Foxconn P55MX Series Manuel utilisateur

Foxconn

Foxconn 45CMX Manuel utilisateur

Foxconn

Foxconn H77M Series Manuel utilisateur

Foxconn

Foxconn 661FXME Fiche technique

Foxconn

Foxconn G31 MX series Instructions d'utilisation d'origine

Foxconn

Foxconn A75M Series Manuel utilisateur

Foxconn

Foxconn A88GMV Series Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
