Flashforge Guider 3 Plus Manuel utilisateur
This guide is only applicable to FLASHFORGE Guider 3 Plus 3D printer
本手册仅适用于闪铸科技引领者 3 Plus打印机
中文P25
用户使用手册
USER GUIDE
EN/CN-A01 Guider 3 Plus 引领者 3 Plus
CONTENT
Notice
Equipment Parameter
1. Equipment Introduction
1.1 - Guider 3 Plus Introduction
1.2 - Packing List
2. Preparation Before Printing
2.1 - Power Connection
2.2 - Filament Loading
2.3 - Equipment Calibration
2.4 - Network Connection
2.4.1 - Wired Network Connection
2.4.2 - Wireless Network Connection
4.1 - File Transfer: Wi-Fi Transfer
4.2 - Printing From a USB Flash Drive
4.3 - Cloud Printing
4.4 - Camera Connection
4.5 - Model Removal After Finishing Printing
5.1 - Printing Screen
5.2 - Filament Screen
5.3 - Preheating Screen
5.4 - Tools Screen
5.5 - Settings Screen
6.1 - Maintenance Screen
6.2 - Extruder Maintenance
6.3 - Platform Flatness Calibration
7. Q&A
3. Software Installation
4. First Printing
5. Equipment Operation Interface Introduction
6. Maintenance
8. Help and Support
05
07
12
19
24
05
06
07
08
10
11
11
11
12
15
22
12
12
13
14
14
15
16
17
17
18
19
19
20
01
NOTICE
SAFETY NOTICE: PLEASE CAREFULLY READ AND STRICTLY FOLLOW
ALL THE SAFETY WARNINGS AND NOTICES BELOW ALL THE TIME.
WORK ENVIRONMENT SAFETY
Please keep the work table of the equipment clean and tidy.
Please ensure that the equipment is away from combustible gases, liquids and
dust when it is in operation. The high temperature generated by equipment operation
may react with combustible gases, liquids, and airborne dust, thus causing fire.
Children and untrained personnel are not allowed to operate the equipment alone.
ELECTRICAL SAFETY
Be sure to ground the equipment. Do not modify the plug of the equipment.
Ungrounded equipment/improperly grounded equipment/modified plug will
inevitably increase the risk of electric leakage.
Do not expose the equipment to damp or hot-sun environment. Humidity will
increase the risk of electric leakage. Exposure to sunlight will accelerate the aging
of plastic parts.
Make sure to only use the power cord provided by Flashforge.
Do not use the equipment during an thunderstorm.
Please shut down the equipment and unplug it if it is not in use for a long time.
PERSONAL SAFETY
Do not touch the extruder, build plate, etc., during printing.
Do not touch the extruder and build plate when finishing printing in order to avoid
high temperature burns or mechanical damage.
Do not wear scarves, masks, gloves, jewelry ornaments or other objects that can
easily get tangled into the equipment when operating it.
Do not operate the equipment while you are tired or under the influence of drugs,
alcohol or medication.
CAUTIONS
Keep the inside of the equipment clean and tidy. Do not drop metal objects into the
sliding chute at the bottom of the build plate.
Please clean up the filament debris in time. It is recommended to operate this outside
the equipment.
Any modification of the equipment by yourself will result in the situation that you will
not be entitled to warranty rights anymore.
Please keep the distance between the extruder and build plate for at least 50mm
during filament loading. Too-close distance may cause nozzle clogging.
02
The room temperature should be between 15℃ and 30℃.
The humidity should be between 20RH% and 70RH%.
Please operate the equipment in a well-ventilated environment.
Do not use the equipment for illegal activities.
Do not use the equipment to make any food storage products.
Do not put the printed model into your mouth.
EQUIPMENT ENVIRONMENT REQUIREMENTS
EQUIPMENT PLACEMENT REQUIREMENTS
COMPATIBLE FILAMENT REQUIREMENTS
FILAMENT STORAGE REQUIREMENTS
LEGAL STATEMENT
The equipment must be placed in a dry and ventilated environment. A distance of
at least 60cm must be reserved around the front, back, left and right sides of the
equipment. The storage temperature should be between 0℃ and 40℃.
When using the equipment, it is recommended to use Flashforge’s filaments.
If non-Flashforge filaments are used, there will be certain differences in material
characteristics, and thus printing parameters may need to be adjusted.
Please store filaments in a dry and dust-free environment after unpacking. It is
recommended to use the matching filament dry box for storage.
The user has no right to make any modification to this user guide.
Flashforge will not be responsible for any safety accidents caused by the disassembly
or modification of the equipment by the customer. No one is allowed to modify or
translate this guide without the permission of Flashforge. This guide is protected by
copyright, and Flashforge reserves the right of the final interpretation of this guide.
First Edition (May 2022)
Copyright © 2022 Zhejiang Flashforge 3D Technology Co., Ltd. All Rights Reserved.
03
Equipment Parameter
Equipment Name
Extruder Quantity
Printing Precision
Positioning Accuracy
Layer Thickness
Build Volume
Nozzle Diameter
Nozzle Type
Printing Speed
Maximum Extruder Temperature
Maximum Platform Temperature
Supported Filament
Power Supply
Slicing Software
Input/Output File Format
Connectivity
Operating Temperature
Compatible Operating System
Compatible Slicing Software
Smart Touch Screen
Build Plate
Net Weight
Equipment Dimensions
Required Space for Installation
Guider 3 Plus
1
± 0.15mm or 0.002 mm/mm [The larger values shall prevail]
X/Y-axis: 0.011mm Z-axis: 0.0025mm
0.05 ~ 0.4mm
350x350x600mm
0.4mm [0.4/0.6/0.8]mm
Stainless steel nozzle
10 ~ 250mm/s
320℃
120℃
PLA/PETG/ASA/ABS/PC/PA/PLA-CF
PETG-CF/PETG-GF/PA-CF/PA-GF
AC100-240V / DC24V / 6.25A, 650W
FlashPrint
Input: 3MF/STL/OBJ/FPP/BMP/PNG / JPG/JPEG；
Output: GX/G / gcode
USB flash drive/Ethernet/Wi-Fi
15 ~ 30℃
Windows XP/Vista/7/8/10、Mac OS
Slic3r, Cura [Need setting]
7-inch
Flexible steel plate platform
70kg
635[L] x 550[W] x 1070[H] mm [Excluding the
protruding width of the filament box]
≥1330*1330*1352mm
04
1. Equipment Introduction
Guider 3 Plus Introduction
1. Upper Cover 2. Extruder
3. Screen Switch 4. USB Port
5. Front Door 6. Flexible Steel Plate
7. Platform Plate 8. Handle 9. Air Filter
10. Camera 11. Chamber Light
12. Filament Chamber 13. Hygrometer
14. Desiccant Position
15. Network Cable Port 16. Power Switch
17. Power Port
6
10
11
12
13
14
15
1
8
16
17
9
7
2
3
4
5
05
1.2 Packing List
3D Printer Glue
Diagonal Pliers
ScraperCleaning Brush Nipper Pliers
Power Cord Lubricating Grease x 2
Elbow TweezersAllen Wrench SetStraight Screwdriver Unclogging Pin Tool
USB Flash DriveHeat Insulating GlovesLeveling Card 3D Printing Filament
Fuse x 2After-sales Service Card User Guide
Thermally Conductive
Adhesive
Desiccant x 12
06
2. Preparation Before Printing
2.1 Power Connection
1. Connect the power cord to the socket
and equipment and press the switch
to start the machine.
2. Turn on the screen switch and the screen light is on.
07
2.2 Filament Loading
1. Open the filament chamber, put in the filament and pass the filament through the
corresponding filament sensor at the top of the chamber inside until the filament
is visible from the other end of the filament guide tube; [Note: When printing,
please put the filament in the left filament chamber for use.]
2. Press the filament feeding handle
on the extruder to insert the filament
into the extruder;
Filament
Handle
08
