Flashforge ADVENTURER 3 V2 Manuel utilisateur

This guide is only applicable to FLASHFORGE Adventurer3 V2 3D printer

ADVENTURER 3 V2

Quick Start Guide

Unpacking

1. Open the box. 2. Remove wrapping paper box on the top,

there is a Quick start, an after-sales

service, an accessory kit, a power cable

and a roll of material on the plastic box.

3. Take out the printer of the carton,

remove bubble pack outside the

printer.

4. Tear o fixed tapes and front door

protective bag.

5. Take power cable out and plug it

into power input.

6. Plug the other end of power cable into

socket, turn on the power switch.

9. Tap [Tools]-[Setting] on the touch screen as the

picture showed above, tap [Move].

Move Camera

FilamentCheck Led

2/3

Status Language

Calibration Home

1/3

Build

Tools

Filament

Network Preheat

Setting About

7. Turn on the power switch. 8. Open the front door.

10.Tap the upper arrow in the moving page to make the extruder raises for

removing the paper box on the bottom easier.

11.Squeeze wrapping paper box to the

middle slighly and take it out.

X: 20.00 Y: 45.00 Z: 36.00

12. Unboxing completed! Recommended that

you take good care of packing materials for

furthur carrying and keeping.

3D Printer Filament

ScrewdriverQuick Start Guide0.3mm 240℃Nozzle 0.4mm 265℃

High Temperature

Nozzle

Power Cable Flexible Build Plate

Kit Contents

Grease

Allen WrenchUnclogging Pin Tool

Getting to know your Adventurer 3 V2

1. Filament guide tube 2. Filament guide tube joint 3. Extruder base

4.Cooling Fan 5. Removable nozzle 6. Extruder cables 7. Clip 8. Led light

9. Turbo Fan Bae 10. Front door 11.Y-Axis sliding slot 12.Platform base

13. Removable build plate 14.Touch-screen 15.USB stick input 16.Power switch

17. Power input 18. Spool holder 19.Filament cover 20. Filament cover handle

21. Moto 22. Filament intake 23.Filament feeding wheel 24. Top cover

25. Air outlet 26. Ethernet input

3. Open the filament cover, insert the filament into the

filament intake, push filament into the feeding wheel

until some resistance is sensed.

Note: Please make sure filament has been pushed into

the feeding wheel!

First Print

1. Tap [Filament], tap [Load], after load completed, tap [OK].

2. As shown on the left, loading starts when the

extruder heated to target temperature.

Build

Tools

Filament

Load

Change

200 /235℃

Heating extruder...

Cancel

235 /235℃

Preheat completed,

Begin loading...

4. Load completed when you see filament come out

of extruder, tap [OK]. Put the spool of filament on

the spool holder, close the filament cover.

Mind the loading direction of filament, make sure to be clockwise as the picture

showed.

235 /235℃

Press ok when new color appears

1. Tap [Build], choose the file path: Print from local memory card.

2. Locate the model file in the model list,

Tap on its right to start printing; or tap

model file picture or file name to enter model

details page, tap to start printing.

3. Extruder will heat up and printer will start printing after heating completed. After

model printing finished, printer will sound a beep and pop out notice on touch

screen.

Model Print

Model Remove

1.As showed in picture, press down dotted line area and draw out

the removable build plate.

When printing completed, extruder and build plate may still hot,

please start operating after cooling down!

2.Bend the build plate, the plate will produce certain deformation, seperating

the plate away from the bottom of model (Please use a scraper to assist

removing when model is too small or big).

Notices
