Flashforge Adventurer 4 Manuel utilisateur

用户使用手册

Adventurer 4 / 冒险家4

User Guide

EN/CN-A01

中文P28

本手册仅适用于闪铸科技冒险家4 3D打印机

This guide is only applicable to FLASHFORGE Adventurer 4 3D printer

Content

Notice

Reference

Chapter 1 Adventurer 4

1.1 - Component Introduction

1.2 - Packing Specification

Chapter 2 Introduction of User Interface

2.1 - Build

2.2 - Prepare

2.2.1 - Preheat

2.2.2 - Filament

2.3 - Settings

2.4 - Maintain

2.4.1 - Upgrade

2.4.2 - Log

2.4.3 - Calibration

2.4.4 - ChangeExtruder

2.4.5 - Maintain

Chapter 3 Software Installation

Chapter 4 Preparation of Device

Chapter 5 Print

Chapter 6 Q&A

Chapter 7 Support and Service

Notice

Safety Notice: please read and strictly follow all the

safety warnings and notice below.

Work Environment Safety

Keep your work place tidy.

Do not operate Adventurer 4 in the presence of flammable liquids, gases or dust,

which will cause fire in the high temperature generated by the equipment.

Keep Adventurer 4 out of children and untrained people’s reach.

Electrical Safety

Always use the Adventurer 4 with a properly grounded outlet. Do not refit

Adventurer 4 plug. Ungrounded / improperly grounded / refitted plugs will

increase the risk of leakage of electricity.

Do not use Adventurer 4 in damp environment or under the burning sun. Damp

environment will increase the risk of leakage / exposure to the sun will accelerate

the aging of plastic parts.

To avoid device damage, please use the power supply provided by Flashforge.

Avoid using the device during a thunderstorm.

In case of uncertain accident, please unplug the device if you do not use it for long.

Personal Safety

Do not touch the nozzle and build plate during printing.

Do not touch the nozzle and plate after printing to avoid high temperature scald

or mechanical damage!

Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and

gloves away from moving parts.

Do not operate the device while you are tired or under the influence of drugs,

alcohol or meditation.

Note： Every printer has been tested before leaving factory. It is normal and will not

be of trouble if there are filament residue remaining in the extruder or slight

scratches on the plate.

Environment Requirements

Place Requirements

Filament Requirements

Filament Storage

The device must be placed in a dry and ventilated environment. The distance of

the left, right and back side space should be at least 20cm, and the distance of the

front side space should be at least 35cm. Device storage temperature: RT 0-40℃.

It’s recommended to use the filaments offered by Flashforge, or from the brands

accepted by Flashforge. Due to the different properties of filaments, you need to

modify printing parameters when using those which are not offered by Flashforge.

Temperature: RT 15-30℃; moisture: 20%-70%.

All polymers degrade with time. Do not unpack filament until necessary. Filament

should be stored in clean and dry conditions.

Cautions

Keep the inside of the device clean and tidy. Do not place metal objects into the

chute at the bottom of the platform.

Please clean up the remaining in time. It is recommended to operate outside the

equipment.

Any modifications to the device will invalidate the guarantee.

Lower the build plate before loading/unloading filament. The distance between

the nozzle and build plate should be kept for at least 50mm.

Operate the device in well-ventilated environment.

Never use the device for illegal activities.

Never use the device to make any food storage vessels.

Never put the prints into your mouth.

Legal Notice

All the information in this document is subject to any amendment or change

without the official authorization from Flashforge.

FLASHFORGE CORPORATION MAKES NO WARRANTY OF ANY KIND WITH REGARD

TO THIS DOCUMENT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

FCC Notice

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions: [1] This device may not cause harmful interference,

and [2] this device must accept any interference received, including

interference that may cause undesired operation.

Flashforge shall not be liable for errors contained herein for incidental

consequential damages in connection with furnishing, performance or use of

this material.

This document contains proprietary information protected by copyright.

Name

Number of Extruder

Positioning Accuracy

Layer Resolution

Build Volume

Nozzle Diameter

Build Speed

Highest extruder Temperature

Filament Support

Power Supply

Device Size

Package Size

Software

Input/Output File

Connectivity

Printing Environment

Adventurer 4

X/Y axis：0.011 mm；Z axis：0.0025 mm

0.1~0.4 mm

220 x 200 x 250 mm

0.4mm (default) 0.6/0.3 mm(optional)

10~150mm/s

265℃/240℃

ABS/PLA/PC/PETG/PLA-CF/ASA/PETG-CF

AC100-240V/4.5A,350W

500(L)*470(W)*540(H) mm

585(L)*570(W)*680(H) mm

FlashPrint

Input: 3MF/STL/OBJ/FPP/BMP/PNG/JPG/JPEG

File；Output: GX/G File

USB Disk/ WIFI/ Ethernet

15-30℃

Reference

Chapter 1 Adventurer 4

5. Filament intake cover

7. Platform base

9. Touch screen

4. Spool holder

1. Power switch

2. Power socket

8. Build plate

6. Front cover

20.Camera

13. Filament guide tube joint

15.Fan for cooling model

11. Ethernet input

12. Extruder

10.USB

16.Fan for cooling extruder

21.Air filter

17.Buckle 18. Air duct

3. Filament cover

19. Nozzle

14.Cable slot

1.1 Component Introduction

3D Printer Filament After-Sales

Service Card

Screwdriver

0.4-265 Nozzle

（Adventurer 4 Equipped）

User Guide Unclogging

Pin Tool

Power Cable

Grease

Allen Wrench

Filament Guide

Tube Joint

Leveling Card

USB Disk

1.2 Packing Specification

用户使用手册

Adventurer 4 / 冒险家4

User Guide

EN/CN-A01

中文P28

本手册仅适用于闪铸科技冒险家4 3D打印机

This guide is only applicable to FLASHFORGE Adventurer 4 3D printer

1.Click [Build], and then choose the path to read the print ﬁle.

The interface layout may change whenever there is an upgrade of

firmware. The functions below are only for demonstration purposes.

2. File list

Tap model file：for file details.

Long press model file：multi-selecting mode on.

Chapter 2 Introduction of User Interface

2.1 Build

Note

The ﬁnished prints will be marked.

Read print file from local

memory card

Read print file from the

USB stick

Details

Extruder temperature

Time used

Speed

Copy the ﬁle to the

local memory card

Amount and type of

ﬁlaments required

Build plate temperature

Pause/Resume printing

Interface

Z：Used when the distance needs to be adjusted between the first printed layer and

the extruder. The up and down arrows indicate that the extruder moves upward or

downward.

Fan：The fan for cooling the model. Wind speed can be adjusted for printing different

filaments.

Click OK to save and apply the changed parameters.

Layer thickness

Check more parameter settings and details

More Settings

You can change ﬁlaments

The switch of LED light

Adjust printing parameters:

extruder temperature/

platform temperature/

printing speed
