This guide is only applicable to FLASHFORGE Guider 3 3D printer
本手册仅适用于闪铸科技引领者 3打印机
中文P26
用户使用手册
USER GUIDE
EN/CN-A01 Guider 3 引领者 3
CONTENT
Notice
Equipment Parameter
1. Equipment Introduction
1.1 - Guider 3 Introduction
1.2 - Packing List
2. Preparation Before Printing
2.1 - Power Connection
2.2 - Filament Loading
2.3 - Equipment Calibration
2.4 - Network Connection
2.4.1 - Wired Network Connection
2.4.2 - Wireless Network Connection
4.1 - File Transfer: Wi-Fi Transfer
4.2 - Printing From a USB Flash Drive
4.3 - Cloud Printing
4.4 - Camera Connection
4.5 - Model Removal After Finishing Printing
5.1 - Printing Screen
5.2 - Filament Screen
5.3 - Preheating Screen
5.4 - Tools Screen
5.5 - Settings Screen
6.1 - Maintenance Screen
6.2 - Extruder Maintenance
6.3 - Platform Replacement
6.3.1 - Glass Platform Replacement
6.3.2 - Flexible Steel Plate Platform Replacement
6.4 - Platform Flatness Calibration
7. Q&A
3. Software Installation
4. First Printing
5. Equipment Operation Interface Introduction
6. Maintenance
8. Help and Support
05
07
12
19
25
05
06
07
08
10
11
11
11
12
15
23
12
12
13
14
14
15
16
17
17
18
19
19
20
20
21
22
01
NOTICE
SAFETY NOTICE: PLEASE CAREFULLY READ AND STRICTLY FOLLOW
ALL THE SAFETY WARNINGS AND NOTICES BELOW ALL THE TIME.
WORK ENVIRONMENT SAFETY
Please keep the work table of the equipment clean and tidy.
Please ensure that the equipment is away from combustible gases, liquids and dust
when it is in operation. The high temperature generated by equipment operation may
react with combustible gases, liquids, and airborne dust, thus causing fire.
Children and untrained personnel are not allowed to operate the equipment alone.
Note: Every 3D printer has undergone printing tests before leaving the factory.
If there are some filament residues in the extruder of the equipment or some
slight scratches on the build plate, it is normal and will not affect its use.
ELECTRICAL SAFETY
Be sure to ground the equipment. Do not modify the plug of the equipment. Not
grounded equipment/improperly grounded equipment/modified plug will inevitably
increase the risk of electric leakage.
Do not expose the equipment to damp or hot-sun environment. Humidity will increase
the risk of electric leakage. Exposure to sunlight will accelerate the aging of plastic
parts.
Make sure to only use the power cord provided by Flashforge.
Do not use the equipment during an thunderstorm.
Please shut down the equipment and unplug it if it is not in use for a long time.
PERSONAL SAFETY
Do not touch the extruder, build plate, etc., during printing.
Do not touch the extruder and build plate when finishing printing in order to avoid
high temperature burns or mechanical damage.
Do not wear scarves, masks, gloves, jewelry ornaments or other objects that can
easily get tangled into the equipment when operating it.
Do not operate the equipment while you are tired or under the influence of drugs,
alcohol or medication.
CAUTIONS
Keep the inside of the equipment clean and tidy. Do not drop metal objects into the
sliding chute at the bottom of the build plate.
Please clean up the filament debris in time. It is recommended to operate this outside
the equipment.
02
The room temperature should be between 15℃ and 30℃.
The humidity should be between 20RH% and 70RH%.
Any modification of the equipment by yourself will result in the situation that you will
not be entitled to warranty rights anymore.
Please keep the distance between the extruder and build plate for at least 50mm
during filament loading. Too-close distance may cause nozzle clogging.
Please operate the equipment in a well-ventilated environment.
Do not use the equipment for illegal activities.
Do not use the equipment to make any food storage products.
Do not put the printed model into your mouth.
EQUIPMENT ENVIRONMENT REQUIREMENTS
EQUIPMENT PLACEMENT REQUIREMENTS
COMPATIBLE FILAMENT REQUIREMENTS
FILAMENT STORAGE REQUIREMENTS
LEGAL STATEMENT
The equipment must be placed in a dry and ventilated environment. A distance of at
least 30cm must be reserved at the left side and rear side of the equipment, and a
distance of at least 45cm must be reserved at the right side and front side of the
equipment.The storage temperature should be between 0℃ and 40℃.
When using the equipment, it is recommended to use Flashforge’s filaments.
If non-Flashforge filaments are used, there will be certain differences in material
characteristics, and thus printing parameters may need to be adjusted.
Please store filaments in a dry and dust-free environment after unpacking. It is
recommended to use the matching filament dry box for storage.
The user has no right to make any modification to this user guide.
Flashforge will not be responsible for any safety accidents caused by the disassembly
or modification of the equipment by the customer. No one is allowed to modify or
translate this guide without the permission of Flashforge. This guide is protected by
copyright, and Flashforge reserves the right of the final interpretation of this guide.
First Edition (August 2022)
Copyright © 2022 Zhejiang Flashforge 3D Technology Co., Ltd. All Rights Reserved.
03
Equipment Parameter
Equipment Name
Extruder Quantity
Printing Precision
Positioning Accuracy
Layer Thickness
Build Volume
Nozzle Diameter
Nozzle Type
Printing Speed
Maximum Extruder Temperature
Maximum Platform Temperature
Supported Filament
Power Supply
Slicing Software
Input/Output File Format
Connectivity
Operating Temperature
Compatible Operating System
Compatible Slicing Software
Smart Touch Screen
Build Plate
Net Weight
Equipment Dimensions
Required Space for Installation
Guider 3
1
± 0.15mm or 0.002 mm/mm [The larger values shall prevail]
X/Y-axis: 0.011mm Z-axis: 0.0025mm
0.05 ~ 0.4mm
300x250x340mm
Default 0.4mm [Optional 0.6/0.8]mm
Stainless steel nozzle
10 ~ 250mm/s
320℃
110℃
ABS/PLA/PC/PA/HIPS/ASA/PETG/PA-CF/PLA-CF
PETG-CF/PETG-GF
AC100-240V/DC 24V/20.8A, 500W
FlashPrint
Input: 3MF/STL/OBJ/FPP/BMP/PNG/JPG/JPEG；
Output: GX/G/gcode
USB flash drive/Ethernet/Wi-Fi
15 ~ 30℃
Windows XP/Vista/7/8/10、Mac OS
Slic3r, Cura [Need setting]
4.3-inch
Flexible steel plate platform/Glass platform
27kg
496[L] x 436[W] x 696[H] mm
≥590*543*758mm
04
1. Equipment Introduction
Guider 3 Introduction
1. Upper Cover 2. Air Filter
3. USB Port 4. Screen Switch
5. Front Door 6. Flexible Steel Plate
7. Platform Plate 8. Filament Chamber Door
9. Chamber Light 10. Camera 11. Extruder
12. Filament Spool Holder
13. Network Cable Port 14. Power Switch
15. Power Port
05
6
1
7
2
3
4
5
11
12
13 14 15
9
8
10
1.2 Packing List
06
Glass Platform Hand Screw Bolt x 2
3D Printer
GlueCleaning Brush
Diagonal PliersScraper Nipper Pliers
Power Cord
Lubricating Grease x 2
Elbow Tweezers
Allen Wrench Set
Straight Screwdriver
Unclogging Pin Tool
USB Flash Drive
Heat Insulating Gloves
Leveling Card
3D Printing Filament
Fuse x 2
After-sales Service Card
User Guide
Thermally Conductive
Adhesive
2. Preparation Before Printing
2.1 Power Connection
1. Connect the power cord to the socket
and equipment and press the switch to
start the machine.
Power Switch
Screen Switch
2. Turn on the screen switch and the screen light is on.
07
2.2 Filament Loading
1. Open the filament chamber door, hang the filament on the filament spool holder,
and pass the filament clockwise through the corresponding filament sensor at the
upper left of the chamber inside until the filament is visible from the other end of
the filament guide tube;
2. Press the filament feeding handle on the
extruder and insert the filament into the
extruder;
Filament
Handle
08
Load Unload Clean
< Load Customize
3. Click the [ ] - [Load] on the screen, select the corresponding filament
for the extruder, start filament feeding, and operate following the
prompts on the screen.
< Load
Custom
Heating extruder, please insert the
filament to spool.
100/200℃
Cancel
09
PLA
1/2
ABS PETG
PC PA66 PA12
