Operating Instructions

Liquiline Compact CM82

Compact multi-parameter transmitter for Memosens

sensors

BA01845C/07/EN/02.20

71497333

2020-07-23

Liquiline Compact CM82 Table of contents

Endress+Hauser 3

Table of contents

1 About this document ................ 4

1.1 Warnings ............................ 4

1.2 Symbols .............................. 4

1.3 Symbols at the device .................... 4

1.4 Documentation ........................ 5

2 Basic safety instructions ............ 6

2.1 Requirements for personnel ............... 6

2.2 Designated use ........................ 6

2.3 Occupational safety ..................... 6

2.4 Operational safety ...................... 6

3 Product description ................. 8

3.1 Product design ......................... 8

4 Incoming acceptance and product

identification ....................... 9

4.1 Incoming acceptance .................... 9

4.2 Product identification .................... 9

4.3 Scope of delivery ...................... 10

4.4 Certificates and approvals ............... 10

5 Installation ....................... 13

5.1 Dimensions .......................... 13

6 Electrical connection .............. 14

6.1 Connection .......................... 14

6.2 Post-connection check .................. 15

7 Operation options ................. 16

7.1 Overview of operating options ............ 16

7.2 Access to operating menu via SmartBlue

(app) ............................... 16

7.3 Access to operating menu via RIA15 ........ 18

8 System integration ................ 19

8.1 Integrating the measuring device into the

system ............................. 19

9 Commissioning .................... 20

9.1 Preparatory steps ...................... 20

9.2 Function check ....................... 20

9.3 Connection via process indicator RIA15 ..... 21

9.4 Establishing connection via SmartBlue (app) .. 27

9.5 Setting the operating language ............ 28

9.6 Date and time ........................ 28

9.7 Configuring the measuring device .......... 28

9.8 Configuration management .............. 35

9.9 Unauthorized access via Bluetooth® LE ...... 36

10 Operation ......................... 38

10.1 Reading measured values ................ 38

10.2 Adapting the measuring device to the process

conditions ........................... 39

11 Calibration ........................ 41

11.1 Types of calibration .................... 41

12 Diagnostics and troubleshooting ... 45

12.1 Diagnostic information via LED ........... 45

12.2 Adapting the diagnostic information ....... 45

12.3 Adapting sensor diagnostic information ..... 46

12.4 Simulation ........................... 55

12.5 Diagnostic list ........................ 56

12.6 Event logbook ........................ 68

12.7 Resetting the measuring device ........... 68

12.8 Device information .................... 69

12.9 Firmware history ...................... 69

13 Maintenance ...................... 70

13.1 Maintenance tasks ..................... 70

14 Repair ............................ 71

14.1 General notes ........................ 71

14.2 Return .............................. 71

14.3 Disposal ............................ 71

15 Accessories ....................... 72

15.1 Sensors ............................. 72

15.2 Software ............................ 75

15.3 Other accessories ...................... 75

16 Technical data .................... 77

16.1 Input ............................... 77

16.2 Output ............................. 77

16.3 Performance characteristics .............. 77

16.4 Power supply ......................... 78

16.5 Environment ......................... 78

16.6 Mechanical construction ................ 80

Index .................................. 81

About this document Liquiline Compact CM82

4 Endress+Hauser

1 About this document

1.1 Warnings

Structure of information Meaning

LDANGER

Causes (/consequences)

If necessary, Consequences of

non-compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation will result in a fatal or serious

injury.

LWARNING

Causes (/consequences)

If necessary, Consequences of

non-compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation can result in a fatal or serious

injury.

LCAUTION

Causes (/consequences)

If necessary, Consequences of

non-compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid this situation can result in minor or more serious injuries.

NOTICE

Cause/situation

If necessary, Consequences of

non-compliance (if applicable)

‣Action/note

This symbol alerts you to situations which may result in damage to

property.

1.2 Symbols

Symbol Meaning

Additional information, tips

Permitted or recommended

Not permitted or not recommended

Reference to device documentation

Reference to page

Reference to graphic

 Result of a step

1.3 Symbols at the device

Symbol Meaning

Reference to device documentation

Liquiline Compact CM82 About this document

Endress+Hauser 5

1.4 Documentation

The following instructions complement these Operating Instructions and are available on

the product pages on the Internet:

Operating Instructions Memosens, BA01245C

• Software description for Memosens inputs

• Calibration of Memosens sensors

• Sensor-specific diagnostics and troubleshooting

Basic safety instructions Liquiline Compact CM82

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for personnel

• Installation, commissioning, operation and maintenance of the measuring system may

be carried out only by specially trained technical personnel.

• The technical personnel must be authorized by the plant operator to carry out the

specified activities.

• The electrical connection may be performed only by an electrical technician.

• The technical personnel must have read and understood these Operating Instructions

and must follow the instructions contained therein.

• Faults at the measuring point may only be rectified by authorized and specially trained

personnel.

Repairs not described in the Operating Instructions provided must be carried out only

directly at the manufacturer's site or by the service organization.

2.2 Designated use

The Liquiline CM72 Liquiline CM82 is a transmitter for connecting digital sensors with

Memosens technology, configurable, with 4..20 mA/HART communication and optional

operation via smartphone or other mobile devices via Bluetooth.

The device is designed for use in the following industries:

• Life science

• Chemical industry

• Water and wastewater

• Food and beverages

• Power stations

• Other industrial applications

2.3 Occupational safety

As the user, you are responsible for complying with the following safety conditions:

• Installation guidelines

• Local standards and regulations

• Regulations for explosion protection

Electromagnetic compatibility

• The product has been tested for electromagnetic compatibility in accordance with the

applicable international standards for industrial applications.

• The electromagnetic compatibility indicated applies only to a product that has been

connected in accordance with these Operating Instructions.

2.4 Operational safety

Before commissioning the entire measuring point:

1. Verify that all connections are correct.

2. Ensure that electrical cables and hose connections are undamaged.

3. Do not operate damaged products, and protect them against unintentional operation.

4. Label damaged products as defective.

Liquiline Compact CM82 Basic safety instructions

Endress+Hauser 7

During operation:

‣If faults cannot be rectified:

products must be taken out of service and protected against unintentional operation.

LCAUTION

Cleaning not switched off during calibration or maintenance activities

Risk of injury due to medium or cleaning agent!

‣If a cleaning system is connected, switch it off before removing a sensor from the

medium.

‣If you wish to check the cleaning function and have therefore not switched off the

cleaning system, wear protective clothing, goggles and gloves or take other appropriate

measures.

Product description Liquiline Compact CM82

8 Endress+Hauser

3 Product description

3.1 Product design

A0036216

 1 Transmitter design

1 Cable

2 Housing

3 Memosens connection

4 LED, for optical signaling of operating statuses of measuring point

3.1.1 Measuring parameters

The transmitter is designed for digital Memosens sensors with inductive plug-in head:

• pH, ORP, pH/ORP combined sensors

• Conductive conductivity

• Dissolved oxygen

Liquiline Compact CM82 Incoming acceptance and product identification

Endress+Hauser 9

4 Incoming acceptance and product

identification

4.1 Incoming acceptance

1. Verify that the packaging is undamaged.

 Notify the supplier of any damage to the packaging.

Keep the damaged packaging until the issue has been resolved.

2. Verify that the contents are undamaged.

 Notify the supplier of any damage to the delivery contents.

Keep the damaged goods until the issue has been resolved.

3. Check that the delivery is complete and nothing is missing.

 Compare the shipping documents with your order.

4. Pack the product for storage and transportation in such a way that it is protected

against impact and moisture.

 The original packaging offers the best protection.

Make sure to comply with the permitted ambient conditions.

If you have any questions, please contact your supplier or your local Sales Center.

4.2 Product identification

4.2.1 Nameplate

The nameplate provides you with the following information on your device:

• Manufacturer identification

• Order code

• Extended order code

• Serial number

• Firmware version

• Ambient and process conditions

• Input and output values

• Safety information and warnings

• Approvals as per version ordered

‣Compare the data on the nameplate with your order.

4.2.2 Product identification

Product page

www.endress.com/CM82

Interpreting the order code

The order code and serial number of your product can be found in the following locations:

• On the nameplate

• In the delivery papers

Obtaining information on the product

1. Go to www.endress.com.

2. Call up the site search (magnifying glass).

3. Enter a valid serial number.

Incoming acceptance and product identification Liquiline Compact CM82

10 Endress+Hauser

4. Search.

 The product structure is displayed in a popup window.

5. Click on the product image in the popup window.

 A new window (Device Viewer) opens. All of the information relating to your

device is displayed in this window as well as the product documentation.

4.3 Scope of delivery

The scope of delivery includes:

• CM82

• Brief Operating Instructions

‣If you have any queries:

Please contact your supplier or local sales center.

4.4 Certificates and approvals

4.4.1  mark

Endress+Hauser Conducta GmbH+CO. KG hereby declares that the radio system type

CM82 complies with directives 2014/53/EU and 2011/65/EU.

The complete text of the EU declaration of conformity can be found at the following web

address:

www.endress.com/CM82

Frequency band: 2400-2483.5 MHz, power output: < 10dBm EIRP

4.4.2 Radio approval

USA/Canada radio approval (FCC/IC)

FCC ID: 2AKGY-BT41INTA01

IC: 22173-BT41INTA01

This device complies with Part 15 of the FCC Rules [and with Industry Canada license-

exempt RSS standard(s)]. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Any changes or modifications made to this equipment not expressly approved by Endress

+Hauser may void the FCC authorization to operate this equipment. This device complies

with Part 15 of the FCC Rules and with Industry Canada license- exempt RSS standard(s).

Operation is subject to the following two conditions:

• this device may not cause harmful interference, and

• this device must accept any interference received, including interference that may cause

undesired operation.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:

• l'appareil ne doit pas produire de brouillage, et

• l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre le fonctionnement.

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

Autres manuels pour Liquiline Compact CM82

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Endress+Hauser Émetteur

Endress+Hauser

Endress+Hauser Liquisys M CLM 223 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT162 Instructions d'installation

Endress+Hauser

Endress+Hauser iTEMP TMT82 Caractéristiques techniques

Endress+Hauser

Endress+Hauser HMX50 Manuel utilisateur

Endress+Hauser

Endress+Hauser RMA 422 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquisys M CLM223 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline 300 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Heat Caractéristiques techniques

Endress+Hauser

Endress+Hauser Memograph CVM40 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Liquisys M CPM223 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquisys M CCM223 Manuel utilisateur

Endress+Hauser

Endress+Hauser Flowmeter Proline 300 Caractéristiques techniques

Endress+Hauser

Endress+Hauser iTEMP TMT162 Manuel

Endress+Hauser

Endress+Hauser Mycom CLM 152 Manuel utilisateur

Endress+Hauser

Endress+Hauser FHX50 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT71 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT162 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT162 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT84 Caractéristiques techniques

Endress+Hauser

Endress+Hauser AT1000 AT1 Manuel utilisateur

Endress+Hauser

Endress+Hauser Liquisys M CLM 223 Manuel utilisateur

Endress+Hauser

Endress+Hauser iTEMP TMT162 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Memograph CVM40 Manuel utilisateur

Endress+Hauser

Endress+Hauser CM14-AAK Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
