EK-Quantum Vector RTX 3080/3090 Backplate Manuel utilisateur

USER GUIDE

BACKPL AT E

EK-Quantum

Vector RTX 3080/3090 Backplate

This product is intended for installation by expert users only. Please

consult with a qualiﬁed technician. Improper installation may result

in damage to your equipment. EK assumes no liability whatsoever,

expressed or implied, for the use of this product or its installation. The

following instructions are subject to change without notice. Please, read

the manual carefully before beginning with the installation process. For

updates, you can visit our ofﬁcial website www.ekwb.com.

Before you start using this product, please follow these basic guidelines:

Carefully read the manual before beginning with the

installation process.

Remove your graphics card from the computer for the safest

mounting process, to prevent any possible damage to your

GPU or its circuit board (PCB).

- 3 -

TABLE OF CONTENTS

BOX CONTENTS 4

BACKPLATE DIMENSIONS 5

INSTALLING THE BACKPLATE 6

PREPARING THE GRAPHICS CARD 6

CUTTING AND PLACING THERMAL PADS 6

ATTACHING THE BACKPLATE 8

TESTING THE LOOP 8

WARRANTY 9

REQUIRED TOOLS 9

SUPPORT AND SERVICE 10

SOCIAL MEDIA 10

- 4 -

BOX CONTENTS

4 mm

6 mm

7mm

M2.5 Nut (5 pcs)

M2,5x6 AX1 Screw (7 pcs)

Thermal PAD G 1,5mm - (120x24mm) (2 pcs) Thermal PAD G 2 mm - (120x24mm) (2 pcs)

M2,5x7 AX1 Screw (7 pcs)

M2,5x4 AX1 Screw (3 pcs)

EK-Quantum Vector RTX 3080/3090 Backplate

PVC Washer M2.5 (10 pcs)

120 mm

24 mm

120 mm

24 mm

120 mm

24 mm

Thermal PAD G 1,0mm - (120x24mm) (2 pcs)

Mounting mechanism - You may not need all the screws, mounting mechanism is universal!

- 5 -

BACKPLATE DIMENSIONS

220,15 mm

99 mm

5,20 mm

- 6 -

INSTALLING THE BACKPLATE

STEP 1

PREPARING THE GRAPHICS CARD

First, complete the installation of your EK-Quantum Vector RTX

3080/3090 water block according to its installation manual.

In case the water block is already installed, remove the six (6) AX1

screws and their PVC washers, as shown in the image.

STEP 2

CUTTING AND PLACING THERMAL PADS

Your backplate comes with thermal pads that have to be cut into

smaller pieces to cover all the VRM components. EK made sure to

provide you with more than an adequate quantity of thermal pads to

complete this Step.

CAUTION: You must remove the protective foil from both

sides of the thermal pad before installation.

Thermal pads:

2x Thermal PAD G 1.0 mm (120 x 24 mm) – EAN: 3830046996770

2x Thermal PAD G 1.5 mm (120 x 24 mm) – EAN: 3830046996787

2x Thermal PAD G 2.0 mm (120 x 24 mm) – EAN: 3830046996794

STEP 1

STEP 2

120 mm

24 mm

1 mm

Thermal PAD G 1.0 mm (120 x 24 mm)

120 mm

24 mm

1.5 mm

Thermal PAD G 1.5mm (120 x 24 mm)

120 mm

24 mm

2 mm

Thermal PAD G 2.0 mm (120 x 24 mm)

- 7 -

STEP 3

Once cut to size, thermal pads should be placed on the backplate,

as illustrated below.

STEP 3

RTX™ 3080

RTX™ 3090

Thermal Pad G 1.5 mm

Thermal Pad

G 2.0mm

Thermal Pad G 1.5 mm

Thermal Pad

G 1.0 mm

Thermal Pad

G 2.0 mm

- 8 -

STEP 4

ATTACHING THE BACKPLATE

Place the backplate on the PCB and make sure all holes are aligned.

Position an M2.5X7 AX1 screw in each of the six (6) mounting holes

(as shown in the image) and tighten them evenly with a Phillips

head screwdriver. Do not use excessive force!

For this Step, you will need:

STEP 4

TESTING THE LOOP

To ensure the installation of EK components was successful, we

recommend you perform a 24-hour leak test.

When your loop is complete and ﬁlled with coolant, connect the pump

to a PSU outside your system. Do not connect power to any of the other

components. Turn on the PSU and let the pump run continuously.

Inspect all parts of the loop, and in case the coolant leaks, ﬁx the issue

and repeat the testing process. To prevent possible damage, please

ensure that all hardware is dry before the system is powered on.

Phillips Head

Screwdriver

M2.5 x 7 AX1

6 pcs

7mm

M2.5X7 AX1

- 9 -

Phillips Head Screwdriver Scissors

REQUIRED TOOLS

WARRANTY

Our products are warranted against defects of materials and quality for

a period of 24 months, starting with the date of delivery to the end-user.

During this period, products will be repaired or have parts replaced at

our discretion, provided that 1) the product is returned to the agent from

whom it was purchased; 2) the product has been purchased by the end-

user and has not been used for commercial purposes; 3) the product has

not been misused, handled carelessly, or used in a manner other than the

way described in the instructions manual. This warranty does not confer

rights other than those expressly set out above and does not cover any

claims for consequential loss or damage. This warranty is offered as an

extra beneﬁt and does not affect your statutory rights as a consumer.

This warranty is voided if the product comes in contact with aggressive

UV additives or other improper liquids. EK water blocks are sealed with a

warranty-voiding circular label, proving the water block has withstood a

pressure leak test. Removing the label will void the leak-free guarantee,

but not the guarantee on the product itself. Any other RMA issues can

be reported to EK Customer Support at www.ekwb.com/support for

further analysis.

In case you need assistance, please contact:

http://support.ekwb.com/

EKWB d.o.o.

Pod lipami 18

1218 Komenda

Slovenia - EU

EKWaterBlocks

@EKWaterBlocks

ekwaterblocks

EKWBofﬁcial

SUPPORT AND SERVICE

SOCIAL MEDIA
