EK-Quantum Vector Strix RTX 3090 Backplate Manuel utilisateur

USER GUIDE

EK-Quantum

Vector FE RTX 3090 D-RGB Active Backplate

This product is intended for installation by expert users only. Please

consult with a qualiﬁed technician. Improper installation may result

in damage to your equipment. EK assumes no liability whatsoever,

expressed or implied, for the use of this product or its installation. The

following instructions are subject to change without notice. Please, read

the manual carefully before beginning with the installation process. For

updates, you can visit our ofﬁcial website www.ekwb.com.

Before you start using this product, please follow these basic

guidelines:

Carefully read the manual before beginning the installation

process.

Remove your graphics card from the computer for the safest

mounting process to prevent any possible damage to your GPU

or its circuit board (PCB).

EK Fittings require only a small amount of force to screw them

ﬁrmly in place since the liquid seal is ensured with the rubber

O-ring gaskets.

The use of quality, market-proven, corrosion-inhibiting coolants

is always strongly recommended for any liquid cooling system.

Do not use pure distilled water as a cooling liquid! For best

results, EK recommends the use of EK-CryoFuel Coolants.

Make sure to bleed air out of your water block thoroughly in

order to reach optimal performance.

EK only guarantees compatibility with included EK-brand

thermal pads. The installation process, cooling performance,

and block contacts are tested exclusively with EK-brand

thermal pads. Listed thermal pad thicknesses apply only to

those included in the package.

EK does not guarantee compatibility with aftermarket

alternatives for thermal interface material.

- 3 -

TABLE OF CONTENTS

BOX CONTENTS 4

ACTIVE BACKPLATE DIMENSIONS 5

REQUIRED TOOLS 5

TECHNICAL SPECIFICATIONS AND PRODUCT PARTS 6

PREPARING THE 3090 FE WATER BLOCK 7

CUTTING AND PLACING THERMAL PADS 8

ATTACHING THE BACKPL ATE 9

CONNECTING THE D-RGB LED STRIP 11

SUPPORT AND SERVICE 12

SOCIAL MEDIA 12

- 4 -

Allen Key 2 mm (1 pc),

EAN: 8901

BOX CONTENTS

20 mm

25 mm

20 mm

27 mm

EK-Loop Multi Allen Key (1 pc),

EAN: 3830046996213

M3x25 DIN7991 Screw – Black (1 pc),

EAN: 9061

M3x25 DIN7991 Screw – Nickel (1 pc),

EAN: 104197

Allen Key 2.5 mm (1 pc),

EAN: 8902

M3x20 DIN7991 Screw – Black (2 pcs),

EAN: 8204

M3x20 DIN7991 Screw - Nickel (2 pcs),

EAN: 104196

M2.5x20 Screw – Black Chrome (4 pcs),

EAN: 104218

M2.5x20 Screw – Nickel (4 pcs),

EAN: 104219

EK-Quantum Vector FE RTX 3090 D-RGB Active Backplate

Terminal Screw M4x27 – Black Chrome

(2 pcs), EAN: 103398

Terminal Screw M4x27 – Nickel (2 pcs),

EAN: 103397

Thermal Pad F 1.0 mm (4 pcs),

EAN: 3830046996732

120 mm

16 mm

- 5 -

212.5 mm

121.5 mm

19.5 mm

40 mm

33.5 mm

62 mm

95 mm

46.5 mm

74.5 mm

12.5 mm

ACTIVE BACKPLATE DIMENSIONS

Phillips Head Screwdriver Scissors

REQUIRED TOOLS

- 6 -

TECHNICAL SPECIFICATIONS AND PRODUCT PARTS

Technical Speciﬁcation:

- Dimensions (L x H x W): 212.5 x 121.5 x 40 mm

- D-RGB (Addressable RGB) Cable Length: 500 mm

- D-RGB LED Count: 24

- D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)

Position EAN Description Quantity

1100663 EK Badge 1

2104128 Top plate cover (Black elox) 1

104129 Top plate cover (Natural elox)

3104124 Top plexi 1

4104126 Main O-ring 1

5100815 LED Strip 1

6104131 Coldplate (Nickel) 1

79041N M3 x 11 DIN7991 (Ni) 13

9041 M3 x 11 DIN7991

85092

OR 12 x 1.5

99041N

M3 x 11 DIN7991 (Ni)

9041

M3 x 11 DIN7991

10 104133 Terminal insert (Nickel) 1

11 5158 OR 35 x 1.5 1

12 102639 EK-Plug G1/4 2

13 104123 AB Terminal 1

14 103398

Terminal screw (Black Chrome)

103397

Terminal screw (Nickel)

- 7 -

For this Step, you will need:

PREPARING THE 3090 FE WATER BLOCK

STEP 1

Unscrew the three (3) M3x12 DIN7991 screws and remove the backplate

cover, as shown in the image..

STEP 1

Allen Key 2 mm

M3 x 12

DIN7991

SCREW

BACKPLATE

COVER

For this Step, you will need:

STEP 2

After removing the backplate cover, four (4) backplate screws

needs to be removed. Detach the backplate as shown in the image.

Preinstalled thermal pads on the PCB also must be

detached. After removing the thermal pads, pre-applied

thermal grease also needs to be removed using a

nonabrasive cloth or Q-tip. EK recommends the use of

denatured alcohol for removing TIM leftovers.

STEP 2

M2.5 x 7 AX1 SCREWS

BAC KP L ATE

Phillips Head Screwdriver

- 8 -

STEP 3

EK-Quantum Vector FE 3090 Active Backplate comes with its own

terminal, meaning the original terminal on the EK-Quantum Vector

FE 3090 water block must be removed.

In case the EK-Quantum Vector FE 3090 water block is

already ﬁlled with coolant, empty the contents of the

water block before continuing with this step. Be careful

that the coolant that remained in the water block does

not contact the GPU!

For this Step, you will need:

Allen Key 2.5 mm

STEP 3

M4 x 24.5 DIN7984

SCREW

FC TERMINAL

STEP 1

Your Active Backplate comes with thermal pads that must be cut into

smaller pieces to cover all the VRM components. EK has included

more than enough thermal pads to complete the following Step(s).

Replacement thermal pads:

Thermal Pad F 1.0 mm – (120 x 16 mm) EAN: 3830046996732

STEP 1

Thermal Pad F – 1.0 mm (120 x 16 mm)

CUTTING AND PLACING THERMAL PADS

120 mm

16 mm

1 mm

- 9 -

STEP 2

Once cut to size thermal pads should be applied to the PCB as

shown in the image.

Thermal Pad F 1.0mm

ATTACHING THE BACKPLATE

STEP 1

For easier installation of the Active Backplate, the preinstalled

terminal and metal plate must be removed. Unscrew the two (2)

Terminal screws (as shown in the image) and remove the terminal.

Save the mention material for later use.

For this Step, you will need:

Allen Key 2.5 mm

STEP 1

AB TERMINAL

TERMINAL SCREW M4 x 27 DIN7984

- 10 -

M3x25 DIN7991

Screw (1 pc)

Allen Key

2 mm

M3x20 7991DIN

Screw (2 pcs)

M2.5x20

Screw (4 pcs)

STEP 3

Before attaching the terminal, make sure that four (4)

O-rings are IN terminal slots, as shown in the image.

20 mm

25 mm

STEP 2

Place the active backplate on the PCB and make sure all holes are

aligned. Position the screws in each of the seven (7) mounting

holes (as shown in the image) and tighten them evenly with Allen

Key 2 mm.

STEP 2

M2.5 x 20

M3 x 20

DIN7991

M3 x 25 DIN7991

For this Step, you will need:
