14" Universal
Notebook Docking Station,
USB Type-C™
User Manual
DA-70868
2
1.0 INTRODUCTION
The 14" docking station from DIGITUS® extends your notebook by 14
extra ports via one USB-C™ connection. It contains, inter alia, three video
ports (HDMI, DisplayPort, VGA) for connecting monitors, projectors, TVs,
etc. Thanks to triple monitor support, these can be used simultaneously.
Under Windows, a video signal can be output simultaneously to three
different ports (SST mode); additionally, three different video signals can
be output to three different graphics ports (MST mode). Mac OS supports
only SST mode. The other interfaces offer connectivity to all common
connections that a modern docking station should have. For example, a
network connection, other USB connections (USB-C™, USB-A), an audio
output or two independent card readers. The integrated USB-C™ port
with PD charging can charge your notebook whilst using the docking
station. The docking station also offers various USB 3.0 and 2.0 ports for
data transfer, connection to periphery devices such as mice and
keyboards and for charging mobile devices. Thanks to the smart cable
routing, the docking station can be connected to either side (left or right)
of your notebook. Get the most out of your notebook and extend your
options – all you need is one free USB-C™ connection.
2.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
•1x Main Unit
•1x User Manual
3
3.0 FEATURES
•Supports UHD up to 4K/30Hz to 3840 x 2160p resolution
•3x Video interfaces (HDMI, DP, VGA) to connect up to three monitors
at the same time (triple display support)
•Triple display support under Windows OS - SST (Single Stream
Transport) and MST (Multi Stream Transport) – mirror and extend
monitor
•Triple display support under Mac OS - SST (Single Stream Transport)
- mirror the monitor
•3x USB 3.0 connections with up to 5 Gbps SuperSpeed data transfer,
a port with BC 1.2 mobile device charging function (1.5 A max.)
•1 x USB Type-C™ connection as a link to your notebook
•1 x USB Type-C™ connection - data transfer (5 Gbps max.)
•1 x USB Type-C™ connection - power delivery 3.0 (100 W max)
•Power Delivery: PD 3.0 up to max. 100 W (20V/5A)
•1 x HDMI connection (max. 4K/30 Hz)
•1 x DisplayPort connection (max. 4K/30 Hz)
•1 x VGA connection (max. 1920 x 1200/60 Hz)
•1 x Gigabit Ethernet connection - connect notebook to the
Internet / LAN
•2x USB 2.0 connections with up to 480 Mbps data transfer and
500 mA (downstream) charging function per port
•2 x Card readers (microSD / SDHC, SDHX, MMC)
– simultaneous use is possible
•1 x Audio stereo jack (3.5 mm)
•Theft protection (use of a notebook lock is possible)
•Supports DisplayPort alternate mode
•DisplayPort (DP) 1.2 support
•Supports SST and MST Mode
(Single Stream Transport mode / Multi Stream Transport mode)
4
•Smart cable routing - connections are possible on both sides of the
notebook (left and right), cables are routed underneath the docking
station
•Suitable for notebooks up to 14" with a USB-C™ port, can also
be used separately lying for all sizes
•USB-C™ version: USB 3.1 (Gen. 1)
Note:
The 2 charts below list the resolutions of the three videos under SST and
MST mode.
Under SST Mode
VGA
HDMI
DP
Single Port
Connected
1080P/60 Hz
NC
NC
NC
4K/30 Hz
NC
NC
NC
4K/30 Hz
Dual Ports
Connected
1080P/60 Hz
1080P/60 Hz
NC
1080P/60 Hz
NC
1080P/60 Hz
NC
4K/30 Hz
4K/30 Hz
Triple Ports
1080P/60 Hz
1080P/60 Hz
1080P/60 Hz
Under MST Mode
VGA
HDMI
DP
Single Port
Connected
1080P/60 Hz
NC
NC
NC
4K/30 Hz
NC
NC
NC
4K/30 Hz
Dual Ports
Connected
1080P/60 Hz
1080P/60 Hz
NC
1080P/60 Hz
NC
1080P/60 Hz
NC
1080P/60 Hz
1080P/60 Hz
Triple Ports
720P/60 Hz
720P/60 Hz
720P/60 Hz
5
Note:
4K mentioned above stands for 4096*2160, 3840*2160;
1080P stands for 1920*1080; 720P stands for 1280*720.
4.0 SPECIFICATIONS
Input/Output Connector
Input
1x USB-C Female
(Connect to Type-C™ Host)
Output
1x USB-C Female (for data)
1x USB-C Female (for PD Charging)
3x USB 3.0 Female
2x USB 2.0 Female
1x HDMI Female
1x DisplayPort Female
1x VGA Female
1x RJ45
1x Micro SD
1x SD/MMC
1x Audio Jack
Mechanical
Weight
247.3 g
Size
349.5*74*18mm
Environmental
Operating Temperature
0°C to +45°C
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
-10°C to +70°C
Storage Humidity
5% to 90 % RH (no condensation)
Power Supply
USB-C Female Port
Bis zu 100 W
6
5.0 CONNECTION DIAGRAM
1
Tablet
9
VGA Display 1920x1200/60 Hz
2
Headphones/Microphone
10
DisplayPort Display 4K/30 Hz
3
Power Button
11
HDMI Display 4K/30 Hz
4
Mouse
12
Type-C™ Charging Adapter
5
USB Stick
13
Anti-Lost Lock
6
Keyboard
14
Notebook
7
SD Memory Cards
15
Printer
8
Ethernet Router
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is
part of the shipping content. If the Declaration of Conformity is missing, you can
request it by post under the below mentioned manufacturer address.
www.assmann.com
ASSMANN Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
