Digitus DA-70867 Manuel utilisateur

USB Type-C™ Multiport Travel Dock,

6-Port

User Manual

DA-70867

1.0 INTRODUCTION

This is a USB-C to two USB 3.0, HDMI, Micro SD, SD/MMC, Type-C™ Data

and PD Charging Adapter. The USB 3.0 port allows you to connect USB

device or another hub to the host USB-C computer, the USB-C female

port supports both PD Charging and data; the HDMI port allows you to

enjoy high definition picture or video on big screen, and the Micro SD

and SD/MMC port allows you to read information in the memory card

on the host PC. It can work on all PCs and mobile phones which support

DP Alt-mode.

2.0 FEATURES

Interface:

1. Type-C™ Female x1 (connect to Type-C™ host PC with our

equipped Type-C™ M to M cable)

2. Type-C™ Female x1 (for data and PD Charging)

3. USB-A Female x2

4. HDMI Female x1

5. SD slot x1, Micro SD slot x1

Support USB 3.0 super speed (5Gbps) transmission, downward

compatible with USB 2.0

One of the two USB-A port supports BC 1.2, the power of this port

can be up to 7.5W (5V/1.5A)

USB 3.0 port supports to charge and transmit data for the USB device

simultaneously

Support HDMI resolution up to 4Kx2K@30Hz

Type-C™ female port supports both data (5Gbps) and PD Charging

100W (20V/5A)

Multiple USB-C interfaces support plug and play, hot swap

Support Secure Digital v3.0 UHS-I (Ultra High Speed):

SDR12(12.5Mbyte/s)/SDR25(25Mbyte/s)/SDR50(50Mbyte/s)/DDR50(

50Mbyte/s)/SDR104(104Mbyte/s)

Note: Support two card slots to work simultaneously

Support Fast Role Swap of PD 3.0, the connected device will not get

disconnected while plugging in and out PD Adapter

Easy to use and carry

Note: Description of the Detached Type-C™ M to M Cable

It is a USB 3.1 Type-C™ Gen2 Full-featured cable with speed up to

10Gbps; E-marked IC and power output up to 5Amp

This product only functions well with our equipped Type-C™ M to M

cable or cable produced by us that has the same spec with the

original one. So to guarantee the proper functioning of this product,

if the equipped cable is lost by accident, please contact our sales to

buy another cable of the same spec and avoid using cable produced

by other manufacturers.

3.0 SPECIFICATIONS

Input/Output Connector

Input USB-C Female x1 (with our Type-C™ M to

M cable)

Output USB 3.0 Female x2

USB-C Female x1 (for data and Charging)

HDMI Female x1

Micro SDX1

SD/MMCX1

Environmental

Operating Temperature 0°C to +45°C

Operating Humidity 10% to 85% RH (no condensation)

Storage Temperature -10°C to +70°C

Storage Humidity 5% to 90% RH (no condensation)

Power Supply

USB-C Female Port Up to 100W (20V/5A)

4.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and

make sure the following items are contained in the shipping carton:

Main unit x1

User Manual x1

5.0 OPERATION

1) Connect the USB-C Female port of this product to USB-C device.

2) Connect the two USB 3.0 outputs of this product to two USB 3.0/2.0

devices

3) Connect HDMI output of this product to HDTV with one HDMI cable

4) Insert Micro SD, SD/MMC card into the responding slots

5) Connect the USB-C charging port, it can charge for the host

computer and support power for this product simultaneously

Note:

1) Not all USB-C ports support all features of the USB Type-C ™ standard.

Make sure your notebook's USB-C port supports DisplayPort Alternate

Mode (DP-Alt Modi) and USB Power Delivery (PD).

2) The video output capability depends on the graphic card of your

notebook and the connected monitor.

6.0 CONNECTION DIAGRAM

Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is

part of the shipping content. If the Declaration of Conformity is missing, you can

request it by post under the below mentioned manufacturer address.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany

HDMI Display Type-C Host PC

Micro SD

Card

SD Card

Type-C Device Type-C PD

Adapter Mouse U DiSk
