Daikin BRC1D528 Manuel utilisateur

Remote controller

BRC1D528

INSTALLATION MANUAL

4 5

6 8

2 3

1 2

MPCB

P2 P1 P2 P1

1 1

4 5

SETTING

UNIT No.

GROUP

562

1+22

2 3

BRC1D528

Remote controller

4PW23716-1

Installation manual

The kit includes the following parts:

1. Remove the upper part of remote

controller

(Refer to ﬁgure 1)

Insert a minus screwdriver into the slots (1) in the

lower part of the remote controller (2 places), and

remove the upper part of the remote controller.

2. Fasten the remote controller

(Refer

to ﬁgure 2)

For the ﬁeld supplied switch box, use optional accessory

KJB111A or KJB211A.

BRC1D528 Remote controller Installation manual

READ THIS MANUAL ATTENTIVELY

BEFORE STARTING UP THE UNIT. DO

NOT THROW IT AWAY. KEEP IT IN YOUR

FILES FOR FUTURE REFERENCE.

IMPROPER INSTALLATION OR

ATTACHMENT OF EQUIPMENT OR

ACCESSORIES COULD RESULT IN

ELECTRIC SHOCK, SHORT-CIRCUIT,

LEAKS, FIRE OR OTHER DAMAGE TO

THE EQUIPMENT. BE SURE ONLY TO

USE ACCESSORIES MADE BY DAIKIN

WHICH ARE SPECIFICALLY DESIGNED

FOR THE USE WITH THE EQUIPMENT

AND HAVE THEM INSTALLED BY A

PROFESSIONAL.

IF UNSURE OF INSTALLATION PROCE-

DURES OR USE, ALWAYS CONTACT

YOUR DEALER FOR ADVICE AND

INFORMATION.

Remote controller Wood screws

Wall plugs Machine screws

The PC board is mounted in the upper part

of the remote controller. Be careful not to

damage the board with the minus

screwdriver.

for exposed mounting, fasten with the two

included wood screws (Ø4x30) and plugs.

for ﬂush-mounting, fasten with the two

included machine screws (M4x16).

NOTE

Choose the ﬂattest place possible for the

mounting surface. Be careful not to

distort the shape of the lower part of the

remote controller by overtightening the

mounting screws.

Installation manual

BRC1D528

Remote controller

4PW23716-1

3. Wire the indoor unit

(Refer to ﬁgure 6)

Connect the terminals on top of the upper part of the

remote controller (P1, P2), and the terminals of the

indoor unit (P1, P2). (P1 and P2 do not have polarity.)

Wiring speciﬁcations

4. Reattach the upper part of the

remote controller

Refer to ﬁgure 4:

First begin ﬁtting from the clips at the bottom.

If controlling one indoor unit or one

group of indoor units with two remote

controllers

Change the MAIN/SUB changeover switch setting as

described below (Refer to ﬁgure 3).

Set one remote controller to “main”, and the other to

“sub”.

indoor unit

lower part of the remote controller

upper part of the remote controller

wired from the rear

wired from the top

notch the part for the wiring to pass through

with nippers, etc.

NOTE

When wiring, run the wiring away from

the power supply wiring in order to avoid

receiving electric noise (external noise).

Wiring type Size

2 wire 0.75–1.25 mm

NOTE

Peel the shield for the part that has to

pass through the inside of the remote

controller case (

). Refer to ﬁgure 5.

Be careful not to pinch the wiring when

attaching.

NOTE 1.

The switch box and wiring for

connection are not included.

Do not directly touch the PC board

with your hand.

Main remote controller (factory set)

Sub remote controller

NOTE 1.

If controlling with one remote controller,

be sure to set it to “main”.

Set the remote controller before turning

the power supply on.

“

” is displayed for about one minute when the

power supply is turned on. During this time the

remote controller can not be operated.

BRC1D528

Remote controller

4PW23716-1

Installation manual

5. Permission level function

■

If required, you can limit the user action by

restricting the number of operable buttons. Refer

to the chapter "Field settings".

■

For switching between level 1 permission and the

selected level in service, proceed as follows:

Keep the fan speed button pressed,

and press the 3 other indicated keys

simultaneously while keeping the fan speed

button pressed.

Refer to ﬁgure 8.

■

If you want to limit the user action on the remote

controller to be deﬁned as “sub”, start with only

connecting this controller to the unit. Make sure

that this controller is set to “main” (factory set)

ﬁrst, change the permission level to the setting

you prefer and only then set the remote controller

to “sub”.

You can now proceed with connecting the remote

controller to be deﬁned as “main”.

6. Field settings

If optional accessories are mounted on the indoor

unit, the indoor unit setting may have to be changed.

Refer to the instruction manual for each optional

accessory.

Refer to ﬁgure 7.

Procedure

(Refer to ﬁgure 7)

When in the normal mode, press the “ ”

button for a minimum of four seconds, and the

FIELD SET MODE is entered.

Select the desired MODE NO. with the “ ”

button.

During group control, when setting by each

indoor unit (mode No. 20, 21, 22 and 23 have

been selected), push the “ ” button and

select the INDOOR UNIT NO. to be set. (This

operation is unnecessary when setting by

group.)

Push the “ ” upper button and select

FIRST CODE NO.

Push the “ ” lower button and select the

SECOND CODE NO.

Push the “ ” button once and the present

settings are SET.

Push the “

”

button to return to the NORMAL

MODE.

Level Operable buttons

All

• on/off button

• schedule timer button

• temperature adjust button

• operation change/ button

•fan speed button

• air ﬂow direction adjust button

• on/off button

• temperature adjust button

•fan speed button

Unit NO

First Code NO

Second Code NO

Mode NO

Field set mode

Installation manual

BRC1D528

Remote controller

4PW23716-1

Example

If during group setting and the time to clean the air

ﬁlter is set to FILTER CONTAMINATION - HEAVY,

SET MODE NO. to “10”, FIRST CODE NO. to “0”, and

SECOND CODE NO. to “02”.

Notes

NOTE 1.

Setting is carried out in the group

mode, however, if the mode number

inside the parentheses is selected,

indoor units can also be set

individually.

The SECOND CODE number is set to

“01” when shipped from the factory.

Do not make any settings not given in

the table.

Not displayed if the indoor unit is not

equipped with that function.

When returning to the normal mode,

“

” may be displayed in the LCD in

order for the remote controller to

initialize itself.

It is not possible to change ﬁeld

settings on the remote controller that

is set to “sub”.

BRC1D528

Remote controller

4PW23716-1

Installation manual

Mode

No.

Note 1

FIRST

CODE

NO. Description of setting

SECOND CODE NO. Note 2

01 02 03 04

10(20)

Filter Contamination - Heavy/Light

(Setting for spacing time of display time

to clean air ﬁlter)

(Setting for when ﬁlter contamination is

heavy, and spacing time of display time to

clean air ﬁlter is to be halved)

Ultra long

life ﬁlter

Approx.

10.000

hrs.

Approx.

5.000

hrs.

——

Long life

ﬁlter

Approx.

2.500

hrs.

Approx.

1.250

hrs.

Standard

ﬁlter

Approx.

200 hrs.

Approx.

100 hrs.

Long-life ﬁlter type (setting of ﬁlter sign indication

time). (Change setting when ultra-long ﬁlter is

installed)

Long-life

ﬁlter

Ultra-long life

ﬁlter ——

Thermostat sensor in remote controller

Use Not use — —

Spacing time of display time to clean air ﬁlter count

(setting for when the ﬁlter sign is not to be displayed)

Display Do not

display ——

11(21) 0

Setting number of connected Sky Air simultaneous

operation system indoor units (setting for

simultaneous operations system)

Pair Twin Triple Double twin

12(22)

ON/OFF input from outside (setting for when forced

ON/OFF is to be operated from outside).

Forced OFF ON/OFF

operation ——

Thermostat differential changeover (setting for when

using remote sensor).

1°C 0.5°C — —

13(23)

High air outlet velocity (for high ceiling applications).

≤

2.7 m >2.7

≤

3.0 m >3.0

≤

3.5 m —

Selection of air ﬂow direction (setting for when a

blocking pad kit has been installed).

4-way ﬂow 3-way ﬂow 2-way ﬂow —

Selection of air ﬂow function (setting for when using

a decoration panel for outlet).

Equipped Not

equipped ——

Air ﬂow direction range setting.

Upper Normal Lower —

Setting the external static pressure (setting

according to the connected duct resistance)

Normal High static

pressure

Low static

pressure —

15(25) 3

Drain pump operation with humidifying.

Equipped Not

equipped ——

Light

Heavy

Installation manual

BRC1D528

Remote controller

4PW23716-1

Notes

Permission level setting

Level 2 Level 3 — —

Leave home function

Not permitted

Permitted — —

Thermostat sensor in remote controller (for limit

operation and leave home function only)

Use Not use — —

Mode

No.

Note 1

FIRST

CODE

NO. Description of setting

SECOND CODE NO. Note 2

01 02 03 04

NOTES

Zandvoordestraat 300, B-8400 Oostende, Belgium

4PW23716-1
