Operating Manual

Handset Wired

OPERATING

MANUAL

OM-BRC51D-0616(2)-DAIKIN

Part No.: R08019045189B

English

CVR-OM-BRC51D-0616(2)-DAIKIN-EN.1 1CVR-OM-BRC51D-0616(2)-DAIKIN-EN.1 1 8/12/20 3:42:50 PM8/12/20 3:42:50 PM

CVR-OM-BRC51D-0616(2)-DAIKIN-EN.2 2CVR-OM-BRC51D-0616(2)-DAIKIN-EN.2 2 8/12/20 3:42:51 PM8/12/20 3:42:51 PM

BRC51D Controller Indication

BRC51D61/63 Controller Indication

BRC51D62/66 Controller Indication

IR receiver

LCD

LED

1-OM-BRC51D-0616(2)-DAIKIN-EN.ini i1-OM-BRC51D-0616(2)-DAIKIN-EN.ini i 8/12/20 3:41:41 PM8/12/20 3:41:41 PM

ENGLISH

1. fButton

Press once to start the air conditioner unit.

Press again to stop the unit.

2. and Button

Press the or button to increase or decrease the set temperature.

Pressing FAN and

SWING

or VIEW button simultaneously to toggle the temperature

setting between °C and °F.

!NOTE

Room Temperature Display is available for selected models only.–

3. Button

Continuously press for 3 seconds to turn ON/OFF the LED display on wall mounted unit.

4. Button (Model dependent)

Press button to turn ON/OFF Quiet operation.

5. Button (Model dependent)

Press button to turn ON/OFF Powerful operation.

6. Button

Press the button to select the type of operating mode.

For cooling only model, the available modes are: COOL ( ), DRY ( ), FAN ( ).

For heat pump model, the available modes are: COOL ( ), HEAT ( ), AUTO ( ), DRY ( ),

FAN ( ).

7. Button

!NOTE

Idle 10 seconds to exit the clock setting.

The clock setting is in 24-hour clock.

–

A) To set the clock –Press and button simultaneously for 3 seconds.

a. Hour will blink.

b. Press or button to change the Hour.

c. Press

button to confirm the Hour, then Minute will blink.

d. Press or button to change the Minute.

e. Press

button to confirm the Minute, then “MON” will blink.

f. Press

or button to change the Day.

g. Press

button to confirm the Day.

–

OPERATING INSTRUCTION

Original Instruction

1-OM-BRC51D-0616(2)-DAIKIN-EN.in1 11-OM-BRC51D-0616(2)-DAIKIN-EN.in1 1 8/12/20 3:41:41 PM8/12/20 3:41:41 PM

B) ON/OFF Timer Setting – Daily Timer Setting

a. Continuously press for 3 seconds.

b. ON Timer 1 Setting

I. “MON” will blink.

II. Use

or button to select the Day and press button to confirm the Day.

III. Hour will blink. Use or button to toggle between Hour and Minute.

Press or button to change the Hour and Minute.

Press

button to confirm the setting.

IV. Repeat Step II to III for the timer setting of other days.

c. ON Timer 2 Setting

I. Press again to enter ON Timer 2 setting, then “MON” will blink.

II. Use

or button to select the Day and press button to confirm the Day.

III. Hour will blink.

Press or button to change the Hour.

Press button to confirm the Hour, then Minute will blink.

IV. Repeat Step II to III for the timer setting of other days.

d. OFF Timer 1 Setting

I. Press again to enter OFF Timer 1 setting, then “MON” will blink.

II. Use

or button to select the Day and press button to confirm the Day.

III. Hour will blink.

Press or button to change the Hour.

Press button to confirm the Hour, then Minute will blink.

IV. Repeat Step II to III for the timer setting of other days.

1-OM-BRC51D-0616(2)-DAIKIN-EN.in2 21-OM-BRC51D-0616(2)-DAIKIN-EN.in2 2 8/12/20 3:41:41 PM8/12/20 3:41:41 PM

ENGLISH

e. OFF Timer 2 Setting

I. Press again to enter OFF Timer 2 setting, then “MON” will blink.

II. Use

or button to select the Day and press button to confirm the Day.

III. Hour will blink.

Press or button to change the Hour.

Press

button to confirm the Hour, then Minute will blink.

IV. Repeat Step II to III for the timer setting of other days.

C) Activation of ON/OFF Timer

a. Press to activate On Timer. will blink.

b. Press

button for navigation of On Timer selection.

c. Press button to confirm the selection, then will blink.

d. Press

button for navigation of Off Timer selection.

e. Press button to confirm the selection and exit.

!NOTE

It is not advisable to set ON TIMER and OFF TIMER to have same values.

Shall these occur, the effective timer will be treated with priority as stated in table below:

–

Priority Timer

1 (Highest) ON TIMER 2

2 OFF TIMER 2

3 ON TIMER 1

4 (Lowest) OFF TIMER 1

1-OM-BRC51D-0616(2)-DAIKIN-EN.in3 31-OM-BRC51D-0616(2)-DAIKIN-EN.in3 3 8/12/20 3:41:42 PM8/12/20 3:41:42 PM

8. Button

Press button to turn ON/OFF the light on ceiling cassette unit.

Continuously press for 3 seconds to enter Feature selection. SLEEP ( )will blink, use

or button to scroll between SLEEP ( ), ECO+ ( ), POWERFUL ( ), QUIET

( ). Press button to confirm the feature. If any button is not pressed within 10 seconds,

it will exit the Feature selection. Some of the features are available for selected models

only.

Features Remarks

SLEEP ( )Available in COOL, HEAT and AUTO mode only.

ECO+ ( )Set temperature automatically adjust to eco-friendly level.

Available in COOL and HEAT mode only.

POWERFUL ( )

If user presses the FAN button or QUIET button or turn off

the unit, the POWERFUL will be disabled. Available in COOL

and HEAT mode for selected models.

QUIET ( )

If user presses the FAN button or POWERFUL button or

turn off the unit, the QUIET feature will be disabled. Available

in COOL and HEAT mode for selected models.

9. Button

Press button continuously will toggle the fan speed in the following order:

!NOTE

Fan setting is not available in DRY ( ) mode.

FAN ( ) mode does not have Auto fan.

–

Continuously press for 3 seconds to ON/OFF Key Lock function. Only fbutton can

be pressed during Key Lock activation.

10.

SWING

Button

Press

SWING

button to turn ON/OFF the automatic air swing function.

To distribute the air to a specific direction, press

SWING

button and wait until the louver

move to the desired direction and press the button once again to confirm.

Special Swing Mode selection (model dependent)

Continuously press for 3 seconds to enter Special Swing Mode. ( ) will blink. Press and

button to toggle between ,and . Press button for confirmation.

!NOTE

Special Swing Mode will only be activated when SWING is ON.–

11. VIEW

Press VIEW button to turn ON the backlight.

–

1-OM-BRC51D-0616(2)-DAIKIN-EN.in4 41-OM-BRC51D-0616(2)-DAIKIN-EN.in4 4 8/12/20 3:41:42 PM8/12/20 3:41:42 PM

ENGLISH

!NOTE

The LED will blink if error occurred.–

If there is any abnormal condition detected, BRC51D controller will blink the error code. The format

for the error code will be as following:

DX Error Code

ERROR

CODE MEANING

E01 Room Sensor Open or Short

E02 Indoor Coil Sensor Open

E03 Outdoor Coil Sensor Open

E04 Compressor Overload/Indoor Coil Sensor Short/Outdoor Coil Sensor Short

E05 Low Refrigerant Charge/Gas Leak/Outdoor Abnormal

E06 Water Pump Fault

E07 Outdoor Coil Sensor Exist (MS model)

E08 Hardware Error (Tact Switch Pin Short)

E09 Indoor Fan Feedback Error

EE EEPROM Error

CW Error Code

ERROR

CODE MEANING

E01 Room Sensor Open or Short

E02 Pipe Water Sensor Open or Short

E04 Pipe Water Temperature Poor

E05 Pipe Water Temperature Bad/Fault

E06 Water Pump Error

E08 Hardware Error (Tact Switch Pin Short)

E09 Indoor Fan Feedback Error

For Inverter Only

ERROR

CODE MEANING

00 Normal

A1 Indoor PCB Error

A3 Drain Pump Abnormal

A5 Antifreeze (Cooling)/Heat Exchanger Overheat (Heating)

A6 Indoor Fan Motor Abnormal

AH Electrical Air Cleaner Abnormal

C4 Indoor Heat Exchanger (1) Thermistor Short/Open

C5 Indoor Heat Exchanger (2) Thermistor Short/Open

C7 Louver Limit Switch Error

C9 Indoor Room Thermistor Short/Open

ERROR INDICATOR

1-OM-BRC51D-0616(2)-DAIKIN-EN.in5 51-OM-BRC51D-0616(2)-DAIKIN-EN.in5 5 8/12/20 3:41:43 PM8/12/20 3:41:43 PM

ERROR

CODE MEANING

E1 Outdoor PCB Error

E3 High Pressure Protection

E4 Low Pressure Protection

E5 Compressor Motor Lock/Compressor Overloaded

E6 Compressor Start-Up Error

E7 Outdoor DC Fan Motor Lock

E8 AC Input Over Current

E9 EXV Error

EA 4 Way Valve Error

F3 Discharge Pipe Overheat

F6 Heat Exchanger Overheat

Compressor

Sensor System Error

H3 High Pressure Switch Error

H6 Compressor Feedback Detection Error

H7 Fan Motor Overloaded/Overcurrent/Sensor Abnormal

H8 AC Current Sensor Error

H9 Outdoor Air Thermistor Short/Open

J1 Pressure Sensor Error

Compressor Discharge Pipe Thermistor

Short/Open

/Misplaced

J5 Suction Pipe Thermistor Short/Open

J6 Outdoor Heat Exchanger Thermistor Short/Open

J7 Subcooling Heat Exchanger Thermistor Short/Open

J8 Liquid Pipe Thermistor Short/Open

J9 Gas Pipe Thermistor Short/Open

L1 Inverter Outdoor PCB Error

L3 Outdoor Control Box Overheat

L4 Heat Sink Overheat

L5 IPM Error/IGBT Error

L8 Inverter Compressor Overcurrent

L9 Compressor Overcurrent Prevention

LC Communication Error

(Outdoor Control PCB And

Inverter PCB)

P1 Open Phase or Voltage Unbalance

P4 Heat Sink Thermistor Short/Open

PJ Capacity Setting Error

U0 Insufﬁcient Gas

U2 DC Voltage Out of Range

U4 Communication Error

U7 Communication Error (Outdoor Control PCB And IPM PCB)

UA Installation Error

UF Piping & Wiring Installation Mismatch/Wrong Wiring/Insufﬁcient Gas

UH Antifreeze (Other Rooms)

1-OM-BRC51D-0616(2)-DAIKIN-EN.in6 61-OM-BRC51D-0616(2)-DAIKIN-EN.in6 6 8/12/20 3:41:43 PM8/12/20 3:41:43 PM

ENGLISH

1. Accessories

The following accessories are included together with this manual. If any part is missing, contact

your dealer immediately.

1.1 Remote controller

1.2 Screw (2 pieces)

1.3 Operational manual

Screw Handset Operation Manual

(2pcs.) (1pcs.) (1pcs.)

2. Step-by-step guide

2.1 Remove upper case.

Insert a screwdriver in the recess of lower case to remove the upper case (2 points).

Remote controller printed-circuit

board is installed on the upper case.

Be careful not to damage the printed-

circuit board with the screwdriver.

Screwdriver

Lower case

Upper case

Be careful not to let dust or moisture

touch the printed-circuit board.

Insert and twist the screwdriver

'LIGHTLY' for removal.

INSTALLATION

!NOTE

Installation and maintenance should be performed by qualiﬁed persons who are familiar with

local code and regulation, and experienced with this type of appliance.

The wired handset has 3 jumpers option to control the board function.

Table 2.0: Summary of Hardware Settings

OPTION With Jumper Without Jumper

SET TEMP. RANGE Set Temperature : 20°C - 30°C Set Temperature : 16°C - 30°C

* TURBO_QUIET

Deactivate Turbo & Quiet Feature

Activate Turbo & Quiet Feature

ROOM TEMPERATURE Deactivate Room Temperature

Display

Activate Room Temperature

Display

* Note: Turbo & Quiet Feature only applicable to specific model.

HARDWARE SETTING

!NOTE

Hardware setting should be performed by installers or technicians.–

1-OM-BRC51D-0616(2)-DAIKIN-EN.in7 71-OM-BRC51D-0616(2)-DAIKIN-EN.in7 7 8/12/20 3:41:43 PM8/12/20 3:41:43 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Daikin Télécommande

Daikin

Daikin BRC7E530W8 Manuel utilisateur

Daikin

Daikin BRC7GA56 Manuel utilisateur

Daikin

Daikin BRC7C812 Manuel utilisateur

Daikin

Daikin OH08-1 Manuel utilisateur

Daikin

Daikin BRC7CB58 Manuel utilisateur

Daikin

Daikin BRC1D71 Manuel utilisateur

Daikin

Daikin BRC2E52C7 Manuel utilisateur

Daikin

Daikin BRC1E73 Manuel utilisateur

Daikin

Daikin BRC7E83 Manuel utilisateur

Daikin

Daikin G8 Manuel d'installation

Daikin

Daikin BRC1E71 Manuel utilisateur

Daikin

Daikin OM-GS02-0112 Manuel utilisateur

Daikin

Daikin BRC1H71W Manuel utilisateur

Daikin

Daikin BRC1E62 Manuel utilisateur

Daikin

Daikin OM-5RTBR-0709(0)-DENV Manuel utilisateur

Daikin

Daikin Madoka Simplified Manuel utilisateur

Daikin

Daikin BRC1H63K Manuel utilisateur

Daikin

Daikin BRC230Z8A Manuel utilisateur

Daikin

Daikin BRC7M530W Manuel utilisateur

Daikin

Daikin BRC1H63W Manuel utilisateur

Daikin

Daikin VRVWII RWEYQ10MY1 Manuel utilisateur

Daikin

Daikin BRC7E830 Manuel utilisateur

Daikin

Daikin OM-GS02-02110 Manuel utilisateur

Daikin

Daikin ARC423A17 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
