16/24-PORT GIGABIT EASY DESKTOP SWITCH

Manual

Building Networks for People

RECYCLABLE

(December 2013)

V 2.00

D-Link GO-SW-16G/GO-SW-24G GIGABIT EASY DESKTOP SWITCH

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of D-Link Corporation is

strictly forbidden.

Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation;

Microsoft and Windows are registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities

claiming the marks and names or their products. D-Link Corporation disclaims any proprietary

interest in trademarks and trade names other than its own.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with this user’s guide, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own

expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference

in which case the user may be required to take adequate measures.

Warnung!

Dies ist ein Produkt der Klasse A. Im Wohnbereich kann dieses Produkt Funkstoerungen

verursachen. In diesem Fall kann vom Benutzer verlangt werden, angemessene Massnahmen

zu ergreifen.

Precaución!

Este es un producto de Clase A. En un entorno doméstico, puede causar interferencias de radio,

en cuyo case, puede requerirse al usuario para que adopte las medidas adecuadas.

Attention!

Ceci est un produit de classe A. Dans un environnement domestique, ce produit pourrait causer

des interférences radio, auquel cas l`utilisateur devrait prendre les mesures adéquates.

Attenzione!

Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente domestico il prodotto può

causare interferenze radio, nel cui caso è possibile che l`utente debba assumere provvedimenti

adeguati.

VCCI Warning

警告使用者：

這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，使用者會

被要求採取某些適當的對策。

CONTENTS

PREFACE………………………………………………………………IV

NOTES,NOTICES,AND CAUTIONS ............................................................IV

SAFETY INSTRUCTIONS..............................................................................V

Protecting Against Electrostatic Discharge .....................................vii

INTRODUCTION 8

ABOUT THIS GUIDE ...................................................................................8

SWITCH DESCRIPTION ...............................................................................8

Switch Features ..................................................................................9

D-LINK GREEN TECHNOLOGY................................................................10

FRONT-PANEL COMPONENTS..................................................................11

LED Indicators .................................................................................11

REAR PANEL DESCRIPTION.....................................................................13

INSTALLATION 14

Package Contents .............................................................................14

BEFORE YOU CONNECT TO THE NETWORK............................................15

Mounting the Switch on a Rack ........................................................16

POWER ON...............................................................................................17

Power Failure...................................................................................17

CONNECTING THE SWITCH 18

Connect to an End Node...................................................................19

Connect to Hub or Switch.................................................................20

Connect to Network Backbone or Server..........................................21

TECHNICAL SPECIFICATIONS 22

GLOSSARY……………………………………………………………..25

D-Link GO-SW-16G/GO-SW-24G GIGABIT EASY DESKTOP SWITCH

Preface

The GO-SW-16G/GO-SW-24G Manual is divided into sections that describe the

system installation and operating instructions with examples.

Section 1, Introduction - A description of the physical features of the Switch,

including LED indicators, ports and panel descriptions.

Section 2, Installation – A description of the physical installation of the Switch,

mounting the Switch in a equipment rack and powering on the Switch.

Section 3, Connecting the Switch – A description of how to connect your

Switch to an end node, hub, another switch or backbone server.

Appendix Technical Specifications - The technical specifications of the GO-

SW-16G/GO-SW-24G.

Notes, Notices, and Cautions

NOTE:

A NOTE indicates important information

that helps you make better use of your device.

NOTICE: A NOTIC

E indicates either potential

damage to hardware or loss of data and tells you

how to avoid the problem.

CAUTION: A CAUTION indicates the potential for

property damage, personal injury or death.

D-Link GO-SW-16G/GO-SW-24G GIGABIT EASY DESKTOP SWITCH

Safety Instructions

Use the following safety guidelines to ensure your own personal safety and to help protect your

system from potential damage. Throughout this safety section, the caution icon ( ) is used to

indicate cautions and precautions that you need to review and follow.

Safety Cautions

To reduce the risk of bodily injury, electrical shock, fire, and damage to the

equipment, observe the following precautions.

Observe and follow service markings. Do not service any product except as

explained in your system documentation. Opening or removing covers that are

marked with the triangular symbol with a lightning bolt may expose you to an

electrical shock. Only a trained service technician should service components inside

these compartments.

If any of the following conditions occur, unplug the product from the electrical outlet

and replace the part or contact your trained service provider:

– The power cable, extension cable, or plug is damaged.

– An object has fallen into the product.

– The product has been exposed to water.

– The product has been dropped or damaged.

– The product does not operate correctly when you follow the operating

instructions.

•

Keep your system away from radiators and heat sources. Also, do not block

cooling vents.

•

Do not place any device on top of Switch, or place the Switch on top of any

device or object that will block the free flow of air through the ventilation slots on

the sides, top, and bottom of the Switch’s case.

•

Keep your hand away from top and bottom of device that generates a

significant amount of heat.

•

Do not spill food or liquids on your system components, and never operate the

product in a wet environment. If the system gets wet, see the appropriate

section in your troubleshooting guide or contact your trained service provider.

•

Do not push any objects into the openings of your system. Doing so can cause

a fire or an electric shock by shorting out interior components.

•

Use the product only with approved equipment.

•

Allow the product to cool before removing covers or touching internal

components.

•

Operate the product only from the type of external power source indicated on

the electrical ratings label. If you are not sure of the type of power source

required, consult your service provider or local power company.

D-Link GO-SW-16G/GO-SW-24G GIGABIT EASY DESKTOP SWITCH

Safety Instructions (continued)

•

To help avoid damaging your system, be sure the voltage selection Switch (if

provided) on the power supply is set to match the power available at your

location:

– 115 volts (V)/60 hertz (Hz) in most of North and South America and

some Far Eastern countries such as South Korea and Taiwan

– 100 V/50 Hz in eastern Japan and 100 V/60 Hz in western Japan.

– 230 V/50 Hz in most of Europe, the Middle East, and the Far East.

•

Also be sure that attached devices are electrically rated to operate with the

power available in your location.

•

Use only approved power cable(s). If you have not been provided with a power

cable for your system or for any AC-powered option intended for your system,

purchase a power cable that is approved for use in your country. The power

cable must be rated for the product and for the voltage and current marked on

the product's electrical ratings label. The voltage and current rating of the cable

should be greater than the ratings marked on the product.

•

To help prevent an electric shock, plug the system and peripheral power cables

into properly grounded electrical outlets. These cables are equipped with three-

prong plugs to help ensure proper grounding. Do not use adapter plugs or

remove the grounding prong from a cable. If you must use an extension cable,

use a 3-wire cable with properly grounded plugs.

•

Observe extension cable and power strip ratings. Make sure that the total

ampere rating of all products plugged into the extension cable or power strip

does not exceed 80 percent of the ampere ratings limit for the extension cable

or power strip.

•

To help protect your system from sudden, transient increases and decreases in

electrical power, use a surge suppressor, line conditioner, or uninterruptible

power supply (UPS).

•

Position system cables and power cables carefully; route cables so that they

cannot be stepped on or tripped over. Be sure that nothing rests on any cables.

•

Do not modify power cables or plugs. Consult a licensed electrician or your

power company for site modifications. Always follow your local/national wiring

rules.

•

When connecting or disconnecting power to hot-pluggable power supplies, if

offered with your system, observe the following guidelines:

– Install the power supply before connecting the power cable to the power

supply.

– Unplug the power cable before removing the power supply.

– If the system has multiple sources of power, disconnect power from the

system by unplugging all power cables from the power supplies.

•

Move products with care; ensure that all casters and/or stabilizers are firmly

connected to the system. Avoid sudden stops and uneven surfaces.

D-Link GO-SW-16G/GO-SW-24G GIGABIT EASY DESKTOP SWITCH

Protecting Against Electrostatic Discharge

Static electricity can harm delicate components inside your system. To prevent static

damage, discharge static electricity from your body before you touch any of the

electronic components, such as the microprocessor. You can do so by periodically

touching an unpainted metal surface on the chassis.

You can also take the following steps to prevent damage from electrostatic

discharge (ESD):

1. When unpacking a static-sensitive component from its shipping carton, do

not remove the component from the antistatic packing material until you

are ready to install the component in your system. Just before unwrapping

the antistatic packaging, be sure to discharge static electricity from your

body.

2. When transporting a sensitive component, first place it in an antistatic

container or packaging.

3. Handle all sensitive components in a static-safe area. If possible, use

antistatic floor pads, workbench pads, and an antistatic grounding strap.

vii

SECTION 1

Introduction

About This Guide

Switch Description

Switch Features

D-Link Green Technology

Ports

Front-Panel Components

LED Indicators

Power Input on Rear Panel

About This Guide

Congratulations on your purchase of the 16/24-PORT GIGABIT EASY

DESKTOP SWITCH. These devices are using compact plastic case

and are highly flexible solution for SOHO or small office customers.

Switch Description

The 16-port GO-SW-16G and 24-port GO-SW-24G Switches provide

dedicated 10, 100 or 1000 Mbps Ethernet bandwidth on each port. The

ports will automatically detect the speed, duplex and MDI/MDIX status

of the device it is connecting to, and adjust these settings accordingly.

The Switch ports can be used to network computers, printers, servers,

routers, other switches or any device equipped with an Ethernet port.

For best performance, use Category 5 or better Ethernet cabling.

This stand alone Switch is very easy to set up. There is no network

management is required; simply power on the Switch and connect the

cables.

However, please keep in mind that the standard rules of available

Ethernet cable length from one device to another which cannot exceed

100 meters (or 300 feet).

Switch Features

The GO-SW-16G 16-Port and GO-SW-24G 24-port Switches do not

require any management. Both Switches are designed for easy

installation, flexibility and high performance. Connect devices to the

Switch as the scale and volume of network traffic increases.

Support 10/100/1000 Base-T on both 16 and 24 ports models

Store and Forward Switching Method

D-Link Green Technology

Auto Negotiation on Duplex Mode

Auto MDI/MDIX supported

Support Full/Half Duplex Transfer Mode on 10/100 Mbps

Support Full Duplex Transfer Mode on 1000 Mbps

Wire-Speed reception and transmission

8K absolute MAC Address (GO-SW-16G) ; 8K absolute MAC

Address (GO-SW-24G)

2Mbits RAM for data buffering (GO-SW-16G) ; 4.1Mbits RAM for

data buffering (GO-SW-24G)

IEEE 802.3x Flow Control for Full-duplex mode

Back Pressure Flow Control for Half-duplex mode

Jumbo Frame support (9216Bytes)

Support IEEE802.3az EEE

Gigabit Ethernet Technology

Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the

same packet structure, format, and support for CSMA/CD protocol, full

duplex, flow control, and management objects, but with a tenfold

increase in theoretical throughput over 100-Mbps Fast Ethernet and a

hundredfold increase over 10-Mbps Ethernet. Since it is compatible

with all 10-Mbps and 100-Mbps Ethernet environments, Gigabit

Ethernet provides a straightforward upgrade without wasting a

company’s existing investment in hardware, software and trained

personnel.

The increased speed and extra bandwidth offered by Gigabit Ethernet

is necessary to coping with the network bottlenecks; more computers

and their bus speeds getting faster, and more applications generate

more traffic in the network. Upgrading key components, such as your

backbone and servers to Gigabit Ethernet can greatly improve network

response times as well as significantly speed up the traffic between

your subnets.

Gigabit Ethernet supports video conferencing, complex imaging and

similar data-intensive applications. Likewise, since data transfers occur

10 times faster than Fast Ethernet, servers outfitted with Gigabit

Ethernet NIC’s are able to perform 10 times the number of operations in

the same amount of time.

D-Link Green Technology

•IEEE 802.3az Energy-Efficient Ethernet (EEE):

It is the first standard in the history of Ethernet to address proactive

reduction in energy consumption for networked devices. The IEEE

802.3 EEE standard defines mechanisms and protocols intended to

reduce the energy consumption of network links during periods of

low utilization, by transitioning interfaces into a low-power state

without interrupting the network connection.

•Power Saving Technology:

•Power saving by link status.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels D-Link Changer

D-Link

D-Link DES-3528 - xStack Switch - Stackable Manuel

D-Link

D-Link DUB-1340 Manuel utilisateur

D-Link

D-Link DSD-150 - SecureSpot Internet Security... Manuel utilisateur

D-Link

D-Link DWS-3160-24TC Manuel utilisateur

D-Link

D-Link TM DES-6500 Manuel utilisateur

D-Link

D-Link DGS-6600 Series Manuel utilisateur

D-Link

D-Link DES-1100-10P Manuel utilisateur

D-Link

D-Link DXS-3227P - xStack Switch - Stackable Manuel utilisateur

D-Link

D-Link DGS-1216T - Switch Manuel utilisateur

D-Link

D-Link xStack DGS-3420 Series Guide de configuration

D-Link

D-Link DI-707 Manuel utilisateur

D-Link

D-Link DES-2110 Manuel utilisateur

D-Link

D-Link DKVM-16 - KVM Switch Manuel utilisateur

D-Link

D-Link DGS-1100-05PDV2 Manuel utilisateur

D-Link

D-Link Web Smart Switch DGS-1210-16 Manuel utilisateur

D-Link

D-Link DES-3350SR Manuel utilisateur

D-Link

D-Link KVM-440 Manuel utilisateur

D-Link

D-Link DES-108 Manuel utilisateur

D-Link

D-Link DXS-3227 - xStack Switch - Stackable Manuel utilisateur

D-Link

D-Link GO-SW-8GE Manuel utilisateur

D-Link

D-Link DGS-1016D - Switch Manuel utilisateur

D-Link

D-Link DMS-108 Manuel utilisateur

D-Link

D-Link DGS-1210-10P Manuel utilisateur

D-Link

D-Link xStack DGS-3324SRi Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
