Before Your Begin

This Quick Installation Guide gives step-by-step instructions for setting up the D-Link

DES-1008F, DES-1008FL/PRO and DES-1008FR/PRO 10/100M Fast Ethernet

Switches. The model you have purchased may appear slightly different from those

shown in the illustrations.

Check Your Package Contents

These are the items included with your DES-1008F, DES-1008FL/PRO,

DES-1008FR/PRO purchase:

If any of the above items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice.

• DES-1008F, DES-1008FL/PRO,

DES-1008FR/PRO

10/100M Fast Ethernet Switch

• Quick Installation Guide

• 7.5V DC, 1A Power Adapter

Using a powe

supply with a

different voltage rating

will damage and void

the warranty for this

product.

DES-1008F

DES-1008FL/PRO

DES-1008FR/PRO

10/100M Fast Ethernet Switch

Setup The DES-1008F,

DES-1008FL/PRO, DES-1008FR/PRO

10/100M Fast Ethernet Switch

The setup of the Switch can be performed using the following steps:

A. Install the DES-1008F, DES-1008FL/PRO, DES-1008FR/PRO in a fairly

cool and dry place. See Technical Specification for the acceptable

operation temperature and humidity ranges.

B. Install the Switch in a site free from strong electromagnetic source, vibration,

dust, and direct sunlight.

C. Leave at least 10cm of space at the left and right hand side of the Switch

for ventilation.

D. Visually inspect the DC power jack and make sure that it is fully secured to

the power adapter.

Mounting the Switch on a Wall

The DES-1008F, DES-1008FL/PRO, DES-1008FR/PRO can also be mounted

on a wall. Two mounting slots are provided on the bottom of the switch for this

purpose. Please make sure that the front panel is exposed in order to view the

LEDs. Please refer to the illustration below:

A. Mounting on a cement wall

1. Mount the Nylon screw anchors into a cement wall.

2. Drive the T3 x 15L screws into the Nylon screw anchors.

3. Hook the mounting holes of the switch back on the screws; you have

completed the wall-mount.

B. Mounting on a wood wall

1. Drive the T3 x 15 L screws into the wood wall.

2. Hook the mounting holes of the switch back on the screws; you have

completed the wall-mount.

(1) 3/4 inch minimum

for wood wall

(2) 3 inch minimum

for cement wall.

Do not stack any device on the Switch.

Connecting The DES-1008F,

DES-1008FL/PRO, DES-1008FR/PRO

To Your Network

DC Power Jack: Power is supplied through an external AC power adapter.

Since the switch does not include a power switch, plugging its power adapter

into a power outlet will immediately power it on.

Auto-MDI-X Function ports: Use these jacks (port1 ~ port-7) for DES-1008F,

DES-1008FL/PRO, DES-1008FR/PRO to connect stations to the hub. An Auto-

MDI-X function will automatically detect if a crossover is required and make the

swap of TX pair and Rx pair internally. With this function, straight-through cable

can be used for any connection. MDI to MDI-X connection rule is not necessary

anymore. In the switches, all TX ports are equipped with this function. You can

use just straight-through type cables for all your connections.

DES-1008F

DES-1008FL/PRO

DES-1008FR/PRO

100BASE-FX Fiber Port: The DES-1008F Fiber port supports a 100BASE-FX

Duplex SC connector for a 1310 nm Multi-mode fiber link of up to 2 km. The

DES-1008FL/PRO Fiber port supports a 100BASE-FX Duplex SC connector for

a 1310 nm Single- mode fiber link of up to 15 km. The DES-1008FR/PRO

Fiber port supports a 100BASE-FX Single SC connector for a TX1310

nm/RX1550nm Single-mode fiber link of up to 20 km.

Duplex Mode Switch: The switch is to select the operation mode either to run

in full or half duplex mode for 100BASE-FX. When turning the switch to FDX,

the fiber port will run at full duplex or turn to HDX, the fiber will run at half

duplex.

LED Indicators

Power

This LED indicator lights green when the switch is receiving power,

otherwise, it is off.

FDX/Col (Full-Duplex/Collision)

This LED indicator lights green when a respective port is in full duplex

(FDX) mode. Otherwise, it is blinking when collisions are occurring on the

respective port.

100M LINK/ACT(green), 10M LINK/ACT(amber)

This LED indicator lights green when the port is connected to a 100Mbps

Fast Ethernet station, if the indicator blinking green will be transmission or

received data on the 100Mbps network. Otherwise, if the indicator lights

amber when the port is connected to a 10Mbps Ethernet station, if the

indicator blinking amber will be transmission or received data on the

10Mbps network.

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within Australia:

D-Link Technical Support over the Telephone:

1300-766-868

Monday to Friday 8:00am to 8:00pm EST

Saturday 9:00am to 1:00pm EST

D-Link Technical Support over the Internet:

http://www.dlink.com.au

email:[email protected]

Tech Support for customers within New Zealand:

D-Link Technical Support over the Telephone:

0800-900-900

Monday to Friday 8:30am to 8:30pm

Saturday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.nz

email:[email protected]

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within South Eastern

Asia and Korea:

D-Link South Eastern Asia and Korea Technical Support

over the Telephone:

+65-6895-5355

Monday to Friday 9:00am to 12:30pm, 2:00pm-6:00pm

Singapore Time

D-Link Technical Support over the Internet:

email:[email protected]

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within India

D-Link Technical Support over the Telephone:

+91-22-26526741

+91-22-26526696 –ext 161 to 167

Monday to Friday 9:30AM to 7:00PM

D-Link Technical Support over the Internet:

http://ww.dlink.co.in

http://www.dlink.co.in/dlink/drivers/support.asp

ftp://support.dlink.co.in

email: [email protected]

Technical Support

You can find software updates and user documentation on the

D-Link website.

D-Link provides free technical support for customers for the

duration of the warranty period on this product.

Customers can contact D-Link technical support through our

web site or by phone.

Tech Support for customers within the Russia

D-Link Technical Support over the Telephone:

(495) 744-00-99

Monday to Friday 10:00am to 6:30pm

D-Link Technical Support over the Internet

http://www.dlink.ru

email: [email protected]

Technical Support

You can find software updates and user documentation on the D-Link website.

Tech Support for customers within the U.A.E & North Africa:

D-Link Technical Support over the Telephone:

(971) 4-391-6480 (U.A.E)

Sunday to Wednesday 9:00am to 6:00pm GMT+4

Thursday 9:00am to 1:00pm GMT+4

D-Link Middle East & North Africa

D-Link Technical Support over the Internet:

http://support.dlink-me.com

email:[email protected]

Tech Support for customers within Israel:

D-Link Technical Support over the Telephone:

(972) 9-9715701

Sunday to Thursday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.il/support/

e-mail: support@dlink.co.il

Tech Support for customers within Turkey:

D-Link Technical Support over the Telephone:

0090 312 473 40 55

Monday to Friday 9:00am to 6:00pm

D-Link Technical Support over the Internet:

http://www.dlink.com.tr

e-mail: [email protected]

Tech Support for customers within Egypt:

D-Link Technical Support over the Telephone:

+202-2919035, +202-2919047

Sunday to Thursday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://support.dlink-me.com

e-mail: [email protected]

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within South Africa

and Sub Sahara Region:

D-Link South Africa and Sub Sahara Technical Support

over the Telephone:

+27-12-665-2165

08600 DLINK ( For South Africa only )

Monday to Friday 8:30am to 9:00pm South Africa Time

D-Link Technical Support over the Internet:

http://www.d-link.co.za

email:[email protected]
