CYP PU-444HBTE Manuel utilisateur

PU-444HBTE

4 x 8 HDMI / HDBaseT™ Matrix (4 x HDBaseT & 4 x HDMI

Outputs, 5Play™ inc. PoE & Single LAN, up to 100m)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 14/04/2014 First release

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................7

5. Features..................................................7

6. Operation Controls and Functions .......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 9

6.3 Side Panel...................................................10

6.4 Remote Control........................................10

6.5 IR Pin Assignment....................................11

6.6 RS-232 Protocols......................................11

6.7 RS-232 & Telnet Commands.................12

6.8 Telnet Control............................................14

6.9 Web GUI Control ......................................16

7. Connection Diagram .......................... 18

8. Specications...................................... 20

8.1 Technical Specication ..........................20

8.2 CAT5e/6/7 Cable Specication ...........20

8.3 Input Timing Support Chart ................21

1. INTRODUCTION

The PU-444HBTE Matrix enables distribution of four HDMI sources to four

HDBaseT™outputs and four HDMI outputs. Each input is independently

routed to any output for maximum source to screen exibility within any

AV system. The four HDBaseT outputs support the transmission of video

(resolutions up to 1080p Full HD and 1920x1200@60Hz), multi-channel

audio, single LAN serving, and control via 2-way IR, RS-232 or Web GUI/

Telnet IP over a single CAT5e/6/7 cable (up to 100m) for each output.

HDMI outputs support the same video resolutions and high denition

audio via certied HDMI cables up to 15m.

The HDBaseT outputs are designed to be used with any compatible

HDBaseT Receiver as follows: PU-507RX / PU-507RX-2H / PU-507RX-SCD /

PU-507WPRX / PU-1109RX. These Receivers support Power over Ethernet

(PoE) function so do not require a separate PSU for power.

Use the LAN serving capabilities of the matrix to add internet connectivity

to every HDBaseT output zone. In addition, this matrix also features IP

control allowing users to access and control the matrix remotely and also

allow additional options for integration of third-party control systems.

2. APPLICATIONS

HDMI system controls

Video/TV wall display and control

Security surveillance and control

Commercial advertising, displaying and control

Lecture room display and control

3. PACKAGE CONTENTS

1 x 4 by 8 Matrix

8 x IR Extender

8 x IR Blaster

x 24V/3.75A DC Power Supply

1 x Remote Control

1 x Operation Manual

4. SYSTEM REQUIREMENTS

Source equipment with HDMI connection cables

Certied CAT5e/6/7 cables

HDMI over CAT5e/6/7 receivers with Certied CAT5e/6/7 cables

Output displays or AV receivers with HDMI connection cables

5. FEATURES

HDMI, HDCP and DVI complaint

Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,

1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA,

1920x1200@60Hz

High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio plus LPCM (up to 192kHz)

Uncompressed data transfer over single CAT cable for HDBaseT

outputs (100m - CAT6/7; 80m - CAT5e)

Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.

Supports RS-232, 2-Way IR, Manual Selection Buttons, and Web GUI/

Telnet IP for control

HDBaseT outputs support Power over Ethernet (PoE) with compatible

receiver units

Selectable EDID settings - TV (downstream) and STD (xed)

Supports LAN serving to all connected HDBaseT zones

Supports 3D signals

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER LOCK MENU OUT

A1D4

HGFE

1 2 3 4 5 6

1LCM: This monitor displays your setting information with each input

and output selection.

2IR: This IR window accepts the remote control signal of this device

only.

3Power Button & LED: Press this button to turn ON the device and

the green LED will illuminate when the power is ON. When the LED

illuminate in red it is in standby mode.

4LCOK: Press this button to lock all the buttons on the panel and the

LED will illuminate. To unlock, just press it again.

5Menu: Press this button once to select EDID setting from STD(internal)

1 or TV(external) 2 then press it again to conrm the selection. Press

this button every time to conrm the selection.

61~4/A~H & OUT/IN button: Press OUT/IN button rst to select the

output/input then press the number button to make the selection

accordingly. For example, output A~B wish to select input 1 and C~E

wish to select input 2. Press OUT→A→B→IN→1→Menu, and then

press OUT→C→D→E→IN→2→Menu. If the menu button is not

pressed the selection will not be changed.

6.2 Rear Panel

SERVICE

RS232

IP &

ETHERNET

B DA F HE

DC 24V

GND

GND GND

IR OUT

IR IN

ALL

V+

IR IN IR OUT

HDMI IN 1 HDMI IN 2 HDMI IN 3 HDMI IN 4

HDMI OUT CAT5e/6/7 OUT CAT5e/6/7 OUT

HDMI OUT

2 3 4 45 5 5 10 115 6

8 9

1RS-232: This slot is to connect with D-Sub 9pin cable from the PC/

Laptop device for RS-232 control.

Note: This RS-232 obtain routable function that is, from the Matrix it can

send commands to all receivers or from receiver sides it can also send

commands to control the Matrix. In order to allow the receivers to send

command to control the Matrix, a null modern cable/adaptor is required.

In order to allow the receivers to send command to control the Matrix, a

null modern cable/adaptor is required.

2IP & Ethernet: This port is for Telnet and Web GUI control. Connect

and active network system with RJ45 terminated cable (for details,

please refers to RS-232 & Telnet commands and Web GUI Control

sections). Also, it allows Ethernet access when connecting to an active

network source or when any of the CAT outputs has the Ethernet link.

Warning: Please do not connect this port directly to the PC/Laptop as the

Telnet function will not work.

3Service: This slot is to connect with mini USB B type cable for rmware

update only.

4HDMI OUT A/C/E/G: These slots are to connect with HD TV/display for

instant display.

5CAT5e/6/7 OUT B/D/F/H: These slots are to connect with HDMI over

CAT5e/6/7 Receiver for signal extension up to 100m.

6HDMI IN 1~4: These slots are to connect to input source equipment

such as DVD player or Set-Top-Box with HDMI cable or DVI to HDMI

converter cable for input signal sending.

7IR IN 1~4: These slots are to connect with IR Extender included in the

package for IR signal receiving.

8IR OUT 1~4: These slots are to connect with IR Blaster included in the

package for IR signal sending.

9ALL IR OUT: This slot is to connect with the IR Blaster for IR signal

received from receiver sides and send to the source side.

10 ALL IR IN: This slot is to connect with the IR extender for IR signal

receiving and send out to receiver sides.

11 DC24V: This slot is to plug the power cord with adaptor included in

the package and then connect them with AC wall outlet for power

supply.

6.3 Side Panel

1Ventilator: These are fan ventilator area, DO NOT block these area or

cover it with any object.

6.4 Remote Control

1Power: Press this button to

switch ON the device or set it to

standby mode.

2IN: Input ports selection 1~4.

3OUT: Output ports selection

A~H.

CR-110

IN OUT
