CYP EL-42S Manuel utilisateur

EL-42S

4-Way HDMI Switcher with 2 Identical Outputs

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer file, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of fire,

electrical shock and injury to persons.

• To prevent fire or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufficient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v2.00 10/07/2019 Updated format/diagrams

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions.......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 8

6.3 Remote Control.......................................... 9

6.4 RS-232 Remote Control Protocol ......... 9

6.5 RS-232 Commands.................................... 9

7. Connection Diagram .......................... 10

8.Technical Specifications...................... 11

1. INTRODUCTION

The EL-42S switcher allows the user to input four HDMI sources and

switch between these sources to display HD content on 2 displays. This

switcher can be controlled via the supplied remote control, RS-232, or by

using the input switching button on the front of the device.

2. APPLICATIONS

Home Cinema/Entertainment

Lecture Room/Hall Presentation

Show Room/Demo Room

Public Commercial Display

Information Board

3. PACKAGE CONTENTS

4-Way HDMI Switcher with 2 Identical Outputs

1×IR CR-32 Remote Control

5 V/2.6 A DC Power Adaptor

Operation Manual

4. SYSTEM REQUIREMENTS

Input source equipment such as Blu-ray/DVD/PS3 player or Set-Top-Box

and output HDMI TV/Display with connection cable)

5. FEATURES

v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

HDMI 4 Way Switcher with 2 Identical Outputs

Resolutions Supported: PC - VGA, SVGA, XGA, SXGA, UXGA & WUXGA

(1920x1200). HDTV - 480i, 576i, 480p, 576p, 720p, 1080i, 1080p and

1080p24fps

High Denition Audio supported - Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio plus LPCM

Auto signal enhancement feature can improve signal quality after

long distance transmission

RS232 & IR Remote Control

Supports 'Deep Colour' (10 & 12 bit)

Dual HDMI outputs for simultaneous connection to two HD Displays

Supports 3D signals

Supports xvYCC

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWERINPUT

4321

1 2 3

1IR Window: This IR Receiver receives the remote control signal from

the included remote control

2HDMI input Select/Indicator: Press the "Input" button sequentially

to switch to your desired input (HDMI 1 to HDMI 4), the LED will

illuminate to indicate which input source is selected

3POWER Switch/Indicator: Press the "POWER" button to turn on/o

the power, the power LED illuminate in red colour means the power is

turned on, when the LED not illuminate power is turned o.

6.2 Rear Panel

RS-232

HDMI OUTHDMI OUT

2 1

HDMI IN

DC 5V

1 3 42

1HDMI Outputs 1 and 2: Connect each of the output ports to the

HDMI display. When more than one output connected, the HDMI

outputs play identical video signal simultaneously.

2RS232: 9-pin D-Sub connector for connecting to your PC or other

control console for remote control.

3HDMI Inputs 1 to 4: Connect each of the input ports to the HDMI or

DVI output of your source equipment such as DVD player or set-top-

box.

4Power: Plug the 5V DC power supply into this unit and connect the

adaptor to AC wall outlet.

6.3 Remote Control

1Power: Press the button to turn on/o the unit.

2Direct input selector: Press 1, 2, 3 or 4 to select

the desired input source.

6.4 RS-232 Remote Control Protocol

Splitter Remote Controller

Pin Definition Pin Definition

1NC 1NC

2TxD 2RxD

3RxD 3TxD

4NC 4NC

5GND 5GND

6NC 6NC

7NC 7NC

8NC 8NC

9NC 9NC

Baud Rate: 9600 bps

Data bit: 8 Bits

Parity: None

Stop Bit: 1 bit

6.5 RS-232 Commands

RS-232 command Operation

POWER 00 Select power OFF

POWER 01 Select power ON

PORT 01 Select port 1

PORT 02 Select port 2

PORT 03 Select port 3

PORT 04 Select port 4

7. CONNECTION DIAGRAM

RS-232

HDMI OUT HDMI OUT

2 1

HDMI IN

DC 5V

HDTV Projector

RS-232 Control System

RS-232

HDMI Outputs

PSU

HDMI Inputs

Set-top Box Games Console

Satellite Receiver Blu-ray Player
