Creality CR-M4 Manuel utilisateur
CR-M4
CR-M4
CREATE REALITY，ACHIEVE DREAMS
3D Printer User ManualV1.4
To Our Dear UsersThank you for choosing Creality. To make using our products easier, please read this User Manual before you start andfollow the instructions provided carefully.Creality is always ready to provide you with high-quality services. If you encounter any issues or have any questions whenusing our products, please use the contact information at the end of this manual to contact us.To further improve your user experience, you can find more about our devices via the following methods:User manual: You can find instructions and videos in the SD card provided with the printer.You can also visit our official website (https://www.creality.com) to find information regarding software, hardware,contact information, device instructions, device warranty information, and more.Firmware UpgradePlease visit our official website https://www.creality.com/download, switch to your language, then select your printerand model. Download the required firmware and install it to use it with your printer.
NOTES 1
2
3
4
5
6
7
8
9
10 Do not use the printer any way other than described here in order to avoid personal injury or property damage.Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.Before using experimental or exotic filaments, we suggest using standard filaments such as ABS or PLA to calibrate and test the machine.Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.Do not wear gloves or loose clothing when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.When cleaning debris from the printer hotend, always use the provided tools. Do not touch the nozzle directly when heated. This can cause personal injury.Children under 10 years old should not use the printer without supervision. 11
12 This machine is equipped with a security protection mechanism. Do not manually move the nozzle or printing platform mechanism manually while booting up, otherwise the device will automatically power off for safety.Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material off the frame,guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface. Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circustance.Do not touch the nozzle, hotbed or motor while the printer is in operation, otherwise you may get burned.
Contents
Equipment Introduction 01-01
02-02
03-03
04-09
10-10
11-11
12-13
14-15
16-17
18-20
Equipment Parameters
Parts List
Product Installation
Equipment Connecting
Start Printing
Filament Infill
Adjusting Pulley tightness
Auto Leveling
Print Method
21-22Routine Maintenance
23-23Circuit Connecting
1. Equipment Introduction1Z-axis Cable Drag Chain
1
2
2X-axis Limit Switch
3Extruder Extrusion Kit
4
4Printing Platform
5Y-axis Tensioner
6USB Flash Drive Port
8
7
7
Type-c port
13
14
8
Material rack
9
Filament Detection
5
6
10
X-axis Cable Drag Chain
10
9
11
X-axis Tensioner
18
19
20
15
16
17
12
Display screen
3
13
Y-axis Motor
14
Pull Rod
15
X-axis Motor
16
Power Switch
17
Z-axis Motor
18
19
20
Y-axis Limit Switch
01
RJ45 Network Interface
Camera Interface
11
12
2. Equipment Parameters
Model
Language
Print Method
Forming process
Number of Extruder
Printing Size
Slice Thickness
Printing Speed
Nozzle Diameter
Nozzle temperature
Filaments
Supported File Format
Power Loss Recovery
Rated Voltage
Filament Detection
CR-M4
USB drive/WiFi/Type-C cable/RJ45 cable
FDM
1
450*450*470mm
0.05-0.35mm
≤ 120 mm/s, generally 50 mm/s
0.4 mm (0.6/0.8 mm optional)
STL/OBJ/AMF
PLA/PETG/TPU/ABS/PLA-Wood/PA/PLA-CF
Yes
100-240V~ 50/60Hz
Yes
Operating System
Rated Power
WIN/MAC/Linux
800W
Basic Parameters
Hotbed temperature
English/ 中文/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk
≤100℃
Ambient Temperature 5℃~35℃
≤300℃
02
3. Parts List
03
Tips: the above accessories are for reference only. Please refer to the physical accessories!
1Base Component 2Gantry Frame Assembly
7Material Rack and
Filament Sensor
8Material Barrel × 2
4Display screen 5Display Screen Frame
9Filament
3 Z-axis Cable Drag Chain
10 Cutting Plier
14 USB Flash Drive
12 Power Cable
11 Blade
Hexagon Socket
Head Cap Screw
M5*45 × 4
20
23 Hexagon Socket
Button Head Screw
M5*10 × 2
24
Hexagon Socket
Button Head Screw
M5*25 × 2
19 M5 Flat Gasket × 2 21 Hexagon Socket
Button Head Screw
M4*20 × 3
Wrench and
Screwdriver
18
22 Countersunk Screw
M3*5 × 3
Cable Tie
15 1.2mmNozzle Cleaner
16 Nozzle Cleaner
17
13 Nozzle Kit
Accessory kit
6Pull Rod x 2
25 0.8mm Nozzle
22
04
4.1 Installation of X-axis Cable Drag Chain
A. Insert the extruder adapter terminals nto the appropriate interfaces.
B. Fix the front end of the X-axis cable drag chain to the extruder back support plate with 3 M3*5 screws.
C. Align the clips and then apply gentle pressure to assemble the drag chain at the rear end of the X-axis.
4.Device InstallationFigure A Figure B Figure C
2Gantry Frame Assembly
22 Countersunk Screw M3*5 × 3
20 20
1
4.2 Gantry Frame Installation
Place the gantry frame on the base slot and pre-fix it first with 4 M5*45 screws aligned with the holes, then tighten to secure it.
05
4.Device Installation Hexagon Socket Head
Cap Screw M5*45 × 4
20
1Base Component
