PAVIRO End‑of‑line supervision module

PVA‑1WEOL

en User manual

PAVIRO End-of-line supervision

module Table of contents | en 3

Bosch Security Systems B.V. 2019-01 | V2 | F01U350870

Table of contents

1Short information 4

2Installation 5

3Technical data 10

4Standards and compliancy 13

5Compatibility with older EOL modules 14

4en | Short information PAVIRO End-of-line supervision

module

2019-01 | V2 | F01U350870 Bosch Security Systems B.V.

1 Short information

The End-of-line (EOL) supervision module monitors the integrity of a

loudspeaker line and can be used in applications where continuous

business music is requested.

In combination with the EOL master, integrated in every Controller and

Router of the PAVIRO system, the loudspeaker line can be monitored

for short and open circuits.

The status LED on the module can be used to check the installation. For

more information, refer to the user documentation for the IRIS-Net,

Controller or Router.

Parts included

Quantity Component

1 End-of-line supervision module

1 Set of screws

1 User manual

PAVIRO End-of-line supervision

module Installation | en 5

Bosch Security Systems B.V. 2019-01 | V2 | F01U350870

2 Installation

To install the End-of-line supervision module you have to:

– Mount the module.

– Set the module address.

– Connect the module to the speaker line.

– Connect the module to earth or ground.

– Check the installation.

Figure2.1: End-of-line supervision module

Item Description

1 DIP switch S1

2 DIP switch S2

3 Status LED

4 Connector (Speaker line + / Speaker line - / Earth)

6en | Installation PAVIRO End-of-line supervision

module

2019-01 | V2 | F01U350870 Bosch Security Systems B.V.

Mount the module

Caution!

Make sure all safety regulations are observed. Mounting the

module on spacers is strongly recommended.

Set the module address

Before connecting the module, a module address must be set with the

DIP switches S2 and S1 (see previous figure and following table). The

module address allows for identification of the affected loudspeaker

line in case an error occurred, such as an open-circuit.

6 5 4 3 2 1 Module

address

DIP switch S2 DIP switch S1

43214 321

OFF OFF OFF OFF OFF OFF 0 (not

connected)

OFF OFF OFF OFF OFF ON 1

OFF OFF OFF OFF ON OFF 2

OFF OFF OFF OFF ON ON 3

OFF OFF OFF ON OFF OFF 4

OFF OFF OFF ON OFF ON 5

OFF OFF OFF ON ON OFF 6

OFF OFF OFF ON ON ON 7

PAVIRO End-of-line supervision

module Installation | en 7

Bosch Security Systems B.V. 2019-01 | V2 | F01U350870

6 5 4 3 2 1 Module

address

DIP switch S2 DIP switch S1

43214 321

OFF OFF ON OFF OFF OFF 8

OFF OFF ON OFF OFF ON 9

OFF OFF ON OFF ON OFF 10

OFF OFF ON OFF ON ON 11

OFF OFF ON ON OFF OFF 12

OFF OFF ON ON OFF ON 13

OFF OFF ON ON ON OFF 14

OFF OFF ON ON ON ON 15

OFF ON OFF OFF OFF OFF 16

OFF ON OFF OFF OFF ON 17

: : : : : :

ON ON ON ON OFF OFF 60

OFF Reserved

OFF To activate the

status LED for

five minutes,

8en | Installation PAVIRO End-of-line supervision

module

2019-01 | V2 | F01U350870 Bosch Security Systems B.V.

6 5 4 3 2 1 Module

address

DIP switch S2 DIP switch S1

43214 321

set the switch

to OFF and

back to ON.

Tab.2.1: DIP switch settings on the module (the settings on delivery are

shown in bold)

Notice!

The module address must be unique within each zone

topology (each controller, router, or amplifier).

Connect the module to the speaker line

Connect the speaker line wires to the plus (+) and minus (-) contacts of

the connector. Make sure the capacitance limit of parallel connected

speaker lines is not exceeded, as described in Technical data, page 10.

Connect the module to earth or ground

Use the earth contact on the connector to connect the module to earth

or ground. To make this connection, you can use:

– a short wire to earth or ground near the installed module,

– the cable shield, or

– any free wire on the cable.

PAVIRO End-of-line supervision

module Installation | en 9

Bosch Security Systems B.V. 2019-01 | V2 | F01U350870

Notice!

The connection to earth or ground should be

below 1kOhm to enable good communication

between the module and the EOL-Master.

Check the installation

Use the LED on the module to check the connection to the speaker line

and earth:

1. Activate the LED for five minutes, by setting switch 4 on DIP switch

S2 to OFF and back to ON.

2. Use the following table to check the status of the installation.

Status LED Description

OFF No voltage supply (for example,

pilot tone is deactivated).

Slow flashing (2Hz) Correct power supply (pilot tone

is on the speaker line). Module is

ready.

Rapid flashing (10Hz), every 40

seconds

A valid command is being

received from the EOL Master.

This indicates a good ground

connection.

Tab.2.2: Status LED for checking installation

10 en | Technical data PAVIRO End-of-line supervision

module

2019-01 | V2 | F01U350870 Bosch Security Systems B.V.

3 Technical data

The technical data in this section is valid for PVA-1WEOL hardware

version 1.2 and firmware version 1.3 in combination with PVA-4CR12 or

PVA-4R24 hardware version 02/00. For information on previous

versions, see Compatibility with older EOL modules, page 14.

Electrical

Power supply 18-22kHz, 8 Veff, 20mW

Wire limits

Minimum RG3MΩ

Maximum Cg 2500nF

Number of modules 60

Mechanical

Product dimensions (Height x Width x

Depth)

15 mm x 78 mm x 60mm

Net weight 30g

Environmental

Operating temperature -5°C to +45°C
