Bosch Professional GCY 42 Instructions de montage

IMPORTANT:

Read Before Using

IMPORTANT :

Lire avant usage

IMPORTANTE:

Leer antes de usar

For English Version

See page 2 Version française

Voir page 25 Versión en español

Ver la página 49

Operating/Safety Instructions

Consignes de sécurité/d’utilisation

Instrucciones de funcionamiento y seguridad

1-877-BOSCH99 (1-877-267-2499)

www.boschtools.com

GCY42

Call Toll Free for

Consumer Information

and Service Locations.

Pour obtenir des informa-

tions et les adresses de

nos centres de service

après-vente, appelez ce

numéro gratuit.

Llame gratis para obtener

información para el con-

sumidor y ubicaciones de

servicio.

2610051886.indd 1 3/8/19 2:18 PM

Safety Symbols

The deﬁnitions below describe the level of severity for

each signal word. Please read the manual and pay atten-

tion to these symbols.

This is the safety alert symbol. It

is used to alert you to potential

personal injury hazards. Obey all

safety messages that follow this

symbol to avoid possible injury

or death.

DANGER indicates a hazardous

situation which, if not avoided,

will result in death or serious

injury.

WARNING indicates a hazardous

situation which, if not avoided,

could result in death or serious

injury.

CAUTION indicates a hazardous

situation which, if not avoided,

could result in minor or moder-

ate injury.

2610051886.indd 2 3/8/19 2:18 PM

Table of Contents

General Safety Rules...................................................4

Getting to Know your Connectivity Module ...................10

Assembly................................................................13

Operating Instructions ..............................................15

Maintenance and Storage ..........................................22

Warranty information................................................23

2610051886.indd 3 3/8/19 2:18 PM

Only use Button/coin cell 3V lithi-

um CR2032 battery. Do not use

any other button/coin cells or other forms of electrical power

supply.

Ensure that battery replacement

is carried out properly. There is a

risk of explosion.

Chemical Burn Hazard. Keep bat-

teries away from children. This

product contains a lithium button/coin cell battery. If a new

or used lithium button/coin cell battery is swallowed or en-

ters the body, it can cause severe internal burns and can lead

to death in as little as 2 hours. If you think a battery might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

Always completely secure the

connectivity compartment. If the

General Safety Rules

Read all safety warnings and all

instructions. Failure to follow the

warnings and instructions may result in electric shock, ﬁre

and/or serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE

REFERENCE

2610051886.indd 4 3/8/19 2:18 PM

connectivity compartment does not close securely, stop us-

ing the product, remove the battery, and keep it away from

children.

When discarding batteries, insu-

late the ‘+’ and ‘–’ terminals with

insulating tape. When disposed of improperly, lithium bat-

teries may short, causing them to become hot, burst or ignite.

Never dispose of the batteries in a

ﬁre or expose to high heat. The

batteries may explode.

Follow all instructions and warn-

ings provided by your Bluetooth®

device manufacturer. Failure to follow recommended pro-

cedures could result in personal injury or property damage.

Exercise extreme caution when

using Bluetooth® devices to con-

trol or change power tool functions. Operation of the de-

vice may be in a diﬀerent area than the paired power tool.

Paired devices may have functionality which allows timed

event programming, including automatically powering on

(e.g. ﬂood light). Depending upon the power tool, these un-

attended operations or function changes without direct line

of sight to the paired tool could result in personal injury or

property damage.

SAVE THESE INSTRUCTIONS

2610051886.indd 5 3/8/19 2:18 PM

Always check tool settings before

use. Settings may be diﬀerent

than when the tool was last used. The connectivity module

enables transfer of data and settings based on Bluetooth®

wireless technology. With module installed, select tool set-

tings may be changed remotely by a paired Bluetooth® de-

vice and user installed app.

The connectivity module GCY42

is equipped with a radio interface.

Local operating restrictions, e.g. in military sites or hos-

pitals, are to be observed. Transmitters have demonstrat-

ed an ability to unintentionally interfere with other devices.

THINK SAFETY

SAFETY IS A COMBINATION OF OPERATOR COMMON

SENSE AND ALERTNESS AT ALL TIMES WHEN THE CON-

NECTIVITY MODULE IS BEING USED.

SAVE THESE INSTRUCTIONS

2610051886.indd 6 3/8/19 2:18 PM

FCC Caution

The manufacturer is not responsible for radio interference

caused by unauthorized modiﬁcations to this equipment.

Such modiﬁcations could void the user’s authority to oper-

ate the equipment.

This device complies with Part 15 of the FCC Rules. Opera-

tion is subject to the following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received, in-

cluding interference that may cause undesired operation.

NOTE! This equipment has been tested and found to com-

ply with the limits for a Class B digital devices, pursuant to

Part 15 of the FCC rules. These limits are designed to pro-

vide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular in-

stallation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment oﬀ and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

SAVE THESE INSTRUCTIONS

2610051886.indd 7 3/8/19 2:18 PM

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweenthe equipmentandre-

ceiver.

• Connecttheequipmentintoanoutletonacircuitdierent

from that to which the receiver is connected.

• Consultthedealeroranexperiencedradio/TVtechnician

for help.

“Exposure to Radio Frequency (RF) Signals: The wireless

device is a radio transmitter and receiver. It is designed and

manufactured not to exceed the emission limit for exposure

to radio frequency (RF) energy set by the Ministry of Health

(Canada), Safety Code 6. These limits are part of compre-

hensive guidelines and established permitted levels of RF

energy for the general population.

These guidelines are based on the safety standards previ-

ously set by international standard bodies. These standards

include a substantial safety margin designed to assure the

safety of all persons, regardless of age and health.

This device and its antenna must not be co-located or oper-

ating in conjunction with any other antenna or transmitter.

SAVE THESE INSTRUCTIONS

2610051886.indd 8 3/8/19 2:18 PM

SAVE THESE INSTRUCTIONS

Industry Canada

This device complies with Industry Canada licence-exempt

RSS standard(s). Operation is subject to the following two

conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including inter-

ference that may cause undesired operation of the device.

The Bosch GCY42 with an FCC ID number TXTGCY42 is an

approved Bluetooth® low energy module for usage in power

tools. You can ﬁnd this FCC ID on the back side of the GCY42

as shown in the drawing.

2610051886.indd 9 3/8/19 2:18 PM

Product Features

The numbering of the product fea-

tures refers to the illustrations on

the graphics pages.

1Button/coin cell battery.

2Connectivity module GCY42.

3Placeholder (part of the power

tool – not included).

4Cover of connectivity module

(part of the power tool – not in-

cluded).

Getting to Know your GCY42 Connectivity

Module

2610051886.indd 10 3/8/19 2:18 PM
