ZKTeco Aurora T1 Manuel utilisateur

Quick Start Guide

urora T1

Version: 1.0

Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the

actual product and the written information in this manual.

-1-

1. Overview

2. Packing List

Front View

Fingerprint Sensor

Time Display Area

Indicator

Device 5V Power Screws

Power Interface

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

9448A

Double Coated Tissue Tape 3M

9448A

Double Coated Tissue Tape

3M Tape

Speaker

Side View

Rear View

User Guide

-2-

3. Device Installation

Mount on the Desk

Mount on the Wall

4) Use the 3M double-sided tape to fix the device on the desktop.

1) Hold the Device with both the hands, and rotate the back cover to 180 degree to

disassemble the Device.

2) Pass the power cable through the wiring hole of the back cover and insert it into the

power interface.

3) After wiring the power cable, push the back cover onto the Device, and rotate it in the

clockwise direction to close it.

1) Hold the Device with both the hands, rotate the back cover to disassemble the Device.

2) Pass the power cable through the wiring hole of the back cover and insert it into the

power interface.

3) Push the back cover on the wall then drill holes, and then fix it with expansion

tubesand screws.

4) Attach the Device onto the back cover, and rotate the Device in the clockwise

direction to close it.

-3-

1. Connect the Device

Step 1: Software Application Access

In the software, the users need to be added and set with Mobile App access on the Web

in advance. Then the users can activate the Mobile App account and login to the mobile

App. Each account can only be bound to one phone.

Email: The account for logging in to the App.

User Permission: Select the User Role with Admin access.

APP Access: Select Enable APP Access to enable the user to use the APP.

Assign License: Click to assign App license for the users.

Home Cont acts Work Device My Company

Org anization

Custom Field

Employe e

General Persona l Do cument Device Ac cess APP Access

Yang Kaijin

1190130

Zk0

Yang

Account I nfor mation

Ema il Use r Permis sion

nati ve.yan g@zkte co.com

APP License

APP A ccess

Ena ble APP A ccess Dis able AP P Access

Assig n Licen se

Lic ense Ke y

B40 25E65- F2FE-4 B82-8 BFE-89 08E

Eﬀe ctive D te

202 0-07-0 6

Exp irati on Dte

202 0-08-0 5

Inv ite use r to download an d use the A PP

Inv ite

Save Clear Ac count

5 6

4. Connect the Device

Step 2: Create the Area

In the software, the device areas need to be created on the Web in advance.

Click Work > Device >Area on the Web.

Code: Enter the serial number of the device.

Area Name: Create the name of the area.

Dashboard

Yang

6192202300106

Attenda nce Policy

App roval Settings

Schedule

Employe e

Device

Area

Ass ignment

Field Work

Daily Activity

Report s

Area

Aurora T1

Home Cont acts Work Device My Company

Code Area Name

Aurora T1

Purpose

Attenda nce

Superior

Select

Remark

DeleteSave

Step 3: Download APP

-4-

-5-

Step 4: Activate and login the APP account

Open the ZKBioCloud APP, enter the registered account and password on the App

interface, and then login after the account is activated.

-6-

Power on the Device. Switch to the Work interface in the ZKBioCloud APP; tap

Device to enter the Device management interface; tap in the upper right corner

to add the Device; select the Bluetooth Device, and the phone will automatically

search for the device.

Step 5: Bind Device

1. In the mobile phone turn on the bluetooth function, and the location

service.

Note:

2. The device needs to be close to the phone to avoid the search failure.

Work

Work B etter

Toget her

Attendan ce Devi ce

Mess age Work

Home

Cont act Me

Device Management

Sea rch

Aurora T1

Auro ra T1

Device Management

Sea rch

Aurora T1

Auro ra T1

Scan QR Code

Bluetooth Device

Can cel

-7-

Device Management

Sea rch

Aurora T1

Auro ra T1

2After the bluetooth connection is successful, it will automatically navigate to the

"Network Setup" page. Select the corresponding wifi, and enter the password. (The

Device flashes yellow when it connects the Wifi successfully, and after it is

successfully connected to the server, the light turns to green.)

When the Device is successfully connected to the network, the Device name, Time Zone

and Area can be changed according to the actual requirement.

After the successful connection of the Device, the server automatically sends data to the

Device.

Net work Se tup

Dev ice SN: 5 90019 51000 48

SSI D

Pass word

Dev ice Mod el: Auro ra T1

Sca nning B lueto oth Dev ice...

Dev cie Nam e Auro ra T1 >

Tim e Zone (UTC +07:0 0) Bang kok >

Area TE >

Dev ice Set up

Complete

-8-

Emp loyee Prole

Yang Kaijin

Enr oll Bio metri c Temp late

Gen der Other

Bir th Date

SSN

Dep artment ZK0

Emp loyee ID 1190130

Position

Hir ed Date 2020/07/07

Mob ile

Pho ne

E-m ail

Enroll Fingerprint

Enro ll Fing erpri nt time o ut

Can cel Retry

Work

Work B etter

Toget her

Attendan ce Devi ce

Mess age Work

Home

Cont act Me

Attendance

My Wor k

Ove rvie w

My Re quest

Timeshee t

Das hboar d

My Team

App roval

5. Enroll Fingerprint

Switch to the Work interface in the ZKBioCloud APP, tap My Team in the Attendance

list interface, and then select the employee who needs to enroll fingerprint. Tap Enroll

Biometric Template, then select the Enroll Fingerprint, and then register the

fingerprint on the Device according to the prompts of the Device.

Emp loyee Prole

Yang Kaijin

Enr oll Bio metri c Temp late

Gen der Other

Bir th Date

SSN

Dep artment ZK0

Emp loyee ID 1190130

Position

Hir ed Date 2020/07/07

Enroll Face

Can cel

Enroll FP

-9-

6. Punch/Verify

Work

Work B etter

Toget her

Attendan ce Devi ce

Mess age Home

Cont act

Attendance

My Wor k

Ove rvie w

My Re quest

Timeshee t

Das hboar d

My Team

App roval

After successful enrollment, the user can punch on the device, or through the APP.

The following figure shows the punch records on the APP:

Timesheet

01 02 03 04

05 06 07 08 0 9 10 11

12 13 14 15 1 6 17 18

19 20 21 22 2 3 24 25

26 27 28 29 3 0 31

Mon ,202 0/07 /06

02:4 5

Che ck In

Che ck Out

02:4 5

Pin gshan 1 88 Gong ye Avenu e and Yukan g Road

nte rsect ion West 1 50 Mil Do nggua n Guang dong C. ..

Pin gshan 1 88 Gong ye Avenu e and Yukan g Road

nte rsect ion West 1 50 Mil Do nggua n Guang dong C. ..

July 2020

Sun Mon Tue Wed Thu Fri Sat
