XtendLan DPC-D241-1 Manuel utilisateur

BUS

S1+ S2+ S-

1 2

MIC adjustment

Lock Control Jumper

Camera Code DIP

Main Connect Port

1 2 3

SPK adjustment

• Fullmetalcoverwithbacklightnameplate

• 4Doorcamerasconnection

• Directlyconnect2separatelocks,unlockmodeandunlocktimecontrolledbyMonitor

Terminal Descriptions

Parts and functions

Name

Camera Lens

Night View LED

Speaker

Nameplate

Call Button

Microphone

90 mm

176 mm

23 mm

Door Camera - DPC-D241-1 User Manual

Inner Power 1 Lock Connection

• Lock Control Jumper: Toselectthelocktype:whenconnectingaElectromechanicallock,setthejumperin1-2

position;whenconnectingaElectromagneticallock,setthejumperin2-3position.

• Camera Code DIP: Total4Cameracanbesupported

1 2

SettotherstCamerawhenmultiCamerasaretobeinstalled;

SettotheCamerawhenthereisonlyoneCameratobeinstalled;

1 2

SettothesecondCamerawhenmultiCamerasaretobeinstalled;

1 2

SettothethirdCamerawhenmultiCamerasaretobeinstalled;

1 2

SettothefourthCamerawhenmultiCamerasaretobeinstalled;

• Main Connect Port:Toconnectthebuslineandtheelectroniclocks.

• BUS:Connecttothebusline,nopolarity.

• PL:Externallockpowerinput,connecttothepowerpositive(power+).

• S1+,S2+:Lockpower(+)output,toconnect2locks.

• S-:Lockpower(-)output,connecttothepower(-)inputoflocks(onlywhenusingthecameratopowerthelocks,

ifusingtheexternalpowersupplyforthelocks,theS-willnotbeconnected).

Thestandardinnerpowerlockconnection,usetheCamerapowertosupplythelock,noneedforexternalpower

supply.TheUnlockModeinthemonitorneedtobeset:forPower-to-Unlocktypelock,UnlockModesetto0(in

Monitor,gotoMain-->Setup-->AdvancedSet-->Informationpage,thenpressandholdtheUnlockButtonfor2

secondstoopentheUnlockModesettingpage);forPower-Off-to-Unlocktypelock,UnlockModesetto1.

1 2

1 2 3

to Monitor

BUS PL S1+ S2+ S- BUS PL S1+ S2+ S-

Jumper position in 1-2

Unlock Mode

0: power-on-to-open

1: power-off-to-open

The lock consumption must not

greater than 12V 500mA.

Electromechanical lock

1 2

1 2 3

to Monitor

Jumper position in 2-3

The lock consumption must not

greater than 12V 300mA.

Electronmagnetical lock

CALL

UNLOCK

TALK/MON

IN-USE

Unlock Mode

0: power-on-to-open

1: power-off-to-open

CALL

UNLOCK

TALK/MON

IN-USE

Connection for Electromechanical lock Connection for Electromagnectical lock

Directlyconnect2electroniclockstothedoorstationandusetheCamerapowertosupplythelocks.Thereare2

separateunlockiconsonMonitorforopeningeachlock.Notethatthe2locksshouldbethesamesafetytype.

Useexternalpowersupplytopowerthelock,inthisway,widerangelockfrom5Vto48Vlockscanbeusedinthe

system.Notethatinthiscase,theLockControlJumperisremovedinbothlocktype.

to Monitor

BUS PL S1+ S2+ S- BUS PL S1+ S2+ S-

The lock consumption must not

greater than 12V 500mA.

Electromechanical lock

Connection for Electromechanical lock Connection for Electromagnectical lock

lock #2

lock #1

to Monitor

The lock consumption must not

greater than 12V 300mA.

Electronmagnetical lock

1 2 3

Jumper position in 1-2

Unlock Mode

0: power-on-to-open

1: power-off-to-open

CALL

UNLOCK

TALK/MON

IN-USE

1 2 3

Jumper position in 2-3

Unlock Mode

0: power-on-to-open

1: power-off-to-open

CALL

UNLOCK

TALK/MON

IN-USE

1 2

1 2 3

to Monitor

BUS PL S1+ S2+ S- BUS PL S1+ S2+ S-

Jumper removed

The lock consumption must not

greater than 48V 1.5A.

1 2

1 2 3

to Monitor

Jumper removed

The lock consumption must not

greater than 48V 1.5A.

Electronmagnetical lock

Adaptor

Unlock Mode

0: power-on-to-open

1: power-off-to-open

CALL

UNLOCK

TALK/MON

IN-USE

Unlock Mode

0: power-on-to-open

1: power-off-to-open

CALL

UNLOCK

TALK/MON

IN-USE

Electromechanical lock

Connection for Electromechanical lock Connection for Electromagnectical lock

Inner Power 2 Locks Connection

External Power Connection

Mounting Without Rain Cover

Electronic Specications

Mounting With Rain Cover

160-165cm

1 2 3 4

160-165cm

1 2 3 4

LockPowersupply: 12Vdc,500mA(suppliedbysystem)

PowerConsumtion: 1Winstandby,12Winworking

Videosignal: 1Vp-p75ohmCCIR

NO,COMexchangecontact: Max.48Vdc1.5A

Unlockingtime: 1to9seconds,setbyMonitor

Workingtemperature: -5ºC+45ºC
