WIKA 3 Series Manuel utilisateur

Operating instructions

Betriebsanleitung

Example, model 333.30.160

Test gauge, model 3

Feinmessmanometer, Typ 3

14569112.01 08/2023 EN/DE

WIKA operating instructions test gauge, model 3

Operating instructions

Test gauge, model 3 Page 3 - 24

Betriebsanleitung

Feinmessmanometer, Typ 3 Seite 25 - 46

WIKA®is a registered trademark in various countries.

WIKA®ist eine geschützte Marke in verschiedenen Ländern.

Prior to starting any work, read the operating instructions!

Keep for later use!

Vor Beginn aller Arbeiten Betriebsanleitung lesen!

Zum späteren Gebrauch aufbewahren!

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

Contents

Declarations of conformity can be found online at www.wika.com.

1. General information 2

2. Design and function 4

3. Safety 5

4. Transport, packaging and storage 11

5. Commissioning, operation 12

6. Faults 16

7. Maintenance and cleaning 17

8. Dismounting and disposal 19

9. Specifications 20

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

1. General information

The instrument described in the operating instructions has been

designed and manufactured using state-of-the-art technology. All

components are subject to stringent quality and environmental

criteria during production. Our management systems are certied

in accordance with ISO 9001 and ISO 14001.

These operating instructions contain important information on

handling the instrument. Working safely requires that all safety

instructions and work instructions are observed.

Observe the relevant local accident prevention regulations and

general safety regulations for the instrument's range of use.

The operating instructions are part of the product and must be

kept in the immediate vicinity of the instrument and readily acces-

sible to skilled personnel at any time. Pass the operating instruc-

tions on to the next operator or owner of the instrument.

Skilled personnel must have carefully read and understood the

operating instructions prior to beginning any work.

In case of a dierent interpretation of the translated and the

English operating instructions, the English wording shall prevail.

The general terms and conditions contained in the sales

documentation shall apply.

Subject to technical modications.

Calibration certicates are issued in accordance with international

standards.

1. General information

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

Further information:

Technical information: IN 00.05

Internet address: www.wika.de / www.wika.com

Model Data sheet

312.20 PM 03.01

311.11, 331.11 PM 03.02

342.11 PM 03.03

332.11 PM 03.04

332.30, 333.30 PM 03.05

332.50, 333.50 PM 03.06

1.1 Explanations of symbols

DANGER!

... indicates a directly dangerous situation resulting in

serious injury or death, if not avoided.

WARNING!

... indicates a potentially dangerous situation that can

result in serious injury or death, if not avoided.

CAUTION!

... indicates a potentially dangerous situation that can

result in light injuries or damage to property or the

environment, if not avoided.

Information

... points out useful tips, recommendations and

information for ecient and trouble-free operation.

1. General information

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

2. Design and function

2.1 Overview

2.2 Description

With the model 3 test gauge described below, the wetted parts

(process connection and pressure element) are made of stainless steel,

copper alloy or Ni-Fe alloy.The nominal size (NS) of 160 mm [6"] or

250 mm [10"] stated is a rounded value referred to the case diameter.

Case designs in accordance with EN 837

Version “S1”, not shown here, is equipped with a blow-out device in

the case back.

Safety version “S3”, shown above, is equipped with a solid bae

wall between the measuring system and the dial and with a blow-out

back. In the event of a failure, the operator is protected at the front

side, as media or components can only be ejected via the back of

the case.

2.3 Scope of delivery

Cross-check scope of delivery with delivery note.

  









Example: Model 332.30.160

Vent valve

Window

Pressure element: Bourdon tube

Pointer

Case: Safety version “S3” in

accordance with EN 837

Dial with scale

Process connection

2. Design and function

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

3. Safety

3.1 Intended use

The instruments described here are suitable:

Models 312.20, 311.11, 342.11: For gaseous and liquid media

that are not highly viscous or crystallising and will not attack

copper alloy or NiFe alloy parts

Models 331.11, 332.1, 33x.30, 33x.50: For gaseous and liquid

aggressive media that are not highly viscous or crystallising, also

in aggressive environments

Models 333.30, 333.50: For high dynamic pressure loads and

vibrations (with case liquid lling)

For pressure measurement with high accuracy

As pressure reference for checking industrial type pressure

gauges

For precision measurement in laboratories

Model 332.11: For mobile precision measurement under particular

safety

Regulations for pressure equipment

Instrument type: Pressure accessory without safety function

Media: Liquid or gaseous, group 1 (hazardous)

Maximum allowable pressure PS, see chapter 3.5 “Labelling /

Safety marking”

Volume of wetted parts: < 0.1 L

The conformity marking CE, UKCA is carried out in accordance

with uid group 1 in accordance with Annex II, Diagram 1 from a

permissible operating pressure > 200 bar

The instrument must only be used with media which are not harmful

to the wetted parts over the entire range of use of the instrument.

A change in the aggregate state or the decomposition of unstable

media is not permitted.

Only use the instrument in applications that lie within its technical

performance limits (e.g. max. ambient temperature, material

compatibility, ...).

3. Safety

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

→ For performance limits, see chapter 9 “Specications”.

In order to achieve an optimal service life of the instru-

ment, it is recommended to load the instrument between

1/3 x PS and 2/3 x PS. See technical information

IN 00.05.

This instrument is not permitted to be used in hazardous areas!

The instrument has been designed and built solely for the intended

use described here, and may only be used accordingly.

The technical specications contained in these operating instructions

and the limit values in accordance with EN 837-1 must be observed.

Improper handling or operation of the instrument outside of its techni-

cal specications and the limit values in accordance with EN 837-1

requires the instrument to be taken out of service immediately and

inspected by an authorised WIKA service engineer.

With instruments which do not correspond to the safety version “S3”,

highly pressurised media might leak out through the possibly burst-

ing window in case of a component failure.

The manufacturer shall not be liable for claims of any type based on

operation contrary to the intended use.

3.2 Improper use

Do not use the instrument within hazardous areas.

Do not use this instrument with abrasive, corrosive and highly

viscous media.

Any use beyond or dierent to the intended use is considered as

improper use.

Unauthorised modications to the instrument are not permissible.

Do not use this instrument in safety or emergency shutdown

devices.

3. Safety

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

3.3 Responsibility of the operator

The instrument is used in the industrial sector. The operator is there-

fore responsible for legal obligations regarding safety at work.

The safety instructions within these operating instructions, as well as

the safety, accident prevention and environmental protection regula-

tions for the application area must be maintained.

The operator is obliged to maintain the product label in a legible

condition.

To ensure safe working on the instrument, the operating company

must ensure

that the instrument is suitable for the particular application in

accordance with its intended use.

that the requisite personal protective equipment is provided.

On the wetted parts of the instrument, small residual

amounts of the adjustment medium (e.g. compressed

air, water, oil) can adhere from production. With

increased requirements for technical cleanliness, suita-

bility for the application must be checked by the operator

before commissioning.

Liquid media with the property of changing the volume

during solidication can damage the measuring system

(e.g. B. water if the freezing point falls below).

3. Safety

14569112.01 08/2023 EN/DE

WIKA operating instructions, test gauge model 3

3.4 Personnel qualification

WARNING!

Risk of injury should qualication be insucient

Improper handling can result in considerable injury and

damage to property.

▶The activities described in these operating instruc-

tions may only be carried out by skilled personnel

who have the qualications described below.

Skilled personnel

Skilled personnel, authorised by the operator, are understood to

be personnel who, based on their technical training, knowledge

of measurement and control technology and on their experience

and knowledge of country-specic regulations, current standards

and directives, are capable of carrying out the work described and

independently recognising potential hazards.

3.5 Personal protective equipment

The personal protective equipment is designed to protect the skilled

personnel from hazards that could impair their safety or health

during work.When carrying out the various tasks on and with the

instrument, the skilled personnel must wear personal protective

equipment.

Follow the instructions displayed in the work area regarding

personal protective equipment!

The requisite personal protective equipment must be provided by the

operating company.

3. Safety

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels WIKA Instrument de mesure

WIKA

WIKA DI10 Manuel utilisateur

WIKA

WIKA 821 Manuel utilisateur

WIKA

WIKA CEP3000 Manuel utilisateur

WIKA

WIKA air2guide A2G-05 Manuel utilisateur

WIKA

WIKA mensor 9476 Manuel utilisateur

WIKA

WIKA 1500 Series Manuel utilisateur

WIKA

WIKA 7000 Series Manuel utilisateur

WIKA

WIKA SERIES CPG 2500 Manuel utilisateur

WIKA

WIKA DG-10 Manuel utilisateur

WIKA

WIKA Delta-comb Manuel utilisateur

WIKA

WIKA A2G-05 Manuel utilisateur

WIKA

WIKA PG23HP Series Manuel utilisateur

WIKA

WIKA SENSeOR AMS01 Manuel utilisateur

WIKA

WIKA DPG40 Manuel utilisateur

WIKA

WIKA PG81 Manuel utilisateur

WIKA

WIKA A2G-10 Manuel utilisateur

WIKA

WIKA PGS23 Manuel utilisateur

WIKA

WIKA NS 63 Manuel utilisateur

WIKA

WIKA FLC-2300 Manuel utilisateur

WIKA

WIKA CPH6400 Manuel utilisateur

WIKA

WIKA DI30 Manuel utilisateur

WIKA

WIKA TC82 Mode d'emploi

WIKA

WIKA TC80 Manuel utilisateur

WIKA

WIKA IL-10 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
