Tripp Lite SmartOnline SU3000XLNAFTA Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: SU3000XLNAFTA
SmartOnline Expandable Tower UPS System - NAFTA assembled version of SU3000XL
Highlights
3000VA / 3KVA on-line, double-conversion, extended-run tower UPS
Maintains sine-wave 110/120V +/-2% output during overvoltages to 138 and
brownouts as low as 65V (50/60Hz auto-sensing)
Simultaneous use communications via HID compliant USB port, serial port,
SNMP/Web card slot and EPO interface
Fault tolerant auto-bypass mode, current monitoring and switched PDU control
via 2 switchable output load banks
Input: NEMA L5-30P (120V) / Output: 4 NEMA5-15R, 4 NEMA5-15/20R & 1
NEMA L5-30R
$250,000 Ultimate Lifetime Insurance (USA and Canada Only)
Description
3000VA on-line, double-conversion UPS system for critical server, network and telecommunications equipment. Upright tower form factor.
Expandable battery runtime with optional BP72V28-3UNAFTA external battery packs. Full-time sine wave 110 or 120V +/-2% output. Online,
double-conversion Uninterruptible Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output back to completely
regulated, filtered AC output. Operates continuously without using battery power during brownouts to 65V and overvoltages to 138V. NEMA L5-30P
input plug; NEMA 5-15R, NEMA 5-15/20R and NEMA L5-30R output receptacles. Network-grade AC surge and noise suppression. Zero transfer
time between AC and battery operation. Network management interfaces support simultaneous communications via USB port, DB9 serial port and
SNMPWEBCARD slot. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows
and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network
interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated 2-bank PDU switching
supports load shedding and remote-reboot of connected equipment. 3-stage metered current monitoring and battery charge status LEDs. Dataline
surge suppression for dialup, DSL or network Ethernet connection. Utility power and voltage regulation LEDs. Audible alarm. Self-test. Fault-tolerant
auto-bypass mode. Field-replaceable, hot-swappable internal batteries and external battery packs. Attractive all-black color scheme. $250,000
connected equipment insurance;
Package Includes
SU3000XLNAFTA UPS System
PowerAlert Software and Cabling
Instruction manual with warranty information
Features
SmartOnline high performance UPS system is ideal for critical voice, data, medical and industrial network applications
True on-line, double-conversion UPS provides perfectly regulated sine wave output within 2% of 110/120V (user selectable) under all usage
conditions
Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time
Removes harmonic distortion, fast electrical impulses, frequency variations and other hard to solve power problems not addressed by other
UPS types
Corrects line voltage conditions as low as 65V and as high as 138V back to selectable 110/120V (+/-2%) values
Standard internal battery set offers 14 minutes runtime at half load (1200W) and 5 minutes at full load (2400W)
Optional BP72V28-3UNAFTA external battery packs offer expandable battery runtime
Space saving upright tower format
Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions
Network interfaces support simultaneous communications via built-in USB, DB9 serial/contact-closure and SNMPWEBCARD slot
HID compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X.
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus
any number of additional servers over IP
UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,
battery capacity, AC line frequency, timed inverter shutoff, activate self-test, load bank output power control and remote reboot, UPS
nominal voltage adjustment and UPS line to battery power voltage setpoints
Built-in Emergency Power Off (EPO) interface with cable
NEMA L5-30P input plug/NEMA 5-15/20R, L5-20R & L5-30R output receptacles
Integrated 2 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual load banks (each
bank has four outlets)
Front panel LEDs offer current monitoring and battery charge level information
UPS ships fully assembled in full compliance with DOT regulations; no time consuming connection of internal batteries by user required
Single line TEL/DSL or network ethernet line surge suppression
$250,000 Ultimate Lifetime Insurance
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
3000
Output kVA capacity
(kVA)
3
Output Watt Capacity
(watts)
2400
Output kW capacity 2.4
Output power factor 0.8
Crest Factor 3:1
Nominal Output
Voltage(s) Supported
110V; 120V
Nominal Voltage details 120V default
Frequency compatibility 50 / 60 Hz
Frequency
compatibility details
Output frequency matches input nominal on startup, defaults to 60 Hz on cold-start
Output voltage
regulation (line mode)
+/- 2%
Output voltage
regulation (Economy
line mode)
+/- 10%
Output voltage
regulation (Battery
mode)
+/- 2%
Built-in UPS output
receptacles
4 5-15R outlet(s); 4 5-15/20R outlet(s); 1 L5-30R outlet(s)
Built-in controllable
switched load banks
Two switchable four-outlet load banks, (bank 1 - four 5-15/20R, bank 2 - four 5-15R outlets)
Output circuit breaker 15A branch rated (x2) - each breaker protects 4 outlets, L5-30R is unbreakered
Basic PDU options PDU2430 (1U / 24 5-15R outlets)
Metered PDU options PDUMV30 (0U / 24 5-15/20R outlets)
Switched PDU options PDUMH30NET (2U / 16 5-15/20R outlets); PDUMV30NET (0U / 24 5-15/20R outlets)
External PDU
redundancy options
*ATS switch options PDUMH20AT & PDUMH20ATNET support dual UPS and hot-swappable UPS configurations
Output AC waveform
(AC mode)
Sine wave
Output AC waveform
(battery mode)
Pure Sine wave
INPUT
Rated input current (at
maximum load)
24A (120V), 26.2A (110V)
Nominal Input
Voltage(s) Supported
110V AC; 120V AC
UPS input connection
type
L5-30P
Input circuit breaker 40A
UPS Input cord length
(ft.)
10
UPS Input cord length
(m)
3
Recommended
Electrical Service
30A 120V
BATTERY
Full load runtime
(minutes)
6 min. (2400w)
Half load runtime
(minutes)
17 min. (1200w)
Expandable battery
runtime
Supports extended runtime with optional external battery packs
External battery pack
compatibility
BP72V15-2U (limit 1); BP72V28RT-3U (multi-pack compatible); BP72V28-3UNAFTA (multi-pack compatible)
DC system voltage
(VDC)
72
Battery recharge rate
(included batteries)
Less than 6 hours from 10% to 80%
Replacement battery
cartridge (internal UPS
battery replacement)
RBC96-3U (quantity 1)
Battery Access Front panel battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Online, double-conversion power conditioning
Overvoltage correction 2% output voltage regulation during overvoltages to 138
Undervoltage correction 2% output voltage regulation during undervoltages to 80
Severe undervoltage
correction
2% output voltage regulation during undervoltages to 65 (under 70% load only)
LEDS ALARMS & SWITCHES
LED Indicators 14 LEDs indicate line power, online mode, economy/bypass mode, on-battery, overload, battery low, replace
battery and fault status information; 4-LED meter displays load and battery charge levels
Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown
conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
480
UPS AC suppression
response time
Instantaneous
UPS Dataline
suppression
1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form
factors supported with
included accessories
Tower
Primary form factor Tower
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / inches)
10.2 x 9 x 20.5
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / cm)
26 x 22.9 x 52.1
UPS / Power Module
weight (lbs)
69.3
UPS / Power Module
weight (kg)
31.5
UPS Shipping
dimensions (height x
width x depth / inches)
15.2 x 13 x 24
UPS Shipping
dimensions (height x
width x depth / cm)
38.7 x 33 x 61
Shipping weight (lbs) 75.2
Shipping weight (kg) 34.1
UPS housing material Steel
Cooling method Fan
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full
load)
1112.7
AC economy mode
BTU / hr. (full load)
520.9
Battery mode BTU / hr.
(full load)
1219.3
AC economy mode
efficiency rating (100%
load)
94%
Audible Noise
COMMUNICATIONS
Communications
interface
USB (HID enabled); DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring
port description
Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure
communications
PowerAlert software Included
Communications cable USB and DB9 cabling included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time No transfer time (0 ms.) in online, double-conversion mode
Low voltage transfer to
battery power (setpoint)
175V (100% load), 80V (
High voltage transfer to
battery power (setpoint)
138
SPECIAL FEATURES
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
High availability UPS
features
Automatic inverter bypass; Hot swappable batteries
Green & high efficiency
features
High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of
economy mode operation
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A
(EMI)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Connected Equipment
Insurance (U.S.,
Canada & Puerto Rico)
$250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
External Battery Packs BP72V15-2U BP72V15-2U - External Battery Pack for UPS System 1
External Battery Packs BP72V28RT-3U BP72V28RT-3U - External Battery Pack for UPS System 1
Shutdown Cable Kits AS400CABLE KIT Power Management Tools - UPS Communication Cable Kit for System
i / AS400 / iSeries Servers
1
SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires
SNMPWEBCARD or switched PDU.)
1
SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3548.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
Table des matières
Autres manuels Tripp Lite UPS
Tripp Lite
Tripp Lite OMNIVS1500XL Manuel utilisateur
Tripp Lite
Tripp Lite OMNIVS1500 Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline Series Manuel utilisateur
Tripp Lite
Tripp Lite OMNI700LCDT Manuel utilisateur
Tripp Lite
Tripp Lite OmniPro 500 Manuel utilisateur
Tripp Lite
Tripp Lite TE Series Manuel utilisateur
Tripp Lite
Tripp Lite OmniSmart RMX 500 VA OM500RMX Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU16KRT-1TF Manuel utilisateur
Tripp Lite
Tripp Lite SM3000RMNAFTA Manuel utilisateur
Tripp Lite
Tripp Lite SMART1050SLTAA Manuel utilisateur
Tripp Lite
Tripp Lite OmniSmart OMNIVS800 Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro 450 RTI Manuel utilisateur
Tripp Lite
Tripp Lite OMNIVSINT800 Manuel utilisateur
Tripp Lite
Tripp Lite Audio/Video On-Line UPS System Manuel utilisateur
Tripp Lite
Tripp Lite PDUMNH20HV Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU40K Manuel utilisateur
Tripp Lite
Tripp Lite RBC36-SLT Manuel utilisateur
Tripp Lite
Tripp Lite SMART600PSGLCD Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro SMART3000RMXL2U Guide d'installation
Tripp Lite
Tripp Lite AVRX Series Manuel utilisateur
Manuels UPS populaires d'autres marques
Pylontech
Pylontech Victron & Pylontech US5000 Manuel utilisateur
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur
Mecer
Mecer ME-1000-WTU Manuel utilisateur
Mustek
Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation
Emerson
Emerson Liebert NXL series Manuel utilisateur
MAKELSAN
MAKELSAN BOXER SERIES Manuel utilisateur
