Tripp Lite SMART1000LCDTAA Manuel utilisateur

TAA-Compliant SmartPro LCD 120V 1000VA 500W

Line-Interactive UPS, AVR, Tower, USB,

TEL/DSL/Coax Protection, 8 Outlets

MODEL NUMBER: SMART1000LCDTAA

Description

The TAA-compliant SMART1000LCDTAA SmartPro LCD 120V, 1000VA/500W Line-Interactive Uninterruptible Power Supply provides battery backup and AC

power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your desktop

computer or audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep your connected equipment running

long enough to save files and shut down safely with no data loss.

While all eight NEMA 5-15R outlets protect against surges, four outlets also provide up to 3 hours of UPS battery support for a DVR component, 60 minutes of

support for a basic desktop PC and LCD monitor, and 10 minutes of support at half load (250W).

Automatic voltage regulation (AVR) corrects undervoltages as low as 89V without using any battery power. EMI/RFI noise filtering improves your equipment’s

performance and prevents damage. A 1038-joule surge suppression rating protects your equipment from harmful power surges.

Space-saving NEMA 5-15P plug with 6-foot cord connects to any NEMA 5-15R socket and allows furniture to be placed flush against the wall. Large rotatable

LCD screen with dimmer shows real-time statuses at a glance. With Tripp Lite’s free PowerAlert software (available via free web download), the

SMART1000LCDTAA enables safe unattended system shutdown and file saves in case of a prolonged power failure.

Features

Reliable Battery Backup

Provides 1000VA/500W high-performance power protection for desktop computers, audio/video components, media centers and other electronics

Supports basic desktop computer and LCD monitor up to 60 minutes or single DVR components up to 3 hours during power outage

Supports 50% load (250W) up to 10 minutes and full load (500W) up to 3 minutes

97% full-load efficiency rating saves money in energy costs

Audible alarm indicates loss of utility power or low battery

Optimized Outlets

Highlights

Supports a basic desktop PC up

to 60 min. during power outage

Features 8 protected outlets—4

battery-protected, 4 surge-only

Offers automatic voltage

regulation (AVR)

LCD screen reports real-time

UPS and power status

Compliant with Federal TAA for

GSA Schedule purchases

Package Includes

SMART1000LCDTAA

TAA-Compliant SmartPro LCD

120V 1000VA/500W

Line-Interactive UPS

USB cable

Telephone cord

Owner’s Manual

1 / 5

4 NEMA 5-15R outlets deliver battery backup for devices that require constant power

All 8 outlets protect against surges or spikes that can harm equipment or data

Space-saving NEMA 5-15P right-angle plug with 6-foot cord connects to any NEMA 5-15R socket

Automatic Voltage Regulation (AVR)

Corrects undervoltages as low as 89V with a 14% boost without drawing battery backup power

Rotatable LCD Status Screen

Large LCD screen shows real-time input voltage, overload, AVR and battery statuses

Rotates for easy viewing in both horizontal and vertical installations

Dimmer switch controls brightness level

AC Line, Coaxial and Tel/DSL Surge Suppression

Surge suppression rating of 1038 joules protects connected equipment and data from harmful power surges

Tel/DSL RJ11 jacks protect standard dialup/DSL phone connection

2.2 Hz coaxial jacks protect CATV, broadband cable internet, satellite or broadcast antenna connections

EMI/RFI Line Noise Filtering

Removes electromagnetic and radio frequency interference that can disrupt or damage your equipment’s performance

USB Communication Port and Free PowerAlert Software

HID-compliant USB port integrates with built-in power management and auto-shutdown of Windows and Mac OS X

Works with Tripp Lite PowerAlert software, available as free web download from www.tripplite.com/poweralert, to enable safe, unattended system

shutdown and file saves during prolonged power failure

TAA-Compliant for GSA Schedule Purchases

Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Specifications

OUTPUT

Output Volt Amp Capacity (VA) 1000

Output kVA Capacity (kVA) 1

Output Watt Capacity (Watts) 500

Nominal Output Voltage(s)

Supported 110V; 115V; 120V

Nominal Voltage Details 115v nominal output in battery mode

Frequency Compatibility 60 Hz

Output Voltage Regulation (Battery

Mode) +/- 5%

Output Receptacles (8) 5-15R

2 / 5

UPS Output Receptacles (Surge

Suppression Only) 4 UPS outlets, 4 surge-only outlets

Output AC Waveform (AC Mode) Sine wave

Output AC Waveform (Battery Mode) PWM sine wave

INPUT

Rated input current (Maximum Load) 12A

Nominal Input Voltage(s) Supported 120V AC

UPS Input Connection Type 5-15P; Right-Angled

UPS Input Cord Length (ft.) 6

UPS Input Cord Length (m) 1.8

Recommended Electrical Service 15A 120V

Input Phase Single-Phase

BATTERY

Full Load Runtime (min.) 3 min. (500w)

Half Load Runtime (min.) 10 min. (250w)

DC System Voltage (VDC) 12

Battery Recharge Rate (Included

Batteries) Less than 16 hours from 10% to 90%

Expandable Runtime No

VOLTAGE REGULATION

Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89

Undervoltage Correction Input voltages between 89 and 104 are boosted by 14%

USER INTERFACE, ALERTS & CONTROLS

Front Panel LCD Display Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace

battery status; LCD screen rotates for rack/tower viewing

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness

Alarm Cancel Operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Audible Alarm Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software

LED Indicators Front panel LCD display

SURGE / NOISE SUPPRESSION

UPS AC Suppression Joule Rating 480

UPS AC Suppression Response

Time Instantaneous

3 / 5

UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out); Coax jacks (1 set)

EMI / RFI AC Noise Suppression Yes

PHYSICAL

Installation Form Factors Supported

with Included Accessories Tower

Primary Form Factor Tower

UPS Power Module Dimensions

(hwd, in.) 11.8 x 3.7 x 7.2

UPS Power Module Dimensions

(hwd, cm) 30.1 x 9.4 x 18.3

UPS Power Module Weight (lbs.) 14.9

UPS Power Module Weight (kg) 6.76

UPS Shipping Dimensions (hwd / in.) 10.4 x 15.6 x 4.8

UPS Shipping Dimensions (hwd /

cm) 26.5 x 39.5 x 12.3

Shipping Weight (lbs.) 16.2

Shipping Weight (kg) 7.4

Primary UPS Height (mm) 300

Primary UPS Width (mm) 94

Primary UPS Depth (mm) 183

Shipping Height (mm) 264

Shipping Width (mm) 396

Shipping Depth (mm) 122

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC Mode BTU / Hr. (Full Load) 61

Battery Mode BTU / Hr. (Full Load) 510

AC Mode Efficiency Rating (100%

Load) 97%

COMMUNICATIONS

Communications Interface USB (HID enabled)

PowerAlert Software For local monitoring via the UPS’s built-in USB port, download PowerAlert Local software at

http://www.tripplite.com/poweralert

Communications Cable USB cable included

4 / 5

WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

Network UPS Tools Compatibility NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at

http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite

LINE / BATTERY TRANSFER

Transfer Time 4 milliseconds (AC to battery) / 3 milliseconds (Battery to AC)

Low Voltage Transfer to Battery

Power (Setpoint) 89

High Voltage Transfer to Battery

Power (Setpoint) 139

SPECIAL FEATURES

Cold Start (Startup in Battery Mode

During a Power Failure) Cold-start operation supported

Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B

(EMI); TAA Compliant

WARRANTY

Product Warranty Period (U.S. &

Canada) 3-year limited warranty

Product Warranty Period (Latin

America) 3-year limited warranty

Product Warranty Period

(International) 2-year limited warranty

Product Warranty Period (Mexico) 3-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:

https://www.tripplite.com/products/product-certification-agencies

5 / 5
