Model #: SMART750USB
Smart USB 750VA Tower Line-Interactive 120V UPS with USB port
Highlights
750VA tower 120V line interactive UPS
Corrects brownouts as low as 89V without using battery power
3 UPS battery supported outlets, 3 surge-only outlets
USB port, TEL/DSL/ethernet protection
NEMA 5-15P input plug and 6 NEMA 5-15R outlets
Description
Tripp Lite's SMART750USB line-interactive UPS system offers automatic voltage regulation, surge suppression and long lasting battery support.
750VA/450 watt power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems,
audio/video equipment and home theater systems. Internal UPS circuits support entry level PC systems for up to 45 minutes during power failures
so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 89
volts back to usable levels without using battery power. Offers complete desktop power protection in an attractive, black tower configuration.
Includes 3 battery-supported outlets for computer, monitor and one vital system peripheral as well as 3 additional surge-only outlets for printers and
other system accessories that do not require battery support. USB port (USB cable included) enables optional unattended system shutdown without
data loss in the case of extended power failure. PowerAlert Software available via free download from www.tripplite.com. Built-in dataline protection
jacks offer protection of a single dialup phone/DSL line or network Ethernet connection. Built-in audible alarm and 4 front panel LEDs indicate line
power status, battery power status, battery low/replace status and voltage boost operation. Offers 3 minutes battery runtime with a full load of
750VA/450 watts and 11 minutes with a half load of 375VA/225 watts. Supports battery replacement via built-in access panel. $200,000 connected
equipment insurance (USA and Canada Only).
Package Includes
SMART750USB Standby UPS System
USB and telephone interconnection cables
Instruction manual with warranty information
Features
SMART750USB line-interactive UPS system offers extended voltage regulation (AVR) and battery support as well as complete AC and
dialup/DSL/Ethernet line surge suppression
Supports entry level PC systems for up to 45 minutes during power failures to enable a safe system shutdown
Supports a max load of 750VA/450 watts for 3 minutes and a half load of 375VA/225 watts for 11 minutes
Automatic Voltage Regulation (AVR) circuits correct brownouts as low as 89 volts without using battery power
Attractive black tower configuration
Includes 3 battery-supported outlets, plus 3 additional surge-only outlets, 6 foot AC line cord (all NEMA 5-15)
USB port enables unattended shutdown without data loss during extended power failures; includes USB cable
Built-in USB port supports on battery, low battery, power restored, AC line voltage, DC battery voltage and battery capacity messaging;
interface supports timed inverter shutoff after unattended shutdown, activate self-test and 10 second reboot of connected equipment
PowerAlert UPS monitoring and unattended shutdown software available via free download from www.tripplite.com
Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting
completely locked computers by automatically switching UPS power off and back on again (part #WATCHDOGSW)
Built-in dataline suppression jacks protect a single dialup phone/DSL line or network Ethernet line connection
Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status
750VA/450 watt power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment
Supports battery replacement via built-in access panel
Compatible with 120V/60Hz applications for USA, Canada, Mexico and more
$200,000 Ultimate Lifetime Insurance (USA and Canada Only)
Specifications
OUTPUT
Output Volt Amp Capacity
(VA)
750
Output Watt Capacity
(watts)
450
Nominal Output Voltage(s)
Supported
115V; 120V
Frequency compatibility 60 Hz
Output voltage regulation
(Battery mode)
115V (+/- 5%)
Built-in UPS output
receptacles
6 5-15R outlet(s)
Surge suppression only
outlets
3 UPS outlets, 3 surge-only outlets
Output AC waveform (AC
mode)
Sine wave
Output AC waveform
(battery mode)
PWM sine wave
INPUT
Rated input current (at
maximum load)
12A
Nominal Input Voltage(s)
Supported
120V AC
UPS input connection type 5-15P
UPS input connection
description
Angled input plug
UPS Input cord length (ft.) 6
UPS Input cord length (m) 1.8
Recommended Electrical
Service
15A 120V
BATTERY
Full load runtime (minutes) 3 min. (450w)
Half load runtime (minutes) 11 min. (225w)
DC system voltage (VDC) 12
Battery recharge rate
(included batteries)
Less than 4.5 hours from 10% to 90%
Replacement battery
cartridge (internal UPS
battery replacement)
RBC51
Battery Access Battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
Undervoltage correction Input voltages between 89 and 104 are boosted by 14%
LEDS ALARMS & SWITCHES
LED Indicators 4 LEDs indicate line power, battery power, overload and battery low/replace status
Alarms Audible alarm indicates power-failure and low-battery conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule
rating
510 joules
UPS AC suppression
response time
Instantaneous
UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form factors
supported with included
accessories
Tower
Installation form factors
supported with optional
accessories
Wallmount (UPSWM - tower mounting kit)
Primary form factor Tower
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / inches)
10.8 x 5.2 x 7.5
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / cm)
27.3 x 13.3 x 19
UPS / Power Module weight
(lbs)
20
UPS / Power Module weight
(kg)
9.1
UPS Shipping dimensions
(height x width x depth /
inches)
14 x 8.5 x 10.5
UPS Shipping dimensions
(height x width x depth / cm)
35.6 x 21.6 x 26.7
Shipping weight (lbs) 22
Shipping weight (kg) 10
UPS housing material PVC
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full
load)
47.3
Battery mode BTU / hr. (full
load)
431.5
COMMUNICATIONS
Communications interface USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB interface cable included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 2-4 milliseconds
Low voltage transfer to
battery power (setpoint)
89
High voltage transfer to
battery power (setpoint)
139
SPECIAL FEATURES
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
High availability UPS
features
Hot swappable batteries
Green & high efficiency
features
Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI)
WARRANTY
Product Warranty Period
(U.S. & Canada)
3-year limited warranty
Product Warranty Period
(International)
2-year limited warranty
Product Warranty Period
(Mexico)
3-year limited warranty
Product Warranty Period
(Puerto Rico)
3-year limited warranty
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$200,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Related Model Description Qty.
DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial lines 1
DNET1 Network Surge Suppressor - Essential protection for data and communication lines 1
DTEL2 Network Surge Suppressor - Essential protection for data and communication lines 1
UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws, 1 Velcro safety
strap)
1
U022-010 10-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
WEXT5-500-1500 5-Year Extended Warranty - For Smart Line-Interactive and Online Tower or Rack
models, 1500VA or less
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?variables.txtModelID=2679.
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
