Tripp Lite SmartOnline SU2200XLNAFTA Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: SU2200XLNAFTA
SmartOnline Expandable Tower UPS System - NAFTA assembled version of SU2200XLa
Highlights
2200VA / 2.2kVA on-line, double-conversion, extended-run tower UPS
Maintains sine-wave 110/120V +/-2% output during overvoltages to 138 and
brownouts as low as 65V (50/60Hz auto-sensing)
Simultaneous communications via HID compliant USB port, serial port,
SNMP/Web card slot and EPO interface
Fault tolerant auto-bypass mode, current monitoring and switched PDU control
via 2 switchable output load banks
Input: NEMA 5-20P (120V, optional 5-15P included) / Output: 6 NEMA
5-15/20R and 1 NEMA L5-20R (120V)
$250,000 Ultimate Lifetime Insurance (USA and Canada Only)
Description
2200VA on-line, double-conversion UPS system for critical server, network and telecommunications equipment. Upright tower form factor.
Expandable battery runtime with optional BP48V60-3UNAFTA external battery packs. Full-time sine wave 110 or 120V +/-2% output. Online,
double-conversion Uninterruptible Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output back to completely
regulated, filtered AC output. Operates continuously without using battery power during brownouts to 65V and overvoltages to 138V. NEMA 5-20P
input plug (optional 5-15P inlcuded); NEMA 5-15/20R and NEMA L5-20R output receptacles. Network-grade AC surge and noise suppression. Zero
transfer time between AC and battery operation. Network management interfaces support simultaneous communications via USB port, DB9 serial
port and SNMPWEBCARD slot. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of
Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3
network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated 2-bank PDU
switching supports load shedding and remote-reboot of connected equipment. 3-stage metered current monitoring and battery charge status LEDs.
Dataline surge suppression for dialup, DSL or network Ethernet connection. Utility power and voltage regulation LEDs. Audible alarm. Self-test.
Fault-tolerant auto-bypass mode. Field-replaceable, hot-swappable internal batteries and external battery packs. Attractive all-black color scheme.
$250,000 connected equipment insurance;
Package Includes
SU2200XLNAFTA UPS System
PowerAlert Software and cabling
Instruction manual with warranty information
Features
SmartOnline high performance UPS system is ideal for critical voice, data, medical and industrial network applications
True on-line, double-conversion UPS provides perfectly regulated sine wave output within 2% of 110/120V (user selectable) under all usage
conditions
Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time
Removes harmonic distortion, fast electrical impulses, frequency variations and other hard to solve power problems not addressed by other
UPS types
Corrects line voltage conditions as low as 65V and as high as 138V back to selectable 110/120V (+/-2%) values
Standard internal battery set offers 14 minutes runtime at half load (800W) and 4.5 minutes at full load (1600W)
Optional BP48V60-3UNAFTA external battery packs offer expandable battery runtime
Space saving upright tower format
Fault tolerant auto-bypass maintains continuous utility output to connected equipment, even in cases where the UPS suffers internal failure
and requires maintenance
Network interfaces support simultaneous communications via built-in USB, DB9 serial and SNMPWEBCARD slot
HID compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus
any number of additional servers over IP
UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,
battery capacity, AC line frequency, timed inverter shutoff, activate self-test, load bank output power control and remote reboot, UPS
nominal voltage adjustment and UPS line to battery power voltage setpoints
Built-in Emergency Power Off (EPO) interface with cable
NEMA 5-20P input plug (user-installable NEMA 5-15P replacement plug included)/NEMA 5-15/20R & NEMA L5-20R output receptacles
Integrated 2 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual load banks
Front panel LEDs offer current monitoring and battery charge level information
UPS ships fully assembled in full compliance with DOT regulations, no time consuming connection of internal batteries by user required
Single line TEL/DSL or network ethernet line surge suppression
$250,000 Ultimate Lifetime Insurance
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
2200
Output kVA capacity
(kVA)
2.2
Output Watt Capacity
(watts)
1600
Output kW capacity 1.6
Output power factor 0.7
Crest Factor 3:1
Nominal Output
Voltage(s) Supported
110V; 120V
Nominal Voltage
details
120V default
Frequency
compatibility
50 / 60 Hz
Frequency
compatibility details
Output frequency matches input nominal on startup, defaults to 60 Hz on cold-start
Output voltage
regulation (line mode)
+/- 2%
Output voltage
regulation (Economy
line mode)
+/- 10%
Output voltage
regulation (Battery
mode)
+/- 2%
Built-in UPS output
receptacles
6 5-15/20R outlet(s); 1 L5-20R outlet(s)
Built-in controllable
switched load banks
Two switchable three-outlet 5-15/20R load banks
Basic PDU options PDUNV (1U / 2 C19, 12 C13 outlets); PDU40TDUAL (0U / 40 5-15/20R outlets)
Metered PDU options PDUMH20 (1U / 13 5-15/20R outlets); PDUMH20AT (1U / 16 5-15/20R outlets)*; PDUMV20 (0U / 16 5-15/20R
outlets); PDUMV40 (0U / 32 5-15/20R outlets)
Switched PDU options PDUMH20ATNET (1U / 16 5-15/20R outlets)*; PDUMV20NET (0U / 24 5-15/20R outlets)
External PDU
redundancy options
*ATS switch options PDUMH20AT & PDUMH20ATNET support dual UPS and hot-swappable UPS configurations
Output AC waveform
(AC mode)
Sine wave
Output AC waveform
(battery mode)
Pure Sine wave
INPUT
Rated input current (at
maximum load)
16A (120V), 17.6A (110V)
Nominal Input
Voltage(s) Supported
110V AC; 120V AC
UPS input connection
type
5-20P
UPS input connection
description
Includes user-installable 5-15P replacement plug
Input circuit breaker 30A
UPS Input cord length
(ft.)
10
UPS Input cord length
(m)
3
Recommended
Electrical Service
20A 120V
BATTERY
Full load runtime
(minutes)
4.5 min. (1600w)
Half load runtime
(minutes)
14 min. (800w)
Expandable battery
runtime
Extended runtime supported via optional external battery packs
External battery pack
compatibility
BP48V24-2U (limit 1); BP48V60RT-3U (multi-pack compatible); BP48V60-3UNAFTA (multi-pack compatible)
DC system voltage
(VDC)
48
Battery recharge rate
(included batteries)
Less than 5 hours from 10% to 90%
Replacement battery
cartridge (internal UPS
battery replacement)
RBC48-SUTWR
Battery Access Battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Online, double-conversion power conditioning
Overvoltage correction 2% output voltage regulation during overvoltages to 138
Undervoltage
correction
2% output voltage regulation during undervoltages to 80
Severe undervoltage
correction
2% output voltage regulation during undervoltages to 65 (under 70% load only)
LEDS ALARMS & SWITCHES
LED Indicators 14 LEDs indicate line power, online mode, economy/bypass mode, on-battery, overload, battery low, replace
battery and fault status information - includes 4-LED meter display for load and battery charge level
Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown
conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
570
UPS AC suppression
response time
Instantaneous
UPS Dataline
suppression
1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form
factors supported with
included accessories
Tower
Primary form factor Tower
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / inches)
10.2 x 9 x 19.5
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / cm)
26 x 22.9 x 49.5
UPS / Power Module
weight (lbs)
53.4
UPS / Power Module
weight (kg)
24.2
UPS Shipping
dimensions (height x
width x depth / inches)
15.2 x 13 x 24
UPS Shipping
dimensions (height x
width x depth / cm)
38.7 x 33 x 61
Shipping weight (lbs) 58.6
Shipping weight (kg) 26.6
UPS housing material Steel
Cooling method Fan
ENVIRONMENTAL
Operating
Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr.
(full load)
812.9
AC economy mode
BTU / hr. (full load)
347.2
Battery mode BTU / hr.
(full load)
885.6
AC economy mode
efficiency rating (100%
load)
94%
Audible Noise < 45 dB at front side 1m
COMMUNICATIONS
Communications
interface
DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring
port description
Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure
communications
PowerAlert software Included
Communications cable DB9 cabling included
WatchDog
compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time No transfer time (0 ms.) in online, double-conversion mode
Low voltage transfer
to battery power
(setpoint)
80V (100% load), 65V (
High voltage transfer
to battery power
(setpoint)
138
SPECIAL FEATURES
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
High availability UPS
features
Automatic inverter bypass; Hot swappable batteries
Green & high
efficiency features
High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of economy
mode operation
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A
(EMI); Meets FCC Part 68 / Industrie Canada (telecommunications); ROHS (Restriction of Hazardous Substances)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Connected Equipment
Insurance (U.S.,
Canada & Puerto Rico)
$250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
External Battery Packs BP48V24-2U BP48V242U - External Battery Pack for UPS System 1
External Battery Packs BP48V60RT-3U External Battery Pack and Cable. 3U, Expandable, Blue 2-Point
Connector
1
Shutdown Cable Kits AS400CABLE KIT Power Management Tools - UPS Communication Cable Kit for System
i / AS400 / iSeries Servers
1
SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires
SNMPWEBCARD or switched PDU.)
1
SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
UPS Accessories MODBUSCARD For remote monitoring and control via MODBUS protocol 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3543.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
Table des matières
Autres manuels Tripp Lite UPS
Tripp Lite
Tripp Lite SmartPro SMART500RT1U Manuel utilisateur
Tripp Lite
Tripp Lite G1010USB Manuel utilisateur
Tripp Lite
Tripp Lite UPS System AVRX750U Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro SMART1000RM2U Manuel utilisateur
Tripp Lite
Tripp Lite SM750XLNAFTA Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU3000RTXL2U Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU120KX2 Manuel utilisateur
Tripp Lite
Tripp Lite SU10KMBPKX Manuel utilisateur
Tripp Lite
Tripp Lite SMART5000XFMRXL Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro SMC10002URM Manuel utilisateur
Tripp Lite
Tripp Lite SM1000RMNAFTA Manuel utilisateur
Tripp Lite
Tripp Lite AVR750U Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU80KX Manuel utilisateur
Tripp Lite
Tripp Lite BCPRO1400 Manuel utilisateur
Tripp Lite
Tripp Lite AGSM7499 Manuel utilisateur
Tripp Lite
Tripp Lite INTERNET525 Manuel utilisateur
Tripp Lite
Tripp Lite UL1778 Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro SMART2600RM2U Instructions d'installation et d'utilisation
Tripp Lite
Tripp Lite BC Personal Datashield BCPERS300 Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline 5KVA Manuel utilisateur
Manuels UPS populaires d'autres marques
Pylontech
Pylontech Victron & Pylontech US5000 Manuel utilisateur
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur
Mecer
Mecer ME-1000-WTU Manuel utilisateur
Mustek
Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation
Emerson
Emerson Liebert NXL series Manuel utilisateur
MAKELSAN
MAKELSAN BOXER SERIES Manuel utilisateur
