Tripp Lite SMART1000LCDU Manuel utilisateur

SmartPro LCD 120V 1000VA 500W Line-Interactive

Desktop UPS, AVR, Tower, USB, TEL/DSL/Coax, 8

Outlets, ENERGY STAR

MODEL NUMBER: SMART1000LCDU

Description

The SMART1000LCDU SmartPro LCD 120V 1000VA 500W Line-Interactive Desktop UPS provides battery backup and AC power protection against

blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your home theater components and

desktop computer system, the SMART1000LCDU switches to battery backup mode in milliseconds to keep your connected equipment running long enough to

save files and shut down safely with no data loss.

While all eight NEMA 5-15R outlets protect against surges, four outlets also provide up to three hours of UPS battery support for a DVR component, 60

minutes of support for a basic desktop PC and LCD monitor, 10 minutes of support at half load (250W) and three minutes of support at full load (500W).

ENERGY STAR certification helps you save money and energy and protect the environment by meeting strict efficiency guidelines set by the U.S.

Environmental Protection Agency.

Automatic voltage regulation (AVR) maintains 120V nominal output over an input range of 89V to 139V without using battery power. EMI/RFI noise filtering

improves your equipment’s performance and prevents damage. A 1038-joule surge suppression rating protects your equipment from harmful power surges.

With Tripp Lite’s free PowerAlert® software (available via web download), the SMART1000LCDU enables safe unattended system shutdown and file saves in

case of a prolonged power failure.

Features

Reliable Battery Backup

Provides 1000VA/500W power protection for home theater components and desktop computer system

Supports basic desktop computer and LCD monitor up to 60 min. or single DVR components up to 3 hr. during power outage

Supports 50% load (250W) up to 10 min. and full load (500W) up to 3 min.

98% full-load efficiency rating saves money in energy costs

Audible alarm indicates loss of utility power or low battery

Protected Outlets

Highlights

Supports a basic desktop PC up

to 60 min. during power outage

8 protected 5-15R outlets—4

battery-supported, 4 surge-only

Offers automatic voltage

regulation (AVR)

LCD screen reports real-time

UPS and power status

Meets strict ENERGY STAR

efficiency guidelines

Package Includes

SMART1000LCDU SmartPro

LCD 120V 1000VA 500W

Line-Interactive Desktop UPS

USB cable

Telephone cable

Owner’s manual

1 / 5

4 NEMA 5-15R outlets deliver battery backup for devices that require constant power

All 8 outlets protect against surges or spikes that can harm equipment or data

Automatic Voltage Regulation (AVR)

Maintains 120V nominal output over input range of 89V–139V without using battery power

Rotatable LCD Status Screen

Large LCD screen shows real-time input voltage, overload, AVR and battery statuses

Rotates for easy viewing in both horizontal and vertical installations

AC Line, Coaxial and Tel/DSL Surge Suppression

1038-joule surge suppression rating protects connected equipment and data from harmful power surges

Tel/DSL RJ11 jacks (with included cable) protect standard dialup/DSL connection

2.2 Hz coaxial jacks protect CATV, broadband cable internet, satellite or broadcast antenna connections

EMI/RFI Line Noise Filtering

Removes electromagnetic and radio frequency interference that can disrupt or damage equipment’s performance

USB Ports

HID-compliant USB port (when used with free PowerAlert software) enables safe unattended system shutdown and file saves in the event of a prolonged

power failure

Front-panel USB port delivers 2.1A for fast charging of smartphones and tablets

ENERGY STAR Certification

Saves you money, saves energy and protects the environment by meeting strict EPA efficiency guidelines

Flexible Installation Options

Space-saving NEMA 5-15P right-angle plug with 6 ft. cord

Adapts to vertical or horizontal installation without special hardware

Specifications

OUTPUT

Output Volt Amp Capacity (VA) 1000

Output Watt Capacity (Watts) 500

Nominal Output Voltage(s)

Supported 115V; 120V

Frequency Compatibility 60 Hz

Output Voltage Regulation (Battery

Mode) 115V (+/- 5%)

Output Receptacles (8) 5-15R

UPS Output Receptacles (Surge

Suppression Only) 4 UPS outlets, 4 surge-only outlets

2 / 5

Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)

Output AC Waveform (AC Mode) Sine wave

Output AC Waveform (Battery Mode) PWM sine wave

INPUT

Rated input current (Maximum Load) 12A

Nominal Input Voltage(s) Supported 120V AC

UPS Input Connection Type 5-15P; Right-Angled

UPS Input Cord Length (ft.) 6

UPS Input Cord Length (m) 1.8

Recommended Electrical Service 15A 120V

Input Phase Single-Phase

BATTERY

Full Load Runtime (min.) 3 min. (500w)

Half Load Runtime (min.) 10 min. (250w)

DC System Voltage (VDC) 12

Battery Recharge Rate (Included

Batteries) Less than 20 hours from 10% to 90%

Internal UPS Replacement Battery

Cartridge RBC51

Battery Access Battery access door

Battery Replacement Description Hot-swappable, user replaceable batteries

Expandable Runtime No

VOLTAGE REGULATION

Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89

Undervoltage Correction Input voltages between 89 and 104 are boosted by 14%

USER INTERFACE, ALERTS & CONTROLS

Front Panel LCD Display Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace

battery status; LCD screen rotates for rack/tower viewing

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness

Alarm Cancel Operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Audible Alarm Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software

SURGE / NOISE SUPPRESSION

3 / 5

UPS AC Suppression Joule Rating 1038

UPS AC Suppression Response

Time Instantaneous

UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out); Coax jacks (1 set)

EMI / RFI AC Noise Suppression Yes

PHYSICAL

Installation Form Factors Supported

with Included Accessories Tower

Primary Form Factor Tower

UPS Power Module Dimensions

(hwd, in.) 11.84 x 3.66 x 7.24

UPS Power Module Dimensions

(hwd, cm) 30.1 x 9.3 x 18.4

UPS Power Module Weight (lbs.) 15.55

UPS Power Module Weight (kg) 7.05

UPS Shipping Dimensions (hwd / in.) 10.43 x 15.55 x 4.8

UPS Shipping Dimensions (hwd /

cm) 26.5 x 39.5 x 12.2

Shipping Weight (lbs.) 16.2

Shipping Weight (kg) 7.4

UPS Housing Material ABS

Primary UPS Height (mm) 301

Primary UPS Width (mm) 93

Primary UPS Depth (mm) 184

Shipping Height (mm) 265

Shipping Width (mm) 395

Shipping Depth (mm) 122

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 5 to 95%, non-condensing

AC Mode BTU / Hr. (Full Load) 31

Battery Mode BTU / Hr. (Full Load) 482

AC Mode Efficiency Rating (100%

Load) 98%

COMMUNICATIONS

4 / 5

Communications Interface USB (HID enabled)

PowerAlert Software For local monitoring via the UPS’s built-in USB port, download PowerAlert Local software at

http://www.tripplite.com/poweralert

Communications Cable USB cable included

WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

Network UPS Tools Compatibility NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at

http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite

LINE / BATTERY TRANSFER

Transfer Time 3 milliseconds

Low Voltage Transfer to Battery

Power (Setpoint) 89

High Voltage Transfer to Battery

Power (Setpoint) 139

SPECIAL FEATURES

Cold Start (Startup in Battery Mode

During a Power Failure) Cold-start operation supported

Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications ENERGY STAR Qualified; Meets FCC Part 15 Category B (EMI); Tested to CSA (Canada); Tested to NOM

(Mexico); Tested to UL1778 (USA)

WARRANTY

Product Warranty Period (U.S. &

Canada) 3-year limited warranty

Product Warranty Period (Latin

America) 3-year limited warranty

Product Warranty Period

(International) 2-year limited warranty

Product Warranty Period (Mexico) 3-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:

https://www.tripplite.com/products/product-certification-agencies

5 / 5
