User's Guide

SLUU321B–June 2008–Revised May 2010

bq2415x YFF EVM

Contents

1 Introduction .................................................................................................................. 1

1.1 EVM Features ...................................................................................................... 1

1.2 General Description ................................................................................................ 2

1.3 I/O Description ...................................................................................................... 2

1.4 Control and Key Parameters Setting ............................................................................ 2

1.5 Recommended Operating Conditions ........................................................................... 2

2 Test Summary ............................................................................................................... 3

2.1 Definitions ........................................................................................................... 3

2.2 Equipment ........................................................................................................... 3

2.3 Equipment Setup ................................................................................................... 4

2.4 Procedure ........................................................................................................... 6

3 PCB Layout Guideline ...................................................................................................... 7

4 Bill of Materials, Board Layout and Schematics ........................................................................ 8

4.1 Bill of Materials ..................................................................................................... 8

4.2 Board Layout ...................................................................................................... 10

4.3 Schematic ......................................................................................................... 12

List of Figures

1 Connections of the HPA172 Kit........................................................................................... 4

2 Original Test Setup for HPA256 (bq2415x EVM)....................................................................... 5

3 The Main Window of the bq2415x Evaluation Software (For bq24150/1/2/0A/1A)................................. 5

4 The Main Window of the bq24153_6_8 Evaluation Software for bq24153/6/8 ..................................... 6

5 Test setup for HPA256 .................................................................................................... 7

6 Top Layer................................................................................................................... 10

7 Bottom Layer............................................................................................................... 10

8 Top Assembly.............................................................................................................. 11

9 Top Silk ..................................................................................................................... 11

List of Tables

1 Factory Jumper Settings ................................................................................................... 4

1 Introduction

1.1 EVM Features

• Evaluation Module For BQ2415x

• High Efficiency Fully Integrated NMOS-NMOS Synchronous Buck Charger With 3MHz Frequency

• Integrated Power FETs for Up To 1.25-A Charge Rate

• Programmable Battery Voltage, Charge Current, and Input Current via I2C Interface

• Input Operating Range 4 V–6 V

• Boost Mode Operation for USB OTG

SLUU321B–June 2008–Revised May 2010 bq2415x YFF EVM

Introduction

www.ti.com

• LED Indication for Status Signals

• Test Points for Key Signals Available for Testing Purpose. Easy Probe Hook-up

• Jumpers Available. Easy to Change Connections.

1.2 General Description

The bq2415x evaluation module is a complete charger module for evaluating compact, flexible,

high-efficiency, USB-friendly switch-mode charge management solution for single-cell Li-ion and

Li-polymer batteries used in a wide range of portable applications.

The bq2415x integrates a synchronous PWM controller, power MOSFETs, input current sensing,

high-accuracy current and voltage regulation, and charge termination, into a small WCSP package.

The charge parameters can be programmed through an I2C interface.

For details, see the bq2415x data sheets (SLUS824,SLUS847,SLUSA27, and SLUS931).

1.3 I/O Description

Jack Description

J1–DC+ AC adapter or USB, positive output

J1–DC– AC adapter or USB, negative output

J2–BAT– Battery negative terminal, connect to DC-

J2-AUXPWR/CD Connect to AUXPWR pin or CD pin

J2-BAT+ Charger positive output, connect to CSOUT pin

J3–SCL I2C clock, connect to SCL pin

J3–SDA I2C data, connect to SDA pin

J3–DC– AC adapter or USB, negative output

J4–STAT Status output, can be connected to STAT pin by JMP1 set to EXT (2-3)

J4–OTG/SLRST Connect to OTG/SLRST pin

J4–DC– AC adapter or USB, negative output

1.4 Control and Key Parameters Setting

Jack Description Factory Setting

LED 1-2: Connect STAT pin to LED on EVM

JMP1 Jumper On LED (1-2)

EXT 2-3: Connect STAT pin to J4-1

HI 1-2: OTG or SLRST high (input or battery voltage)

JMP2 LO 2-3: OTG or SLRST low (ground) See Table 1

JMP3 J2-BAT+ connect to J2-AUXPWR/CD

JMP4 AUXPWR/CD pin connect to high or low or float

JMP5 OTG/SLRST pin 10k resistor to ground or float Jumper ON

1.5 Recommended Operating Conditions

Min Typ Max Unit Notes

Supply voltage, VIN Input voltage from ac adapter input 4 5 6 V

Battery voltage, VBAT Voltage applied at VBAT terminal of J8 0 3-4.2 4.44 V

Supply current, IAC Maximum input current from ac adapter input 0 0.1–0.5 1.5 A

Charge current, Ichrg Battery charge current 0.55 0.7 1.25 A

Operating junction temperature range, TJ0 125 °C

2bq2415x YFF EVM SLUU321B–June 2008–Revised May 2010

www.ti.com

Test Summary

2 Test Summary

2.1 Definitions

This procedure details how to configure the HPA256 evaluation board. On the test procedure the following

naming conventions are followed. Refer to the HPA256 schematic for details.

VXXX : External voltage supply name (VADP, VBT, VSBT)

LOADW: External load name (LOADR, LOADI)

V(TPyyy): Voltage at internal test point TPyyy. For example, V(TP12) means the voltage at

TP12.

V(Jxx): Voltage at jack terminal Jxx

V(TP(XXX)): Voltage at test point “XXX”. For example, V(ACDET) means the voltage at the test

point which is marked as “ACDET”.

V(XXX, YYY): Voltage across point XXX and YYY.

I(JXX(YYY)): Current going out from the YYY terminal of jack XX.

Jxx(BBB): Terminal or pin BBB of jack xx

Jxx ON : Internal jumper Jxx terminals are shorted

Jxx OFF: Internal jumper Jxx terminals are open

Jxx (-YY-) ON: Internal jumper Jxx adjacent terminals marked as “YY” are shorted

Measure: →A,B Check specified parameters A, B. If measured values are not within specified limits

the unit under test has failed.

Observe →A,B Observe if A, B occur. If they do not occur, the unit under test has failed.

Assembly drawings have location for jumpers, test points and individual components.

2.2 Equipment

2.2.1 POWER SUPPLIES

Power Supply #1 (PS#1): a power supply capable of supplying 5-V at 2-A is required.

2.2.2 LOAD #1

A 10V (or above), 2A (or above) electronic load that can operate at constant current mode.

2.2.3 LOAD #2

A HP 6060B 3-60V/0–60A, 300W system DC electronic load.

Or: equivalent

2.2.4 METERS

Four Fluke 75, (equivalent or better)

Or: Two equivalent voltage meters and two equivalent current meters. The current meters must be able to

measure 2A current.

2.2.5 COMPUTER

A computer with at least one USB port and a USB cable. The bq2415x evaluation software must be

properly installed.

2.2.6 HPA172 COMMUNICATION KIT

A HPA172 USB to I2C communication kit.

SLUU321B–June 2008–Revised May 2010 bq2415x YFF EVM

Computer

USB port

USB Interface

Adapter

I/O

USB

Texas Instruments

10-pin

Ribbon

Cable

To EVM

Test Summary

www.ti.com

2.2.7 SOFTWARE

For -001, -002, -003, -004, -005 unzip BQ2415xSetup.zip and double click on the “SETUP.EXE” file.

Follow the installation steps.

For -006, -007, -008 unzip BQ24153_6_8Setup.zip and double click on the “SETUP.EXE” file. Follow the

installation steps.

2.3 Equipment Setup

(A) Set the power supply #1 for 5V ± 100mV DC, 2.0 ± 0.1A current limit and then turn off supply.

(B) Connect the output of power supply #1 in series with a current meter (multimeter) to J1 (DC+, DC–).

(D) Connect the Load #2 in series with a current meter (multimeter) to J2 (BAT+, BAT–). Make sure a

voltage meter is connected across J2 (BAT+, BAT–). Turn on the Load #2. Use the constant voltage

mode. Set the output voltage to 2.5V.

(E) Turn off Load #2.

(F) Connect J5 to HPA172 kit by 10-pin ribbon cable. Connect the USB port of the HPA172 kit to the USB

port of the computer. The connections are shown in Figure 1.

Figure 1. Connections of the HPA172 Kit

(G) Installed jumpers per Table 1

Table 1. Factory Jumper Settings

Spin JMP1 JMP2 JMP3 JMP4 JMP5

HPA256-001 (-LED-) ON (-LO-) ON ON OFF ON

(bq24150)

HPA256-002 (-LED-) ON (-LO-) ON ON OFF ON

(bq24151)

HPA256-003 (-LED-) ON (-LO-) ON ON OFF ON

(bq24152)

HPA256-004 (-LED-) ON (-LO-) ON ON OFF ON

(bq24150A)

HPA256-005 (-LED-) ON (-LO-) ON ON OFF ON

(bq24151A)

HPA256-006 (-LED-) ON (-LO-) ON OFF (-LO-) ON ON

(bq24153)

HPA256-007 (-LED-) ON (-HI-) ON OFF (-LO-) ON ON

(bq24156)

HPA256-008 (-LED-) ON (-LO-) ON OFF (-LO-) ON ON

(bq24158)

4bq2415x YFF EVM SLUU321B–June 2008–Revised May 2010

BQ2415x EVM

DC+

J 1

DC -

BAT+

SC L

BAT -

APPLICATION

CIRCUIT

J 4

D1 JMP1 JMP2

JMP3

AUXPWR

SDA

DC-

ST AT

OTG

S LR S T

JMP5

JMP4

Iin I

Power

supply #1

ILoad

Ichrg

USB

Cable HPA172 Ribbon

Cable

www.ti.com

Test Summary

(H) After the steps above, the test setup for HPA272 is shown in Figure 2

Figure 2. Original Test Setup for HPA256 (bq2415x EVM)

(I) Turn on the computer.

• For -001, -002, -003, -004, -005, open the bq2415x evaluation software. The main window of the

software is shown in Figure 3.

• For -006, -007, -008, open the bq24153_6_8 evaluation software. Select part number (bq24153,

bq24156, and bq24158) and click GO button. The main window of the software is show in

Figure 4.

Figure 3. The Main Window of the bq2415x Evaluation Software (For bq24150/1/2/0A/1A)

SLUU321B–June 2008–Revised May 2010 bq2415x YFF EVM

Test Summary

www.ti.com

Figure 4. The Main Window of the bq24153_6_8 Evaluation Software for bq24153/6/8

2.4 Procedure

2.4.1 Charge Voltage and Current Regulation

1. Make sure the EQUIPMENT SETUP steps are followed. Turn on PS#1.

2. Software setup:

• For -001, -002, -003, -004, -005, click Immediate Update Disabled button. It changes to Immediate

Update Enabled. Check Auto Reset Enable, set Rate to 5 seconds. Check Periodic Updates, set

Rate to 1 second. Make sure Operation Mode is Charger Mode. Uncheck Charge Current

Termination. Check STAT Pin. Select Battery Regulation Voltage to 4.20V.

• For -006, -007, -008, Make sure Immediate Updates is enabled. Check Periodic Resets, set Rate

to 5 seconds. Check Periodic Reads, set Rate to 1 second. Make sure Operation Mode is Charger

Mode. Uncheck Charge Current Termination. Check STAT Pin. Select Charge Current Sense

Voltage to Normal. Select Battery Regulation Voltage to 4.20V.

Measure →V(J2(VBAT+, VBAT–)) = 4.2 ± 100mV

Observe →D1 is on.

3. Enable Load #2.

Measure →V(J2(VBAT+, VBAT–)) = 2.5 ± 100mV

Measure →Ichrg = 160mA ± 40mA

Measure →Iin = 93mA ± 5mA

4. Select Charge Current to 950mA, select Input Current Limit to 500mA.

Measure →Ichrg = 750mA ± 100mA

Measure →Iin = 475mA ± 25mA

5. Check Disable Charger. Turn off PS#1, turn off Load #2 and disconnect

6bq2415x YFF EVM SLUU321B–June 2008–Revised May 2010

BQ2415x EVM

DC+

J 1

DC -

BAT+

SC L

BAT -

APPLICATION

CIRCUIT

J 4

D1 JMP1 JMP2

JMP3

AUXPWR

SDA

DC-

ST AT

OT G

SLRS T

JMP5

JMP4

Power

supply #1

Load

I in

USB

Cable HPA172 Ribbon

Cable

www.ti.com

PCB Layout Guideline

2.4.2 Boost Function (For -001, -002, -003, -004, -005, -006, -008 only)

1. Adjust PS#1 output to 3.7V and disable the output. Connect the PS#1 in series with a current meter

(multimeter) to J2 (BAT+, BAT–). Make sure a voltage meter is connected across J2 (BAT+, BAT–).

2. Set the Load #1 current to 200mA ± 20mA but disable the output. Connect the output of the Load #1 in

series with a current meter (multimeter) to J1 (DC+, DC–). Make sure a voltage meter is connected

across J1 (DC+, DC–). The setup is now like Figure 5 for HPA256.

Figure 5. Test setup for HPA256

3. Turn on PS#1 output

4. Software setup: Change Operation Mode to Boost Mode.

Measure →V(J1(DC+, DC–))=5V ± 0.2V

5. Enable Load #1.

Measure →V(J1(DC+, DC–))=5V ± 0.2V

Measure →Iin = 330mA ± 40mA

Measure →Io = 200mA ± 20mA

3 PCB Layout Guideline

1. To obtain optimal performance, the power input capacitors, connected from input to PGND, should be

placed as close as possible to the IC.

2. The output inductor should be placed close to the IC and the output capacitor connected between the

inductor and PGND of the IC. The intent is to minimize the current path loop area from the SW pin

through the LC filter and back to the PGND pin. To prevent high frequency oscillation problems, proper

layout to minimize high frequency current path loop is critical.

3. The sense resistor should be adjacent to the junction of the inductor and output capacitor. Route the

sense leads connected across the RSNS back to the IC, close to each other (minimize loop area) or

on top of each other on adjacent layers (do not route the sense leads through a high-current path).

4. Place all decoupling capacitor close to their respective IC pin and as close as to PGND (do not place

components such that routing interrupts power stage currents). All small control signals should be

routed away from the high current paths.

5. The PCB should have a ground plane (return) connected directly to the return of all components

through vias (two vias per capacitor for power-stage capacitors, two vias for the IC PGND, one via per

capacitor for small-signal components). A star ground design approach is typically used to keep circuit

block currents isolated (high-power/low-power small-signal) which reduces noise-coupling and

ground-bounce issues. A single ground plane for this design gives good results. With this small layout

and a single ground plane, there is no ground-bounce issue, and having the components segregated

minimizes coupling between signals.

6. The high-current charge paths into VBUS, PMID and from the SW pins must be sized appropriately for

the maximum charge current in order to avoid voltage drops in these traces. The PGND pins should be

connected to the ground plane to return current through the internal low-side FET.

SLUU321B–June 2008–Revised May 2010 bq2415x YFF EVM

Bill of Materials, Board Layout and Schematics

www.ti.com

4 Bill of Materials, Board Layout and Schematics

4.1 Bill of Materials

'24150- '24151- bq241 '24150 '24151 '24153- '24156- '24158- RefDes Value Description Size Part Number MFR

001 002 52-003 A-004 A-005 006 007 008

1 1 1 1 1 1 1 1 C1 1uF Capacitor, Ceramic, 603 GRM188R61C105K muRata

X5R, 16V, +-10%

1 1 1 1 1 1 1 1 C2 4.7uF Capacitor, Ceramic, 805 GRM21BR71C475K muRata

X7R, 16V, +-10%

2 2 2 2 2 2 2 2 C3, C9 10uF Capacitor, Ceramic, 603 GRM188R60J106M muRata

X5R, 6.3V, +-20%

2 2 2 2 2 2 2 2 C4, C5 1uF Capacitor, Ceramic, 402 GRM155R61A105K muRata

X5R, 10V, +-10%

1 1 1 1 1 1 1 1 C6 10nF Capacitor, Ceramic, 402 GRM155R61C103K muRata

X5R, 16V, +-10%

2 2 2 2 2 2 2 2 C7, C8 0.1uF Capacitor, Ceramic, 402 GRM155R71C104K muRata

X7R, 16V, +-10%

1 1 1 1 1 1 1 1 D1 Green Diode, LED, Green, 603 LTST-C190GKT Liteon

2.1-V, 20-mA, 6-mcd

1 1 1 1 1 1 1 1 D2 BAT54C Diode, Dual Schottky, SOT23 BAT54C Vishay-Liteon

200-mA, 30-V

1 1 1 1 1 1 1 1 J1 ED1514/2DS Terminal Block, 2-pin, 0.27 x 0.25 inch ED1514/2DS OST

6-A, 3.5mm

3 3 3 3 3 3 3 3 J2, J3, J4 ED1515/3DS Terminal Block, 3-pin, 0.41 x 0.25 inch ED1515/3DS OST

6-A, 3.5mm

1 1 1 1 1 1 1 1 J5 2510- Connector, Male 0.338 x 0.788 2510-6002UB 3M

6002UB Straight 2x5 pin, 100mil inch

spacing, 4 Wall

3 3 3 3 3 3 3 3 JMP1, PTC03SAAN Header, 3-pin, 100mil 0.100 inch x 3 PTC03SAAN Sullins

JMP2, spacing, (36-pin strip)

JMP4

2 2 2 2 2 2 2 2 JMP3, PTC02SAAN Header, 2-pin, 100mil 0.100 inch x 2 PTC02SAAN Sullins

JMP5 spacing, (36-pin strip)

4 4 4 4 4 4 4 4 929950-00 Shorting jumpers, 2-pin, 929950-00 3M/ESD

100mil spacing,

1 1 1 1 1 1 1 1 L1 1.0uH 2.5mmx2mm, 1.0uH, 0.11x0.09 inch "LQM2HPN1R0MJ0 or muRata or

+/-30%, 1.5A MIPS2520D1R0 or FDK or

MDT2520-CN1R0M or TOKO or

CP1008" Inter-Technical

1 1 1 1 1 1 1 1 R1 0.068 Resistor, Chip, 402 ERJ-2BWJR068X Panasonic

68mohm, 125mW, 5%

8bq2415x YFF EVM SLUU321B–June 2008–Revised May 2010

www.ti.com

Bill of Materials, Board Layout and Schematics

'24150- '24151- bq241 '24150 '24151 '24153- '24156- '24158- RefDes Value Description Size Part Number MFR

001 002 52-003 A-004 A-005 006 007 008

1 1 1 1 1 1 1 1 R2 5.1k Resistor, Chip, 603 Std Std

5.1k-Ohms, 1/16-W, 5%

1 1 1 1 1 1 1 1 R3 10k Resistor, Chip, 603 Std Std

10k-Ohms, 1/16-W, 5%

1 1 1 1 1 1 1 1 R4 200 Resistor, Chip, 603 Std Std

200-Ohms, 1/16-W, 5%

1 1 1 1 1 1 1 1 R5 200 Resistor, Chip, 603 Std Std

200-Ohms, 1/16-W, 5%

1 0 0 0 0 0 0 0 U1 BQ24150YF IC, Battery Charger for WCSP BQ24150YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

0 1 0 0 0 0 0 0 U1 BQ24151YF IC, Battery Charger for WCSP BQ24151YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

0 0 1 0 0 0 0 0 U1 BQ24152YF IC, Battery Charger for WCSP BQ24152YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

0 0 0 1 0 0 0 0 U1 BQ24150AY IC, Battery Charger for WCSP BQ24150AYFF TI

FF Single-Cell Li-Ion and

Li-Polymer Battery

0 0 0 0 1 0 0 0 U1 BQ24151AY IC, Battery Charger for WCSP BQ24151AYFF TI

FF Single-Cell Li-Ion and

Li-Polymer Battery

0 0 0 0 0 1 0 0 U1 BQ24153YF IC, Battery Charger for WCSP BQ24153YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

0 0 0 0 0 0 1 0 U1 BQ24156YF IC, Battery Charger for WCSP BQ24156YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

0 0 0 0 0 0 0 1 U1 BQ24158YF IC, Battery Charger for WCSP BQ24158YFF TI

F Single-Cell Li-Ion and

Li-Polymer Battery

1 1 1 1 1 1 1 1 -- HPA256 PCB, 2.0 In x 2.0 In x PCB Any

0.031 In

SLUU321B–June 2008–Revised May 2010 bq2415x YFF EVM

Bill of Materials, Board Layout and Schematics

www.ti.com

4.2 Board Layout

Figure 6. Top Layer

Figure 7. Bottom Layer

10 bq2415x YFF EVM SLUU321B–June 2008–Revised May 2010

Table des matières

Autres manuels Texas Instruments Microcontrôleur

Texas Instruments

Texas Instruments MSP430F67461 Manuel utilisateur

Texas Instruments

Texas Instruments OMAP-L138/C6748 Manuel utilisateur

Texas Instruments

Texas Instruments bq24707EVM Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad CC1312PSIP Manuel utilisateur

Texas Instruments

Texas Instruments Serial Programming Adapter MSP430 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320 2806 Series Manuel du produit

Texas Instruments

Texas Instruments TMDX654IDKEVM Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad MSP-EXP430FR5994 Manuel utilisateur

Texas Instruments

Texas Instruments Serial Programming Adapter MSP430 Manuel utilisateur

Texas Instruments

Texas Instruments DLP Discovery 4100 Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon Products CC2400DK Manuel utilisateur

Texas Instruments

Texas Instruments TPS6594-Q1 Series Manuel utilisateur

Texas Instruments

Texas Instruments CC3235MODSF SimpleLink Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F28004x Manuel du produit

Texas Instruments

Texas Instruments MSP430 series Manuel utilisateur

Texas Instruments

Texas Instruments TAS6584-Q1 EVM Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink MSP432P4 Series Manuel du produit

Texas Instruments

Texas Instruments MSP430F6745 Manuel utilisateur

Texas Instruments

Texas Instruments MSP430F67671 Manuel utilisateur

Texas Instruments

Texas Instruments LMK03318EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS570LS Manuel utilisateur

Texas Instruments

Texas Instruments TMDXRM42HDK Manuel utilisateur

Texas Instruments

Texas Instruments MSP430F5638 Manuel utilisateur

Texas Instruments

Texas Instruments MSP430 series Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F800 Manuel utilisateur

Energy micro

Energy micro EFM32 Giant Gecko Starter Kit Manuel utilisateur

Mikroe

Mikroe click Proximity 2 Manuel utilisateur

Texas Instruments bq2415 Series Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques
