CC2543-CC2544 Development Kit Quick Start Guide

Opening the Box and Running the Packet Error Rate Test Application

1. Kit Contents

•2 x SmartRF05EB (the two large boards)

•2 x CC2543 Evaluation Module (CC2543EM)

•2 x Pulse W1010 Antennas

•1 x CC2544 Dongle

•Cables

•Documentation

The RF boards in this kit are FCC and IC

certified and tested/complies with ETSI/R&TTE

over temperature from 0 to +35°C. The antenna,

W1010 from Pulse, is a ¼ wave dipole antenna

with 2 dBi gain.

Caution! The kit contains ESD

sensitive components. Handle with

care to prevent permanent damage.

2. Hardware Requirements

To run the example described in this Quick

Start Guide, you would need either two

CC2543Ems mounted on SmartRF05

Evaluation Boards (SmartRF05EB - Rev 1.8.1

or later). Or a single CC2543EM mounted on

a SmartRF05EB and a CC2544 Dongle

(powered through USB). The SmartRF05EBs

are included in the CC2543-CC2544DK.

More information about the SmartRF05EB can

be found in www.ti.com/lit/swru210.

The CC2543EM boards can also be plugged

into a battery board (see www.ti.com/tool/soc-

bb) for standalone operation.

3. Hardware Setup

Connect the antenna to the SMA connector on

the CC2543EM. Tighten the antenna’s screw

firmly on to the SMA connector. If not properly

connected, you might see reduced RF

performance.

Next, mount the CC2543EMs firmly on to

connectors P5 and P6 on the SmartRF05EB.

The CC2544 Dongle can be connected to any

USB port to power the device.

Caution! To minimize risk of injury, avoid

touching components during operation if

symbolized as hot.

4. Power Options

There are several ways of applying power to the

SmartRF05EB.

•2 x 1.5 V AA Alkaline Batteries

•USB

•External Power Supply

For the batteries and USB, there are voltage

regulators on the SmartRF05EB that will set the

on-board voltage to 3.3 V. The external power

supply should set a voltage that does not exceed

3.3 V. Note that there should only be one

active power source at any one time.

Warning! To minimize risk of personal injury or

property damage, never use rechargeable

batteries to power the board.

5. Power the

Boards

Find jumper P11 on

the top side of each

SmartRF05EB. This jumper is used to set the

power source for the board. Set P11 to “1-2” if

you are using battery power. Set P11 to “2-3” if

you are using USB or an

external power supply.

Once you have set P11,

find switch P8 on the top

side of each

SmartRF05EB. To power up the boards, flip the

switch from the “OFF” position to “ON”.

Do not leave EVM powered when

unattended.

6. Start-up Screen

The CC2543EMs and the CC2544 Dongle

will be pre-loaded with a Packet Error Rate

(PER) test application. The LCD screens on

the two SmartRF05EBs should display the

messages below:

A green led (LED2 on CC2544Dongle, LED1

on SmartRF05EB) will blink continuously

After the application has started.

7. Choosing Mode

The application can be used between two

CC2543EM’s or between a single CC2543EM

and the CC2544 Dongle. There are two possible

modes of operation called “Remote” and

“Master”. The CC2544Dongle is set to master by

default as it is the only option for this device in

this application. After button S1 is pushed at the

start up screen, the mode selection screen

(showed to the left below) will appear. The

Remote mode is shown by default. Press the

joystick up and down to change between master

and remote mode and press button S1 to

confirm.

In the remote mode all the parameters for the

current PER test must be set up before the test

begins.

8. Master Mode

In “Master” mode, the radio will repeatedly (once

every 10 milliseconds) send out a “beacon”

signal (250 kbps, GFSK modulation, 160 kHz

deviation, 2479 MHz) and listen for a response

from the remote device. Once the beacon is

acknowledged by the “Remote”, the actual PER

test begins. During the PER test, packets are

sent at a fixed repetition rate of 10 msec.

No more actions are needed from the user for

this master device to work.

9. Frequency Selection

When the remote mode is chosen, a series of

settings must be configured to set up the link for

the PER test. The frequency must be selected

first. Move the joystick up or down to change the

frequency (channel) and press S1 to confirm the

choice.

10. Modulation Setup

There are 6 different modulation schemes

available for this application. The different

bitrates are 250 Kbps, 500 Kbps, 1Mbps and 2

Mbps. MSK modulation is used for the 500 Kbps

rate and GFSK for the rest. Move the joystick up

or down to change the scheme and press S1 to

confirm the choice.

11. Packet Length

The packet length can be set to 10, 16, 32, 64 or

120 bytes. Move the joystick up or down to

change the packet length and press S1 to

confirm the choice.

12. Number of Packets

The total number of packets to be sent for each

run can be set to 200, 1000, 5000, 10000 and .

Move the joystick up or down to change the

number of packets and press S1 to confirm the

choice.

13. Test Running

The remote device acknowledges the beacon

signal from the master and sends the

configuration packet. The PER test begins. While

the master device is sending packets the yellow

led will be lit on the smartRF05EB (“LED3”) or

the red led on the CC2544 Dongle (“LED1”).

14. PER Test Summary

The first results screen will display the number of

packets received without errors (“Good”), the

number that were received with a CRC error

(“Bad”), and the number that were expected but

not received (“LOST”). Push button S1 to

proceed to the second results screen.

15. Repeat Test

The final screen allows the test to be repeated by

pushing “Button 1” (S1). Note that the set up data

is maintained. If you wish to enter different test

parameters, you may do so by pushing “EM

RESET” button, located at the approximate

center of the SmartRF05EB.

Additional Tools and Links

SmartRF™ Studio

SmartRF Studio allows you to configure the radio,

run RF performance tests, and run link tests

between the two SmartRF05EBs.

SmartRF Studio can be downloaded from

www.ti.com/smartrfstudio

SmartRF Flash Programmer

Texas Instruments has a simple tool which can

be used to program and flash the CC2543 and

CC2544.

SmartRF Flash Programmer can be

downloaded from www.ti.com/tool/flash-

programmer

IAR Embedded Workbench

To develop software, program, and debug the

CC2543 and CC2544, you should use IAR

Embedded Workbench for 8051.

More information on IAR EW8051, including a

free evaluation version download, can be found at

www.iar.com/ew8051.
