DAC7731 Evaluation Module

March 2003 DAP EVMs

User’s Guide

SLAU099

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,

enhancements, improvements, and other changes to its products and services at any time and to discontinue

any product or service without notice. Customers should obtain the latest relevant information before placing

orders and should verify that such information is current and complete. All products are sold subject to TI’s terms

and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in

accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI

deems necessary to support this warranty. Except where mandated by government requirements, testing of all

parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for

their products and applications using TI components. To minimize the risks associated with customer products

and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,

in which TI products or services are used. Information published by TI regarding third-party products or services

does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.

Use of such information may require a license from a third party under the patents or other intellectual property

of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction

of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for

such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that

product or service voids all express and any implied warranties for the associated TI product or service and

is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM IMPORTANT NOTICE

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:

This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION

PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided

may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective

considerations, including product safety measures typically found in the end product incorporating the goods.

As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic

compatibility and therefore may not meet the technical requirements of the directive.

Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide, the kit may be returned

within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE

WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,

IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY

PARTICULAR PURPOSE.

The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user

indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products

received may not be regulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction

of the product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic

discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE

TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not

exclusive.

TI assumesno liability for applications assistance, customer product design, software performance, or

infringement of patents or services described herein.

Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM

User’s Guide prior to handling the product. This notice contains important safety information about temperatures

and voltages. For further safety concerns, please contact the TI application engineer.

Persons handling the product must have electronics training and observe good laboratory practice standards.

No license is granted under any patent right or other intellectual property right of TI covering or relating to any

machine, process, or combination in which such TI products or services might be or are used.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM WARNINGS AND RESTRICTIONS

It is important to operate this EVM within the input voltage ranges specified in the EVM user’s

guide. The DC power supply for the digital section should not exceed +5 V. The DC power

supply for the analog section should not exceed +15 V to –15V. If used, the external reference

voltage input should not exceed 10 V.

Exceeding the specified input range may cause unexpected operation and/or irreversible

damage to the EVM. If there are questions concerning the input range, please contact a TI

field representative prior to connecting the input power.

Applying loads outside of the specified output range may result in unintended operation and/or

possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to

connecting any load to the EVM output. If there is uncertainty as to the load specification,

please contact a TI field representative.

During normal operation, some circuit components may have case temperatures greater than

60°C. The EVM is designed to operate properly with certain components above 60°C as long

as the input and output ranges are maintained. These components include but are not limited

to linear regulators, switching transistors, pass transistors, and current sense resistors. These

types of devices can be identified using the EVM schematic located in the EVM User’s Guide.

When placing measurement probes near these devices during operation, please be aware

that these devices may be very warm to the touch.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

Information About Cautions and Warnings

iii

Preface

Read This First

About This Manual

This user’s guide describes the characteristics, operation, and use of the

DAC7731 evaluation module. It covers all pertinent areas involved in properly

using this EVM board along with the devices that it supports. The physical PCB

layout, schematic diagram, and circuit descriptions are included.

How to Use This Manual

This document contains the following chapters:

Chapter 1—EVM Overview

Chapter 2—PCB Design and Performance

Chapter 3—EVM Operation

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Trademarks

Related Documentation From Texas Instruments

To obtain a copy of any of the following TI documents, call the Texas

Instruments Literature Response Center at (800) 477-8924 or the Product

Information Center (PIC) at (972) 644-5580. When ordering, identify this

manual by its title and literature number. Updated documents can also be

obtained through our website at www.ti.com.

Data Sheets: Literature Number:

DAC7731 SBAS249

REF102 SBCS022

OPA627 SBOS165

Questions about this or other Data Converter EVM’s?

If you have questions about this or other Texas Instruments Data Converter

evaluation modules, please feel free to e-mail the Data Converter Application

Team at dataconvap[email protected].Include in the subject heading the

product you have questions or concerns with.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to subpart

J of part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademarks

The TI Logo is a trademark of Texas Instruments.

SPI and QSPI are trademarks of Motorola, Inc.

Contents

1 EVM Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.1 Supply Voltage 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.2 Reference Voltage 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 EVM Basic Functions 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 PCB Design and Performance 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 PCB Layout 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 EVM Performance 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Bill of Materials 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 EVM Operation 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Factory Default Settings 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Host Processor Operation 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.1 Unity Gain Output 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.2 Output Gain of Two 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.3 Capacitive Load Drive 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Jumper Setting 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Schematic 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

Figures

1-1 EVM Block Diagram 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-1 Top Silkscreen 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-2 Layer 1 (Top Signal Plane) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-3 Layer 2 (Ground Plane) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-4 Layer 3 (Power Plane) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-5 Layer 4 (Bottom Signal Plane) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-6 Bottom Silkscreen 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-7 Drill Drawing 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-8 DAC7731EVM Test Parameters 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-9 INL and DNL Characterization Graphs 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

2-1 Parts Lists 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1 Factory Default Jumper Setting 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-2 Unity Gain Output Jumper Settings 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-3 Gain of Two Output Jumper Settings 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-4 Capacitive Load Drive Output Jumper Settings 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-5 Jumper Setting Functions 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

EVM Overview

This chapter gives a general overview of the DAC7731 evaluation module

(EVM) and describes some of the factors that must be considered when using

the module.

Topic Page

1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 EVM Basic Functions 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Features

1-2

1.1 Features

This EVM features the DAC7731 digital-to-analog converter. The

DAC7731EVM is a simple evaluation module designed for a quick and easy

way to evaluate the functionality and performance of the high resolution,

single-channel, and serial input DAC. This EVM features a serial interface to

communicate with any host microprocessor or TI DSP (with SPI capability)

base system.

1.2 Power Requirements

The following sections describe the power requirements of the EVM.

1.2.1 Supply Voltage

The dc power-supply requirement for the digital section of the EVM is typically

5 V connected to the J3-1 or via J6-10 terminal (when plugged in with another

EVM board or interface card) and is referenced to ground through the J3-2

and J6-5 terminal. The dc power-supply requirement for the analog section

(VCC and VSS) of this EVM range is from 15.75 V to -15.75 V maximum. The

analog section connects through J1-3 and J1-1 respectively, or through J6-1

and J6-2 terminals and are referenced to analog ground through J1-2 and

J6-6 terminals.

The VCC supply source is also used to provide the positive rail of the external

output op amp while the negative rail can be selected between VSS and AGND

via the W5 jumper. The external op amp is installed as an option to provide

output signal conditioning or boost capacitive load drive and for other output

mode requirements.

To avoid potential damage to the EVM board, make sure that the

correct cables are connected to their respective terminals as

labeled on the EVM board.

Stresses above the maximum listed voltage ratings may cause

permanent damage to the device.

1.2.2 Reference Voltage

Although the DAC7731 has a built-in 10-V reference, an external reference

circuit is provided in the EVM board. The external reference circuit can be

isolated if the internal reference voltage is selected.

The 10-V precision voltage reference is provided to supply the external voltage

reference for the DAC through REF102, U3, via jumper W4 by shorting

pins 1 and 2. An adjustable 100-kΩpotentiometer, R11, is installed in series

with 20 kΩ, R10, to allow the user to adjust the reference voltage to its desired

settings. TP1 and TP2 are also provided, as well as J4-20, to allow the user

to connect other external reference source if the onboard reference circuit is

not desired. The external voltage reference must not exceed 10 V dc.

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments TMS320C6748 Manuel utilisateur

Texas Instruments

Texas Instruments DAC8811 Manuel utilisateur

Texas Instruments

Texas Instruments bq2570 Series Manuel utilisateur

Texas Instruments

Texas Instruments TRF3750 Series Manuel utilisateur

Texas Instruments

Texas Instruments TPS54672EVM-222 Manuel utilisateur

Texas Instruments

Texas Instruments TPS54362B EVM Manuel utilisateur

Texas Instruments

Texas Instruments THS1030/31EVM Manuel utilisateur

Texas Instruments

Texas Instruments ADS7042EVM-PDK Manuel utilisateur

Texas Instruments

Texas Instruments TPS61020EVM Manuel utilisateur

Texas Instruments

Texas Instruments BOOSTXL-CAPKEYPAD Manuel utilisateur

Texas Instruments

Texas Instruments TPS65912xEVM-081 Mode d'emploi

Texas Instruments

Texas Instruments TWL6032 Manuel utilisateur

Texas Instruments

Texas Instruments TPA3101D2 Manuel utilisateur

Texas Instruments

Texas Instruments SN65LVDS387EVM Manuel utilisateur

Texas Instruments

Texas Instruments DRV8601 Manuel utilisateur

Texas Instruments

Texas Instruments AFE79 Series Instructions de montage

Texas Instruments

Texas Instruments MCT8316ZT Manuel utilisateur

Texas Instruments

Texas Instruments TPA152 Manuel utilisateur

Texas Instruments

Texas Instruments DLP NIRscan EVM Manuel utilisateur

Texas Instruments

Texas Instruments TDP158RSBEVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS2559EVM-624 Manuel utilisateur

Texas Instruments

Texas Instruments MCT8316ZTEVM Manuel utilisateur

Texas Instruments

Texas Instruments DAC81408EVM Manuel utilisateur

Texas Instruments

Texas Instruments TAS5514B Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
