Texas Instruments CDCM1804 Manuel utilisateur



 

2006 High Performance Analog/CDC

User’s Guide

SCAU009C

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,

enhancements, improvements, and other changes to its products and services at any time and to discontinue

any product or service without notice. Customers should obtain the latest relevant information before placing

orders and should verify that such information is current and complete. All products are sold subject to TI’s terms

and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in

accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI

deems necessary to support this warranty. Except where mandated by government requirements, testing of all

parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for

their products and applications using TI components. To minimize the risks associated with customer products

and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,

in which TI products or services are used. Information published by TI regarding third-party products or services

does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.

Use of such information may require a license from a third party under the patents or other intellectual property

of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction

of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for

such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that

product or service voids all express and any implied warranties for the associated TI product or service and

is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Following are URLs where you can obtain information on other Texas Instruments products and application

solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio

Data Converters dataconverter.ti.com Automotive www.ti.com/automotive

DSP dsp.ti.com Broadband www.ti.com/broadband

Interface interface.ti.com Digital Control www.ti.com/digitalcontrol

Logic logic.ti.com Military www.ti.com/military

Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork

Microcontrollers microcontroller.ti.com Security www.ti.com/security

Low Power Wireless www.ti.com/lpw Telephony www.ti.com/telephony

Video & Imaging www.ti.com/video

Wireless www.ti.com/wireless

Mailing Address: Texas Instruments

Post Office Box 655303 Dallas, Texas 75265

EVALUATION BOARD/KIT IMPORTANT NOTICE

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:.

This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR

EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end−product fit for general

consumer use. Persons handling the product(s) must have electronics training and observe good engineering

practice standards. As such, the goods being provided are not intended to be complete in terms of required

design−, marketing−, and/or manufacturing−related protective considerations, including product safety and

environmental measures typically found in end products that incorporate such semiconductor components or

circuit boards. This evaluation board/kit does not fall within the scope of the European Union directives regarding

electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC, CE or UL, and therefore

may not meet the technical requirements of these directives or other related directives.

Should this evaluation board/kit not meet the specifications indicated in the User’s Guide, the board/kit may be

returned within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE

EXCLUSIVE WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES,

EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR

FITNESS FOR ANY PARTICULAR PURPOSE.

The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user

indemnifies TI from all claims arising from the handling or use of the goods. Due to the open construction of the

product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic

discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE

TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not

exclusive.

TI assumes no liability for applications assistance, customer product design, software performance, or

infringement of patents or services described herein.

Please read the User’s Guide and, specifically, the Warnings and Restrictions notice in the User’s Guide prior

to handling the product. This notice contains important safety information about temperatures and voltages. For

additional information on TI’s environmental and/or safety programs, please contact the TI application engineer

or visit www.ti.com/esh.

No license is granted under any patent right or other intellectual property right of TI covering or relating to any

machine, process, or combination in which such TI products or services might be or are used.

FCC WARNING

This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR

EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end−product fit for general

consumer use. It generates, uses, and can radiate radio frequency energy and has not been tested for

compliance with the limits of computing devices pursuant to part 15 of FCC rules, which are designed to provide

reasonable protection against radio frequency interference. Operation of this equipment in other environments

may cause interference with radio communications, in which case the user at his own expense will be required

to take whatever measures may be required to correct this interference.

Mailing Address: Texas Instruments Post Office Box 655303 Dallas, Texas 75265

EVM WARNINGS AND RESTRICTIONS

It is important to operate this EVM within the input voltage range of 3 V and 6 V.

Exceeding the specified input range may cause unexpected operation and/or irreversible

damage to the EVM. If there are questions concerning the input range, please contact a TI

field representative prior to connecting the input power.

Applying loads outside of the specified output range may result in unintended operation and/or

possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to

connecting any load to the EVM output. If there is uncertainty as to the load specification,

please contact a TI field representative.

During normal operation, some circuit components may have case temperatures greater than

45°C. The EVM is designed to operate properly with certain components above 60°C as long

as the input and output ranges are maintained. These components include but are not limited

to linear regulators, switching transistors, pass transistors, and current sense resistors. These

types of devices can be identified using the EVM schematic located in the EVM User’s Guide.

When placing measurement probes near these devices during operation, please be aware

that these devices may be very warm to the touch.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

How to Use This Manual

iii

Preface



About This Manual

The CDCM1804/CDCP1803 evaluation module (EVM) allows evaluation of

the CDCM1804/CDCP1803 LVPECL clock drivers. The CDCM1804 provides

three LVPECL and one CMOS outputs, while the CDCP1803 provides three

LVPECL outputs only. This user’s guide provides a brief overview of the EVM,

setup and operation instructions, and typical test results that can be expected.

In addition, it provides recommendations on proper termination, decoupling,

and how to use the CDCM1804/CDCP1803 in single-ended applications, such

as LVTTL, LVCMOS, or other differential clock signals such as LVPECL,

LVDS, HSTL, SSTL−2, CML VML or similar 2.5-V or 3.3-V signals and provide

a differential LVPECL output.

Requesting an EVM

Contact your local marketing or sales representative to request a

CDCM1804/CDCP1803 EVM.

How to Use This Manual

This document contains the following chapters:

-Chapter 1—Introduction

-Chapter 2—EVM PCB

-Chapter 3—EVM Configuration

-Chapter 4 Using the EVM

-Chapter 5—Schematics, Parts List, Board Stackup, Board Layouts, and

References

How to Use This Manual

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to subpart

J of part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

For More Information

If you need assitance with this device, please email

[email protected]

Contents



1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 EVM PCB 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Use of the EVM 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Design of Differential Traces 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Other Design Tweaks 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 CDCM1804/CDCP1803 EVM Kit Contents 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 CDCM1804/CDCP1803 EVM Configuration 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Default EVM Delivery 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Mode Setting for CDCM1804/CDCP1803 Through EN, S0, S1, and S2 3-2. . . . . . . . . . . .

4 Using the EVM 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 EVM Power Connections 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2 Applying An Input 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Typical Test Results 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Schematic, Parts List, Board Stack Up, Board Layouts, and References 5-1. . . . . . . . . . . . .

5.1 Schematic 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Parts List 5-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 Board Stackup and Layouts 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 References 5-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents



1−1 CDCM1804/CDCP1803 EVM Default Setup 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−1 EVM Power Connections for the CDCM1804/CDCP1803 Evaluation 4-2. . . . . . . . . . . . . . . . .

4−2 Typical Output From the CDCM1804/CDCP1803 EVM 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−1 Schematic of the EVM Signal Path 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−2 Top Layer 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−3 PWR1 Layer 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−4 GND1 Layer 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−5 Bottom Layer 5-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction



The Texas Instruments (TIt) CDCM1804/CDCP1803 evaluation module

(EVM) is used to evaluate the CDCM1804/CDCP1803 clock driver (24-pin

MLF) and ease the evaluation of the clock drivers without having to modify

existing board design.

The CDCM1804 clock drivers distributes one pair of differential clock input to

three pairs of differential clock outputs (Y0:Y2) and an additional CMOS output

(Y3) with minimum skew for clock distribution. The CDCM1804 is specifically

designed for driving 50-Ωtransmission lines.

The CDCP1803 clock drivers distributes one pair of differential clock inputs to

three pairs of differential clock outputs (Y0:Y2) with minimum skew for clock

distribution. The CDCP1803 is specifically designed for driving 50-Ω

transmission lines.

Both devices are capable of accepting any differential swing as small as 150

mV and as high as a 3.6-V signal swing, which makes it ideal for signal level

translation. Both the CDCM1804 and the CDCP1803 can accept single-ended

signals such as LVTTL or LVCMOS or other differential clock signals such as

LVPECL, LVDS, HSTL, SSTL−2, CML, and VML or similar 2.5-V or 3.3-V

signals and provide a differential LVPECL output.

The CDCM1804/CDCP1803 are both 3.3-V LVPECL clock drivers

(CDCM1804 provides three LVPECL + one CMOS outputs). This evaluation

module (EVM) is designed to quickly evaluate the CDCM1804/CDCP1803

with flexibility in having single-ended or differential signals or as level

translator. In addition, the CDCM1804/CDCP1803 incorporate a VBB

reference voltage pin to support reception of single-ended input signals such

as: LVTTL, LVCMOS, LVPECL, HSTL, SSTL−2, CML, and LVDS (when the IN

input pair are ac-coupled).

This user’s guide gives a brief overview of the EVM, setup and operation

instructions, and typical test results that can be expected. Detailed information

relating to the CDCM1804/CDCP1803 can be found in the devices respective

data sheets, available from www.ti.com/clocks. A picture of the EVM, with

CDCM1804/CDCP1803 device installed, is shown in Figure 1−1.

Chapter 1

1-2

Figure 1−1.CDCM1804/CDCP1803 EVM Default Setup

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments ADS1254 Manuel utilisateur

Texas Instruments

Texas Instruments TLV320AIC3109EVM-K Manuel utilisateur

Texas Instruments

Texas Instruments ADS42JB46 Manuel utilisateur

Texas Instruments

Texas Instruments CDCM9102EVM Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-ADS1119 Manuel utilisateur

Texas Instruments

Texas Instruments bq26220EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments UCC28064EVM-004 Manuel utilisateur

Texas Instruments

Texas Instruments LMK00725EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS25200EVM-618 Manuel utilisateur

Texas Instruments

Texas Instruments bq24165 Manuel utilisateur

Texas Instruments

Texas Instruments TAS2559 Manuel utilisateur

Texas Instruments

Texas Instruments DP83869EVM Manuel utilisateur

Texas Instruments

Texas Instruments CDCE 9 Series Manuel utilisateur

Texas Instruments

Texas Instruments LP-MSPM0C1104 Manuel utilisateur

Texas Instruments

Texas Instruments HSS-MOTHERBOARDEVM Manuel utilisateur

Texas Instruments

Texas Instruments TRF7970A BoosterPack Manuel utilisateur

Texas Instruments

Texas Instruments DRV2625 Haptics BoosterPack Manuel utilisateur

Texas Instruments

Texas Instruments TPS23523EVM-863 Manuel utilisateur

Texas Instruments

Texas Instruments TPS2480 EVM Manuel utilisateur

Texas Instruments

Texas Instruments DAC8580 Manuel utilisateur

Texas Instruments

Texas Instruments ESD224 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC3220MOD Series Manuel utilisateur

Texas Instruments

Texas Instruments LM76005QEVM Manuel utilisateur

Texas Instruments

Texas Instruments TDC7200EVM Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
