Texas Instruments BQ76905 Manuel utilisateur

EVM User's Guide: BQ76905EVM

BQ76905 Evaluation Module

Description

The Texas Instruments' BQ76905EVM is a complete

evaluation system for the BQ76905, The BQ76905 is

a highly integrated, high accuracy battery monitor and

protector for 2-series to 5-series Li-Ion, LiPolymer,

and LiFePO4 battery packs.

The circuit module connects directly to the cells in

a battery, or can be connected with a power supply

and the included cell simulator resistors. With the on-

board interface or compatible external interface board

and Microsoft® Windows® based PC graphical user

interface (GUI) software, the user can view the device

registers, evaluate voltage, current and temperature

accuracy, adjust protection limits and enable FET

control outputs.

Get Started

1. Order the BQ76905 EVM from ti.com.

2. Download the latest BQSTUDIO-TEST from the

BQSTUDIO tool page.

3. Follow the instructions in this user's guide to get

started.

Features

• Complete evaluation system for the BQ76905 2-

cell to 5-cell Li-Ion, LiPolymer, and LiFePO4 high

accuracy battery monitor

• Power connections available on test points

• Communication available with included USB

interface adapter or available on 4-pin connector

• Resistor cell simulator for quick setup with only a

power supply

• PC software available for configuration

Applications

•Cordless power tools and garden tools

•Vacuum cleaners

•Non-military drones

•Other industrial battery pack (2-series to 5-series)

www.ti.com Description

SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

BQ76905 Evaluation Module 1

1 Evaluation Module Overview

1.1 Introduction

The BQ76905 features a high accuracy monitoring system with dedicated coulomb counter and accumulated

charge integration, a highly configurable protection subsystem, and support for host controlled cell balancing.

Integration includes low-side protection NFET drivers, a programmable LDO for external system use, and an

I2C host communication interface supporting up to 400-kHz operation with optional CRC. The evaluation module

includes one BQ76905 integrated circuit (IC), sense resistor, one thermistor, power FETs, and all other onboard

components necessary to protect the cells from overcharge, over discharge, short circuit, overcurrent discharge,

over temperature, and under temperature.

1.2 Kit Contents

• BQ76905 circuit module

• USB A to microUSB cable

1.3 Specification

This section summarizes the performance specifications of the BQ76905 circuit module in the default 5-cell

series FET configuration.

Typical voltage depends on the number of cells configured. Typical current depends on the application. Board

cooling can be required for continuous operation at or below maximum current.

Table 1-1. Performance Specification Summary

Specification Min Typ Max Unit

Input voltage BATT+ with respect to BATT– 3 – 25 V

Continuous charge or discharge current 0 – 6 A

Operating temperature range 20 25 30 °C

1.4 Device Information

Table 1-2. Device Information

EVM Part Number Chemistry Configuration Capacity

BQ76905EVM Li-Ion 5 cells Any

Note

Although capacity is shown as Any, practical limits of the physical construction of the module typically

limits the operation of the EVM to a 1P or 2P battery construction. Refer to the physical construction

section for board details.

Evaluation Module Overview www.ti.com

2BQ76905 Evaluation Module SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

2 Hardware

2.1 Before You Begin

The following warnings and cautions are noted for the safety of anyone using or working close to the BQ76905

EVM. Observe all safety precautions.

Warning

The BQ76905EVM circuit module can become hot during operation due to

dissipation of heat. Avoid contact with the board. Follow all applicable safety

procedures applicable to your laboratory.

Caution Do not leave the EVM powered when unattended.

CAUTION

The default settings of the BQ76905 do not limit performance to the ratings of the EVM. Set all

protections appropriately and limit current for safe operation.

CAUTION

The circuit module has signal traces, components, and component leads on the bottom of the board,

which can result in exposed voltages, hot surfaces or sharp edges. Do not reach under the board

during operation.

CAUTION

The circuit module can be damaged by over temperature. To avoid damage, monitor the temperature

during evaluation and provide cooling, as needed, for your system environment. Do not operate

beyond the current and voltage limits in the Specification Table.

CAUTION

Some power supplies can be damaged by application of external voltages. If using more than

1 power supply, check your equipment requirements and use blocking diodes or other isolation

techniques, as needed, to prevent damage to your equipment.

CAUTION

The communication interface is not isolated on the EVM. Be sure no ground potential difference

exists between the computer and the EVM. Also, be aware that the computer is referenced to the

battery-potential of the EVM.

CAUTION

Connections for rated current must be made at the terminal block. Test points are not rated for the

board current.

www.ti.com Hardware

SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

BQ76905 Evaluation Module 3

2.2 Required Equipment

The following equipment is required to operate the BQ76905 EVM in a simple demonstration:

• DC power supply, 0–35 V at 2.5 A

• DC voltmeter

• Computer with USB port and compatible Windows operating system and access to the internet

• Test leads to connect equipment

• Electronic load or assorted resistors

Additional equipment can be desired to operate the BQ76905 with a more extensive demonstration.

2.3 BQ76905 Circuit Module Use

The BQ76905 circuit module contains the BQ76905 IC and related circuitry to demonstrate the features of the

IC. Surface mount FETs are provided for the high current path. A thermistor provides temperature sensing on the

board. Other components provide support for the IC and connections to the board. Basic operation is described

in Section 3. For details of the circuit, refer to Section 5.

2.3.1 Cell Simulator

The EVM includes a resistive cell simulator made up of 200-Ω series resistors. The taps of the resistor network

are connected to the cell inputs using shunts on the J10 header. BAT- is always connected to the resistor divider

network. Installing a shunt on the top cell location connects the top cell input to the resistor divider to provide

simulated voltages for the other cell inputs. If the shunt is not installed on the top cell position of the header,

then all lower inputs are pulled to VSS. Installing shunts for the lower cell positions connects the input to the

simulated voltage. Since here is no indication of the cell simulator connection, the user must be aware of the

shunt installation.

2.3.2 Evaluating with Load Current

With the BQ76905 configured and the FETs enabled, discharge current can be demonstrated by attaching

appropriate resistors or a DC load at the PACK terminals as shown in Figure 2-1.

DC Power Supply

+ -

Install cell

simulator shunts

DC Load + -

Figure 2-1. Evaluating with Load Current

Hardware www.ti.com

4BQ76905 Evaluation Module SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

2.3.3 Evaluating Charge and Discharge Currents

Bipolar power supplies source or sink currents to maintain the set voltage. When bipolar supplies are available,

the bipolar supplies can be used for both the battery and pack side of the board to allow charge and discharge

currents without re-connecting the equipment. Be sure to set the supplies appropriately to prevent exceeding the

ratings of the EVM.

Bipolar DC Power Supply

(source/sink)

+ -

Install cell

simulator shunts

Bipolar DC Power Supply

(source/sink) + -

Figure 2-2. Evaluating with Charge or Discharge Current

www.ti.com Hardware

SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

BQ76905 Evaluation Module 5

2.3.4 Evaluating with Simulated Current

Section 3 describes connection for basic operation. Providing more than recognizable current in that

configuration can require a power supply with a significant power rating. Applying a charge current can damage

some power supplies. Figure 2-3 shows a method to force current through the control path without a high

wattage power supply or special equipment. The load power supply must be set at a low voltage in a constant

current mode. Polarity can be reversed on the load supply to simulate a charge current. The battery simulation

supply must never be reversed.

DC Power Supply

+ -

Install cell

simulator shunts DC Power Supply

(Simulated load) +

Figure 2-3. Simulating Current Setup

Hardware www.ti.com

6BQ76905 Evaluation Module SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

2.3.5 Reducing the Cell Count

The BQ76905 must have the top and bottom cells used for proper operation. Cell count can be reduced by

shorting the unused cell inputs from the next-to-top down. Cell count can be reduced for basic evaluation by

shorting unused cells at the input terminal block. Follow the recommendations in the data sheet for which cells to

short. This works for both operation with the cell simulator and cells, but can have some side effects in transient

tests because the shorted resistors are parallel to the cell IC where the capacitor provides a signal path to

the used input. See Figure 2-4 for an example of simple reduced cell configuration for 3 cells. For the best

evaluation with reduced cells in a transient environment, short the VCx pins at the capacitor and remove the

unused input resistor. When using the cell simulator, shorting the unused cell at the terminal block is still required

to eliminate the simulated cell voltage. Shorting the cell inputs at the terminal block screw terminals is suggested

since the cell inputs are apparent if the board is re-used for a different cell count. Table 2-1 shows configuration

recommendations for reduced cell count, this table assumes the board has been set-up as detailed in Section 3.

By default, the BQ76905 EVM has VC4A/B and VC3A/B shorted at the IC inputs. However, the user

must make sure to also short CELL6 to CELL5 and CELL4 to CELL3 on the cell input terminals prior

to making any cell reduction, as explained in Section 3.

Table 2-1. Reducing Cell Count

Unused cell

(numbered from bottom

cell 1)

Short cell input

terminals

Input resistor to

remove

Replace capacitor with

0 ohm IC inputs shorted

Cell 4 CELL5 to CELL4 R8 C7 VC4A/B to VC3A/B

Cell 3 CELL3 to CELL2 R11 C9 VC3A/B to VC2

DC Power Supply

+ -

Install cell

simulator shunts

Short

CELL6 all the way

down to CELL2

Figure 2-4. Example 3 Cell Simple Evaluation Configuration

www.ti.com Hardware

SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

BQ76905 Evaluation Module 7

2.3.6 Connecting Cells

The EVM is constructed with a single connection to the top and bottom of the cell stack. Cell voltage for these

cells is sensed on the board.

The cell simulator provides resistors between the cell inputs. When the cell simulator shunts are installed, these

resistors load the cells and divide the voltage to any unconnected inputs as cells are connected. If desired, then

the cell simulator shunts can be installed during cell connection and removed after cell connection. The shunts

must be removed after connection of cells or the cells are discharged by the constant drain of the cell simulator

resistors.

BAT- is the reference voltage for the IC and must be connected first. After BAT- cells can be connected in any

order. Cell connection from the bottom up minimizes the voltage step size applied to the board. Recommended

connection sequence for the EVM when connecting cells is bottom up:

1. Connect BAT–

2. Connect cells bottom up: CELL1, CELL2, CELL3 ...

3. Be sure the cell simulator shunts are removed

Figure 2-5 shows an example connecting cells with an EVM configuration reduced to 4 cells.

Remove cell

simulator shunts to

avoid draining cells

If connecting cells confirm operation before connecting.

Use all appropriate fusing, insulation, isolation and

shielding necessary for safe operation. Board has exposed

contacts. Do not leave unattended

For 4 cells, connect 3th

cell to CELL6 to CELL3

inputs

Figure 2-5. Example Connection with 4 Cells

Hardware www.ti.com

8BQ76905 Evaluation Module SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

2.3.7 Connecting to a Host

After initial operation of the monitor with the BQStudio software, consider operating the board connected to and

controlled by a microcontroller board. To do this, unpopulate J6 and J2, and populate J1 and J5. J6 and J2

disconnect the I2C lines of the BQ76905 from the on-board MCU. J1 and J5 connect the I2C pullup resistors to

REGOUT.

DC Power Supply

+ -

Install cell

simulator shunts

Add shunts for

pull-ups if pull-

ups not provided

on MCU board

MCU

Evaluation Board

SCL

Remove shunts

for on-board MCU

connection

SDA

Figure 2-6. Host Connection Concept

2.3.8 Hardware Configuration

2.3.8.1 Configuration Jumpers

Certain features on the BQ76905EVM can be configured by jumpers or shunts on headers. See Section 5.1 for

details of the header pins.

J1 and J5 connect the BQ76905 I2C lines to pull-up resistors at REGOUT for off-board MCU communications.

J2 and J6 connect the I2C lines of the BQ76905 to the on-board MCU.

J7 connects the ALERT pin to a pull-up resistor at REGOUT.

J8 connects/disconnects the on-board thermistor from the TS pin.

J10 cell simulator connections.

The cell simulator headers and are discussed in board connection diagrams.

2.3.9 Configuration Register Programming

Configuration register programming is done once hardware configuration is set with jumpers. Configuration

registers are set in the Data Memory screen and are different from the status registers displayed in the Registers

screen. See the BQ76905 data sheet (SLUSF45) and supporting documentation for register information. When

a configuration file is available, the file can be imported to set all operational selections at once. However, a

configuration file loaded with Data Memory Import can load as little as 1 parameter, so the user must be familiar

with the contents of imported files. With a new device or after loading a configuration file, individual register

changes can be made. Configuration register programming typically involves the following general principles

selected in various register names:

1. Selection of the protection features to be enabled

2. Selection of the protection thresholds for the enabled features

3. Setting the FET control options

4. Exporting (saving) the configuration register file for future use

www.ti.com Hardware

SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

BQ76905 Evaluation Module 9

3 Quick Start Guide

The BQ76905 registers must be configured to enable most protections, select the monitored cells, and enable

the protection FETs on the EVM. This section does not describe current protection settings.

These steps describe quick connection of the BQ76905 EVM to demonstrate operation of the AFE portion of the

EVM. For more detailed descriptions, refer to other sections of the user's guide.

Refer to Figure 3-1 for the following steps.

1. Download the BQSTUDIO software from the tool folder link www.ti.com/tool/BQSTUDIO or search from

www.ti.com.

2. Install the BQStudio software (see Section 4.1.2).

3. Install the cell simulator shunts.

4. VC4A to VC4B and VC3A to VC3B are shorted directly at the pins. However, CELL6 to CELL 5 and CELL4

to CELL 3 must also be shorted at the cell-side for proper circuit module functionality.

5. Position shunts for the I2C to MCU connection.

6. Attach the on-board communication adapter USB connector to the PC using USB cable.

7. Connect a 0-V DC power supply capable of 250 mA minimum between the “BAT-” and "7P" terminals and

adjust to approximately 15 V.

8. Start the BQStudio software. If there is proper communication, then the GUI opens with a register display.

Click on the Scan button to enable repeated update of the display. The power supply can be adjusted within

range of the part to observe voltage changes in the GUI register display.

9. Select the Data Memory button in the BQStudio window.

10. Select the Settings button. Set the Enabled Protections A CUV bit.

11. Select the Protections button. Set the Cell Undervoltage Protection Threshold to 2800.

12. In the Commands panel click on the FET_ENABLE button.

13. In the Registers view click on the Scan icon so that the registers update periodically. Observe that the CHG

and DSG bits in the Battery Status register are on. Measure the PACK voltage on the board if desired.

14. Adjust the supply voltage to approximately 12.5 V. In the registers view observe that the DSG bit goes off.

15. Make other adjustments as desired for evaluation. See other sections of this user guide for details of

operation.

16. When complete with this quick start demonstration, exit the BQStudio software and turn off the power supply.

Refer to other sections of this user's guide for additional details.

Short

CELL6 to CELL5 and

CELL4 to CELL3

DC Power Supply

+ -

Install cell

simulator shunts

Position shunts

to uC_SCL and

uC_SDA

Figure 3-1. EVM Connection for Basic Operation

Quick Start Guide www.ti.com

10 BQ76905 Evaluation Module SLUUCY9 – NOVEMBER 2023

Submit Document Feedback

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments TPA6047A4 Manuel utilisateur

Texas Instruments

Texas Instruments DRV10964 Manuel utilisateur

Texas Instruments

Texas Instruments DAC5674 EVM Manuel utilisateur

Texas Instruments

Texas Instruments DRV8833C Manuel utilisateur

Texas Instruments

Texas Instruments LMK04832EVM-CVAL Manuel utilisateur

Texas Instruments

Texas Instruments LM5123EVM-BST Manuel utilisateur

Texas Instruments

Texas Instruments TPS2388EVM-612 Manuel utilisateur

Texas Instruments

Texas Instruments WiLink WL 1MOD Series Manuel utilisateur

Texas Instruments

Texas Instruments TPS92410EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments DLP NIRscan EVM Manuel utilisateur

Texas Instruments

Texas Instruments BQ25180 Manuel utilisateur

Texas Instruments

Texas Instruments bq27x10EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS272C45 Manuel utilisateur

Texas Instruments

Texas Instruments TPS54335AEVM-010 Manuel utilisateur

Texas Instruments

Texas Instruments TPS5430 Manuel utilisateur

Texas Instruments

Texas Instruments DAC5652AEVM Manuel utilisateur

Texas Instruments

Texas Instruments bq76PL536 EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMUXBQB-DYYEVM Manuel utilisateur

Texas Instruments

Texas Instruments bq77915EVM-014 Manuel utilisateur

Texas Instruments

Texas Instruments ISO7220 Series Manuel utilisateur

Texas Instruments

Texas Instruments HD3SS3220 Manuel utilisateur

Texas Instruments

Texas Instruments bq2023EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC3235MODS Manuel utilisateur

Texas Instruments

Texas Instruments BOOSTXL-TPS652170 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
