WS9255 Manual

Features:

DCF Radio control time function

12/24 hour format

Daily Alarm Function

Snooze function(OFF or 1~60min)

Low battery indicator

Humidity: Indoor & Outdoor measurable range: 20%RH ~ 95%RH

Temperature:

oIndoor temperature measurement ranges: -9.9°C (14.1°F) ~ 50°C (122°F)

oOutdoor temperature measurement ranges: -25°C (-13°F) ~ 50°C (122°F)

oTemperature alternatively in ℃or ℉.

oOutdoor thermometer and ice alert

Maximum /minimum value query of temperature and humidity

Wireless Outdoor Sensor:

oWall Mount or Table Stand

o3 Channel selectable

o433.92MHz RF transmitting frequency

oMaximum transmission power: 13 dBm

o30 meter transmission range in an open area

Weather forecasting function

Power Supply:

Weather Station:

Battery: 2 x LR6 AA

Wireless Outdoor Sensor:

Battery: 2 x LR6 AA

EN2

Weather Station

EN3

EN4

Part A - LCD

A1: Weather forecast pattern

A2: Time

A3: Radio Controlled Icon

A4: Time DST icon

A5: Weather station low battery indicator

A6: Indoor temperature and humidity

A7: Outdoor temperature and humidity

A8: Ice alert icon

Part B –Back buttons

B1: “MODE/SET”button

B2: “MEM” button

B3: “+/WAVE” button

B4: “-/CH” button

B5: battery door

Part C –TOP button

C1:“Light/snooze”touch button

Part D –Wireless Outdoor Sensor

D1: Battery door

D2: Channel switch

D3: TX button

Initial operation:

Open Weather Station battery compartment cover

Insert 2 x AA batteries observing polarity [ “+” and “ –“ marks]

When you insert the batteries, all icons on the LCD display will light up for 3 seconds,

you will hear a beep tone and the station detects indoor temperature & humidity.

The Weather Station will now start the outdoor remote sensor reception. This

operation takes about 3 minutes and is displayed by a flashing reception RF antenna

symbol in the “OUTDOOR” display area on the receiver.

Open Wireless Outdoor Sensor battery compartment cover, Insert 2 x AA batteries

observing polarity [ “+” and “–“ marks].

After receiver has a connection to the outdoor remote sensor after 3 minutes, it will

enter the radio controlled time signal reception mode.

Reception of the DCF signal:

The clock will automatically search the DCF (radio controlled time) signal after 3

minutes of any restart or changing of new fresh batteries. The radio mast icon starts

to flash.

At 1:00 /2:00 / 3:00 am, the clock automatically carries out the synchronization

procedure with the DCF signal to correct any deviations to the exact time. If the

synchronization attempt is unsuccessful (the radio mast icon disappears from the

display), the system will automatically attempt another synchronization at the next

full one hour. This procedure is repeated automatically up to total 5 times.

To start manual DCF signal reception, press and hold the “WAVE”button for two

seconds. If no signal is received within 7 minutes, then the DCF signal search stops

(the radio mast icon disappears) and will start again at the next full one hour.

During DCF reception to stop searching radio signal, press the “WAVE” button once.

Please note:

EN5

Aflashing radio mast icon indicates that the DCF signal reception has started

Acontinuously displayed radio mast icon indicates that the DCF signal was received

successfully

We recommend a minimum distance of 2.5 meters to all sources of interference,

such as televisions or computer monitors

Radio reception is weaker in rooms with concrete walls (e.g.: in cellars) and in

offices. In such extreme circumstances, place the system close to the window.

During the DCF reception mode, only the

"SNOOZE/LIGHT" and “WAVE”button function, other buttons have no function. If

you want to use other functions , please press the “WAVE”button to exit the

DCF reception mode.

Manual time setting:

Press and hold the “MODE” button for 2 seconds, the temperature unit in °C starts to

flash. Now use “+” and “-” buttons to choose between °C or °F temperature unit.

Press “MODE” button to confirm your setting, 12/24HR start to flash. Now use “+”

and “-”buttons to set the set 12 or 24 hour mode.

Press “MODE” to confirm your setting, the time zone starts to flash. Now use “+” and

“-”buttons set a time zone (-12 to +12). For example for UK, the time zone is -01,

for Germany it is 00.

Press “MODE” to confirm your setting, the Hour display starts to flash. Now use “+”

and “-”buttons to set the hour.

Press “MODE” to confirm your setting, the Minute display starts to flash. Now use “+”

and “-”buttons to set the minute.

Press “MODE” button to confirm your setting, the weather forecast pattern display

starts to flash. Now use “+” and “-”buttons to select the current weather pattern.

Press “MODE” to confirm your setting and to end the setting procedures. Then the

station will return to the normal mode.

Please note:

If there is no valid operation within 20 seconds, the station will automatically return to

normal time mode from the set mode.

Setting the alarm:

Press “+” button once, LCD display the “ ” icon, the alarm function is ON, Then

press once “+” button, the “ ” icon will disappear from the display, the alarm

function is OFF.

Press “MODE” button once, LCD displays alarm time. Then press and hold “MODE”

button for 2 seconds until hour of the alarm time starts to flash. Use the “+” and “-”

buttons to set the hour. Press “MODE” button to confirm your setting.

The minute of the alarm time starts to flash. Use the “+” and “-”buttons to set the

minute. Press “MODE” button to confirm your setting.

The snooze time of the alarm starts to flash. Use the “+” and “-”buttons to set the

required minute. The snooze time can be set from OFF to 60 minutes.

Press “MODE” button to confirm your setting and to end the setting procedure.

Please note:

If there is no valid operation within 20 seconds, the station will automatically return to

normal time mode from the alarm time set mode.

EN6

The alarm will sound for 2 minutes if you do not deactivate it by pressing any button.

In this case the alarm will be repeated automatically after 24 hours.

Rising alarm sound (crescendo, duration: 2 minutes) changes the volume 4 times

whilst the alarm signal is heard.

Switching off the alarm signal

Press any button except the “SNOOZE/LIGHT” button to stop the alarm signal. It is not

necessary to reactivate the alarm. It switches itself automatically to the alarm time which

has already been set.

Snooze function

Touch the “SNOOZE/LIGHT” button the alarm signal sounds to get to SNOOZE mode. The

alarm signal sounds again after already been set. If OFF was selected in the SNOOZE time

setting, the alarm will not repeat.

RF Transmission Procedure:

The weather station automatically starts receiving transmission from outdoor thermo

sensor for outdoor temperature & humidity after batteries inserted.

The outdoor sensor will automatically transmit temperature and humidity signal to

the Weather Station after batteries inserted.

If Weather Station failed to receive transmission from outdoor sensor (“- -”display on

the LCD), press and hold “-/CH”button for 3 seconds to receive transmission

manually. RF icon “ ” flashes on the LCD，The Weather Station to receive the

outdoor sensor.

If the weather station is used with 2 or 3 transmitters, press “-/CH” button shortly to

display CH2, CH3 or cyclic display.

P re ss "-/C H "

P re ss "-/C H " P re ss "-/C H " P re ss "-/C H "

A u to m a tic A u to m a tic

A u to m a tic

5S 5S

Press „-/CH“

Automatic

EN7

Maximum/minimum temperature/humidity

Press once “MEM” button, the LCD will display maximum value of temperature/

humidity. The LCD will display the minimum value of temperature/humidity. If the

“MEM” button is pressed again the maximum value is displayed.

While displaying MAX or MIN values, there is “MAX” or “MIN” on the LCD.

Press and hold “MEM” button for 3 seconds. The temperature/humidity

maximum/minimum value will reset to the current values

Please note:

If the temperature reading is below ranges, the LL.L will be displayed. If the temperature

reading is above ranges, the HH.H will be displayed.

Ice alert

The ice alert symbol appears and flashing next to the outdoor temperature when the

outdoor temperature at –1℃to + 3 ℃or +30℉to + 37℉.

Weather forecasting function

The weather forecast is calculated from evaluation of fluctuations in the barometric

pressure and may deviate from the actual weather conditions.

The weather station displays the following weather symbols:

su n n y

slig h tly c lo u d y

c lo u d y

ra in y

The weather symbols indicate the weather fluctuation over the next eight hours and

not the current weather.

Background lighting

Touch the “SNOOZE/LIGHT” button, the backlight illuminates for 8 seconds.

Hereby, Technotrade declares that the products WS 9255 and TX205D-TH are in

compliance with the essential requirements and other relevant provisions of Directive

2014/53/EU and ROHS 2011/65/EC. The original EU declaration of conformity may be

found at: www.technoline.de/doc/4029665092553

sunny

slightly

cloudy

rainy

EN8

Specifications

Time zone: -12~12Hr

IN Temperature measuring range: -9.9~50°C/14.2~122°F

OUT Temperature measuring range: -25~50°C /-13~122°F

Temperature resolution: 0.1°C /°F

Temperature accuracy:

0°C ~40℃: ±1°C

–25°C ~-0°C, 40°C ~50°C: ±2°C

32°F ~104°F: ±1.8°F

–13°F ~32°F, 104°F ~122°F: ±3.6°F

Humidity measuring range: 20-95%

Humidity resolution: 1%

Humidity accuracy:

40-80%: ±5%

20~39%,81-95%: ±8%

RF receiving distance: 30 meter (open area)

Environmental reception effects

The station obtains the accurate time with wireless technology. Same as all wireless

devices, the reception is maybe affected by the following circumstances:

long transmitting distance

nearby mountains and valleys

near freeway, railway, airports, high voltage cable etc.

near construction site

among tall buildings

inside concrete buildings

near electrical appliances (computers, TV’s, etc) and metallic structures

inside moving vehicles

Place the station at a location with optimal signal, i.e. close to a window and away from

metal surfaces or electrical appliances.

Precautions

This main unit is intended to be used only indoors.

Do not subject the unit to excessive force or shock.

Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.

Do not immerse in water.

Avoid contact with any corrosive materials.

Do not dispose this unit in a fire as it may explode.

Do not open the inner back case or tamper with any components of this unit.

Batteries safety warnings

Use only alkaline batteries, not rechargeable batteries.

Install batteries correctly by matching the polarities (+/-).

Always replace a complete set of batteries.

Never mix used and new batteries.

Remove exhausted batteries immediately.

Remove batteries when not in use.

Do not recharge and do not dispose of batteries in fire as the batteries may explode.

EN9

Ensure batteries are stored away from metal objects as contact may cause a short

circuit.

Avoid exposing batteries to extreme temperature or humidity or direct sunlight.

Keep all batteries out of reach from children. They are a choking hazard.

Use the product only for its intended purpose!

Consideration of duty according to the battery law

Old batteries do not belong to domestic waste because they could

cause damages of health and environment. You can return used

batteries free of charge to your dealer and collection points. As

end-user you are committed by law to bring back needed batteries to

distributors and other collecting points!

Consideration of duty according to the law of electrical devices

This symbol means that you must dispose of electrical devices

separated from the General household waste when it reaches the end of

its useful life. Take your unit to your local waste collection point or

recycling centre. This applies to all countries of the European Union,

and to other European countries with a separate waste collection

system.

Table des matières

Autres manuels Technoline Station météorologique

Technoline

Technoline WS550 Manuel utilisateur

Technoline

Technoline WS 6449 Manuel utilisateur

Technoline

Technoline WS 6750 Manuel utilisateur

Technoline

Technoline WS 6870 Manuel utilisateur

Technoline

Technoline WS 8301 Manuel utilisateur

Technoline

Technoline WS 9120 Manuel utilisateur

Technoline

Technoline WS9767 Manuel utilisateur

Technoline

Technoline WS9050 Manuel utilisateur

Technoline

Technoline WS6620 Manuel utilisateur

Technoline

Technoline WS 6448 Manuel utilisateur

Technoline

Technoline Mobile Alerts MA 10920 Manuel utilisateur

Technoline

Technoline WA3090 Manuel utilisateur

Technoline

Technoline WS-6010 Manuel utilisateur

Technoline

Technoline WS9135 Manuel utilisateur

Technoline

Technoline WS 585 Manuel utilisateur

Technoline

Technoline WS6462 Manuel utilisateur

Technoline

Technoline MOBILE ALERTS MA 10430 Manuel utilisateur

Technoline

Technoline WS9480 Manuel utilisateur

Technoline

Technoline WS 9485 Manuel utilisateur

Technoline

Technoline WS6815 Manuel utilisateur

Technoline

Technoline WS9132 Manuel utilisateur

Technoline

Technoline WS6442 Manuel utilisateur

Technoline

Technoline WS 6830 Manuel utilisateur

Technoline

Technoline WS 6832 Manuel utilisateur

Manuels Station météorologique populaires d'autres marques

Auriol

Auriol AHFL 433 A1 Manuel utilisateur

NexSens

NexSens G2-HYDROMET Manuel utilisateur

Hyundai

Hyundai WS 2202 Manuel utilisateur

IROX

IROX HBVR761 UV-X Manuel utilisateur

La Crosse Technology

La Crosse Technology C86371 Manuel utilisateur

ADE

ADE WS 1711 Manuel utilisateur

Auriol

Auriol z29592 Manuel utilisateur

Auriol

Auriol 296289 Manuel utilisateur

Hyundai

Hyundai WS 2266 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2210 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-811561 Manuel utilisateur

Ventus

Ventus W177 Manuel utilisateur

National Geographic

National Geographic VA Colour RC Manuel utilisateur

Renkforce

Renkforce 1208067 Manuel utilisateur

Levenhuk

Levenhuk Discovery Report WA40 Manuel utilisateur

Instant Transmission

Instant Transmission MA 10410 Manuel utilisateur

Lutron Electronics

Lutron Electronics PHB-318 Manuel utilisateur

WAREMA

WAREMA EWFS Weather station eco Manuel utilisateur
