La Crosse Technology Page 1

Wireless Forecast Station

Model C86371 | Instruction Manual

Introduction

The Wireless Forecast Station with 12 Hour Color Forecast and Snooze Alarm features radio-controlled

time, weather forecast, indoor and outdoor temperature/humidity as well as heat index and dew point, on

a stylish, colorful, and easy to read tabletop display. Use the integrated USB charging port to charge your

devices when the Wireless Forecast Station is plugged into a power outlet.

THIS WIRELESS FORECAST STATION LEARNS!

Please allow 3-4 weeks for barometer calibration to generate an accurate forecast.

Wireless Forecast Station

Outdoor Temperature/Humidity Transmitter: TX14TH

Time

Date

Week Day

Outdoor readings:

Temperature

Humidity

Heat Index

Dew Point

MIN/MAX

Snooze/Light button

Forecast icons:

Sunny

Partly Sunny

Cloudy

Rainy

Stormy

(All icons are

shown in this

illustration)

Indoor readings:

Temperature

Humidity

Heat Index

Dew Point

MIN/MAX

La Crosse Technology Page 2

Table of Contents

Introduction 1

Wireless Forecast Station 1

Outdoor Temperature/Humidity Transmitter TX14TH 1

Table of Contents 2

Features 3

Initial Setup 3

Power the Wireless Forecast Station 4

A/C Power Adapter 4

Batteries 4

Install Batteries in the Outdoor Transmitter 4

WWVB Radio-controlled Time 5

WWVB Reception Icon 5

Manual Signal Search 5

Function Buttons 5

Program Menu 6

WWVB ON/OFF 6

Time Zone 6

Daylight Saving Time Indicator 7

12-hour or 24-hour Time Format 7

Set Time 7

Set Calendar 7

Fahrenheit/Celsius 7

Alarm Set 8

Deactivate Alarm 8

Snooze Alarm 8

USB Charge Port 8

Backlight 9

A/C Power Adapter 9

Batteries 9

Weather Forecast Icon 9

LCD Screen 10

Min/Max Temperature Data 10

View Min/Max 10

Reset Min/Max 10

Heat Index 11

Dew Point Temperature 11

Outdoor Temperature/Humidity Flashes 11

Low Battery Icon 11

Use Multiple Outdoor Transmitters 12

Channel Scroll 12

Other Display Icons 12

WWVB Reception Icon 12

Indoor Readings 12

Outdoor Temperature Channel 12

Snooze 12

Alarm Icon 13

Care and Maintenance 13

Position the Outdoor Transmitter 13

Wall Mount 13

Position the Wireless Forecast Station 13

Specifications 14

Indoor 14

Outdoor 14

Humidity 14

Power Requirements 14

Battery Life 14

Dimensions 14

Accuracy 14

Indoor Temperature 14

Indoor Humidity 14

La Crosse Technology Page 3

Outdoor Temperature 15

Outdoor Humidity 15

Barometric Pressure 15

Warranty Information 15

FCC Disclaimers 16

Features

•ATOMIC time and date (auto sets)

•12/24 hour time with snooze alarm and alarm icon

•Charge devices with USB charging port

•Calendar display: month, day, date

•Heat index and dew point

•Forecast: sunny, partly sunny, cloudy, rainy and stormy

•12 hour forecast based on changing barometric pressure

•IN / OUT temperature (°F / °C)

•IN / OUT humidity (%RH)

•MIN / MAX records (24-hour readings)

•Time zone selection: Atlantic Time (AST), Eastern Time (EST), Central Time (CST), Mountain Time

(MST), Pacific Time (PST), Alaskan Time (AKT) and Hawaiian Time (HAT)

•Light up the Wireless Forecast Station with a press of a button using battery power OR continuous

light using the AC adapter with ON / OFF option

•LCD light dimmer for nighttime use

•Low battery icon for Wireless Forecast Station and sensor

•Sits on desktop or tabletop

•3 "AA" Alkaline batteries (not included) OR optional 5.0V AC adapter (included)

Initial Setup

1. Insert A/C adapter into the wall outlet then into the Wireless Forecast Station or insert 3 AA batteries

(not included) into the Wireless Forecast Station (see Power the Wireless Forecast Station). The

Wireless Forecast Station will light up and show, indoor temperature, humidity and channel 1.

2. Insert 2 fresh AA batteries into the transmitter, observing the correct polarity (see Install Batteries in

the Outdoor Transmitter).

Note: The CH switch is set to Channel 1 by default. Confirm channel 1 is selected.

3. Keep the transmitter 5-10 feet from the Wireless Forecast Station for 15 minutes to establish a good

connection.

4. Within 3 minutes the station will beep and the outdoor temperature should be shown on the Wireless

Forecast Station. If the outdoor temperature does not show after 3 minutes remove power from the

transmitter and the Wireless Forecast Station for 60 seconds and start again from step 1.

5. For optimum 433 MHz transmission, the outdoor transmitter should be placed a distance of no more

than 200 feet (60 meters, open air) from the Wireless Forecast Station.

IMPORTANT: When operating on a/c power, to avoid interference, the backlight and USB charge port

will turn off for 2-10 minutes while the Wireless Forecast Station searches for the WWVB signal. Both

features will return after the 2-10 minute search.

Do Not Mix Old and New Batteries

Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries

La Crosse Technology Page 4

Power the Wireless Forecast Station

The Wireless Forecast Station can be powered by the 5-volt a/c adapter or batteries.

A/C Power Adapter

Insert enclosed 5-volt a/c power adapter into a wall outlet, then into the Wireless Forecast Station.

Batteries

1. Remove battery cover: Slide tab to the right and pull out to remove battery cover.

2. Install three fresh AA batteries according to the polarity markings.

Do Not Mix Old and New Batteries

Do Not Mix Alkaline, Lithium, Standard, or Rechargeable Batteries

If the Wireless Forecast Station does not display indoor temperature after 60 seconds, remove adapter

and batteries, and wait for at least 60 seconds before repeating the setup process.

Install Batteries in the Outdoor Transmitter

1. Slide the battery cover down, then lift off the back of the transmitter.

Note: Be careful not to break the tabs on the battery cover.

2. Confirm the channel selector switch is on channel 1.

3. Insert two fresh AA batteries into the transmitter. Observe the correct

polarity (see marking inside battery compartment).

4. Keep transmitter 5-10 ft. from the Wireless Forecast Station during setup.

5. After 15 minutes, if the outdoor temperature shows on the Wireless

Forecast Station, you can move the outdoor transmitter outside to a

shaded location within range of the Wireless Forecast Station.

Battery

Compartment

5-Volt a/c adapter

La Crosse Technology Page 5

WWVB Radio-controlled Time

The NIST radio station, WWVB, is located in Ft. Collins, and transmits the exact time signal continuously

throughout the United States at 60 kHz. The signal can be received up to 2,000 miles away through the

internal antenna in the Wireless Forecast Station. However, due to the nature of the Earth’s Ionosphere,

reception is very limited during daylight hours. The Wireless Forecast Station will search for a signal every

night when reception is best. The WWVB radio station derives its signal from the NIST Atomic Clock in

Boulder, Colorado. A team of atomic physicists continually measures every second of every day to an

accuracy of ten billionths of a second a day. These physicists have created an international standard,

measuring a second as 9,192,631,770 vibrations of a Cesium 133 atom in a vacuum. This atomic clock

regulates the WWVB transmitter.

WWVB Reception Icon

The WWVB time reception icon with full signal strength will appear on screen in front of the

date when the reception of time is successful.

The tower icon will show solid when the Wireless Forecast Station has received the WWVB signal.

No tower icon is shown. The Wireless Forecast Station was unable to receive a signal at this time.

Reposition the Wireless Forecast Station for better signal reception or try again at bedtime.

The Wireless Forecast Station will start searching at UTC: 07:00 and if no reception on the first

attempt they will try again at 08:00, 09:00 and 10:00. Each attempt will be at least 2 minutes and the

most will be 10 minutes.

If there is no signal or too much interference the receiver will only be on for 2 minutes.

If the signal is good it may catch a signal in ABOUT 2-3 minutes.

If the signal is marginal it will try to catch a signal for up to 10 minutes.

IMPORTANT: When operating on a/c power, the backlight and USB charge port will turn off while the

Wireless Forecast Station searches for the WWVB signal, to avoid interference. Both features will

return after the 2-10 minute search which occurs during the late night or early morning hours.

Note: In case the Wireless Forecast Station is not able to detect the WWVB-signal (disturbances,

transmitting distance, etc.); the time may be manually set.

Manual Signal Search

In normal mode, hold the RCC button until the reception icon appears to force a search of the WWVB

signal. The WWVB icon will flash during the search. If this icon disappears after the 2-minute search,

the radio time signal is not available at the moment.

Recommended distance to any interfering sources like computer monitors or TV sets is a minimum of

6 feet (2 meters).

Within ferro-concrete rooms (basements, superstructures), the received signal is naturally weakened.

In extreme cases, please place the unit close to a window and/ or point its front or back towards the

Fort Collins, Colorado, transmitter.

During nighttime, the atmospheric disturbances are usually less severe and reception is possible in

most cases. A single daily reception is adequate to keep the accuracy deviation below 1 second.

Note: In case the Wireless Forecast Station is not able to detect the WWVB-signal (disturbances,

transmitting distance, etc.), the time and date can be manually set (see “program menu”).

Function Buttons

La Crosse Technology Page 6

Button

Press and Release Functions

Hold 3-5 seconds

SET

Move through program menu Confirm

setting.

Enter program menu, set time,

date, etc.

ALARM

View Alarm

Activate/Deactivate Alarm

Alarm set

+/RCC

1 step forward (setup)

Search for WWVB signal

Fast advance (setup)

-/°C/°F

Select temperature in °C/° F

1 step backward (setup)

Fast backward (set)

MIN/MAX

1-time MAX values

2-times MIN values

Resets all MIN / MAX values

HEAT/DEW

1-time Heat Index

2-times Dew Point

Switch channels

(when using multiple transmitters)

Search for remote transmitter

LIGHT HI/LO HOLD

ON/OFF

Dim backlight for night time.

Turn continuous backlight

ON or OFF (a/c adapter)

LIGHT/SNOOZE (top)

Activates backlight when using only

batteries.

Trigger snooze alarm

Program Menu

The SET button will moves through the items in the program menu. The +/RCC or -/°C/°F button will

change these values.

WWVB reception ON or OFF

Time Zone (Seven Time Zones)

Daylight Saving Indicator

12/24 hour time format

Manual time set (Hour, Minutes)

Calendar set (Year, Month, Date)

WWVB Reception ON/OFF

The WWVB time reception defaults to ON. To turn the WWVB reception OFF:

1. Hold the SET button for 5 seconds.

2. WWVB and ON will flash.

3. Press and release the +/RCC or -/°C/°F button to turn this OFF.

4. Confirm with the SET button and move to the Time Zone.

Time Zone

This station offers seven time zones listed in letter format (default is EST):

AST Atlantic Time

EST Eastern Time

CST Central Time

MST Mountain Time

PST Pacific Time

AKT Alaskan Time

HAT Hawaiian Time

1. EST will flash.

2. Press and release the +/RCC or -/°C/°F button to select a different Time Zone.

3. Confirm with the SET button and move to Daylight Saving Indicator.

WWVB

TIME

ZONE

EST

La Crosse Technology Page 7

Daylight Saving Time Indicator

DST will default to the ON position as most of the country observes the DST change. If you live in an

area does not observe the DST change, switch this to the OFF position.

1. DST and ON will flash.

2. Press and release the +/RCC or -/°C/°F button to turn DST to OFF.

3. Confirm with the SET button and move to 12/24 hour time format.

12-hour or 24-hour Time Format

The Time may be displayed in 12-hour or 24-hour format. Default is 12-hour time.

Note: When in 12-hour format AM or PM will show in front of the hour.

1. 12H will flash.

2. Press and release the +/RCC or -/°C/°F button to select 24-hour time.

3. Confirm with the SET button and move to Set Time.

Set Time

To set the time manually:

1. The hour digit will flash.

2. Press and release the +/RCC or -/°C/°F button to select the hour.

3. Press and release the SET button to set the minutes.

4. The minute’s digit will flash.

5. Press and release the +/RCC or -/°C/°F button to select the minutes.

6. Confirm with the SET button and move to Set Calendar.

Set Calendar

The date default of the Wireless Forecast Station is 1. 1. 2010.

To set the calendar:

1. The year will flash.

2. Press and release the +/RCC or -/°C/°F button to set the year (between year 2010-2039).

3. Press the SET button again to confirm and to enter the month setting.

4. The month will flash.

5. Press and release the +/RCC or -/°C/°F button to set the month.

6. Press the SET button again to confirm and enter the date setting.

7. The date will flash.

8. Press and release the +/RCC or -/°C/°F button to set the date.

9. Confirm all calendar settings with the SET button to confirm and exit the program menu.

Note: The day of the week will set automatically once the year, month and date are set.

Fahrenheit/Celsius

1. Press and release the -/°C/°F button once to switch from Fahrenheit to Celsius.

DST

12H

2010

1M.1D

La Crosse Technology Page 8

Alarm Set

Hold the ALARM button for 5 seconds to enter the alarm time set mode.

1. The alarm hour digit will flash.

2. Press and release the +/RCC or -/°C/°F button to select the hour.

3. Press and release the SET button to set the minutes. The minute digits

will flash.

4. Press and release the +/RCC or -/°C/°F button to select the minutes.

5. Confirm with the SET button and exit.

6. The alarm icon will show above the minutes indicating the alarm is active.

7. The alarm icon will flash when the alarm is sounding.

Deactivate Alarm

1. Press and release the ALARM button once to show Alarm Time.

2. Press and release the ALARM button to deactivate the Alarm. The alarm icon will disappear

indicating the alarm is no longer active.

Snooze

1. When the alarm sounds, press the SNOOZE/LIGHT button to trigger snooze alarm for 10 minutes.

The snooze icon Zz will flash when the snooze feature is active.

2. To stop alarm for one day, press ALARM button, while in snooze mode. The alarm icon will remain

solid.

Note: When the alarm sounds, it continues for 2 minutes and then shuts off completely.

USB Charge Port

The integrated USB charging port (on back) will charge devices when the Wireless Forecast Station is

plugged into a power outlet.

For example: you can use the USB charge cord to connect your cell phone to the USB charge port on

the back of the Wireless Forecast Station and allow your phone to charge. The Wireless Forecast Station

must be operating with a/c power in order to charge your device.

DO NOT try to charge the Wireless Forecast Station by connecting a USB cable from the Wireless

Forecast Station to your computer etc. This is an output port only.

Connect your existing USB charging cord for your external device to the USB charging port on the

back of the Wireless Forecast Station to begin to charge. Charging times will vary.

Note: Check that your device will charge with the USB cord it came with. Many USB cords are for

data transfer only, and cannot be used for charging.

Output: 1A maximum current USB.

Do NOT overload USB port.

Note: This is a power output (charging) port only. This port will not supply power to the Wireless

Forecast Station.

IMPORTANT: When operating on a/c power, to avoid interference, the backlight and USB charge port

will turn off while the Wireless Forecast Station searches for the WWVB signal. The backlight and USB

charge port resume after a 2-10 minute search which occurs during the late night or early morning hours.

Integrated USB Charge Port

La Crosse Technology Page 9

Backlight

A/C Adapter

The backlight can show continuously when operating the Wireless Forecast Station with the 5-volt a/c

adapter.

1. HIGH: The backlight is defaulted to HI (brightness) when the a/c adapter is in use.

2. LO: Press and release the LIGHT HI/LO button to dim the brightness of the backlight.

3. Press and release the LIGHT HI/LO button again to return to full strength (HIGH).

Note: When the Adapter is NOT in use, the High/Low backlight feature is not available.

1. OFF: Hold the HOLD ON/OFF button for 5 seconds, until the station beeps, to turn the backlight off to

sleep.

2. ON: Hold the HOLD ON/OFF button again until the station beeps, to turn the backlight on.

Note: When the backlight is off, press any button to activate the backlight for 8 seconds, and then it will

turn off again.

Battery Power

Press and release the SNOOZE/LIGHT button and the backlight will show for 8 seconds, when operating

on batteries only.

Weather Forecast Icons

The Wireless Forecast Station unit predicts weather condition for the next 12-hours based on the change

of atmospheric pressure. As weather conditions cannot be 100% correctly forecasted we cannot be

responsible for any loss caused by an incorrect forecast.

THIS STATION LEARNS!

Please allow 3-4 weeks for barometer calibration to generate an accurate forecast.

IMPORTANT: As the Wireless Forecast Station builds memory, it will compare the current average

pressure to the past forty day average pressure for increased accuracy. The longer the Wireless Forecast

Station operates in one location the more accurate the forecast icons will be.

The icons forecast the weather in terms of getting better or worse and not necessarily sunny or rainy as

each icon indicates. For example, if the current weather is cloudy and the rainy icon is displayed, it does

not mean that the product is faulty because it is not raining. It simply means that the air pressure has

dropped and the weather is expected to get worse but not necessarily rainy.

Common to weather forecasting, absolute accuracy cannot be guaranteed. The weather forecasting

feature is estimated to have an accuracy level of about 75% due to the varying areas the Wireless

Forecast Station has been designed for use. In areas that experience sudden changes in weather (for

example from sunny to rain), the Wireless Forecast Station will be more accurate compared to use in

areas where the weather is stagnant most of the time (for example mostly sunny).

La Crosse Technology Page 10

LCD Screen

The LCD screen is split into 5 sections displaying the information for time, calendar, weather forecast,

indoor data, and outdoor data.

MIN/MAX Temperature Data

This Wireless Forecast Station features daily minimum and maximum temperatures each day starting at

midnight (12:00 AM). The Wireless Forecast Station automatically resets the min/max temperatures at

midnight (12:00 AM).

View Min/Max

MAX: From a normal display press and release the MIN/MAX button once to view maximum

temperature and humidity values for Indoor and Outdoor data. The word MAX will appear next to the

indoor and outdoor temperature.

MIN: From a normal display press and release the MIN/MAX button twice to view minimum temperature

and humidity values for Indoor or Outdoor data. The word MIN will appear next to the indoor and

outdoor temperature.

Reset Min/Max

Hold the MIN/MAX button for 5 seconds to manually reset all indoor and outdoor minimum and maximum

values. (The Wireless Forecast Station automatically resets the min/max temperatures at midnight: 12:00

AM).

Note: If you are using multiple transmitters connected to the Wireless Forecast Station, all channels will

reset at the same time.

Autres manuels pour C86371

Table des matières

Autres manuels La Crosse Technology Station météorologique

La Crosse Technology

La Crosse Technology WS-3502 Manuel utilisateur

La Crosse Technology

La Crosse Technology WD-3104U Manuel utilisateur

La Crosse Technology

La Crosse Technology T83646 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2010 Manuel utilisateur

La Crosse Technology

La Crosse Technology WW85784 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology C84428 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2306 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9117U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-7014CH-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2510 Manuel de formation

La Crosse Technology

La Crosse Technology Wireless Weather Station Manuel utilisateur

La Crosse Technology

La Crosse Technology TX231TH Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9020U Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1409BT Manuel utilisateur

La Crosse Technology

La Crosse Technology 724-1415BL Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1414Bv3 Manuel utilisateur

La Crosse Technology

La Crosse Technology 302-604 Fiche technique

La Crosse Technology

La Crosse Technology WS-7042 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9037U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-805 Guide d'installation

La Crosse Technology

La Crosse Technology WS-2800 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-9125TWC-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-1415FCTv2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 308-145B Manuel utilisateur

Manuels Station météorologique populaires d'autres marques

Auriol

Auriol AHFL 433 A1 Manuel utilisateur

NexSens

NexSens G2-HYDROMET Manuel utilisateur

Hyundai

Hyundai WS 2202 Manuel utilisateur

IROX

IROX HBVR761 UV-X Manuel utilisateur

ADE

ADE WS 1711 Manuel utilisateur

Auriol

Auriol z29592 Manuel utilisateur

Auriol

Auriol 296289 Manuel utilisateur

Hyundai

Hyundai WS 2266 Manuel utilisateur

Ventus

Ventus W177 Manuel utilisateur

National Geographic

National Geographic VA Colour RC Manuel utilisateur

Renkforce

Renkforce 1208067 Manuel utilisateur

Levenhuk

Levenhuk Discovery Report WA40 Manuel utilisateur

Instant Transmission

Instant Transmission MA 10410 Manuel utilisateur

Lutron Electronics

Lutron Electronics PHB-318 Manuel utilisateur

WAREMA

WAREMA EWFS Weather station eco Manuel utilisateur

TFA

TFA 30.3013.IT Manuel utilisateur

Alecto

Alecto WS-1200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR966PA Manuel utilisateur
