EN.1

WS 6720 - Weather station

Instructions manual

Precautions

This main unit is intended to be used only indoors.

Do not subject the unit to excessive force or shock.

Do not expose the unit to extreme temperatures, direct sunlight, dust or humidity.

Do not immerse in water.

Avoid contact with any corrosive materials.

Do not dispose this unit in a fire as it may explode.

Do not open the inner back case or tamper with any components of this unit.

Batteries safety warnings

Use only alkaline batteries, not rechargeable batteries.

Install batteries correctly by matching the polarities (+/-).

Always replace a complete set of batteries.

Never mix used and new batteries.

Remove exhausted batteries immediately.

Remove batteries when not in use.

Do not recharge and do not dispose of batteries in fire as the batteries may explode.

Ensure batteries are stored away from metal objects as contact may cause a short circuit.

Avoid exposing batteries to extreme temperature or humidity or direct sunlight.

Keep all batteries out of reach from children. They are a choking hazard.

Use the product only for its intended purpose!

Consideration of duty according to the battery law

Old batteries do not belong to domestic waste because they could cause damages of health and environment.

You can return used batteries free of charge to your dealer and collection points. As end-user you are committed

by law to bring back needed batteries to distributors and other collecting points!

Consideration of duty according to the law of electrical devices

This symbol means that you must dispose of electrical devices separated from the General household waste when

it reaches the end of its useful life. Take your unit to your local waste collection point or recycling centre. This

applies to all countries of the European Union, and to other European countries with a separate waste collection

system.

EN.2

QUICK START

1. Slide open the battery cover at the back of your wireless thermometer-clock.

2. Insert 2 x AAA batteries into the battery compartment by observing the correct + / -

polarity signs inside the battery compartment.

3. Replace the battery cover. In few seconds the LCD shows the default time, calendar

and the current indoor temperature and it starts to search for outdoor temperature

signal.

EN.3

4. Then insert 2 x AAA batteries into the outdoor sensor. The outdoor temperature will be

displayed with “CH1” shown on the lower line of the LCD. Your Thermometer-clock will

be synchronized with outdoor sensor at Channel 1, the outdoor temperature will be

display.

Remarks:

Keep in mind that your outdoor sensor has a 30-meter open air transmission with no

obstructions. Actual transmission range will vary depending on what is in the path of the

signal. Each obstruction (roof, walls, floors, ceilings, thick trees, etc.) will effectively cut

signal range in half.

TO SET CALENDAR, 12/24-HR TIME AND TIME

1. Press and hold SET / ALM SET for 2 seconds, time digits change to year “2008 YR”

and flash. Press / to set year.

2. Then press SET / ALM SET once again, month digits flash. Press / button to set

month.

3. Then press SET / ALM SET once again, date digits flash. Press / button to set

date.

4. Press SET / ALM SET once again, time digits change “24 Hr”, press / to select

“12 Hr” time format or “24 Hr” time format. When “12 Hr” is selected, AM / PM icon will

be displayed.

5. Then press SET / ALM SET once again, time digits “0:00” show up and the hour digits

flash. Press / to set the hours.

6. Then press SET / ALM SET once again, minute digits flash. Press / button to set

the minutes.

7. Press SET / ALM SET to return to normal mode, or it will return to normal mode in

around 7 seconds if no press of any other buttons.

TO SET ALARM TIME

1. Press SET / ALM SET once, time digits change to alarm time digits “AM 7:00 AL”. Then

press and hold SET / ALM SET for 2 seconds, the hour digits flash. Press / to set

your desired hours of alarm time.

2. Press SET / ALM SET again, alarm minute digits flash. Press / to set alarm

minutes.

3. Press SET / ALM SET again, time digits change to “05” and flash. Press / to set

the snooze duration from 1 to 20 minutes.

4. Press SET / ALM SET to return to normal mode, or it will return to normal mode in

around 8 seconds if no further press of any other buttons.

To turn on or off your alarm

Press SET / ALM SET once to display the alarm time. When alarm time is displayed, press

to turn on / off the daily alarm. When the alarm function is turned on, the icon

appears between the hour and minute digits.

To use snooze alarm

When time reaches your set alarm time, your clock will give beep sound to wake you up.

The icon will flash.

EN.4

1. Press SNOOZE once to stop the alarm temporarily, the icon keeps flashing. The

alarm will beep again in 5 minutes.

2. To stop the alarm, press / CHANNEL (ALM On-Off) once, the alarm beep will stop

and the icon become static, alarm will beep again same time next day.

Alarm Duration : 2 minutes

TO DISPLAY TEMPERATURE

Simply press (°C/°F) to display temperature in degree C or degree F.

To read the Maximum-Minimum temperature records

Press MAX/MIN once to view the indoor-outdoor maximum or minimum temperatures.

When the maximum indoor-outdoor temperatures are displayed, press and hold the MAX

will clear the maximums and the unit will start to record and display fresh data again.

When the minimum indoor-outdoor temperature and humidity are displayed, press and

hold the MIN will clear the minimums and the unit will start to record and display fresh data

again.

TO USE THE WEATHER FORECAST

There are four types of weather display in your weather station :

SUNNY

SUNNY AND CLOUDY

CLOUDY

RAINY

EN.5

Remarks:

For better use of your weather station, place it at a location with open air circulation e.g.

close by an open window. Placing it at air-conditioned environment will affect its accuracy.

After your weather station is powered up, it will take around 24 hours to get stable. The

weather icons on the display give a reference to the next 6-12 hours weather conditions. It

may not match with the current weather condition outside.

TO SYNCHRONIZE YOUR CLOCK WITH MULTIPLE OUTDOOR SENSORS

Your wireless thermometer-clock is equipped with one outdoor sensor. You could purchase

second or third outdoor sensor to work with this thermometer-clock at the same time.

1. Press / CHANNEL (ALM On-Off) once, the lowest line of the LCD shows “CH2” and

show “--“. Then press and hold / CHANNEL / ALM On-Off for 2 seconds, until the

CH2 icon blinks, your weather station is searching for the signal of another outdoor

transmitter at Channel 2.

2. Slide open the battery door of your second transmitter, slide the switch to the middle

position marked with 2, then insert two AAA batteries into the battery compartment by

observing the correct +/- polarity. Replace the battery cover.

3. The outdoor temperature of your second transmitter will appear on the LCD together

with “CH2” icon within few seconds. If the data still does not appear, take out and

reinstall batteries to your second transmitter once.

4. To synchronize your weather station with a third outdoor sensor, repeat the same step

by choosing “CH3” on your weather station and select 3 on the switch on your third

transmitter.

TROUBLE SHOOTING

1. In case your wireless thermometer-clock shows irrelevant information or digits, it maybe

affected by electrostatic discharge or interferences from other devices. Press the

RESET button once. Your unit will be reset to default setting of time and calendar and

you need set time and calendar again.

2. In case the outdoor temperature shows “--“ :

2.1) press / CHANNEL (ALM On-Off) to view the correct channel i.e. “CH1” is your

default channel

2.2) If Outdoor temperature shows “CH1”, press and hold / CHANNEL (ALM ON-

OFF) for 2 seconds. The outdoor temperature should be displayed in around 1 minute.

2.3) if the above do not work, repeat 2.2), then bring in the outdoor sensor and take out

and reinstall batteries to your outdoor transmitter.

Remark:

If you observe a Low Battery icon on the lower left LCD, which means

your outdoor sensor is at low battery level, replace the batteries of your wireless transmitter

with fresh batteries.

SPECIFICATIONS

Indoor Temp. Range -10°C to +50°C (+14.2°F to +122°F)

Outdoor Temp. Range -50°C to + 70°C (-58°F to +158°F)

Out of Range Display Temperature: HH.H / LL.L

Outdoor Temperature Interval every 1 minute

Temperature Resolution 0.1°C

Alarm Duration 2 minutes

Transmission distance up to 30 meters
