Sonoff BASICR3 Manuel utilisateur

Wi-Fi DIY Smart Switch

User manual V1.0

· 中文 ------- 1 - 4 · English ----- 5 - 8

· Spanish ---13-16

· French -----17-20

· German ----- 9-12

· Italian----- 21-24

· Russian ----25-28

产品参数

保护盖

配置按钮 / 手动开关

BASICR3: 开关指示灯

RFR3: 遥控信号指示灯

Wi-Fi信号指示灯

产品介绍

BASICR3不支持433.92MHz遥控功能。

最大输入

最大输出

支持平台

Wi-Fi

频率

材料

产品规格

AC 100-240V 50/60Hz 10A

IEEE 802.11 b/g/n 2.4GHz

433.92MHz

PC V0

91x43x25mm

BASICR3

BASICRFR3

型号

(Android 4.1 & iOS 9.0) 或者更高版本

SONOFF TECHNOLOGIES CO., LTD. 中文

产品特点

APP灵活控制

用您的智能手机在任何地方打开或关闭家里的

电灯和风扇，设置定时开关、分享给您的家人

控制等等。

APP控制智能定时语音控制

分享控制

433MHz 遥控器

无需交换机

局域网模式

同步反馈

场景联动

中文

SONOFF TECHNOLOGIES CO., LTD.

恢复出厂设置

长按配置按钮5秒直到Wi-Fi指示灯呈两短一长闪烁

再松开，此时设备重置成功，默认进入快速模式

(Touch)。

更换新的网络环境使用时，需要恢复出厂设置，再

重新进行网络连接。

BASICRFR3支持使用433.92MHz遥控器控制开

关，可独立学习遥控器按键，此功能属于本地近

程无线遥控与Wi-Fi网络无关。

遥控配对

学习配对遥控器方法：

长按设备上配置按钮直到红色遥控信号指示灯闪烁

一下，然后按下遥控器按键即可学习成功。

清除遥控器配对方法：

长按设备上配置按钮直到红色遥控信号指示灯闪烁

两下，然后按下遥控器对应已学习的按键即可清

除已学习的按键码值。

中文

SONOFF TECHNOLOGIES CO., LTD.

2.蓝灯1秒快闪两下：说明设备已连接到了Wi-Fi

但没有连上外网。

请确认您的Wi-Fi当前连接外网是否稳定、正常。如时

好时坏，频繁出现这种双闪情况，说明您的网络不稳

定，并非产品原因。

常见问题

问：设备添加成功后，显示离线，无法控制？

答：设备刚添加成功后，需要1-2分钟时间连接您

的路由器并连网。如果长时间还是显示不在

线，请根据Wi-Fi指示灯的状态来判断：

1. 蓝灯1秒快闪一下：说明设备没有连上您的Wi-Fi。

① 可能是Wi-Fi密码输入不正确.

② 可能是设备离您的路由器太远，信号太弱，或

环境有干扰。请先将设备靠近路由器，如无改

善，重新添加一遍.

③ 设备不能识别5G的Wi-Fi，请选择2.4G的Wi-Fi

重新添加.

④ 检查您的路由器后台是否开启MAC地址过滤，

如有，请关闭。

中文

SONOFF TECHNOLOGIES CO., LTD.

BASICR3 does not support the remote controller with

433.92MHz.

AC 100-240V 50/60Hz 10A

IEEE 802.11 b/g/n 2.4GHz

433.92MHz

PC V0

91x43x25mm

BASICR3

BASICRFR3

Model

Max. input

Max. output

Operating

systems

Wi-Fi standard

Material

Dimension

Android 4.1 or higher &

iOS 9.0 or higher

Specifications

Product Introduction

BASICR3: On/off LED indicator

BASICRFR3: Remote-controlled LED indicator

Protective cover Wi-Fi LED indicator

Pairing button/Manual switch

English

SONOFF TECHNOLOGIES CO., LTD.

Features

Remote Control

Turn on/off the light or fan from anywhere, schedule

power on/off and share APP with your family to control.

App Control Timing Schedules Voice Control

Share Control Sync Status No Hub Required

Smart Scenes LAN Control RF Remote Control

English

SONOFF TECHNOLOGIES CO., LTD.

Please reset the switch to factory defaults if you want to

use other Wi-Fi networks, then reconnect the network.

Factory Reset

Long press the pairing button for about 5s until the

Wi-Fi LED indicator changes in a cycle of two short and

one long ash and release, then the reset is successful.

The device enters quick pairing mode (Touch).

RF Remote Controller Pairing

The BASICRFR3 supports the remote controller with

433.92MHz frequency brand to turn on/off, and each

channel can learn it independently, which is local short

-range wireless control not Wi-Fi control.

Pairing Method:

Long press the pairing button on the switch until the red

remote-controlled LED indicator ashes once, then

press the remote control button you want to pair for

successful learning.

Clearing Method:

Long press the pairing button on the switch until the red

remote-controlled LED indicator ashes twice, then

press the learned button corresponding to the remote

controller to clear code values of all learned buttons.

English

SONOFF TECHNOLOGIES CO., LTD.

Common Problems

Q: Why my device stays “Ofine”?

A: The newly added device needs 1 – 2mins to connect

Wi-Fi and network. If it stays ofine for a long time,

please judge these problems by the blue Wi-Fi

indicator status:

1. The blue Wi-Fi indicator quickly ashes once per

second, which means that the switch failed to

connect your Wi-Fi:

① Maybe you have entered a wrong Wi-Fi password.

② Maybe there's too much distance between the

switch your router or the environment causes

interference, consider getting close to the router.

If failed, please add it again.

③ The 5G Wi-Fi network is not supported and only

supports the 2.4GHz wireless network.

④ Maybe the MAC address ltering is open. Please

turn it off.

2.Blue indicator quickly ashes twice per second,

which means your device has connected to Wi-Fi

but failed to connect to the server.

Ensure a steady enough network. If double ash

occurs frequently, which means you access an

unsteady network, not the product problem. If the

network is normal, try to press the “Reset Button”

or turn off the power to restart the switch.

English

SONOFF TECHNOLOGIES CO., LTD.

BASICR3 unterstützt keine Fernbedienung mit

433,92 MHz.

AC 100-240V 50/60Hz 10A

IEEE 802.11 b/g/n 2.4GHz

433,92MHz

PC V0

91x43x25mm

BASICR3

BASICRFR3

Produktvorstellung

BASICR3: Ein/Aus-LED-Anzeige

BASICRFR3: Fernbedienungs-LED-Anzeige

Schutzhülle WLAN-LED-Anzeige

Kopplungstaste/Manueller Schalter

Technische Daten

Max. Ausgang

Betriebssysteme

WLAN-Standard

Betriebssysteme

Abmessungen

Android 4.1 oder höher und

iOS 9.0 oder höher

Modell

Max. Eingang

Materialien

German

SONOFF TECHNOLOGIES CO., LTD.
