SMART Board MX Manuel utilisateur

Digital whiteboard. Web browser. Screen sharing. The

SMARTBoard® MX series with iQ has all the essentials educators

need for bringing the devices students love into any learning

environment. The SMARTBoard MX series with iQ is a great value

for schools that need an interactive display on a budget.

Front control panel

The front control panel includes buttons for turning the

display on and off, selecting the video source, opening the

display’s settings, freezing and unfreezing the screen, and

controlling the volume.

Front connector panel

The front connector panel includes connectors for USBdrives

and other devices and a computer or other input source.

Viewing a connected computer’s input

1. Connect a device to the display’s HDMI 1, HDMI 2, HDMI 3 or

VGA connectors.

NOTE

To enable touch control of the device, connect a USB cable

to the associated USB port.

2. Press Input on the front control panel.

The Input selection menu appears.

NOTE

Inputs with devices connected are blue, and inputs

without a connection are black.

3. Tap the input you want to view.

The display looks for a connection, and the computer’s

desktop appears on the display’s screen.

Switching to the iQ experience

1. Press Input on the front control panel.

The Input selection menu appears.

2. Tap OPS.

The iQ experience appears on the display’s screen.

Using the Home screen

You can also open Screen Share, the Files Library and settings

from the Home screen.

To show the Home screen

Tap the Home button .

Whiteboard

Using Whiteboard, you can write and erase notes on the display

just as you do on a traditional dry erase board. You can also save

your notes for later reference and share them using the

SMARTkapp® app.

To start a Whiteboard

Open the Apps Library and tap Whiteboard .

To write in digital ink

1. Pick up a pen.

2. Use the pen to write in digital ink.

SMARTBoard® MX

smarttech.com/kb/171345

SMARTBoard MX

To erase digital ink

Move your fist or palm over the digital ink

you want to erase.

To pan

Press the screen and move your finger left or right.

TIP

You can use the following tools during your Whiteboard

session:

Return to the previous screen.

Change the pen type, ink width, and ink color

Connect your smart phone or other mobile device to

the display using the SMARTkapp app.

Disconnect your smart phone or other mobile device.

Save snapshots of the whiteboard to your smart phone

or other mobile device.

Save all notes in the Files Library and clear the

Whiteboard.

SMARTNotebook Player

(educationmodelsonly)

Use SMARTNotebook Player to open, view and interact with

SMARTNotebook software files. Notebook Player makes it easy to

present SMARTNotebook files and play activities on the display.

You can also install the Notebook Player app on your iOS device

to view and control SMART Notebook files from the device.

To open SMARTNotebook files stored on a USBdrive

1. Copy the SMARTNotebook files from your computer to the

USB drive.

2. Insert the USB drive into one of the USB receptacles on the

front connector panel. See Front connector panel on the

previous page.

3. Open the Files Library.

4. Tap USB Files.

5. Select the file you want to open.

To open SMARTNotebook files using Share To Board

1. Open the Files Library.

A four-digit code appears.

2. On a computer, open the SMARTNotebook file you want to

share and select File > Share.

3. Click Share with a SMARTBoard.

4. Click ADDBOARDS, enter the four-digit code that appears

on the display, and then click Connect.

Select the display you want to share the file with, and then

click Share Now.

5. On the display, select the file’s thumbnail to open the file .

To open SMARTNotebook files using Print to Board

See Share to the Notebook Player app.

TIPS

lMove between pages and documents by selecting the

PageSorter button at the bottom of the screen.

lFrom the Home screen, tap Files Library to select a

different document.

Browser

You can use Browser to view web sites on the display.

To use Browser

1. Open the Apps Library and tap Browser .

2. Use Browser as you would use a web browser on your

computer or mobile device.

Screenshots

When using the Browser app or Screen Share app, you can write

or draw on an annotation layer and save the screenshot to the

Files Library.

To write or draw on an annotation layer

1. Pick up one of the display’s pens.

2. Use the pen to write or draw in digital ink.

3. Tap Close or Back in the command bar.

4. Tap Save to save the screenshot in the Files Library.

Tap Discard to discard the screenshot and return to the app.

smarttech.com/kb/171345

Was this document helpful?

smarttech.com/docfeedback/171345

SMARTBoard MX

To open a saved screenshot

1. Open the Files Library.

2. Select a screenshot by tapping the screenshot’s tile.

Screen Share

You can share content from computers and mobile devices on

the display wirelessly using Screen Share.

Screen Share supports the following devices:

Chromebook™ laptops, using Google™ Cast

Chrome™browser extension

Windows® computers, using Miracast*, Google Cast

Chromebrowser extension or AirParrot

Mac computers and iOS devices, using AirPlay

Android™ devices, using Cast Screen

*Windows 10 and Windows 8.1 operating systems only

To use Screen Share

1. Show the Home screen and tap Screen Share .

2. Share the computer or mobile device’s screen following the

instructions in Using Screen Share.

Cleaning up the display

After you’ve finished using the display, show the Home screen

and tap Clean Up to clean up the display for the next user.

More information

For more information about the SMARTBoard

MX series interactive displays, browse to the

following page or scan the QR code.

https://support.smarttech.com/docs/redir

ect/?product=smartboardmx

For more information, visit smarttech.com/smartroom

For more training, visit smarttech.com/trainingforbusiness

U.S. and/or other countries. All third-party product and company names may be trademarks of their respective owners. Contents are subject to change without notice. 12/2018.

Was this document helpful?

smarttech.com/docfeedback/171345 smarttech.com/kb/171345
